Page 1 NWA3550 IEEE 802.11a/b/g Outdoor WLAN Access Point User’s Guide Version 3.60 6/2008 Edition 2 DEFAULT LOGIN IP Address http://192.168.1.2 Password 1234 www.zyxel.com...
Page 3: About This User's Guide
Help us help you. Send all User Guide-related comments, questions or suggestions for improvement to the following address, or use e-mail instead. Thank you! The Technical Writing Team, ZyXEL Communications Corp., 6 Innovation Road II, Science-Based Industrial Park, Hsinchu, 300, Taiwan.
Page 4: Document Conventions
Document Conventions Document Conventions Warnings and Notes These are how warnings and notes are shown in this User’s Guide. Warnings tell you about things that could harm you or your device. Notes tell you other important information (for example, other things you may need to configure or helpful tips) or recommendations.
Page 5 Icons Used in Figures Figures in this User’s Guide may use the following generic icons. The ZyXEL Device icon is not an exact representation of your device. ZyXEL Device Server Telephone NWA3550 User’s Guide Computer Notebook computer DSLAM Firewall Switch Router Document Conventions...
Page 6: Safety Warnings
Safety Warnings For your safety, be sure to read and follow all warning notices and instructions. • Do NOT use this product near water, for example, in a wet basement or near a swimming pool. • Do NOT expose your device to dampness, dust or corrosive liquids. •...
Page 7 Safety Warnings NWA3550 User’s Guide...
Page 8 Safety Warnings NWA3550 User’s Guide...
Page 9: Table Of Contents
Introduction ... 31 Introducing the ZyXEL Device ... 33 Introducing the Web Configurator ... 43 Status Screens ... 47 Management Mode ... 51 Tutorial ... 55 The Web Configurator ... 83 System Screens ... 85 Wireless Configuration ... 91 Wireless Security Configuration ... 109 MBSSID and SSID ...
Page 10 Contents Overview NWA3550 User’s Guide...
Page 11: Table Of Contents
About This User's Guide ... 3 Document Conventions... 4 Safety Warnings... 6 Contents Overview ... 9 Table of Contents... 11 List of Figures ... 19 List of Tables... 27 Part I: Introduction... 31 Chapter 1 Introducing the ZyXEL Device ... 33 1.1 Introducing the ZyXEL Device ...
Page 12 Table of Contents 2.3 Navigating the Web Configurator ... 45 Chapter 3 Status Screens ... 47 3.1 The Status Screen ... 47 Chapter 4 Management Mode... 51 4.1 About CAPWAP ... 51 4.1.1 CAPWAP Discovery and Management ... 52 4.1.2 CAPWAP and DHCP ... 52 4.1.3 CAPWAP and IP Subnets ...
Page 13 5.4.5 Configure the SERVER_2 Network ... 79 5.4.6 Checking your Settings and Testing the Configuration ... 80 5.4.6.1 Checking Settings ... 80 5.4.6.2 Testing the Configuration ... 81 Part II: The Web Configurator ... 83 Chapter 6 System Screens ... 85 6.1 System Overview ...
Page 14 Table of Contents 7.7.3 AP+Bridge Mode ... 106 7.7.4 MBSSID Mode ... 108 Chapter 8 Wireless Security Configuration ... 109 8.1 Wireless Security Overview ... 109 8.1.1 SSID ... 109 8.1.2 MAC Address Filter ... 109 8.1.3 User Authentication ...110 8.1.4 Encryption ...110 8.2 Security Modes ...111 8.3 Configuring Security ...111...
Page 15 10.5 Configuring Roaming ... 137 10.5.1 Requirements for Roaming ... 138 Chapter 11 IP Screen... 141 11.1 Factory Ethernet Defaults ... 141 11.2 TCP/IP Parameters ... 141 11.2.1 WAN IP Address Assignment ... 141 11.3 Configuring IP Settings ... 142 Chapter 12 Rogue AP...
Page 16 Table of Contents 13.11.2 Configuring SNMP ... 165 13.11.2.1 The SNMPv3 User Profile Screen ... 167 Chapter 14 Internal RADIUS Server ... 169 14.1 Internal RADIUS Overview ... 169 14.2 Internal RADIUS Server Setting ... 169 14.3 Trusted AP Overview ... 171 14.4 Configuring Trusted AP ...
Page 17 17.2 Configuring VLAN ... 204 17.2.1 Wireless VLAN ... 204 17.2.2 RADIUS VLAN ... 206 17.2.3 Configuring Management VLAN Example ... 207 17.2.4 Configuring Microsoft’s IAS Server Example ... 210 17.2.4.1 Configuring VLAN Groups ... 210 17.2.4.2 Configuring Remote Access Policies ...211 17.2.5 Second Rx VLAN ID Example ...
Page 18 Table of Contents Appendix C Pop-up Windows, JavaScripts and Java Permissions ... 283 Appendix D Importing Certificates... 289 Appendix E IP Addresses and Subnetting ... 313 Appendix F Text File Based Auto Configuration... 321 Appendix G Legal Information... 329 Appendix H Customer Support... 333 Index...
Page 19: List Of Figures
List of Figures List of Figures Figure 1 Access Point Application ... 34 Figure 2 Bridge Application ... 35 Figure 3 Repeater Application ... 35 Figure 4 AP+Bridge Application ... 36 Figure 5 Multiple BSSs ... 37 Figure 6 Dual WLAN Adaptors Example ... 38 Figure 7 CAPWAP Network Example ...
Page 20 List of Figures Figure 39 Tutorial: Example Network ... 76 Figure 40 Tutorial: SSID Profile ... 78 Figure 41 Tutorial: SSID Edit ... 78 Figure 42 Tutorial: Layer-2 Isolation Edit ... 79 Figure 43 Tutorial: MAC Filter Edit (SERVER_1) ... 79 Figure 44 Tutorial: SSID Profiles Activated ...
Page 21 List of Figures Figure 82 ROGUE AP > Configuration ... 148 Figure 83 ROGUE AP > Friendly AP ... 149 Figure 84 ROGUE AP > Rogue AP ... 150 Figure 85 How SSH Works ... 152 Figure 86 Remote Management: Telnet ... 154 Figure 87 Remote Management: FTP ...
Page 22 List of Figures Figure 125 Specifying Windows-Group Condition ... 212 Figure 126 Adding VLAN Group ... 213 Figure 127 Granting Permissions and User Profile Screens ... 213 Figure 128 Authentication Tab Settings ... 214 Figure 129 Encryption Tab Settings ... 214 Figure 130 Connection Attributes Screen ...
Page 23 List of Figures Figure 168 Mac OS X 10.4: Network Preferences > Ethernet ... 255 Figure 169 Mac OS X 10.4: Network Utility ... 255 Figure 170 Mac OS X 10.5: Apple Menu ... 256 Figure 171 Mac OS X 10.5: Systems Preferences ... 256 Figure 172 Mac OS X 10.5: Network Preferences >...
Page 24 List of Figures Figure 211 Internet Explorer 7: Select Certificate Store ... 292 Figure 212 Internet Explorer 7: Certificate Import Wizard ... 293 Figure 213 Internet Explorer 7: Security Warning ... 293 Figure 214 Internet Explorer 7: Certificate Import Wizard ... 293 Figure 215 Internet Explorer 7: Website Identification ...
Page 25 List of Figures Figure 254 Subnetting Example: After Subnetting ... 317 Figure 255 Text File Based Auto Configuration ... 321 Figure 256 Configuration File Format ... 323 Figure 257 WEP Configuration File Example ... 324 Figure 258 802.1X Configuration File Example ... 325 Figure 259 WPA-PSK Configuration File Example ...
Page 26 List of Figures NWA3550 User’s Guide...
Page 27: List Of Tables
List of Tables List of Tables Table 1 The Status Screen ... 47 Table 2 The Management Mode Screen ... 54 Table 3 Tutorial: Example Information ... 59 Table 4 Tutorial: Rogue AP Example Information ... 69 Table 5 Tutorial: Friendly AP Information ... 71 Table 6 Tutorial: SSID Profile Security Settings ...
Page 28 List of Tables Table 39 WIRELESS > MAC Filter ... 135 Table 40 MAC Address Filter ... 136 Table 41 Private IP Address Ranges ... 141 Table 42 IP Setup ... 142 Table 43 ROGUE AP > Configuration ... 148 Table 44 ROGUE AP >...
Page 29 List of Tables Table 82 ZyXEL Device Compatible Antenna Cables ... 240 Table 83 Power over Ethernet Injector Specifications ... 241 Table 84 Power over Ethernet Injector RJ-45 Port Pin Assignments ... 241 Table 85 IEEE 802.11g ... 273 Table 86 Wireless Security Levels ... 274 Table 87 Comparison of EAP Authentication Types ...
Page 30 List of Tables NWA3550 User’s Guide...
Page 31: Introduction
Introduction Introducing the ZyXEL Device (33) Introducing the Web Configurator (43) Status Screens (47) Tutorial (55)
Page 33: Introducing The Zyxel Device
H A P T E R Introducing the ZyXEL Device This chapter introduces the main applications and features of the ZyXEL Device. It also introduces the ways you can manage the ZyXEL Device. 1.1 Introducing the ZyXEL Device Your ZyXEL Device extends the range of your existing wired network without additional wiring, providing easy network access to mobile users.
Page 34: Access Point
Chapter 1 Introducing the ZyXEL Device 1.2.1 Access Point The ZyXEL Device is an ideal access solution for wireless Internet connection. A typical Internet access application for your ZyXEL Device is shown as follows. Clients A, B and C can access the wired network through the ZyXEL Devices. Figure 1 Access Point Application 1.2.2 Bridge / Repeater The ZyXEL Device can act as a wireless network bridge and establish wireless links with...
Page 35: Ap + Bridge
Figure 2 Bridge Application Ethernet 2 Figure 3 Repeater Application Ethernet 2 1.2.3 AP + Bridge In AP+Bridge mode, the ZyXEL Device supports both AP and bridge connection at the same time. In the figure below, A and B use X as an AP to access the wired network, while X and Y communicate in bridge mode.
Page 36: Mbssid
Chapter 1 Introducing the ZyXEL Device Figure 4 AP+Bridge Application 1.2.4 MBSSID A BSS (Basic Service Set) is the set of devices forming a single wireless network (usually an access point and one or more wireless clients). An SSID (Service Set IDentifier) is the name of a BSS.
Page 37: Pre-Configured Ssid Profiles
Figure 5 Multiple BSSs VoIP_SSID 1.2.5 Pre-Configured SSID Profiles The ZyXEL Device has two pre-configured SSID profiles. 1 VoIP_SSID. This profile is intended for use by wireless clients requiring the highest QoS (Quality of Service) level for VoIP (Voice over IP) telephony and other applications requiring low latency.
Page 38: Capwap
Chapter 1 Introducing the ZyXEL Device Figure 6 Dual WLAN Adaptors Example WLAN2 802.11b/g Bridge 1.3 CAPWAP The ZyXEL Device supports CAPWAP (Control And Provisioning of Wireless Access Points). This is ZyXEL’s implementation of the IETF’s (Internet Engineering Task Force) CAPWAP protocol.
Page 39: Ways To Manage The Zyxel Device
Figure 7 CAPWAP Network Example 1.4 Ways to Manage the ZyXEL Device Use any of the following methods to manage the ZyXEL Device. • Web Configurator. This is recommended for everyday management of the ZyXEL Device using a (supported) web browser. •...
Page 40: Wireless Security
Chapter 1 Introducing the ZyXEL Device • Change any default passwords on the ZyXEL Device, such as the password used for accessing the ZyXEL Device’s web configurator (if it has a web configurator). Use a password with a combination of letters and numbers and change your password regularly. Write down the password and put it in a safe place.
Page 41 Chapter 1 Introducing the ZyXEL Device Your ZyXEL Device has two wireless LAN adaptors, WLAN1 and WLAN2. WLAN1 uses the RF1 antenna and WLAN2 uses the RF2 antenna. If you connect only one antenna, you can use only the associated wireless LAN adaptor.
Page 42 Chapter 1 Introducing the ZyXEL Device NWA3550 User’s Guide...
Page 43: Introducing The Web Configurator
H A P T E R This chapter describes how to access the ZyXEL Device’s web configurator and provides an overview of its screens. 2.1 Accessing the Web Configurator 1 Make sure your hardware is properly connected and prepare your computer or computer network to connect to the ZyXEL Device (refer to the Quick Start Guide).
Page 44: Resetting The Zyxel Device
Chapter 2 Introducing the Web Configurator Figure 8 Change Password Screen 6 Click Apply in the Replace Certificate screen to create a certificate using your ZyXEL Device’s MAC address that will be specific to this device. Figure 9 Replace Certificate Screen You should now see the Status screen.
Page 45: Methods Of Restoring Factory-Defaults
2.2.1 Methods of Restoring Factory-Defaults You can erase the current configuration and restore factory defaults in the following ways: • Use the web configurator to restore defaults (refer to • Transfer the configuration file to your ZyXEL Device using FTP. See the section on SMT configuration for more information.
Page 46 Chapter 2 Introducing the Web Configurator NWA3550 User’s Guide...
Page 47: Status Screens
H A P T E R The Status screen displays when you log into the ZyXEL Device, or click STATUS in the navigation menu. Use the Status screens to look at the current status of the device, system resources, interfaces and SSID status.
Page 48 Chapter 3 Status Screens Table 1 The Status Screen LABEL System Information System Name Model Firmware Version System Up Time Current Date Time WLAN1 Operating Mode WLAN2 Operating Mode Management VLAN LAN MAC WLAN1 MAC WLAN2 MAC System Resources Flash Memory WLAN1 Associations WLAN2 Associations...
Page 49 Table 1 The Status Screen LABEL Status Rate SSID Status Interface SSID BSSID Security VLAN System Status Show Statistics Association List Channel Usage Logs Rogue AP List NWA3550 User’s Guide DESCRIPTION This field indicates whether or not the ZyXEL Device is using the interface. For each interface, this field displays Up when the ZyXEL Device is using the interface and Down when the ZyXEL Device is not using the interface.
Page 50 Chapter 3 Status Screens NWA3550 User’s Guide...
Page 51: Management Mode
H A P T E R This chapter discusses the MGNT MODE (Management Mode) screen. This screen determines whether the ZyXEL Device is used in its default, standalone mode, or as part of a CAPWAP (Control And Provisioning of Wireless Access Points) network. 4.1 About CAPWAP The ZyXEL Device supports CAPWAP (Control And Provisioning of Wireless Access Points).
Page 52: Capwap Discovery And Management
Chapter 4 Management Mode 4.1.1 CAPWAP Discovery and Management The link between CAPWAP-enabled access points proceeds as follows: 1 An AP in managed AP mode joins a wired network (receives a dynamic IP address). 2 The AP sends out a management request, looking for an AP in CAPWAP AP controller mode.
Page 53: Notes On Capwap
Figure 13 CAPWAP and DHCP Option 43 SUBNET 1 CONTROLLER (STATIC IP) 4.1.4 Notes on CAPWAP This section lists some additional features of ZyXEL’s implementation of the CAPWAP protocol. • When the AP controller uses its internal RADIUS server, managed APs also use the AP controller’s authentication server to authenticate wireless clients.
Page 54: Table 2 The Management Mode Screen
Chapter 4 Management Mode The following table describes the labels in this screen. Table 2 The Management Mode Screen LABEL Standalone AP Managed AP Apply Reset DESCRIPTION Select this to manage the ZyXEL Device using its own web configurator, neither managing nor managed by other devices. Select this to have the ZyXEL Device managed by another ZyXEL Device on your network.
Page 55: Tutorial
H A P T E R This chapter first provides an overview of how to configure the wireless LAN on your ZyXEL Device, and then gives step-by-step guidelines showing how to configure your ZyXEL Device for some example scenarios. 5.1 How to Configure the Wireless LAN This section shows how to choose which wireless operating mode you should use on the ZyXEL Device, and the steps you should take to set up the wireless LAN in each wireless mode.
Page 56: Configuring Dual Wlan Adaptors
Chapter 5 Tutorial 5.1.1.1 Configuring Dual WLAN Adaptors The ZyXEL Device is equipped with dual wireless adaptors. This means you can configure two different wireless networks to operate simultaneously. See details. You can configure each wireless adaptor separately in the WIRELESS > Wireless screen. To configure the first wireless network, select WLAN1 in the WLAN Interface field and follow the steps in Section 5.1.2 on page...
Page 57: Figure 15 Configuring Wireless Lan
Figure 15 Configuring Wireless LAN Select the WLAN Interface you want to configure. Bridge / Access Point Repeater Mode. Mode. Select 802.11 Select 802.11 Mode and Mode and Channel ID. Channel ID. Select SSID Configure Profile. WDS Security. Configure SSID Profile. Edit Security Profile.
Page 58: Further Reading
Chapter 5 Tutorial 5.1.3 Further Reading Use these links to find more information on the steps: • Choosing 802.11 Mode: see • Choosing a wireless Channel ID: see • Selecting and configuring SSID profile(s): see on page 125. • Configuring and activating WDS Security: see •...
Page 59: Change The Operating Mode
Figure 16 Tutorial: Example MBSSID Setup VoIP_SSID The standard network (SSID04) has access to all resources. The VoIP network (VoIP_SSID) has access to all resources and a high Quality of Service (QoS) setting (see for information on QoS). The guest network (Guest_SSID) has access to the Internet and the network printer only, and a low QoS setting.
Page 60: Figure 17 Tutorial: Wireless Lan: Before
Chapter 5 Tutorial Figure 17 Tutorial: Wireless LAN: Before Select MBSSID from the Operating Mode drop-down list box. The screen displays as follows. Figure 18 Tutorial: Wireless LAN: Change Mode NWA3550 User’s Guide...
Page 61: Configure The Voip Network
This Select SSID Profile table allows you to activate or deactivate SSID profiles. Your wireless network was previously using the SSID04 profile, so select SSID04 in one of the Profile list boxes (number 3 in this example). Select the Active box for the entry and click Apply to activate the profile. Your standard wireless network (SSID04) is now accessible to your wireless clients as before.
Page 62: Set Up Security For The Voip Profile
Chapter 5 Tutorial Figure 20 Tutorial: VoIP SSID Profile Edit • Choose a new SSID for the VoIP network. In this example, enter VOIP_SSID_Example. Note that although the SSID changes, the SSID profile name (VoIP_SSID) remains the same as before. •...
Page 63: Figure 21 Tutorial: Voip Security
Figure 21 Tutorial: VoIP Security You already chose to use the security02 profile for this network, so select the radio button for security02 and click Edit. The following screen appears. Figure 22 Tutorial: VoIP Security Profile Edit • Change the Name field to “VoIP_Security” to make it easier to remember and identify. •...
Page 64: Activate The Voip Profile
Chapter 5 Tutorial • Click Apply. The WIRELESS > Security screen displays. Ensure that the Profile Name for entry 2 displays “VoIP_Security” and that the Security Mode is WPA2-PSK. Figure 23 Tutorial: VoIP Security: Updated 5.2.2.2 Activate the VoIP Profile You need to activate the VoIP_SSID profile before it can be used.
Page 65: Set Up Security For The Guest Profile
Figure 25 Tutorial: Guest Edit • Choose a new SSID for the guest network. In this example, enter Guest_SSID_Example. Note that although the SSID changes, the SSID profile name (Guest_SSID) remains the same as before. • Select Disable from the Hide Name (SSID) list box. This makes it easier for guests to configure their own computers’...
Page 66: Set Up Layer 2 Isolation
Chapter 5 Tutorial • Select WPA-PSK in the Security Mode field. WPA-PSK provides strong security that is supported by most wireless clients. Even though your Guest_SSID clients do not have access to sensitive information on the network, you should not leave the network without security.
Page 67: Activate The Guest Profile
Figure 29 Tutorial: Layer 2 Isolation Profile Enter the MAC addresses and descriptions of the two network devices you want users on the guest network to be able to access: the main network router (00:AA:00:AA:00:AA) and the network printer (AA:00:AA:00:AA:00). Click Apply. 5.2.3.3 Activate the Guest Profile You need to activate the Guest_SSID profile before it can be used.
Page 68: Testing The Wireless Networks
Chapter 5 Tutorial Figure 30 Tutorial: Activate Guest Profile Your guest wireless network is now ready to use. 5.2.4 Testing the Wireless Networks To make sure that the three networks are correctly configured, do the following. • On a computer with a wireless client, scan for access points. You should see the Guest_SSID network, but not the VoIP_SSID network.
Page 69: Figure 31 Tutorial: Wireless Network Example
Your wireless network operates in an office building. It consists of four access points (all ZyXEL Devices) and a variable number of wireless clients. You also know that the coffee shop on the ground floor has a wireless network consisting of a single access point, which can be detected and accessed from your floor of the building.
Page 70: Set Up And Save A Friendly Ap List
Chapter 5 Tutorial Table 4 Tutorial: Rogue AP Example Information DEVICE Access Point D File / Mail Server E Access Point 1 The ZyXEL Device can detect the MAC addresses of APs automatically. However, it is more secure to obtain the correct MAC addresses from another source and add them to the friendly AP list manually.
Page 71: Figure 33 Tutorial: Friendly Ap (After Data Entry)
2 Fill in the MAC Address and Description fields as in the following table. Click Add after you enter the details of each AP to include it in the list. Table 5 Tutorial: Friendly AP Information MAC ADDRESS 00:AA:00:AA:00:AA AA:00:AA:00:AA:00 A0:0A:A0:0A:A0:0A 0A:A0:0A:A0:0A:A0 AF:AF:AF:FA:FA:FA...
Page 72: Figure 34 Tutorial: Configuration
Chapter 5 Tutorial Figure 34 Tutorial: Configuration 4 Click Export. If a window similar to the following appears, click Save. Figure 35 Tutorial: Warning 5 Save the friendly AP list somewhere it can be accessed by all the other access points on the network.
Page 73: Activate Periodic Rogue Ap Detection
5.3.2 Activate Periodic Rogue AP Detection Take the following steps to activate rogue AP detection on the first of your ZyXEL Devices. 1 In the ROGUE AP > Configuration screen, select Enable from the Rogue AP Period Detection field. Figure 37 Tutorial: Periodic Rogue AP Detection 2 In the Period field, enter how often you want the ZyXEL Device to scan for rogue APs.
Page 74: Configure Your Other Access Points
Chapter 5 Tutorial Figure 38 Tutorial: Log Settings • In this example, your mail server’s IP address is 192.168.1.25. Enter this IP address in the Mail Server field. • Enter a subject line for the alert e-mails in the Mail Subject field. Choose a subject that is eye-catching and identifies the access point - in this example, “ALERT_Access_Point_A”.
Page 75: Test The Setup
Now you need to configure the other wireless access points on your network to do the same things. For each access point, take the following steps. 1 From a computer on the wired network, enter the access point’s IP address and login to its Web configurator.
Page 76: Your Requirements
Chapter 5 Tutorial You have two secure servers (1 and 2 in the following figure). Wireless user “Alice” (A) needs to access server 1 (but should not access server 2) and wireless user “Bob” (B) needs to access server 2 (but should not access server 1). Your ZyXEL Device is marked Z. C is a workstation on your wired network, D is your main network switch, and E is the security gateway you use to connect to the Internet.
Page 77: Configure The Server_1 Network
2 Configure the SERVER_1 network’s MAC filter profile. 3 Configure the SERVER_1 network’s layer-2 isolation profile. 4 Repeat steps 1 ~ 3 for the SERVER_2 network. 5 Check your settings and test the configuration. To configure layer-2 isolation, you need to know the MAC addresses of the devices on your network, which are as follows.
Page 78: Figure 40 Tutorial: Ssid Profile
Chapter 5 Tutorial Figure 40 Tutorial: SSID Profile 2 Select SERVER_1’s entry and click Edit. The following screen displays. Figure 41 Tutorial: SSID Edit Select l2Isolation03 in the L2 Isolation field, and select macfilter03 in the MAC Filtering field. Click Apply. 3 Click the Layer-2 Isolation tab.
Page 79: Configure The Server_2 Network
Figure 42 Tutorial: Layer-2 Isolation Edit Enter the network switch’s MAC Address and add a Description (“NET_SWITCH” in this case) in Set 1’s entry. Enter server 1’s MAC Address and add a Description (“SERVER_1” in this case) in Set 2’s entry. Change the Profile Name to “L-2-ISO_SERVER_1”...
Page 80: Checking Your Settings And Testing The Configuration
Chapter 5 Tutorial To do this, repeat the procedure in information. Table 9 Tutorial: SERVER_2 Network Information SSID Screen Index Profile Name SSID Edit (SERVER_2) Screen L2 Isolation MAC Filtering Layer-2 Isolation (L2Isolation04) Screen Profile Name Set 1 Set 2 Set 3 MAC Filter (macfilter04) Edit Screen Profile Name...
Page 81: Testing The Configuration
Figure 44 Tutorial: SSID Profiles Activated 2 Next, click the SSID tab. Check that each configured SSID profile uses the correct Security, Layer-2 Isolation and MAC Filter profiles, as shown in the following figure. Figure 45 Tutorial: SSID Tab Correct Settings If the settings are not as shown, follow the steps in the relevant section of this tutorial again.
Page 82 Chapter 5 Tutorial Attempt to access the Internet. You should be able to do so. Attempt to access Server 2. You should be unable to do so. If you can do so, layer-2 isolation is misconfigured. • Using Alice’s computer and wireless client, and incorrect security settings, attempt to associate with the SERVER_1 network.
Page 83: The Web Configurator
The Web Configurator System Screens (85) Wireless Configuration (91) Wireless Security Configuration (109) MBSSID and SSID (121) Other Wireless Configuration (129) IP Screen (141) Rogue AP (145) Remote Management Screens (151) Internal RADIUS Server (169) Certificates (177) Log Screens (195) VLAN (203) Maintenance (221)
Page 85: System Screens
H A P T E R 6.1 System Overview This section provides information on general system setup. 6.2 Configuring General Setup Click SYSTEM > General. Figure 46 System > General The following table describes the labels in this screen. Table 10 System > General LABEL DESCRIPTION General Setup...
Page 86: Administrator Authentication On Radius
Chapter 6 System Screens Table 10 System > General LABEL System DNS Servers First DNS Server Second DNS Server Third DNS Server Apply Reset 6.3 Administrator Authentication on RADIUS The administrator authentication on RADIUS feature lets a (external or internal) RADIUS server authenticate management logins to the ZyXEL Device.
Page 87: Figure 47 System > Password
Figure 47 SYSTEM > Password. The following table describes the labels in this screen. Table 11 Password LABEL Enable Admin at Local Select this check box to have the device authenticate management logins to Use old setting Use new setting Old Password New Password Retype to Confirm...
Page 88: Configuring Time Setting
Chapter 6 System Screens Table 11 Password LABEL RADIUS Apply Reset 6.4 Configuring Time Setting To change your ZyXEL Device’s time and date, click SYSTEM > Time Setting. The screen appears as shown. Use this screen to configure the ZyXEL Device’s time based on your local time zone.
Page 89: Table 12 System > Time Setting
The following table describes the labels in this screen. Table 12 SYSTEM > Time Setting LABEL Current Time Current Date Manual New Time (hh:mm:ss) New Date (yyyy:mm:dd) Get from Time Server Auto User Defined Time Server Address Time Zone Daylight Savings Start Date End Date NWA3550 User’s Guide...
Page 90: Pre-Defined Ntp Time Servers List
Chapter 6 System Screens Table 12 SYSTEM > Time Setting LABEL Apply Reset 6.5 Pre-defined NTP Time Servers List When you turn on the ZyXEL Device for the first time, the date and time start at 2000-01-01 00:00:00. When you select Auto in the SYSTEM > Time Setting screen, the ZyXEL Device then attempts to synchronize with one of the following pre-defined list of NTP time servers.
Page 91: Wireless Configuration
H A P T E R Wireless Configuration This chapter discusses how to configure the ZyXEL Device’s Wireless screens. 7.1 Wireless Network Overview The following figure provides an example of a wireless network. Figure 49 Example of a Wireless Network The wireless network is the part in the blue circle.
Page 92: Wireless Lan Basics
Chapter 7 Wireless Configuration Like radio stations or television channels, each wireless network uses a specific channel, or frequency, to send and receive information. • Every device in the same wireless network must use security compatible with the AP. Security stops unauthorized devices from using the wireless network. It can also protect the information that is sent in the wireless network.
Page 93: Wmm Qos Priorities
7.3.1.1 WMM QoS Priorities The following table describes the WMM QoS priority levels that the ZyXEL Device uses. Table 14 WMM QoS Priorities PRIORITY LEVEL voice (WMM_VOICE) video (WMM_VIDEO) best effort (WMM_BEST_EFFORT) background (WMM_BACKGROUND) 7.3.2 ATC Automatic Traffic Classifier (ATC) is a bandwidth management tool that prioritizes data packets sent across the network.
Page 94: Atc+Wmm
Chapter 7 Wireless Configuration You should activate ATC on the ZyXEL Device if your wireless network includes networking devices that do not support WMM QoS, or if you want to prioritize traffic but do not want to configure WMM QoS settings. 7.3.3 ATC+WMM The ZyXEL Device can use a mapping mechanism to use both ATC and WMM QoS.
Page 95: Type Of Service (Tos)
7.3.4 Type Of Service (ToS) Network traffic can be classified by setting the ToS (Type Of Service) values at the data source (for example, at the ZyXEL Device) so a server can decide the best method of delivery, that is the least cost, fastest route and so on.
Page 96: Spanning Tree Protocol (Stp)
Chapter 7 Wireless Configuration The following table lists which WMM QoS priority level the ZyXEL Device uses for specific DSCP values. Table 19 ToS and IEEE 802.1d to WMM QoS Priority Level Mapping DSCP VALUE 224, 192 160, 128 96, 0 64, 32 A.
Page 97: How Stp Works
For each LAN segment, a designated bridge is selected. This bridge has the lowest cost to the root among the bridges connected to the LAN. 7.4.3 How STP Works After a bridge determines the lowest cost-spanning tree with STP, it enables the root port and the ports that are the designated ports for connected LANs, and disables all other ports that participate in STP.
Page 98: Wireless Screen Overview
Chapter 7 Wireless Configuration 7.6 Wireless Screen Overview The following is a list of the wireless screens you can configure on the ZyXEL Device. 1 Configure the ZyXEL Device to operate in AP, Bridge/Repeater, AP+Bridge or MBSSID mode in the Wireless screen. You can also select an SSID Profile in the Wireless screen.
Page 99: Figure 51 Wireless: Access Point
Figure 51 Wireless: Access Point The following table describes the general wireless LAN labels in this screen. Table 22 Wireless: Access Point LABEL DESCRIPTION WLAN Interface Select which WLAN adapter you want to configure. It is recommended that you configure the first WLAN adapter for AP functions and use the second WLAN adapter for bridge functions.
Page 100 Chapter 7 Wireless Configuration Table 22 Wireless: Access Point LABEL DESCRIPTION Disable channel This field displays only when you select 802.11a in the 802.11 Mde field. Select this switching for if you do not want to use DFS Choose Set the operating frequency/channel depending on your particular region. Channel ID To manually set the ZyXEL Device to use a channel, select a channel from the drop- down list box.
Page 101: Bridge/Repeater Mode
Table 22 Wireless: Access Point LABEL DESCRIPTION SSID Profile The SSID (Service Set IDentifier) identifies the Service Set with which a wireless station is associated. Wireless stations associating to the access point (AP) must have the same SSID. Select an SSID Profile from the drop-down list box. Configure SSID profiles in the SSID screen (see information on configuring SSID).
Page 102: Figure 52 Bridging Example
Chapter 7 Wireless Configuration Figure 52 Bridging Example LAN1 Be careful to avoid bridge loops when you enable bridging in the ZyXEL Device. Bridge loops cause broadcast traffic to circle the network endlessly, resulting in possible throughput degradation and disruption of communications. The following examples show two network topologies that can lead to this problem: •...
Page 103: Figure 54 Bridge Loop: Bridge Connected To Wired Lan
Chapter 7 Wireless Configuration Figure 54 Bridge Loop: Bridge Connected to Wired LAN Bridge Bridge Ethernet To prevent bridge loops, ensure that you enable STP in the Wireless screen or your ZyXEL Device is not set to bridge mode while connected to both wired and wireless segments of the same LAN.
Page 104: Figure 55 Wireless: Bridge/Repeater
Chapter 7 Wireless Configuration Figure 55 Wireless: Bridge/Repeater The following table describes the bridge labels in this screen. Table 23 Wireless: Bridge/Repeater LABEL WLAN Interface Operating Mode DESCRIPTIONS Select which WLAN adapter you want to configure. It is recommended that you configure the first WLAN adapter for AP functions and use the second WLAN adapter for bridge functions.
Page 105 Table 23 Wireless: Bridge/Repeater LABEL 802.11 mode Disable channel switching for DFS Choose Channel ID RTS/CTS Threshold Fragmentation Threshold Output Power Enable WDS Security Select this to turn on security for the ZyXEL Device’s Wireless Distribution NWA3550 User’s Guide DESCRIPTIONS Select 802.11b Only to allow only IEEE 802.11b compliant WLAN devices to associate with the ZyXEL Device.
Page 106: Ap+Bridge Mode
Chapter 7 Wireless Configuration Table 23 Wireless: Bridge/Repeater LABEL TKIP (ZyAIR Series Compatible) Index Active Remote Bridge MAC Address Table 22 on page 99 7.7.3 AP+Bridge Mode Select AP+Bridge as the Operating Mode in the WIRELESS > Wireless screen to have the ZyXEL Device function as a bridge and access point simultaneously.
Page 107: Figure 56 Wireless: Ap+Bridge
Chapter 7 Wireless Configuration Figure 56 Wireless: AP+Bridge See the tables describing the fields in the Access Point and Bridge/Repeater operating modes for descriptions of the fields in this screen. NWA3550 User’s Guide...
Page 108: Mbssid Mode
Chapter 7 Wireless Configuration 7.7.4 MBSSID Mode Select MBSSID as the Operating Mode. Refer to instructions and detailed information. See settings. Chapter 9 on page 121 for configuration Chapter 8 on page 109 for details on the security NWA3550 User’s Guide...
Page 109: Wireless Security Configuration
H A P T E R Wireless Security Configuration This chapter describes how to use the Security and RADIUS screens to configure wireless security on your ZyXEL Device. 8.1 Wireless Security Overview The following sections introduce different types of wireless security you can set up in the wireless network.
Page 110: User Authentication
Chapter 8 Wireless Security Configuration 8.1.3 User Authentication Authentication is the process of verifying whether a wireless device is allowed to use the wireless network. You can make every user log in to the wireless network before they can use it.
Page 111: Security Modes
When you use WPA2 or WPA2-PSK in your ZyXEL Device, you can select WPA2-MIX or WPA2-PSK-MIX to support WPA as well. In this case, if some of the devices support WPA and some support WPA2, you should set up WPA2-PSK-MIX or WPA2-MIX (depending on the type of wireless network login) in the ZyXEL Device.
Page 112: Security: Wep
Chapter 8 Wireless Security Configuration Figure 57 Wireless > Security The following table describes the labels in this screen. Table 26 WIRELESS > Security LABEL Index Profile Name Security Mode Edit The next screen varies according to the Security Mode you select. 8.3.1 Security: WEP Select WEP in the Security Mode field to display the following screen.
Page 113: Security: 802.1X Only
Figure 58 WIRELESS > Security: WEP The following table describes the labels in this screen. Table 27 Security: WEP LABEL DESCRIPTION Profile Name Type a name to identify this security profile. Security Mode Choose WEP in this field. WEP Encryption Select 64-bit WEP, 128-bit WEP or 152-bit WEP to enable data encryption.
Page 114: Security: 802.1X Static 64-Bit, 802.1X Static 128-Bit
Chapter 8 Wireless Security Configuration Figure 59 Security: 802.1x Only The following table describes the labels in this screen. Table 28 Security: 802.1x Only LABEL Profile Name Security Mode ReAuthentication Timer Idle Timeout Apply Reset 8.3.3 Security: 802.1x Static 64-bit, 802.1x Static 128-bit Select 8021x-Static64 or 8021x-Static128 in the Security Mode field to display the following screen.
Page 115: Figure 60 Security: 802.1X Static 64-Bit, 802.1X Static 128-Bit
Figure 60 Security: 802.1x Static 64-bit, 802.1x Static 128-bit The following table describes the labels in this screen. Table 29 Security: 802.1x Static 64-bit, 802.1x Static 128-bit LABEL DESCRIPTION Profile Name Type a name to identify this security profile. Security Mode Choose 8021x-Static64 or 8021x-Static128 in this field.
Page 116: Security: Wpa
Chapter 8 Wireless Security Configuration 8.3.4 Security: WPA Select WPA in the Security Mode field to display the following screen. Figure 61 Security: WPA The following table describes the labels in this screen. Table 30 Security: WPA LABEL Name Security Mode ReAuthentication Timer Idle Timeout...
Page 117: Figure 62 Security:wpa2 Or Wpa2-Mix
Figure 62 Security:WPA2 or WPA2-MIX The following table describes the labels not previously discussed Table 31 Security: WPA2 or WPA2-MIX LABEL DESCRIPTIONS Profile Name Type a name to identify this security profile. Security Mode Choose WPA2 or WPA2-MIX in this field. ReAuthentication Specify how often wireless stations have to resend usernames and passwords in Timer...
Page 118: Security: Wpa-Psk, Wpa2-Psk, Wpa2-Psk-Mix
Chapter 8 Wireless Security Configuration 8.3.6 Security: WPA-PSK, WPA2-PSK, WPA2-PSK-MIX Select WPA-PSK, WPA2-PSK or WPA2-PSK-MIX in the Security Mode field to display the following screen. Figure 63 Security: WPA-PSK, WPA2-PSK or WPA2-PSK-MIX The following table describes the labels not previously discussed Table 32 Security: WPA-PSK, WPA2-PSK or WPA2-PSK-MIX LABEL Profile Name...
Page 119: Introduction To Radius
8.4 Introduction to RADIUS RADIUS is based on a client-sever model that supports authentication and accounting, where the access point is the client and the server is the RADIUS server. The RADIUS server handles the following tasks, among others: • Authentication Determines the identity of the users.
Page 120: Table 33 Radius
Chapter 8 Wireless Security Configuration The following table describes the labels in this screen. Table 33 RADIUS LABEL Index Profile Name Primary Backup RADIUS Option Internal External Active RADIUS Server IP Address RADIUS Server Port Share Secret Active Accounting Server IP Address Accounting Server Port...
Page 121: Mbssid And Ssid
H A P T E R This chapter describes how to configure and use your ZyXEL Device’s MBSSID mode and configure SSID profiles. 9.1 Wireless LAN Infrastructures See the Wireless LAN chapter for some basic WLAN scenarios and terminology. 9.1.1 MBSSID Traditionally, you needed to use different APs to configure different Basic Service Sets (BSSs).
Page 122: Configuring Multiple Bsss
Chapter 9 MBSSID and SSID The switch adds PVID (Port VLAN IDentity) tags to incoming frames that don’t already have tags (on switch ports where PVID is enabled). Figure 65 Multiple BSS with VLAN Example LAN 1 VLAN 1 BSS 1 9.1.5 Configuring Multiple BSSs Click WIRELESS >...
Page 123: Figure 66 Wireless: Multiple Bss
Figure 66 Wireless: Multiple BSS The following table describes the labels in this screen. Table 34 Wireless: Multiple BSS LABEL WLAN Interface Operating Mode NWA3550 User’s Guide DESCRIPTION Select which WLAN adapter you want to configure. It is recommended that you configure the first WLAN adapter for AP functions and use the second WLAN adapter for bridge functions.
Page 124 Chapter 9 MBSSID and SSID Table 34 Wireless: Multiple BSS LABEL 802.11 Mode Super Mode Choose Channel ID Scan Disable channel switching for DFS RTS/CTS Threshold Fragmentation Threshold Output Power Rates Configuration DESCRIPTION Select 802.11b Only to allow only IEEE 802.11b compliant WLAN devices to associate with the ZyXEL Device.
Page 125: Ssid
Table 34 Wireless: Multiple BSS LABEL Select SSID Profile Index Active Profile Enable Spanning Tree Control (STP) Enable Roaming Apply Reset 9.2 SSID When the ZyXEL Device is set to Access Point, AP+Bridge or MBSSID mode, you need to choose the SSID profile(s) you want to use in your wireless network (see for more information on operating modes).
Page 126: Figure 67 Ssid
Chapter 9 MBSSID and SSID Figure 67 SSID The following table describes the labels in this screen. Table 35 SSID LABEL Index Name SSID Security RADIUS Layer 2 Isolation MAC Filter Edit DESCRIPTION This field displays the index number of each SSID profile. This field displays the identification name of each SSID profile on the ZyXEL Device.
Page 127: Configuring Ssid
9.2.2 Configuring SSID Each SSID profile references the settings configured in the following screens: • WIRELESS > Security (one of the security profiles). • WIRELESS > RADIUS (one of the RADIUS profiles). • WIRELESS > MAC Filter (the MAC filter list, if activated in the SSID profile). •...
Page 128 Chapter 9 MBSSID and SSID Table 36 Configuring SSID LABEL Layer-2 Isolation Intra-BSS Traffic blocking MAC Filtering Apply Reset DESCRIPTION Select the Quality of Service priority for this BSS’s traffic. • In the pre-configured VoIP_SSID profile, the QoS setting is VoIP. This is not user-configurable.
Page 129: Other Wireless Configuration
H A P T E R Other Wireless Configuration This chapter describes how to configure the Layer-2 Isolation and MAC Filter screens on your ZyXEL Device. 10.1 Layer-2 Isolation Introduction Layer-2 isolation is used to prevent wireless clients associated with your ZyXEL Device from communicating with other wireless clients, APs, computers or routers in a network.
Page 130: The Layer-2 Isolation Screen
Chapter 10 Other Wireless Configuration Figure 69 Layer-2 Isolation Application MAC addresses that are not listed in the Allow devices with these MAC addresses table are blocked from communicating with the ZyXEL Device’s wireless clients except for broadcast packets. Layer-2 isolation does not check the traffic between wireless clients that are associated with the same AP.
Page 131: Configuring Layer-2 Isolation
Figure 70 WIRELESS > Layer 2 Isolation The following table describes the labels in this screen. Table 37 WIRELESS > Layer-2 Isolation LABEL DESCRIPTION Index This is the index number of the profile. Profile Name This field displays the name given to a layer-2 isolation profile in the Layer-2 Isolation Configuration screen.
Page 132: Figure 71 Wireless > Layer-2 Isolation Configuration Screen
Chapter 10 Other Wireless Configuration Figure 71 WIRELESS > Layer-2 Isolation Configuration Screen The following table describes the labels in this screen. Table 38 WIRELESS > Layer-2 Isolation Configuration LABEL Profile Name Allow devices with these MAC addresses Index MAC Address Description Apply Reset...
Page 133: Layer-2 Isolation Examples
10.3.1 Layer-2 Isolation Examples The following section shows you example layer-2 isolation configurations on the ZyXEL Device (A). When configuring, remember to select the correct layer-2 isolation profile in the WIRELESS > SSID > Edit screen of the relevant SSID profile. Figure 72 Layer-2 Isolation Example Configuration 10.3.1.1 Layer-2 Isolation Example 1 In the following example wireless clients 1 and 2 can communicate with network router B and...
Page 134: Layer-2 Isolation Example 2
Chapter 10 Other Wireless Configuration 10.3.1.2 Layer-2 Isolation Example 2 In the following example wireless clients 1 and 2 can communicate with access point D and file server C but not wireless client 3. • Enter the router’s, server’s and access point D’s MAC addresses in the MAC Address fields.
Page 135: Configuring Mac Filtering
Figure 75 WIRELESS > MAC Filter The following table describes the labels in this screen. Table 39 WIRELESS > MAC Filter LABEL DESCRIPTION Index This is the index number of the profile. Profile Name This field displays the name given to a MAC filter profile in the MAC Filter Configuration screen.
Page 136: Figure 76 Mac Address Filter
Chapter 10 Other Wireless Configuration Figure 76 MAC Address Filter The following table describes the labels in this screen. Table 40 MAC Address Filter LABEL Profile Name Filter Action Index MAC Address Description Apply Reset DESCRIPTION Type a name to identify this profile. Define the filter action for the list of MAC addresses in the MAC address filter table.
Page 137: Configuring Roaming
To activate MAC filtering on an SSID profile, select the correct filter from the Enable MAC Filtering drop-down list box in the WIRELESS > SSID > Edit screen and click Apply. 10.5 Configuring Roaming A wireless station is a device with an IEEE 802.11a/b/g compliant wireless interface. An access point (AP) acts as a bridge between the wireless and wired networks.
Page 138: Requirements For Roaming
Chapter 10 Other Wireless Configuration Figure 77 Roaming Example The steps below describe the roaming process. 1 Wireless station Y moves from the coverage area of access point AP 1 to that of access point AP 2. 2 Wireless station Y scans and detects the signal of access point AP 2. 3 Wireless station Y sends an association request to access point AP 2.
Page 139: Figure 78 Roaming
Chapter 10 Other Wireless Configuration Figure 78 Roaming Select the Enable Roaming check box and click Apply. NWA3550 User’s Guide...
Page 140 Chapter 10 Other Wireless Configuration NWA3550 User’s Guide...
Page 141: Ip Screen
H A P T E R This chapter discusses how to configure IP settings on the ZyXEL Device. 11.1 Factory Ethernet Defaults The Ethernet parameters of the ZyXEL Device are preset in the factory with the following values: 1 IP address of 192.168.1.2 2 Subnet mask of 255.255.255.0 (24 bits) These parameters should work for the majority of installations.
Page 142: Configuring Ip Settings
Chapter 11 IP Screen Regardless of your particular situation, do not create an arbitrary IP address; always follow the guidelines above. For more information on address assignment, please refer to RFC 1597, Address Allocation for Private Internets and RFC 1466, Guidelines for Management of IP Address Space. 11.3 Configuring IP Settings Click IP to display the screen shown next.
Page 143 Table 42 IP Setup LABEL Apply Reset NWA3550 User’s Guide DESCRIPTION Click Apply to save your changes. Click Reset to begin configuring this screen afresh. Chapter 11 IP Screen...
Page 144 Chapter 11 IP Screen NWA3550 User’s Guide...
Page 145: Rogue Ap
H A P T E R This chapter discusses rogue wireless access points (APs) and how to configure the ZyXEL Device’s rogue AP detection feature. 12.1 Rogue AP Introduction A rogue AP is a wireless access point operating in a network’s coverage area that is not a sanctioned part of that network.
Page 146: Honeypot" Attack
Chapter 12 Rogue AP Figure 80 Rogue AP: Example 12.2.1 “Honeypot” Attack Rogue APs need not be connected to the legitimate network to pose a severe security threat. In the following example, an attacker (X) is stationed in a vehicle outside a company building, using a rogue access point equipped with a powerful antenna.
Page 147: Configuring Rogue Ap Detection
Figure 81 “Honeypot” Attack 12.3 Configuring Rogue AP Detection You can configure the ZyXEL Device to detect rogue IEEE 802.11a (5 GHz) and IEEE 802.11b/g (2.4 GHz) APs. If you have more than one AP in your wireless network, you must also configure the list of “friendly”...
Page 148: Rogue Ap: Friendly Ap
Chapter 12 Rogue AP Figure 82 ROGUE AP > Configuration The following table describes the labels in this screen. Table 43 ROGUE AP > Configuration LABEL Rogue AP Period Detection Period (minutes) Expiration Time (minutes) Friendly AP List Export File Path Browse Import Apply...
Page 149: Rogue Ap List
Figure 83 ROGUE AP > Friendly AP The following table describes the labels in this screen. Table 44 ROGUE AP > Friendly AP LABEL Add Friendly AP MAC Address Description Friendly AP List MAC Address SSID Channel Security Last Seen Description Delete 12.3.3 Rogue AP List...
Page 150: Figure 84 Rogue Ap > Rogue Ap
Chapter 12 Rogue AP Figure 84 ROGUE AP > Rogue AP The following table describes the labels in this screen. Table 45 ROGUE AP > Rogue AP LABEL Rogue AP List Refresh Active MAC Address SSID Channel Security Last Seen Description Add to Friendly AP List Reset...
Page 151: Remote Management Screens
H A P T E R Remote Management Screens This chapter provides information on the Remote Management screens. 13.1 Remote Management Overview Remote management allows you to determine which services/protocols can access which ZyXEL Device interface (if any) from which computers. You may manage your ZyXEL Device from a remote location via: Table 46 Remote Management Overview •...
Page 152: System Timeout
Chapter 13 Remote Management Screens 13.1.2 System Timeout There is a default system management idle timeout of five minutes (three hundred seconds). The ZyXEL Device automatically logs you out if the management session remains idle for longer than this timeout period. The management session does not time out when a statistics screen is polling.
Page 153: Ssh Implementation On The Zyxel Device
The SSH client sends a connection request to the SSH server. The server identifies itself with a host key. The client encrypts a randomly generated session key with the host key and server key and sends the result back to the server. The client automatically saves any new server public keys.
Page 154: Figure 86 Remote Management: Telnet
Chapter 13 Remote Management Screens Figure 86 Remote Management: Telnet The following table describes the labels in this screen. Table 47 Remote Management: Telnet LABEL TELNET Server Port You can change the server port number for a service if needed, however you must use the same port number in order to use that service for remote management.
Page 155: Configuring Ftp
13.6 Configuring FTP You can use FTP (File Transfer Protocol) to upload and download the ZyXEL Device’s firmware and configuration files, please see the User’s Guide chapter on firmware and configuration file maintenance for details. To use this feature, your computer must have an FTP client.
Page 156: Www (Http And Https)
Chapter 13 Remote Management Screens 13.7 WWW (HTTP and HTTPS) HTTPS (HyperText Transfer Protocol over Secure Socket Layer, or HTTP over SSL) is a web protocol that encrypts and decrypts web pages. Secure Socket Layer (SSL) is an application- level protocol that enables secure transactions of data by ensuring confidentiality (an unauthorized party cannot read the transferred data), authentication (one party can identify the other party) and data integrity (you know if data has been changed).
Page 157: Configuring Www
13.8 Configuring WWW To change your ZyXEL Device’s World Wide Web settings, click REMOTE MGNT > WWW. Figure 89 Remote Management: WWW The following table describes the labels in this screen. Table 49 Remote Management: WWW LABEL DESCRIPTION Server Port You may change the server port number for a service if needed, however you must use the same port number in order to use that service for remote management.
Page 158: Https Example
Chapter 13 Remote Management Screens Table 49 Remote Management: WWW LABEL DESCRIPTION Server Access Select a ZyXEL Device interface from Server Access on which incoming HTTPS access is allowed. You can allow only secure web configurator access by setting the WWW Server Access field to Disable and setting the HTTPS Server Access field to an interface(s).
Page 159: Netscape Navigator Warning Messages
13.9.2 Netscape Navigator Warning Messages When you attempt to access the ZyXEL Device HTTPS server, a Website Certified by an Unknown Authority screen pops up asking if you trust the server certificate. Click Examine Certificate if you want to verify that the certificate is from the ZyXEL Device. If Accept this certificate temporarily for this session is selected, then click OK to continue in Netscape.
Page 160: Login Screen
Chapter 13 Remote Management Screens • The issuing certificate authority of the ZyXEL Device’s HTTPS server certificate is not one of the browser’s trusted certificate authorities. The issuing certificate authority of the ZyXEL Device's factory default certificate is the ZyXEL Device itself since the certificate is a self-signed certificate.
Page 161: Figure 93 Example: Lock Denoting A Secure Connection
Chapter 13 Remote Management Screens Figure 93 Example: Lock Denoting a Secure Connection Click Login and you then see the next screen. The factory default certificate is a common default certificate for all ZyXEL Device models. Figure 94 Replace Certificate Click Apply in the Replace Certificate screen to create a certificate using your ZyXEL Device’s MAC address that will be specific to this device.
Page 162: Snmp
Chapter 13 Remote Management Screens Figure 95 Device-specific Certificate Click Ignore in the Replace Certificate screen to use the common ZyXEL Device certificate. You will then see this information in the My Certificates screen. Figure 96 Common ZyXEL Device Certificate 13.10 SNMP Simple Network Management Protocol (SNMP) is a protocol used for exchanging management information between network devices.
Page 163: Figure 97 Snmp Management Model
SNMP is available only if TCP/IP is configured. Figure 97 SNMP Management Model An SNMP managed network consists of two main types of component: agents and a manager. An agent is a management software module that resides in a managed device (the ZyXEL Device).
Page 164: Supported Mibs
Chapter 13 Remote Management Screens 13.10.1 Supported MIBs The ZyXEL Device supports MIB II, which is defined in RFC-1213 and RFC-1215, as well as the proprietary ZyXEL private MIB. The purpose of the MIBs is to let administrators collect statistical data and monitor status and performance. 13.10.2 SNMP Traps The ZyXEL Device can send the following traps to the SNMP manager.
Page 165: Snmp Trap Interface Index
Table 50 SNMP Traps TRAP NAME pwTrapTFTPStatus pwTFTPStatus 13.11 SNMP Trap Interface Index Some traps include an SNMP interface index. The following table maps the SNMP interface indexes to the ZyXEL Device’s physical and virtual ports. Table 51 SNMP Interface Index to Physical and Virtual Port Mapping TYPE INTERFACE Physical...
Page 166: Figure 98 Remote Management: Snmp
Chapter 13 Remote Management Screens Figure 98 Remote Management: SNMP The following table describes the labels in this screen. Table 52 Remote Management: SNMP LABEL SNMP Configuration Get Community Set Community Trap Destination SNMP Version Trap Community User Profile Configure SNMPv3 User Profile DESCRIPTION Enter the Get Community, which is the password for the incoming Get and...
Page 167: The Snmpv3 User Profile Screen
Table 52 Remote Management: SNMP LABEL DESCRIPTION SNMP Service Port You may change the server port number for a service if needed, however you must use the same port number in order to use that service for remote management. Service Access Select the interface(s) through which a computer may access the ZyXEL Device using this service.
Page 168 Chapter 13 Remote Management Screens Table 53 Remote Management: SNMP User Profile LABEL Confirm Password Access Type Authentication Protocol Privacy Protocol Enable SNMPv3User User Name Password Confirm Password Access Type Authentication Protocol Privacy Protocol Apply Reset DESCRIPTION Re-enter the Password. For the administrator, this is always Set.
Page 169: Internal Radius Server
H A P T E R Internal RADIUS Server The ZyXEL Device can use its internal RADIUS server to authenticate wireless clients. It can also serve as a RADIUS server to authenticate other APs and their wireless clients. For more background information on RADIUS, see 14.1 Internal RADIUS Overview The ZyXEL Device has a built-in RADIUS server that can authenticate wireless clients or...
Page 170: Figure 100 Internal Radius Server Setting Screen
Chapter 14 Internal RADIUS Server The internal RADIUS server does not support domain accounts (DOMAIN/ user). When you configure your Windows XP SP2 Wireless Zero Configuration PEAP/MS-CHAPv2 settings, deselect the Use Windows logon name and password check box. When authentication begins, a pop-up dialog box requests you to type a Name, Password and Domain of the RADIUS server.
Page 171: Trusted Ap Overview
Table 54 Internal RADIUS Server Setting Screen Setting (continued) LABEL DESCRIPTION Type This field displays what kind of certificate this is. REQ represents a certification request and is not yet a valid certificate. Send a certification request to a certification authority, which then issues a certificate. Use the My Certificate Import screen to import the certificate and replace the request.
Page 172: Configuring Trusted Ap
Chapter 14 Internal RADIUS Server Figure 101 Trusted AP Overview ZyXEL RADIUS Server 1 Configure an IP address and shared secret in the Trusted AP database to authenticate an AP as a trusted AP. 2 Configure wireless client user names and passwords in the Trusted Users database to use a trusted AP as a relay between the ZyXEL Device’s internal RADIUS server and the wireless clients.
Page 173: Figure 102 Trusted Ap Screen
Figure 102 Trusted AP Screen The following table describes the labels in this screen. Table 55 Trusted AP LABEL DESCRIPTION Index This field displays the trusted AP index number. Active Select this check box to have the ZyXEL Device use the IP Address and Shared Secret to authenticate a trusted AP.
Page 174: Configuring Trusted Users
Chapter 14 Internal RADIUS Server 14.5 Configuring Trusted Users A trusted user entry consists of a wireless client user name and password. To configure trusted user entries, click AUTH SERVER > Trusted Users. The screen appears as shown. Figure 103 Trusted Users Screen The following table describes the labels in this screen.
Page 175 Table 56 Trusted Users LABEL DESCRIPTION Type a password (up to 31 ASCII characters) for this user profile. Note that as you Password type a password, the screen displays a (*) for each character you type. The password on the wireless client’s utility must be the same as this password. Note: If you are using PEAP authentication, this password field is Apply Click Apply to save your changes.
Page 176 Chapter 14 Internal RADIUS Server NWA3550 User’s Guide...
Page 177: Certificates
H A P T E R This chapter gives background information about public-key certificates and explains how to use them. 15.1 Certificates Overview The ZyXEL Device can use certificates (also called digital IDs) to authenticate users. Certificates are based on public-private key pairs. A certificate contains the certificate owner’s identity and public key.
Page 178: Advantages Of Certificates
Chapter 15 Certificates Certification authorities maintain directory servers with databases of valid and revoked certificates. A directory of certificates that have been revoked before the scheduled expiration is called a CRL (Certificate Revocation List). The ZyXEL Device can check a peer’s certificate against a directory server’s list of revoked certificates.
Page 179: Configuration Summary
Figure 105 Certificate Details 4 Use a secure method to verify that the certificate owner has the same information in the Thumbprint Algorithm and Thumbprint fields. The secure method may vary according to your situation. Possible examples would be over the telephone or through an HTTPS connection.
Page 180: Figure 106 My Certificates
Chapter 15 Certificates Figure 106 My Certificates The following table describes the labels in this screen. Table 57 My Certificates LABEL PKI Storage Space in Use Replace Index Name Type Subject DESCRIPTION This bar displays the percentage of the ZyXEL Device’s PKI storage space that is currently in use.
Page 181: Certificate File Formats
Table 57 My Certificates (continued) LABEL DESCRIPTION Issuer This field displays identifying information about the certificate’s issuing certification authority, such as a common name, organizational unit or department, organization or company and country. With self-signed certificates, this is the same information as in the Subject field. Valid From This field displays the date that the certificate becomes applicable.
Page 182: Importing A Certificate
Chapter 15 Certificates 15.7 Importing a Certificate Click CERTIFICATES > My Certificates and then Import to open the My Certificate Import screen. Follow the instructions in this screen to save an existing certificate to the ZyXEL Device. You can import only a certificate that matches a corresponding certification request that was generated by the ZyXEL Device.
Page 183: Creating A Certificate
The following table describes the labels in this screen. Table 58 My Certificate Import LABEL DESCRIPTION File Path Type in the location of the file you want to upload in this field or click Browse to find it. Browse Click Browse to find the certificate file you want to upload. Apply Click Apply to save the certificate on the ZyXEL Device.
Page 184: Table 59 My Certificate Create
Chapter 15 Certificates The following table describes the labels in this screen. Table 59 My Certificate Create LABEL Certificate Name Subject Information Common Name Organizational Unit Organization Country Key Length Enrollment Options Create a self-signed certificate Create a certification request and save it locally for later manual enrollment Create a certification...
Page 185: My Certificate Details
Table 59 My Certificate Create (continued) LABEL CA Server Address CA Certificate Request Authentication Apply Cancel After you click Apply in the My Certificate Create screen, you see a screen that tells you the ZyXEL Device is generating the self-signed certificate or certification request. After the ZyXEL Device successfully enrolls a certificate or generates a certification request or a self-signed certificate, you see a screen with a Return button that takes you back to the My Certificates screen.
Page 186: Figure 109 My Certificate Details
Chapter 15 Certificates Figure 109 My Certificate Details The following table describes the labels in this screen. Table 60 My Certificate Details LABEL Name Property Default self-signed certificate which signs the imported remote host certificates. DESCRIPTION This field displays the identifying name of this certificate. If you want to change the name, type up to 31 characters to identify this certificate.
Page 187 Table 60 My Certificate Details (continued) LABEL DESCRIPTION Certificate Path Click the Refresh button to have this read-only text box display the hierarchy of certification authorities that validate the certificate (and the certificate itself). If the issuing certification authority is one that you have imported as a trusted certification authority, it may be the only certification authority in the list (along with the certificate itself).
Page 188: Trusted Cas
Chapter 15 Certificates Table 60 My Certificate Details (continued) LABEL SHA1 Fingerprint Certificate in PEM (Base-64) Encoded Format Export Apply Cancel 15.10 Trusted CAs Click CERTIFICATES > Trusted CAs to open the Trusted CAs screen. This screen displays a summary list of certificates of the certification authorities that you have set the ZyXEL Device to accept as trusted.
Page 189: Importing A Trusted Ca's Certificate
The following table describes the labels in this screen. Table 61 Trusted CAs LABEL DESCRIPTION PKI Storage This bar displays the percentage of the ZyXEL Device’s PKI storage space that is Space in Use currently in use. When you are using 80% or less of the storage space, the bar is green.
Page 190: Trusted Ca Certificate Details
Chapter 15 Certificates You must remove any spaces from the certificate’s filename before you can import the certificate. Figure 111 Trusted CA Import The following table describes the labels in this screen. Table 62 Trusted CA Import LABEL DESCRIPTION File Path Type in the location of the file you want to upload in this field or click Browse to find it.
Page 191: Figure 112 Trusted Ca Details
Figure 112 Trusted CA Details The following table describes the labels in this screen. Table 63 Trusted CA Details LABEL DESCRIPTION Name This field displays the identifying name of this certificate. If you want to change the name, type up to 31 characters to identify this key certificate. You may use any character (not including spaces).
Page 192 Chapter 15 Certificates Table 63 Trusted CA Details (continued) LABEL Certificate Information Type Version Serial Number Subject Issuer Signature Algorithm Valid From Valid To Key Algorithm Subject Alternative Name Key Usage Basic Constraint CRL Distribution Points MD5 Fingerprint DESCRIPTION These read-only fields display detailed information about the certificate. This field displays general information about the certificate.
Page 193 Table 63 Trusted CA Details (continued) LABEL DESCRIPTION SHA1 Fingerprint This is the certificate’s message digest that the ZyXEL Device calculated using the SHA1 algorithm. You cannot use this value to verify that this is the remote host’s actual certificate because the ZyXEL Device has signed the certificate; thus causing this value to be different from that of the remote host’s actual certificate.
Page 194 Chapter 15 Certificates NWA3550 User’s Guide...
Page 195: Log Screens
H A P T E R This chapter contains information about configuring general log settings and viewing the ZyXEL Device’s logs. 16.1 Configuring View Log The web configurator allows you to look at all of the ZyXEL Device’s logs in one location. Click LOGS >...
Page 196: Configuring Log Settings
Chapter 16 Log Screens Table 64 View Log LABEL Source Destination Notes Email Log Now Refresh Clear Log 16.2 Configuring Log Settings To change your ZyXEL Device’s log settings, click LOGS > Log Settings. The screen appears as shown. Use the Log Settings screen to configure to where and when the ZyXEL Device is to send the logs and which logs and/or immediate alerts it is to send.
Page 197: Figure 114 Log Settings
Figure 114 Log Settings The following table describes the labels in this screen. Table 65 Log Settings LABEL Address Info Mail Server Mail Subject Send Log to Send Alerts to NWA3550 User’s Guide DESCRIPTION Enter the server name or the IP address of the mail server for the e-mail addresses specified below.
Page 198: Example Log Messages
Chapter 16 Log Screens Table 65 Log Settings LABEL SMTP Authentication User Name Password Syslog Logging Active Syslog IP Address Log Facility Send Log Log Schedule Day for Sending Time for Sending Clear log after sending mail Send Immediate Alert Apply Reset 16.3 Example Log Messages...
Page 199: Table 67 Icmp Notes
Table 66 System Maintenance Logs LOG MESSAGE DHCP client gets %s DHCP client IP expired DHCP server assigns %s SMT Login Successfully SMT Login Fail WEB Login Successfully WEB Login Fail TELNET Login Successfully TELNET Login Fail FTP Login Successfully FTP Login Fail Table 67 ICMP Notes TYPE...
Page 200: Log Commands
Chapter 16 Log Screens Table 67 ICMP Notes (continued) TYPE CODE DESCRIPTION Pointer indicates the error Timestamp Timestamp request message Timestamp Reply Timestamp reply message Information Request Information request message Information Reply Information reply message Table 68 Sys log LOG MESSAGE Mon dd hr:mm:ss hostname src="<srcIP:srcPort>"...
Page 201: Log Command Example
16.5 Log Command Example This example shows how to set the ZyXEL Device to record the error logs and alerts and then view the results. ras> sys logs load ras> sys logs category error 3 ras> sys logs save ras> sys logs display access time source | 11/11/2002 15:10:12 | 172.22.3.80:137...
Page 202 Chapter 16 Log Screens NWA3550 User’s Guide...
Page 203: Vlan
H A P T E R This chapter discusses how to configure VLAN on the ZyXEL Device. 17.1 VLAN A VLAN (Virtual Local Area Network) allows a physical network to be partitioned into multiple logical networks. Stations on a logical network can belong to one or more groups. Only stations within the same group can talk to each other.
Page 204: Configuring Vlan
Chapter 17 VLAN 17.2 Configuring VLAN The ZyXEL Device allows you to configure VLAN based on SSID profile (wireless VLAN), and / or based on your RADIUS server (RADIUS VLAN). • When you use wireless VLAN, the ZyXEL Device tags all packets from an SSID with the VLAN ID you set in the Wireless VLAN screen.
Page 205: Figure 115 Wireless Vlan
Figure 115 Wireless VLAN The following table describes the labels in this screen Table 70 Wireless VLAN FIELD Enable VIRTUAL LAN Management VLAN ID VLAN Mapping Table Index NWA3550 User’s Guide DESCRIPTION Select this box to enable VLAN tagging. Enter a number from 1 to 4094 to define this VLAN group. At least one device in your network must belong to this VLAN group in order to manage the ZyXEL Device.
Page 206: Radius Vlan
Chapter 17 VLAN Table 70 Wireless VLAN FIELD Name SSID VLAN ID Second Rx VLAN ID Apply Reset 17.2.2 RADIUS VLAN Click VLAN > RADIUS VLAN. The following screen appears. Figure 116 RADIUS VLAN DESCRIPTION This is the name of the SSID profile. This is the SSID the profile uses.
Page 207: Configuring Management Vlan Example
The following table describes the labels in this screen. Table 71 RADIUS VLAN LABEL Block station if RADIUS server assigns VLAN name error! VLAN Mapping Table Index Active VLAN ID Name Apply Reset 17.2.3 Configuring Management VLAN Example This section shows you how to create a VLAN on an Ethernet switch. By default, the port on the ZyXEL Device is a member of the management VLAN (VLAN ID 1).
Page 208: Figure 117 Management Vlan Configuration Example
Chapter 17 VLAN Figure 117 Management VLAN Configuration Example MVID = 10 Port 2 Perform the following steps in the switch web configurator. This example uses the ZyXEL switch screenshots. 1 Click VLAN under Advanced Application. 2 Click Static VLAN. 3 Select the ACTIVE check box.
Page 209: Figure 120 Vlan-Aware Switch - Vlan Status
Figure 120 VLAN-Aware Switch - VLAN Status Follow the instructions in the Quick Start Guide to set up your ZyXEL Device for configuration. The ZyXEL Device should be connected to the VLAN-aware switch. In the above example, the switch is using port 1 to connect to your computer and port 2 to connect to the ZyXEL Device: Figure 117 on page 1 In the ZyXEL Device web configurator click VLAN to open the VLAN setup screen.
Page 210: Configuring Microsoft's Ias Server Example
Chapter 17 VLAN 17.2.4 Configuring Microsoft’s IAS Server Example Dynamic VLAN assignment can be used with the ZyXEL Device. Dynamic VLAN assignment allows network administrators to assign a specific VLAN (configured on the ZyXEL Device) to an individual’s Windows User Account. When a wireless station is successfully authenticated to the network, it is automatically placed into it’s respective VLAN.
Page 211: Configuring Remote Access Policies
Figure 122 New Global Security Group 2 In VLAN Group ID Properties, click the Members tab. • The IAS uses group memberships to determine which user accounts belong to which VLAN groups. Click the Add button and configure the VLAN group details. 3 Repeat the previous step to add each VLAN group required.
Page 212: Figure 124 New Remote Access Policy For Vlan Group
Chapter 17 VLAN • Enter a Policy friendly name that describes the policy. Each Remote Access Policy will be matched to one VLAN Group. An example may be, Allow - VLAN 10 Policy. • Click Next. Figure 124 New Remote Access Policy for VLAN Group 2 The Conditions window displays.
Page 213: Figure 126 Adding Vlan Group
Figure 126 Adding VLAN Group 6 When the Permissions options screen displays, select Grant remote access permission. • Click Next to grant access based on group membership. • Click the Edit Profile button. Figure 127 Granting Permissions and User Profile Screens 7 The Edit Dial-in Profile screen displays.
Page 214: Figure 128 Authentication Tab Settings
Chapter 17 VLAN Figure 128 Authentication Tab Settings 8 Click the Encryption tab. Select the Strongest encryption option. This step is not required for EAP-MD5, but is performed as a safeguard. Figure 129 Encryption Tab Settings 9 Click the IP tab and select the Client may request an IP address check box for DHCP support.
Page 215: Figure 130 Connection Attributes Screen
Figure 130 Connection Attributes Screen 11 The RADIUS Attribute screen displays. From the list, three RADIUS attributes will be added: • Tunnel-Medium-Type • Tunnel-Pvt-Group-ID • Tunnel-Type • Click the Add button • Select Tunnel-Medium-Type • Click the Add button. Figure 131 RADIUS Attribute Screen 12 The Enumerable Attribute Information screen displays.
Page 216: Figure 132 802 Attribute Setting For Tunnel-Medium-Type
Chapter 17 VLAN Figure 132 802 Attribute Setting for Tunnel-Medium-Type 13 Return to the RADIUS Attribute Screen shown as • Select Tunnel-Pvt-Group-ID. • Click Add. 14 The Attribute Information screen displays. • In the Enter the attribute value in: field select String and type a number in the range 1 to 4094 or a Name for this policy.
Page 217: Figure 134 Vlan Attribute Setting For Tunnel-Type
Figure 134 VLAN Attribute Setting for Tunnel-Type 17 Return to the RADIUS Attribute Screen shown as • Click the Close button. • The completed Advanced tab configuration should resemble the following screen. Figure 135 Completed Advanced Tab Repeat the Configuring Remote Access Policies procedure for each VLAN Group defined in the Active Directory.
Page 218: Second Rx Vlan Id Example
Chapter 17 VLAN 17.2.5 Second Rx VLAN ID Example In this example, the ZyXEL Device is configured to tag packets from SSID01 with VLAN ID 1 and tag packets from SSID02 with VLAN ID 2. VLAN 1 and VLAN 2 have access to a server, S, and the Internet, as shown in the following figure.
Page 219: Figure 137 Configuring Ssid: Second Rx Vlan Id Example
4 Select the SSID profile you want to configure (SSID03 in this example), and enter the VLAN ID number (between 1 and 4094). 5 Enter a Second Rx VLAN ID. The following screen shows SSID03 tagged with a VLAN ID of 3 and a Second Rx VLAN ID of 4. Figure 137 Configuring SSID: Second Rx VLAN ID Example 6 Click Apply to save these settings.
Page 220 Chapter 17 VLAN NWA3550 User’s Guide...
Page 221: Maintenance
H A P T E R This chapter displays system information such as ZyNOS firmware, port IP addresses and port traffic statistics. 18.1 Maintenance Overview The maintenance screens can help you view system information, upload new firmware, manage configuration and restart your ZyXEL Device. 18.2 System Status Screen Click MAINTENANCE to open the System Status screen, where you can see information about your ZyXEL Device.
Page 222: System Statistics
Chapter 18 Maintenance Table 73 System Status LABEL DHCP Show Statistics 18.2.1 System Statistics Click Maintenance > Show Statistics. Read-only information here includes port status, packet specific statistics and bridge link status. Also provided are "system up time" and "poll interval(s)".
Page 223: Association List
The following table describes the labels in this screen. Table 74 System Status: Show Statistics LABEL Port Status TxPkts RxPkts Collisions Tx B/s Rx B/s Up Time WLAN1 WLAN2 Index Remote Bridge MAC Status TxPkts RxPkts Poll Interval(s) Set Interval Stop 18.3 Association List View the wireless stations that are currently associated with the ZyXEL Device in the...
Page 224: Channel Usage
Chapter 18 Maintenance Figure 140 Association List The following table describes the labels in this screen. Table 75 Association List LABEL Stations Index MAC Address Association Time SSID Signal WDS Link Index Remote Bridge MAC Link Time Security Refresh 18.4 Channel Usage The Channel Usage screen shows whether a channel is used by another wireless network or not.
Page 225: F/W Upload Screen
Figure 141 Channel Usage The following table describes the labels in this screen. Table 76 Channel Usage LABEL DESCRIPTION SSID This is the Service Set IDentification name of the AP in an Infrastructure wireless network or wireless station in an Ad-Hoc wireless network. For our purposes, we define an Infrastructure network as a wireless network that uses an AP and an Ad-Hoc network (also known as Independent Basic Service Set (IBSS)) as one that doesn’t.
Page 226: Figure 142 Firmware Upload
Chapter 18 Maintenance Figure 142 Firmware Upload The following table describes the labels in this screen. Table 77 Firmware Upload LABEL File Path Browse... Upload Do not turn off the ZyXEL Device while firmware upload is in progress! After you see the Firmware Upload in Process screen, wait two minutes before logging into the ZyXEL Device again.
Page 227: Configuration Screen
Figure 144 Network Temporarily Disconnected After two minutes, log in again and check your new firmware version in the System Status screen. If the upload was not successful, the following screen will appear. Click Return to go back to the F/W Upload screen. Figure 145 Firmware Upload Error 18.6 Configuration Screen Chapter 24 on page 251...
Page 228: Backup Configuration
Chapter 18 Maintenance Figure 146 Configuration 18.6.1 Backup Configuration Backup configuration allows you to back up (save) the ZyXEL Device’s current configuration to a file on your computer. Once your ZyXEL Device is configured and functioning properly, it is highly recommended that you back up your configuration file before making configuration changes.
Page 229: Figure 147 Configuration Upload Successful
Chapter 18 Maintenance Do not turn off the ZyXEL Device while configuration file upload is in progress. After you see a “restore configuration successful” screen, you must then wait one minute before logging into the ZyXEL Device again. Figure 147 Configuration Upload Successful The ZyXEL Device automatically restarts in this time causing a temporary network disconnect.
Page 230: Back To Factory Defaults
Chapter 18 Maintenance 18.6.3 Back to Factory Defaults Pressing the Reset button in this section clears all user-entered configuration information and returns the ZyXEL Device to its factory defaults as shown on the screen. The following warning screen will appear. Figure 150 Reset Warning Message You can also press the RESET button to reset your ZyXEL Device to its factory default settings.
Page 231: Troubleshooting And Specifications
Troubleshooting and Specifications Troubleshooting (233) Product Specifications (237)
Page 233: Troubleshooting
H A P T E R This chapter offers some suggestions to solve problems you might encounter. The potential problems are divided into the following categories. • Power and Hardware Connections • ZyXEL Device Access and Login • Internet Access •...
Page 234 Chapter 19 Troubleshooting I forgot the password. 1 The default password is 1234. 2 If this does not work, you have to reset the device to its factory defaults. Contact your vendor. I cannot see or access the Login screen in the web configurator. 1 Make sure you are using the correct IP address.
Page 235: Internet Access
4 If this does not work, you have to reset the device to its factory defaults. Contact your vendor. I cannot access the SMT. See the troubleshooting suggestions for configurator. Ignore the suggestions about your browser. I cannot use FTP to upload / download the configuration file. / I cannot use FTP to upload new firmware.
Page 236: Wireless Router/Ap Troubleshooting
Chapter 19 Troubleshooting The Internet connection is slow or intermittent. 1 There might be a lot of traffic on the network. If the ZyXEL Device is sending or receiving a lot of information, try closing some programs that use the Internet, especially peer-to-peer applications.
Page 237: Product Specifications
H A P T E R Product Specifications The following tables summarize the ZyXEL Device’s hardware and firmware features. Table 79 Hardware Specifications SPECIFICATION Dimensions Weight Power Ethernet Port Power over Ethernet (PoE) Antenna Specifications Output Power Operating Environment NWA3550 User’s Guide DESCRIPTION 256 (W) x 246 (D) x 82 (H) mm 2000 g...
Page 238: Table 80 Firmware Specifications
Chapter 20 Product Specifications Table 79 Hardware Specifications SPECIFICATION Storage Environment Approvals Table 80 Firmware Specifications Default IP Address Default Subnet Mask Default Password Wireless LAN Standards Wireless security Layer 2 isolation Multiple BSSID (MBSSID) Rogue AP detection Internal RADIUS server VLAN DESCRIPTION Temperature: -40º...
Page 239 Table 80 Firmware Specifications STP (Spanning Tree Protocol) / RSTP (Rapid STP) WMM QoS Certificates SSL Passthrough MAC Address Filter Wireless Association List Logging and Tracing Embedded FTP and TFTP Servers Auto Configuration SNMP CAPWAP (Control and Provisioning of Wireless Access Points) NWA3550 User’s Guide Chapter 20 Product Specifications...
Page 240: Table 81 Zyxel Device Compatible Antennas
Chapter 20 Product Specifications Compatible ZyXEL Antennas At the time of writing, you can use the following antennas in your ZyXEL Device. Table 81 ZyXEL Device Compatible Antennas MODEL EXT-108 EXR-109 FEATURES Frequency 2400 ~ 2500 2400 ~ 2500 2400 ~ 2500 2400 ~ 2500 2400 Band (MHz) Gain (dBi) Max.
Page 241: Table 83 Power Over Ethernet Injector Specifications
Power over Ethernet (PoE) Specifications You can use a power over Ethernet injector to power this device. The injector must comply to IEEE 802.3af. Table 83 Power over Ethernet Injector Specifications Power Output Power Current Table 84 Power over Ethernet Injector RJ-45 Port Pin Assignments PIN NO 1 2 3 4 5 6 7 8 NWA3550 User’s Guide...
Page 242 Chapter 20 Product Specifications NWA3550 User’s Guide...
Page 243: Appendices And Index
Appendices and Index Setting Up Your Computer’s IP Address (245) Wireless LANs (269) Pop-up Windows, JavaScripts and Java Permissions (283) Importing Certificates (289) IP Addresses and Subnetting (313) Text File Based Auto Configuration (321) Legal Information (329) Customer Support (333) Index (339)
Page 245: Appendix A Setting Up Your Computer's Ip Address
P P E N D I X Setting Up Your Computer’s IP Your specific ZyXEL device may not support all of the operating systems described in this appendix. See the product specifications for more information about which operating systems are supported. This appendix shows you how to configure the IP settings on your computer in order for it to be able to communicate with the other devices on your network.
Page 246: Figure 152 Windows Xp: Start Menu
Appendix A Setting Up Your Computer’s IP Address Figure 152 Windows XP: Start Menu 2 In the Control Panel, click the Network Connections icon. Figure 153 Windows XP: Control Panel 3 Right-click Local Area Connection and then select Properties. Figure 154 Windows XP: Control Panel > Network Connections > Properties NWA3550 User’s Guide...
Page 247: Figure 155 Windows Xp: Local Area Connection Properties
Appendix A Setting Up Your Computer’s IP Address 4 On the General tab, select Internet Protocol (TCP/IP) and then click Properties. Figure 155 Windows XP: Local Area Connection Properties 5 The Internet Protocol TCP/IP Properties window opens. NWA3550 User’s Guide...
Page 248: Figure 156 Windows Xp: Internet Protocol (Tcp/Ip) Properties
Appendix A Setting Up Your Computer’s IP Address Figure 156 Windows XP: Internet Protocol (TCP/IP) Properties 6 Select Obtain an IP address automatically if your network administrator or ISP assigns your IP address dynamically. Select Use the following IP Address and fill in the IP address, Subnet mask, and Default gateway fields if you have a static IP address that was assigned to you by your network administrator or ISP.
Page 249: Figure 157 Windows Vista: Start Menu
1 Click Start > Control Panel. Figure 157 Windows Vista: Start Menu 2 In the Control Panel, click the Network and Internet icon. Figure 158 Windows Vista: Control Panel 3 Click the Network and Sharing Center icon. Figure 159 Windows Vista: Network And Internet 4 Click Manage network connections.
Page 250: Figure 160 Windows Vista: Network And Sharing Center
Appendix A Setting Up Your Computer’s IP Address Figure 160 Windows Vista: Network and Sharing Center 5 Right-click Local Area Connection and then select Properties. Figure 161 Windows Vista: Network and Sharing Center During this procedure, click Continue whenever Windows displays a screen saying that it needs your permission to continue.
Page 251: Figure 162 Windows Vista: Local Area Connection Properties
Appendix A Setting Up Your Computer’s IP Address Figure 162 Windows Vista: Local Area Connection Properties 7 The Internet Protocol Version 4 (TCP/IPv4) Properties window opens. NWA3550 User’s Guide...
Page 252: Figure 163 Windows Vista: Internet Protocol Version 4 (Tcp/Ipv4) Properties
Appendix A Setting Up Your Computer’s IP Address Figure 163 Windows Vista: Internet Protocol Version 4 (TCP/IPv4) Properties 8 Select Obtain an IP address automatically if your network administrator or ISP assigns your IP address dynamically. Select Use the following IP Address and fill in the IP address, Subnet mask, and Default gateway fields if you have a static IP address that was assigned to you by your network administrator or ISP.
Page 253: Figure 164 Mac Os X 10.4: Apple Menu
1 Click Apple > System Preferences. Figure 164 Mac OS X 10.4: Apple Menu 2 In the System Preferences window, click the Network icon. Figure 165 Mac OS X 10.4: System Preferences 3 When the Network preferences pane opens, select Built-in Ethernet from the network connection type list, and then click Configure.
Page 254: Figure 166 Mac Os X 10.4: Network Preferences
Appendix A Setting Up Your Computer’s IP Address Figure 166 Mac OS X 10.4: Network Preferences 4 For dynamically assigned settings, select Using DHCP from the Configure IPv4 list in the TCP/IP tab. Figure 167 Mac OS X 10.4: Network Preferences > TCP/IP Tab. 5 For statically assigned settings, do the following: •...
Page 255: Figure 168 Mac Os X 10.4: Network Preferences > Ethernet
• In the Subnet Mask field, type your subnet mask. • In the Router field, type the IP address of your device. Figure 168 Mac OS X 10.4: Network Preferences > Ethernet 6 Click Apply Now and close the window. Verifying Settings Check your TCP/IP properties by clicking Applications >...
Page 256: Figure 170 Mac Os X 10.5: Apple Menu
Appendix A Setting Up Your Computer’s IP Address Mac OS X: 10.5 The screens in this section are from Mac OS X 10.5. 1 Click Apple > System Preferences. Figure 170 Mac OS X 10.5: Apple Menu 2 In System Preferences, click the Network icon. Figure 171 Mac OS X 10.5: Systems Preferences 3 When the Network preferences pane opens, select Ethernet from the list of available connection types.
Page 257: Figure 172 Mac Os X 10.5: Network Preferences > Ethernet
Figure 172 Mac OS X 10.5: Network Preferences > Ethernet 4 From the Configure list, select Using DHCP for dynamically assigned settings. 5 For statically assigned settings, do the following: • From the Configure list, select Manually. • In the IP Address field, enter your IP address. •...
Page 258: Figure 173 Mac Os X 10.5: Network Preferences > Ethernet
Appendix A Setting Up Your Computer’s IP Address Figure 173 Mac OS X 10.5: Network Preferences > Ethernet 6 Click Apply and close the window. Verifying Settings Check your TCP/IP properties by clicking Applications > Utilities > Network Utilities, and then selecting the appropriate Network interface from the Info tab.
Page 259: Figure 175 Ubuntu 8: System > Administration Menu
Linux: Ubuntu 8 (GNOME) This section shows you how to configure your computer’s TCP/IP settings in the GNU Object Model Environment (GNOME) using the Ubuntu 8 Linux distribution. The procedure, screens and file locations may vary depending on your specific distribution, release version, and individual configuration.
Page 260: Figure 177 Ubuntu 8: Administrator Account Authentication
Appendix A Setting Up Your Computer’s IP Address 3 In the Authenticate window, enter your admin account name and password then click the Authenticate button. Figure 177 Ubuntu 8: Administrator Account Authentication 4 In the Network Settings window, select the connection that you want to configure, then click Properties.
Page 261: Figure 179 Ubuntu 8: Network Settings > Properties
Figure 179 Ubuntu 8: Network Settings > Properties • In the Configuration list, select Automatic Configuration (DHCP) if you have a dynamic IP address. • In the Configuration list, select Static IP address if you have a static IP address. Fill in the IP address, Subnet mask, and Gateway address fields.
Page 262: Figure 181 Ubuntu 8: Network Tools
Appendix A Setting Up Your Computer’s IP Address Verifying Settings Check your TCP/IP properties by clicking System > Administration > Network Tools, and then selecting the appropriate Network device from the Devices tab. The Interface Statistics column shows data if your connection is working properly. Figure 181 Ubuntu 8: Network Tools Linux: openSUSE 10.3 (KDE) This section shows you how to configure your computer’s TCP/IP settings in the K Desktop...
Page 263: Figure 182 Opensuse 10.3: K Menu > Computer Menu
Make sure you are logged in as the root administrator. Follow the steps below to configure your computer IP address in the KDE: 1 Click K Menu > Computer > Administrator Settings (YaST). Figure 182 openSUSE 10.3: K Menu > Computer Menu 2 When the Run as Root - KDE su dialog opens, enter the admin password and click OK.
Page 264: Figure 184 Opensuse 10.3: Yast Control Center
Appendix A Setting Up Your Computer’s IP Address Figure 184 openSUSE 10.3: YaST Control Center 4 When the Network Settings window opens, click the Overview tab, select the appropriate connection Name from the list, and then click the Configure button. Figure 185 openSUSE 10.3: Network Settings 5 When the Network Card Setup window opens, click the Address tab NWA3550 User’s Guide...
Page 265: Figure 186 Opensuse 10.3: Network Card Setup
Figure 186 openSUSE 10.3: Network Card Setup 6 Select Dynamic Address (DHCP) if you have a dynamic IP address. Select Statically assigned IP Address if you have a static IP address. Fill in the IP address, Subnet mask, and Hostname fields. 7 Click Next to save the changes and close the Network Card Setup window.
Page 266: Figure 187 Opensuse 10.3: Network Settings
Appendix A Setting Up Your Computer’s IP Address Figure 187 openSUSE 10.3: Network Settings 9 Click Finish to save your settings and close the window. Verifying Settings Click the KNetwork Manager icon on the Task bar to check your TCP/IP properties. From the Options sub-menu, select Show Connection Information.
Page 267: Figure 189 Opensuse: Connection Status - Knetwork Manager
Appendix A Setting Up Your Computer’s IP Address Figure 189 openSUSE: Connection Status - KNetwork Manager NWA3550 User’s Guide...
Page 268 Appendix A Setting Up Your Computer’s IP Address NWA3550 User’s Guide...
Page 269: Appendix B Wireless Lans
P P E N D I X Wireless LAN Topologies This section discusses ad-hoc and infrastructure wireless LAN topologies. Ad-hoc Wireless LAN Configuration The simplest WLAN configuration is an independent (Ad-hoc) WLAN that connects a set of computers with wireless adapters (A, B, C). Any time two or more wireless adapters are within range of each other, they can set up an independent network, which is commonly referred to as an ad-hoc network or Independent Basic Service Set (IBSS).
Page 270: Figure 191 Basic Service Set
Appendix B Wireless LANs Figure 191 Basic Service Set An Extended Service Set (ESS) consists of a series of overlapping BSSs, each containing an access point, with each access point connected together by a wired network. This wired connection between APs is called a Distribution System (DS). This type of wireless LAN topology is called an Infrastructure WLAN.
Page 271: Figure 192 Infrastructure Wlan
Figure 192 Infrastructure WLAN Channel A channel is the radio frequency(ies) used by IEEE 802.11a/b/g wireless devices. Channels available depend on your geographical area. You may have a choice of channels (for your region) so you should use a different channel than an adjacent AP (access point) to reduce interference.
Page 272: Figure 193 Rts/Cts
Appendix B Wireless LANs Figure 193 RTS/CTS When station A sends data to the AP, it might not know that the station B is already using the channel. If these two stations send data at the same time, collisions may occur when both sets of data arrive at the AP at the same time, resulting in a loss of messages for both stations.
Page 273: Table 85 Ieee 802.11G
If the Fragmentation Threshold value is smaller than the RTS/CTS value (see previously) you set then the RTS (Request To Send)/CTS (Clear to Send) handshake will never occur as data frames will be fragmented before they reach RTS/CTS size. Preamble Type Preamble is used to signal that data is coming to the receiver.
Page 274: Table 86 Wireless Security Levels
Appendix B Wireless LANs Wireless security methods available on the ZyXEL Device are data encryption, wireless client authentication, restricting access by device MAC address and hiding the ZyXEL Device identity. The following figure shows the relative effectiveness of these wireless security methods available on your ZyXEL Device.
Page 275: Types Of Radius Messages
Determines the network services available to authenticated users once they are connected to the network. • Accounting Keeps track of the client’s network activity. RADIUS is a simple package exchange in which your AP acts as a message relay between the wireless client and the network RADIUS server.
Page 276 Appendix B Wireless LANs For EAP-TLS authentication type, you must first have a wired connection to the network and obtain the certificate(s) from a certificate authority (CA). A certificate (also called digital IDs) can be used to authenticate users and a CA issues certificates and guarantees the identity of each certificate owner.
Page 277: Table 87 Comparison Of Eap Authentication Types
Dynamic WEP Key Exchange The AP maps a unique key that is generated with the RADIUS server. This key expires when the wireless connection times out, disconnects or reauthentication times out. A new WEP key is generated each time reauthentication is performed. If this feature is enabled, it is not necessary to configure a default encryption key in the Wireless screen.
Page 278 Appendix B Wireless LANs Encryption Both WPA and WPA2 improve data encryption by using Temporal Key Integrity Protocol (TKIP), Message Integrity Check (MIC) and IEEE 802.1x. WPA and WPA2 use Advanced Encryption Standard (AES) in the Counter mode with Cipher block chaining Message authentication code Protocol (CCMP) to offer stronger encryption than TKIP.
Page 279: Wireless Client Wpa Supplicants
Wireless Client WPA Supplicants A wireless client supplicant is the software that runs on an operating system instructing the wireless client how to use WPA. At the time of writing, the most widely available supplicant is the WPA patch for Windows XP, Funk Software's Odyssey client. The Windows XP patch is a free download that adds WPA capability to Windows XP's built-in "Zero Configuration"...
Page 280: Figure 195 Wpa(2)-Psk Authentication
Appendix B Wireless LANs 4 The AP and wireless clients use the TKIP or AES encryption process to encrypt data exchanged between them. Figure 195 WPA(2)-PSK Authentication Security Parameters Summary Refer to this table to see what other security parameters you should configure for each Authentication Method/ key management protocol type.
Page 281: Antenna Characteristics
Positioning the antennas properly increases the range and coverage area of a wireless LAN. Antenna Characteristics Frequency An antenna in the frequency of 2.4GHz (IEEE 802.11b) or 5GHz(IEEE 802.11a) is needed to communicate efficiently in a wireless LAN. Radiation Pattern A radiation pattern is a diagram that allows you to visualize the shape of the antenna’s coverage area.
Page 282 Appendix B Wireless LANs For omni-directional antennas mounted on a table, desk, and so on, point the antenna up. For omni-directional antennas mounted on a wall or ceiling, point the antenna down. For a single AP application, place omni-directional antennas as close to the center of the coverage area as possible.
Page 283: Appendix C Pop-Up Windows, Javascripts And Java Permissions
P P E N D I X Pop-up Windows, JavaScripts and Java Permissions In order to use the web configurator you need to allow: • Web browser pop-up windows from your device. • JavaScripts (enabled by default). • Java permissions (enabled by default). Internet Explorer 6 screens are used here.
Page 284: Figure 197 Internet Options: Privacy
Appendix C Pop-up Windows, JavaScripts and Java Permissions 2 Clear the Block pop-ups check box in the Pop-up Blocker section of the screen. This disables any web pop-up blockers you may have enabled. Figure 197 Internet Options: Privacy 3 Click Apply to save this setting. Enable pop-up Blockers with Exceptions Alternatively, if you only want to allow pop-up windows from your device, see the following steps.
Page 285: Figure 198 Internet Options: Privacy
Figure 198 Internet Options: Privacy 3 Type the IP address of your device (the web page that you do not want to have blocked) with the prefix “http://”. For example, http://192.168.167.1. 4 Click Add to move the IP address to the list of Allowed sites. Figure 199 Pop-up Blocker Settings NWA3550 User’s Guide Appendix C Pop-up Windows, JavaScripts and Java Permissions...
Page 286: Figure 200 Internet Options: Security
Appendix C Pop-up Windows, JavaScripts and Java Permissions 5 Click Close to return to the Privacy screen. 6 Click Apply to save this setting. JavaScripts If pages of the web configurator do not display properly in Internet Explorer, check that JavaScripts are allowed.
Page 287: Figure 201 Security Settings - Java Scripting
Figure 201 Security Settings - Java Scripting Java Permissions 1 From Internet Explorer, click Tools, Internet Options and then the Security tab. 2 Click the Custom Level... button. 3 Scroll down to Microsoft VM. 4 Under Java permissions make sure that a safety level is selected. 5 Click OK to close the window.
Page 288: Figure 203 Java (Sun)
Appendix C Pop-up Windows, JavaScripts and Java Permissions JAVA (Sun) 1 From Internet Explorer, click Tools, Internet Options and then the Advanced tab. 2 Make sure that Use Java 2 for <applet> under Java (Sun) is selected. 3 Click OK to close the window. Figure 203 Java (Sun) NWA3550 User’s Guide...
Page 289: Appendix D Importing Certificates
P P E N D I X Importing Certificates This appendix shows you how to import public key certificates into your web browser. Public key certificates are used by web browsers to ensure that a secure web site is legitimate. When a certificate authority such as VeriSign, Comodo, or Network Solutions, to name a few, receives a certificate request from a website operator, they confirm that the web domain and contact information in the request match those on public record with a domain name registrar.
Page 290: Figure 204 Internet Explorer 7: Certification Error
Appendix D Importing Certificates Figure 204 Internet Explorer 7: Certification Error 2 Click Continue to this website (not recommended). Figure 205 Internet Explorer 7: Certification Error 3 In the Address Bar, click Certificate Error > View certificates. Figure 206 Internet Explorer 7: Certificate Error 4 In the Certificate dialog box, click Install Certificate.
Page 291: Figure 207 Internet Explorer 7: Certificate
Figure 207 Internet Explorer 7: Certificate 5 In the Certificate Import Wizard, click Next. Figure 208 Internet Explorer 7: Certificate Import Wizard 6 If you want Internet Explorer to Automatically select certificate store based on the type of certificate, click Next again and then go to step 9. NWA3550 User’s Guide Appendix D Importing Certificates...
Page 292: Figure 209 Internet Explorer 7: Certificate Import Wizard
Appendix D Importing Certificates Figure 209 Internet Explorer 7: Certificate Import Wizard 7 Otherwise, select Place all certificates in the following store and then click Browse. Figure 210 Internet Explorer 7: Certificate Import Wizard 8 In the Select Certificate Store dialog box, choose a location in which to save the certificate and then click OK.
Page 293: Figure 212 Internet Explorer 7: Certificate Import Wizard
Figure 212 Internet Explorer 7: Certificate Import Wizard 10 If you are presented with another Security Warning, click Yes. Figure 213 Internet Explorer 7: Security Warning 11 Finally, click OK when presented with the successful certificate installation message. Figure 214 Internet Explorer 7: Certificate Import Wizard NWA3550 User’s Guide Appendix D Importing Certificates...
Page 294: Figure 215 Internet Explorer 7: Website Identification
Appendix D Importing Certificates 12 The next time you start Internet Explorer and go to a ZyXEL web configurator page, a sealed padlock icon appears in the address bar. Click it to view the page’s Website Identification information. Figure 215 Internet Explorer 7: Website Identification Installing a Stand-Alone Certificate File in Internet Explorer Rather than browsing to a ZyXEL web configurator and installing a public key certificate when prompted, you can install a stand-alone certificate file if one has been issued to you.
Page 295: Figure 217 Internet Explorer 7: Open File - Security Warning
Figure 217 Internet Explorer 7: Open File - Security Warning 3 Refer to steps 4-12 in the Internet Explorer procedure beginning on complete the installation process. Removing a Certificate in Internet Explorer This section shows you how to remove a public key certificate in Internet Explorer 7. 1 Open Internet Explorer and click Tools >...
Page 296: Figure 219 Internet Explorer 7: Internet Options
Appendix D Importing Certificates Figure 219 Internet Explorer 7: Internet Options 3 In the Certificates dialog box, click the Trusted Root Certificates Authorities tab, select the certificate that you want to delete, and then click Remove. Figure 220 Internet Explorer 7: Certificates 4 In the Certificates confirmation, click Yes.
Page 297: Figure 221 Internet Explorer 7: Certificates
Figure 221 Internet Explorer 7: Certificates 5 In the Root Certificate Store dialog box, click Yes. Figure 222 Internet Explorer 7: Root Certificate Store 6 The next time you go to the web site that issued the public key certificate you just removed, a certification error appears.
Page 298: Figure 224 Firefox 2: Page Info
Appendix D Importing Certificates 3 The certificate is stored and you can now connect securely to the web configurator. A sealed padlock appears in the address bar, which you can click to open the Page Info > Security window to view the web page’s security information. Figure 224 Firefox 2: Page Info Installing a Stand-Alone Certificate File in Firefox Rather than browsing to a ZyXEL web configurator and installing a public key certificate...
Page 299: Figure 226 Firefox 2: Options
Figure 226 Firefox 2: Options 3 In the Certificate Manager dialog box, click Web Sites > Import Figure 227 Firefox 2: Certificate Manager 4 Use the Select File dialog box to locate the certificate and then click Open. NWA3550 User’s Guide Appendix D Importing Certificates...
Page 300: Figure 228 Firefox 2: Select File
Appendix D Importing Certificates Figure 228 Firefox 2: Select File 5 The next time you visit the web site, click the padlock in the address bar to open the Page Info > Security window to see the web page’s security information. Removing a Certificate in Firefox This section shows you how to remove a public key certificate in Firefox 2.
Page 301: Figure 230 Firefox 2: Options
Figure 230 Firefox 2: Options 3 In the Certificate Manager dialog box, select the Web Sites tab, select the certificate that you want to remove, and then click Delete. Figure 231 Firefox 2: Certificate Manager 4 In the Delete Web Site Certificates dialog box, click OK. NWA3550 User’s Guide Appendix D Importing Certificates...
Page 302: Figure 232 Firefox 2: Delete Web Site Certificates
Appendix D Importing Certificates Figure 232 Firefox 2: Delete Web Site Certificates 5 The next time you go to the web site that issued the public key certificate you just removed, a certification error appears. Opera The following example uses Opera 9 on Windows XP Professional; however, the screens can apply to Opera 9 on all platforms.
Page 303: Figure 234 Opera 9: Security Information
Figure 234 Opera 9: Security information Installing a Stand-Alone Certificate File in Opera Rather than browsing to a ZyXEL web configurator and installing a public key certificate when prompted, you can install a stand-alone certificate file if one has been issued to you. 1 Open Opera and click Tools >...
Page 304: Figure 236 Opera 9: Preferences
Appendix D Importing Certificates Figure 236 Opera 9: Preferences 3 In the Certificates Manager, click Authorities > Import. Figure 237 Opera 9: Certificate manager NWA3550 User’s Guide...
Page 305: Figure 238 Opera 9: Import Certificate
4 Use the Import certificate dialog box to locate the certificate and then click Open. Figure 238 Opera 9: Import certificate 5 In the Install authority certificate dialog box, click Install. Figure 239 Opera 9: Install authority certificate 6 Next, click OK. NWA3550 User’s Guide Appendix D Importing Certificates...
Page 306: Figure 240 Opera 9: Install Authority Certificate
Appendix D Importing Certificates Figure 240 Opera 9: Install authority certificate 7 The next time you visit the web site, click the padlock in the address bar to open the Security information window to view the web page’s security details. Removing a Certificate in Opera This section shows you how to remove a public key certificate in Opera 9.
Page 307: Figure 242 Opera 9: Preferences
Appendix D Importing Certificates Figure 242 Opera 9: Preferences 3 In the Certificates manager, select the Authorities tab, select the certificate that you want to remove, and then click Delete. NWA3550 User’s Guide...
Page 308: Figure 243 Opera 9: Certificate Manager
Appendix D Importing Certificates Figure 243 Opera 9: Certificate manager 4 The next time you go to the web site that issued the public key certificate you just removed, a certification error appears. There is no confirmation when you delete a certificate authority, so be absolutely certain that you want to go through with it before clicking the button.
Page 309: Figure 244 Konqueror 3.5: Server Authentication
Figure 244 Konqueror 3.5: Server Authentication 3 Click Forever when prompted to accept the certificate. Figure 245 Konqueror 3.5: Server Authentication 4 Click the padlock in the address bar to open the KDE SSL Information window and view the web page’s security details. Figure 246 Konqueror 3.5: KDE SSL Information Installing a Stand-Alone Certificate File in Konqueror Rather than browsing to a ZyXEL web configurator and installing a public key certificate...
Page 310: Figure 247 Konqueror 3.5: Public Key Certificate File
Appendix D Importing Certificates Figure 247 Konqueror 3.5: Public Key Certificate File 2 In the Certificate Import Result - Kleopatra dialog box, click OK. Figure 248 Konqueror 3.5: Certificate Import Result The public key certificate appears in the KDE certificate manager, Kleopatra. Figure 249 Konqueror 3.5: Kleopatra 3 The next time you visit the web site, click the padlock in the address bar to open the KDE SSL Information window to view the web page’s security details.
Page 311: Figure 250 Konqueror 3.5: Settings Menu
Figure 250 Konqueror 3.5: Settings Menu 2 In the Configure dialog box, select Crypto. 3 On the Peer SSL Certificates tab, select the certificate you want to delete and then click Remove. Figure 251 Konqueror 3.5: Configure 4 The next time you go to the web site that issued the public key certificate you just removed, a certification error appears.
Page 312 Appendix D Importing Certificates NWA3550 User’s Guide...
Page 313: Appendix E Ip Addresses And Subnetting
P P E N D I X IP Addresses and Subnetting This appendix introduces IP addresses and subnet masks. IP addresses identify individual devices on a network. Every networking device (including computers, servers, routers, printers, etc.) needs an IP address to communicate across the network.
Page 314: Figure 252 Network Number And Host Id
Appendix E IP Addresses and Subnetting Figure 252 Network Number and Host ID How much of the IP address is the network number and how much is the host ID varies according to the subnet mask. Subnet Masks A subnet mask is used to determine which bits are part of the network number, and which bits are part of the host ID (using a logical AND operation).
Page 315: Table 90 Subnet Masks
Subnet masks are expressed in dotted decimal notation just like IP addresses. The following examples show the binary and decimal notation for 8-bit, 16-bit, 24-bit and 29-bit subnet masks. Table 90 Subnet Masks BINARY OCTET 8-bit mask 11111111 16-bit mask 11111111 24-bit mask 11111111...
Page 316: Figure 253 Subnetting Example: Before Subnetting
Appendix E IP Addresses and Subnetting Table 92 Alternative Subnet Mask Notation (continued) SUBNET MASK 255.255.255.192 255.255.255.224 255.255.255.240 255.255.255.248 255.255.255.252 Subnetting You can use subnetting to divide one network into multiple sub-networks. In the following example a network administrator creates two sub-networks to isolate a group of servers from the rest of the company network for security reasons.
Page 317: Figure 254 Subnetting Example: After Subnetting
Figure 254 Subnetting Example: After Subnetting In a 25-bit subnet the host ID has 7 bits, so each sub-network has a maximum of 2 possible hosts (a host ID of all zeroes is the subnet’s address itself, all ones is the subnet’s broadcast address).
Page 318: Table 94 Subnet 2
Appendix E IP Addresses and Subnetting Table 94 Subnet 2 IP/SUBNET MASK IP Address IP Address (Binary) Subnet Mask (Binary) Subnet Address: 192.168.1.64 Broadcast Address: 192.168.1.127 Table 95 Subnet 3 IP/SUBNET MASK IP Address IP Address (Binary) Subnet Mask (Binary) Subnet Address: 192.168.1.128 Broadcast Address:...
Page 319: Table 98 24-Bit Network Number Subnet Planning
Table 97 Eight Subnets (continued) SUBNET SUBNET ADDRESS Subnet Planning The following table is a summary for subnet planning on a network with a 24-bit network number. Table 98 24-bit Network Number Subnet Planning NO. “BORROWED” HOST BITS The following table is a summary for subnet planning on a network with a 16-bit network number.
Page 320: Private Ip Addresses
Appendix E IP Addresses and Subnetting Table 99 16-bit Network Number Subnet Planning (continued) NO. “BORROWED” HOST BITS Configuring IP Addresses Where you obtain your network number depends on your particular situation. If the ISP or your network administrator assigns you a block of registered IP addresses, follow their instructions in selecting the IP addresses and the subnet mask.
Page 321: Appendix F Text File Based Auto Configuration
P P E N D I X This chapter describes how administrators can use text configuration files to configure the wireless LAN settings for multiple APs. Text File Based Auto Configuration Overview You can use plain text configuration files to configure the wireless LAN settings on multiple APs.
Page 322: Table 100 Auto Configuration By Dhcp
Appendix F Text File Based Auto Configuration If adjacent APs use the same configuration file, you should leave out the channel setting since they could interfere with each other’s wireless traffic. Auto Configuration by DHCP A DHCP response can use options 66 and 67 to assign a TFTP server IP address and a filename.
Page 323: Figure 256 Configuration File Format
Use the following procedure to have the AP download the configuration file. Table 102 Configuration via SNMP STEPS MIB VARIABLE Step 1 pwTftpServer Step 2 pwTftpFileName Step 3 pwTftpFileType Step 4 pwTftpOpCommand Verifying Your Configuration File Upload Via SNMP You can use SNMP management software to display the configuration file version currently on the device by using the following MIB.
Page 324: Figure 257 Wep Configuration File Example
Appendix F Text File Based Auto Configuration Configuration File Rules You can only use the other ZyNOS commands but continues to check the next command. The AP ignores any improperly formatted commands and continues to check the next line. If there are any errors while processing the configuration file, the AP generates a message with the line number and reason for the first error (subsequent errors during the processing of an individual configuration file are not recorded).
Page 325: Figure 258 802.1X Configuration File Example
Figure 258 802.1X Configuration File Example !#ZYXEL PROWLAN !#VERSION 12 wcfg security 2 name Test-8021x wcfg security 2 mode wcfg security 2 wep key1 abcdefghijklm wcfg security 2 wep key2 bcdefghijklmn wcfg security 2 wep keyindex 1 wcfg security 2 reauthtime 1800 wcfg security 2 idletime 3600 wcfg security save wcfg radius 2 name radius-rd...
Page 326: Figure 260 Wpa Configuration File Example
Appendix F Text File Based Auto Configuration Figure 260 WPA Configuration File Example !#ZYXEL PROWLAN !#VERSION 14 wcfg security 4 name Test-wpa wcfg security 4 mode wpa wcfg security 4 reauthtime 1800 wcfg security 4 idletime 3600 wcfg security 4 groupkeytime 1800 wcfg security save wcfg radius 4 name radius-rd1 wcfg radius 4 primary 172.0.20.38 1812 20 enable...
Page 327: Figure 261 Wlan Configuration File Example
Appendix F Text File Based Auto Configuration Figure 261 Wlan Configuration File Example !#ZYXEL PROWLAN !#VERSION 15 wcfg ssid 1 name ssid-wep wcfg ssid 1 security Test-wep wcfg ssid 2 name ssid-8021x wcfg ssid 2 security Test-8021x wcfg ssid 2 radius radius-rd wcfg ssid 3 name ssid-wpapsk wcfg ssid 3 security Test-wpapsk wcfg ssid 4 name ssid-wpa2psk...
Page 328 Appendix F Text File Based Auto Configuration NWA3550 User’s Guide...
Page 330 Appendix G Legal Information If this device does cause harmful interference to radio/television reception, which can be determined by turning the device off and on, the user is encouraged to try to correct the interference by one or more of the following measures: 1 Reorient or relocate the receiving antenna.
Page 331: Zyxel Limited Warranty
Viewing Certifications 1 Go to http://www.zyxel.com. 2 Select your product on the ZyXEL home page to go to that product's page. 3 Select the certification you wish to view from this page. ZyXEL Limited Warranty ZyXEL warrants to the original end user (purchaser) that this product is free from any defects in materials or workmanship for a period of up to two years from the date of purchase.
Page 332 Appendix G Legal Information NWA3550 User’s Guide...
Page 333: Appendix H Customer Support
• Sales E-mail: sales@zyxel.com.tw • Telephone: +886-3-578-3942 • Fax: +886-3-578-2439 • Web: www.zyxel.com • Regular Mail: ZyXEL Communications Corp., 6 Innovation Road II, Science Park, Hsinchu 300, Taiwan China - ZyXEL Communications (Beijing) Corp. • Support E-mail: cso.zycn@zyxel.cn • Sales E-mail: sales@zyxel.cn •...
Page 334 Czech Republic • E-mail: info@cz.zyxel.com • Telephone: +420-241-091-350 • Fax: +420-241-091-359 • Web: www.zyxel.cz • Regular Mail: ZyXEL Communications, Czech s.r.o., Modranská 621, 143 01 Praha 4 - Modrany, Ceská Republika Denmark • Support E-mail: support@zyxel.dk • Sales E-mail: sales@zyxel.dk •...
Page 335 Germany • Support E-mail: support@zyxel.de • Sales E-mail: sales@zyxel.de • Telephone: +49-2405-6909-69 • Fax: +49-2405-6909-99 • Web: www.zyxel.de • Regular Mail: ZyXEL Deutschland GmbH., Adenauerstr. 20/A2 D-52146, Wuerselen, Germany Hungary • Support E-mail: support@zyxel.hu • Sales E-mail: info@zyxel.hu • Telephone: +36-1-3361649 •...
Page 336 • Support Telephone: +1-800-978-7222 • Sales E-mail: sales@zyxel.com • Sales Telephone: +1-714-632-0882 • Fax: +1-714-632-0858 • Web: www.zyxel.com • Regular Mail: ZyXEL Communications Inc., 1130 N. Miller St., Anaheim, CA 92806- 2001, U.S.A. Norway • Support E-mail: support@zyxel.no • Sales E-mail: sales@zyxel.no •...
Page 337 • Support E-mail: support@zyxel.es • Sales E-mail: sales@zyxel.es • Telephone: +34-902-195-420 • Fax: +34-913-005-345 • Web: www.zyxel.es • Regular Mail: ZyXEL Communications, Arte, 21 5ª planta, 28033 Madrid, Spain Sweden • Support E-mail: support@zyxel.se • Sales E-mail: sales@zyxel.se • Telephone: +46-31-744-7700 •...
