E N J O Y T H E F R E E D O M O F W I R E L E S S N E T W O R K I N G
R2 Wireless Access Platform Installation Guide
E N T E R A S Y S . C O M
9033683-05

Advertisement

Table of Contents
loading

Related Manuals for Enterasys RoamAbout R2

Summary of Contents for Enterasys RoamAbout R2

  • Page 1 ™ E N J O Y T H E F R E E D O M O F W I R E L E S S N E T W O R K I N G R2 Wireless Access Platform Installation Guide E N T E R A S Y S .
  • Page 3 Enterasys Networks reserves the right to make changes in specifications and other information contained in this document and its web site without prior notice. The reader should in all cases consult Enterasys Networks to determine whether any such changes have been made.
  • Page 4 Notice FCC Notice Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
  • Page 5 BEFORE OPENING OR UTILIZING THE ENCLOSED PRODUCT, CAREFULLY READ THIS LICENSE AGREEMENT. This document is an agreement (“Agreement”) between the end user (“You”) and Enterasys Networks, Inc. on behalf of itself and its Affiliates (as hereinafter defined) (“Enterasys”) that sets forth Your rights and obligations with respect to the Enterasys software program (including any accompanying documentation, hardware or media) (“Program”) in the package and prevails over any additional, conflicting or inconsistent...
  • Page 6 52.227-19 (a) through (d) of the Commercial Computer Software-Restricted Rights Clause and its successors, and (iii) in all respects is proprietary data belonging to Enterasys and/or its suppliers. For Department of Defense units, the Program is considered commercial computer software in accordance with DFARS section 227.7202-3 and its successors, and use, duplication, or disclosure by the Government is subject...
  • Page 7 Enterasys’ failure to enforce a term upon Your breach of such term shall not be construed as a waiver of Your...
  • Page 8 EC Directive 73/23/EEC EN 55022 EN 55024 EN 60950 EN 60825 Equipment Type/Environment: Networking Equipment, for use in a Commercial or Light Industrial Environment. Enterasys Networks, Inc. declares that the equipment packaged with this notice conforms to the above directives.

  • Page 9: Table Of Contents

    Contents Preface Purpose of This Manual ............ix Intended Audience .
  • Page 10 Verifying the Operation of the RoamAbout R2........

  • Page 11: Preface

    Preface Purpose of This Manual This manual describes how to install and set up the RoamAbout R2 Wireless Access Platform (hereafter called the RoamAbout R2). It also includes problem solving, and connector pin assignment information. Intended Audience This manual is intended for use by personnel who will install and set up the RoamAbout R2.

  • Page 12: Document Conventions

    Preface Document Conventions The following symbols are used in this document: Symbol Meaning ELECTRICAL HAZARD: Warns against an action that could result in personal injury or death. CAUTION: Contains information essential to avoid bodily injury, or information that could cause damage to the equipment.

  • Page 13: Associated Documents

    The following table lists the RoamAbout products and information location. The documentation, drivers, and utilities can also be downloaded from the RoamAbout Wireless web site. Check the RoamAbout Wireless web site regularly for product upgrades. www.enterasys.com/wireless Component Information Location All RoamAbout components RoamAbout 802.11 Wireless Networking Guide...

  • Page 14: Getting Help

    A description of the failure • A description of any action(s) already taken to resolve the problem • The serial and revision numbers of all involved Enterasys Networks products in the network • A description of your network environment (layout, cable type) •...

  • Page 15: Preparing For Installation

    Before installing the RoamAbout R2, you must complete the following tasks: • If you have an existing Access Point 2000 and want to install the RoamAbout R2 in its place, refer to Upgrading from an Existing Access Point 2000 on page 3-2 important information.

  • Page 16: Reviewing The Site Requirements

    Reviewing the Site Requirements Reviewing the Site Requirements Please review the site requirements before you install the RoamAbout R2. Hardware Requirements The physical specifications for the RoamAbout R2 are provided in Table 1-1. Table 1-1: RoamAbout R2 Physical Specifications (with security cover)

  • Page 17: Power Supply And Connector Specifications (World)

    If the remote power feature is used, you must test the Ethernet cable from the remote power injector to the RoamAbout R2 for continuity and correct pinout before power is applied. Enterasys assumes no responsibility if the specifications set forth as follows are not followed.

  • Page 18: Regulatory Compliance

    Reviewing the Site Requirements Table 1-3: RoamAbout R2 Power Supply Specifications (World) Parameter Value Output voltage 42 to 59 VDC Output current 457 mA to 325 mA • Redundant Power Application Redundant power may be applied to the RoamAbout R2.

  • Page 19: Unpacking And Inspecting

    Physically inspect all cartons for shipping damage. Report any damage to your shipping carrier. Also verify that you have received the correct basic components and options as listed on the following pages. Report any discrepancies to your Enterasys Sales Representative.
  • Page 20 Installation Guide PC Card The RoamAbout R2 supports both the RoamAbout 802.11a and 802.11b PC Cards, and their variants. To determine which PC Card is needed for your configuration, refer to the RoamAbout 802.11 Certification and Regulatory Information document available on the Enterasys Networks web site at: www.enterasys.com/wireless...

  • Page 21: Options

    Unpacking and Inspecting Options The options shown below are available for the RoamAbout R2 (contact your Enterasys Representative), and are described in the following table. Option Description Order Number RoamAbout R2 Mezzanine slot upgrade option for RBTRC-MZ RBTR2-AA and RBTR2-AB (user...

  • Page 22: Testing The Coverage Area

    RoamAbout R2. The coverage area is where wireless clients can be physically located and still connect to the RoamAbout R2. Coverage area is determined by a number of factors, including the speed of the RoamAbout PC Card, physical obstructions, and noise levels.

  • Page 23: Cabling And Wiring

    Cabling and Wiring This chapter presents detailed step-by-step procedures to select, configure, and install the correct power, cabling, and wiring for your RoamAbout R2. CAUTION: The Enterasys 5652054-xx International DC Power Supply (ships with the RoamAbout R2) and the RBTR2-PS3 Redundant DC Power Supply have overload protection.

  • Page 24: Selecting A Power Configuration

    Redundant Power Configuration The RoamAbout R2 can be connected to an independent source of local power and to an independent source of remote power. If one of these power sources goes down, the RoamAbout R2 continues uninterrupted operation with power received from the other...

  • Page 25: Remote Power Injector Installation

    Remote Power Injector Installation Remote Power Injector Installation The remote power injector provides operating power to the RoamAbout R2 (referenced in the following figure as RoamAbout AP) using the Ethernet cable. The injector receives input power (via the PWR jack) from either the power supply supplied with the RoamAbout R2 or directly from the site facility.
  • Page 26 Remote Power Injector Installation To install the remote power injector, perform the following steps: 1. Use a cable tester to check the cable wiring to the RoamAbout R2. Check continuity and pairing. 2. Select a mounting location: — Close to the Ethernet wiring panel or Ethernet port.

  • Page 27: Rack Mount Kit Installation

    Rack Mount Kit Installation Rack Mount Kit Installation The rack mount kit allows you to install up to three remote power injectors into one standard rack-mount panel to provide for the operation of up to three RoamAbout R2s. The information presented in the Remote Power Injector Installation on page 2-3 applies to each of the three remote power injectors in the rack mount kit.
  • Page 28 5. Insert an Ethernet cable connector into the Network jack of one of the remote power injectors. 6. Insert the RoamAbout R2 cable connector into the RoamAbout AP jack of the same remote power injector. 7. Repeat Steps 5 and 6 for each RoamAbout R2.

  • Page 29: Power Supply Installation

    Power Supply Installation Power Supply Installation To install the 100-240VAC power supply, perform the following steps: 1. Verify that you have the correct power supply connector. USA (NEMA 5-15 TO IEC-C13) EU (CEE7 TO IEC-C13) UK (UK TO IEC-C13) AU (AS3112 TO IEC-C13) 2.

  • Page 30: Ethernet Wiring Configuration

    If you have an existing 10BaseT Ethernet cable in place, you can connect the cable directly to the RoamAbout R2. You can also connect the Ethernet cable to the remote power injector, then connect the remote power injector to the RoamAbout R2.

  • Page 31: Installing The Roamabout R2

    Chapter 3 Installing the RoamAbout R2 This chapter provides the procedures to install the RoamAbout R2 and its options. It also provides the basic configurations using the console, RoamAbout AP Manager, Telnet, and R2 Web Management. Refer to the Roamabout 802.11 Wireless Networking Guide for additional configuration information.

  • Page 32: Upgrading From An Existing Access Point 2000

    RoamAbout R2 in its place, please refer to the following important information. You cannot interchange the Access Point 2000 with the RoamAbout R2 without replacing the power supplies and, if applicable, the power injector and redundant power supply. You must use the power supply, power injector, and the redundant power supply shipped with the RoamAbout R2.

  • Page 33: Wall/Ceiling Outlet Box Installation

    Wall/Ceiling Outlet Box Installation Wall/Ceiling Outlet Box Installation Follow the step-by-step procedure below to install the RoamAbout R2 to an outlet box. 1. Make sure the site primary power for the RoamAbout R2 conforms to the specifications detailed in Chapter 2, Cabling and Wiring.
  • Page 34 6. Secure the mounting bracket to the wall outlet box. 7. Secure the RoamAbout R2 to the mounting bracket: a) Insert the two RoamAbout R2 shoulder screws into the two mounting bracket screw slots until secure. b) Slide the shoulder screws in the mounting screw slots until the screws are secure.
  • Page 35 Wall/Ceiling Outlet Box Installation 8. Refer to the Regulatory information, FCC requirements, and installation information shipped with the PC Card before you install it into the RoamAbout To install the PC Card: a) Position the card as shown below. b) Carefully insert the card. c) Press down firmly to seat the card.
  • Page 36 Wall/Ceiling Outlet Box Installation 9. If you install the optional range extender antenna or outdoor antenna (RoamAbout 802.11b PC Card only): a) Remove the dust cover from the PC Card. b) Insert the antenna cable connector into the PC Card connector. c) Gently press down on the cable connector to secure the antenna connection.
  • Page 37 Connect the output of the power module/ redundant power module to the RoamAbout 12. Connect the power module into an AC outlet. 13. Verify that the power is on by observing that some of the RoamAbout R2 LEDs are flashing or lit.
  • Page 38 Wall/Ceiling Outlet Box Installation 14. Secure the cover: a) Position the cover over the RoamAbout R2. b) Make sure the cover clears the PC Card (and the optional antenna cable). c) Push the cover down until all four snaps are secured.

  • Page 39: Surface Wallmount Installation

    Surface Wallmount Installation Surface Wallmount Installation Follow the step-by-step procedure below to install the RoamAbout R2 on the surface of a wall, cubical wall, vertical support structure, or ceiling. 1. Make sure the site primary power for the RoamAbout R2 conforms to the...
  • Page 40 3. Remove the mounting bracket from the RoamAbout R2: a) Completely loosen the captive screw. b) Slide the bracket until the two screw slots are directly below the two mounting screws. c) Lift and remove the bracket from the RoamAbout R2. Remove Mounting Bracket Screw...
  • Page 41 Surface Wallmount Installation 5. Secure the mounting bracket to the wall: a) Locate at least two mounting holes/slots on the mounting bracket that line up with a wall stud. b) Use two screws to secure the mounting bracket to the wall stud. c) Use plastic anchors and screws, or self-anchoring screws to secure the mounting bracket to the wallboard.
  • Page 42 Surface Wallmount Installation 6. Secure the RoamAbout R2 to the mounting bracket: a) Insert the two RoamAbout R2 shoulder screws into the two mounting bracket screw slots. b) Slide the shoulder screws in the mounting screw slots until the screws are secure.
  • Page 43 Surface Wallmount Installation 7. Refer to the Regulatory information, FCC requirements, and installation information shipped with the PC Card before you install it into the RoamAbout To install the PC Card: a) Position the card as shown below. b) Carefully insert the card. c) Press down firmly to seat the card.
  • Page 44 Surface Wallmount Installation 8. If you install the optional range extender antenna or outdoor antenna (RoamAbout 802.11b PC Card only): a) Remove the dust cover from the PC Card. b) Insert the antenna cable connector into the PC Card connector. c) Gently press down on the cable connector to secure the antenna connection.
  • Page 45 Power Supply Installation on Connector page 2-7. Ethernet Cable 11. Connect the power module into an AC Connector outlet. R2_31 12. Verify that the power is on by observing that some of the RoamAbout R2 LEDs are flashing or lit. 3-15...
  • Page 46 Surface Wallmount Installation 13. Secure the cover: a) Position the cover over the RoamAbout R2. b) Make sure the cover clears the antenna. c) Push the cover down until all four snaps are secured. Snaps R2_28 d) Lock the cover in place using the key.

  • Page 47: Console Port Connection

    RoamAbout R2 console port, do the following: 1. Choose a device (terminal or personal computer) to connect to the RoamAbout R2. 2. Connect a null modem cable or equivalent to the device and the RoamAbout R2: Assignment...

  • Page 48: Connecting An Open-Ended Cable To The Console Port

    To connect to the console port at a later date, open HyperTerminal and select File → Open to open the RoamAbout R2 Console Port connection. 5. Press <Enter> a few times until the RoamAbout R2 Installation Menu is displayed. The installation menu allows you to display and modify various RoamAbout R2 and wireless networking parameters.

  • Page 49: Verifying The Operation Of The Roamabout R2

    The Reload/Reset button is used to download a new firmware image to the RoamAbout R2, and to reset the RoamAbout R2 to the factory defaults. You need to write down the MAC address (in the MAC ADD box) for use when configuring the RoamAbout R2.
  • Page 50 Name Description System Status Lights when the RoamAbout R2 passes self-test. If the RoamAbout R2 fails the test, the LED blinks at a steady rate. Power Lights when the power is on. Wired Forwarding Lights when the RoamAbout R2 is forwarding packets to the wired Ethernet port.
  • Page 51 Verifying the Operation of the RoamAbout R2 Table 3-2: RoamAbout R2 LED Patterns Wireless Wireless Wireless Wireless Wired Power System Meaning of Forwarding Forwarding Forwarding LED Pattern Slot 2 Slot 2 Slot 1 Slot 1 No power. Check power connections.

  • Page 53: Configuring The Roamabout R2

    The RoamAbout R2 provides a number of interfaces, but only the console port or AP Manager allows you to initially configure the R2 with an IP address. For more information about all the interfaces, refer to the RoamAbout 802.11 Wireless Networking Guide.

  • Page 54: Using The Console Port

    To manage the RoamAbout R2 with the console port, do the following: 1. Press the <Return> key at the terminal that is connected to the RoamAbout R2 console port until the Main Menu displays. If using a computer, start the terminal emulation program and connect to the console port.

  • Page 55: Using The Roamabout Ap Manager

    — The password is case-sensitive and must be a minimum of eight ASCII characters. 7. If necessary, change the default gateway and subnet mask. Click OK when completed. 8. In the Identification dialog box, enter the text to describe the RoamAbout R2. Click the Help button for details. Click OK when completed.

  • Page 57: F Upgrade And Reset

    Appendix F Upgrade and Reset This appendix describes how to upgrade the RoamAbout R2 firmware using the console port, AP Manager, or the web-based management. It also describes how to reset the R2 to all factory defaults. Check the Enterasys Networks Wireless web site for the latest RoamAbout AP Manager and firmware.

  • Page 58: Upgrade Firmware

    Loader.exe file, or start the TFTP server that you want to use. 2. Choose Reset/Upgrade from the RoamAbout R2 Console Main menu. 3. Choose Upgrade Flash. 4. Enter the latest G*.Z file for firmware upgrades, or B*.BIN file for BootROM upgrades in the Image file path.

  • Page 59: Using The Roamabout Ap Manager

    9. Click Yes to confirm the upgrade, then click OK to reconfirm the upgrade. 10. AP Manager displays a Poll dialog box that prompts you to poll the RoamAbout R2. Polling the RoamAbout R2 lets you know when the upgrade is complete.

  • Page 60: Using Web Management

    Upgrade Firmware 11. Click Yes in the Poll dialog box to start the poll. You will receive a “Reload Status = Success” message when the upgrade is complete. The upgrade takes approximately one minute. AP Manager prompts you to reset the unit after the upgrade is complete. 12.

  • Page 61: Hardware Reset To Factory Defaults

    RoamAbout R2. To reset the RoamAbout R2 to the factory defaults, perform the following steps: 1. Record the MAC address of the RoamAbout R2 and the G*.Z firmware file name. The G*.Z firmware file is located in the Program Files/RoamAbout/Manager directory.
  • Page 62 Hardware Reset to Factory Defaults 8. When the LEDs start blinking, quickly insert and remove something similar to a toothpick into the small hole on the unit labeled S1. NetRider Loader indicates a loading status. CAUTION: The NetRider Loader application only indicates when the file copy is completed, it does not indicate when the upgrade is complete.
