5 Click <Browse>. Select the file to be downloaded and set protocol to Xmodem. Click
<Send>. The following interface pops up:
6 After completing the download, the system begins writing data to Flash memory, and then
displays the following information on the screen:
Download successfully!
137680480 bytes downloaded!
Input the File Name:
Updating File cf:/
........
Update Success!
======================<SERIAL SUB-MENU>======================
|Note:the operating device is CF Card
| <1> Download Application Program To SDRAM And Run
| <2> Update Main Application File
| <3> Update Backup Application File
| <4> Update Secure Application File
| <5> Modify Serial Interface Parameter
| <6> Exit To Main Menu
=============================================================
Enter your choice(1-6): 6
msr50-cmw520-b1508p01-si.bin
msr50-cmw520-b1508p01-si.bin
