Overview This Quick Start Guide shows how to set up and configure the NWA3550 Access Point (marked AP in the figure) to allow wireless clients to securely access your wired network. See your User’s Guide for more information. You may need your Internet access information. This guide shows you how to: 1 Connect the Hardware 2 Access the Web Configurator...
1 Connect the Hardware 1 Use an Ethernet cable to connect the Ethernet port (opposite the power socket) on the included MS-POE-IJ power injector (A in the figure) to the NWA3550’s Ethernet port. 2 Use an Ethernet cable to connect the other Ethernet port (next to the power socket) to a computer for initial configuration.
Page 4
2 Access the Web Configurator Use Internet Explorer 6.0 and later or Netscape Navigator 7.0 and later versions with JavaScript enabled and pop-up blocking disabled. 2.1 Set Up Your Computer’s IP Address Note down your computer’s current IP settings before you change them. First, set your computer to use a static IP address in the 192.168.1.3 - 192.168.1.254 range with a subnet mask of 255.255.255.0.
Page 5
2 Click Login (the default password 1234 is already entered). 3 Change the login password by entering a new password and clicking Apply. Be sure to record the new password and keep it in a safe place. If you change the password and then forget it, you will need to reset the NWA3550.
ENGLISH 5 The STATUS screen appears. 3 Configure the NWA3550 3.1 Configure System Settings 1 Click SYSTEM in the navigation panel.
Page 7
2 The SYSTEM > General screen appears. System Name is for identifying the NWA3550 on your network. Choose a distinctive name, or leave this at its default. Domain Name: Enter a domain name if your ISP requires one for authentication. Otherwise you can leave it blank or set to whatever may have displayed automatically.
3.2 Configure Wireless Settings 1 Click WIRELESS in the navigation panel. The following screen appears. The wireless stations and the NWA3550 must use the same SSID, channel ID and encryption settings for wireless communication. WLAN Interface: Ensure that WLAN1 is selected. Operating Mode: Ensure that Access Point mode is selected.
Page 9
3 Click the SSID tab. The following screen appears. Ensure the settings for SSID03 are at their default values. The default SSID (the name of the network) is ZyXEL03, its default Security setting is Security01. Layer 2 Isolation and MAC Filter are set to Disable by default.
Page 10
5 This is where you can enter the security settings for your wireless network. The fields you fill in differ according to the type of security you select in the Security Mode field. Select None if you do not wish to use wireless security.
Page 11
3.3 Configure IP Settings 1 You need to set your NWA3550’s IP address to be in the same subnet as your network. Click IP in the navigation panel. Select Get automatically from DHCP if you want to have a DHCP server on your network assign an IP address to the NWA3550.
Page 12
If the NWA3550 cannot communicate with the network, ensure that the NWA3550 is using an IP address on the same subnet as the switch / router. 4 Install the Hardware Complete the following procedures to install the NWA3550 on a pole or wall. 4.1 Hardware Mounting In general, the best location for the access point is at the center of your intended wireless coverage area.
Page 13
4.1.2 Assembling the Mounting Bracket 1 Use one M8*110 screw, one M8 washer, one M8 spring washer and one M8 nut to attach the wall/pole bracket to the articulation bracket. 4.1.3 Pole Mounting 1 Align the mounting bracket with the holes on the rear of the NWA3550.
Page 14
3 Adjust the NWA3550, cables and antennas for correct orientation. 4.1.4 Wall-mounting 1 Select a position free of obstructions on a sturdy wall. 2 Position the wall/pole bracket on the wall to mark how far apart the screws should be placed.
Procedure to View a Product’s Certification(s) 1 Go to www.zyxel.com. 2 Select your product from the drop-down list box on the ZyXEL home page to go to that product's page. 3 Select the certification you wish to view from this page.
Übersicht In dieser Kurzanleitung erfahren Sie, wie der NWA3550 (im Beispiel unten mit einem AP gekennzeichnet) installiert und konfiguriert wird, damit Wireless-Clients sicher auf Ihr kabelgebundenes Netzwerk zugreifen können. Weitere Informationen finden Sie im Benutzerhandbuch. Halten Sie die Daten für Ihren Internetzugang bereit. In dieser Anleitung wird beschrieben, wie Sie Folgendes tun können: 1 Die Hardware anschließen.
Page 17
1 Anschließen der Hardware 1 Schließen Sie ein Ethernetkabel an den Ethernetanschluss (gegenüber dem Netzanschluss) des mitgelieferten MS-POE-IJ Power Injectors (in der Abbildung A) an den Ethernet-Anschluss des NWA3550 an. 2 Schließen Sie ein Ethernetkabel an den anderen Ethernetanschluss (neben dem Netzanschluss) für die Erstkonfiguration an einen Computer an.
Page 18
Wenn die LED nicht leuchtet, prüfen Sie die Kabelverbindungen, und stellen Sie sicher, dass das Kabel nicht beschädigt ist. Wenn die LED weiterhin nicht leuchtet, wenden Sie sich an Ihren Händler. 2 Zugreifen auf den Web-Konfigurator Verwenden Sie den Internet Explorer 6.0 oder den Netscape Navigator 7.0 und neuere Versionen davon mit aktiviertem JavaScript und aktivierter Pop- up-Funktion.
Page 19
Wenn Sie nicht auf den Web-Konfigurator zugreifen können, prüfen Sie, ob die IP-Adressen und Subnetz-Masken des NWA3550s und des Computers im selben IP-Adressbereich liegen (siehe Abschnitt 2.1). 2 Klicken Sie auf Login (Anmelden) (das Standardkennwort 1234 ist bereits vorgegeben). 3 Ändern Sie das Kennwort, indem Sie ein neues Kennwort eingeben und auf Apply (Übernehmen) klicken.
Page 20
4 Klicken Sie auf Apply (Übernehmen), um das werkseitig eingerichtete Standardzertifikat für zusätzliche Sicherheit zu ersetzen. Sie können jedoch auch auf Ignore (Ignorieren) klicken, wenn Sie das Zertifikat jetzt nicht ändern möchten. 5 Das STATUS-Fenster erscheint. 3 Konfigurieren des NWA3550s 3.1 Konfigurieren der Systemeinstellungen 1 Klicken Sie in der Navigationsleiste auf SYSTEM (System).
Page 21
2 Das Fenster SYSTEM > General (System > Allgemein) erscheint. Der System Name (Systemname) identifiziert den NWA3550 in Ihrem Netzwerk. Wählen Sie einen Namen oder belassen Sie diesen als Standard. Domain Name (Domainname): Geben Sie einen Domainnamen ein, wenn Ihr Internetdienstanbieter diesen für die Authentifizierung benötigt.
Page 22
3.2 Konfigurieren der Drahtloseinstellungen 1 Klicken Sie in der Navigationsleiste auf WIRELESS (Drahtlos). Das folgende Fenster erscheint. Die Drahtlosstationen und das NWA3550 müssen für die Drahtloskommunikation dieselbe SSID, dieselbe Kanal-ID und dieselben Verschlüsselungseinstellungen verwenden. WLAN Interface (WLAN-Schnittstelle): Wählen Sie die Option WLAN1. Operating Mode (Betriebsmodus): Wählen Sie als Betriebsmodus die Option Access Point.
Page 23
3 Klicken Sie auf die Registerkarte SSID. Das folgende Fenster erscheint. Wählen Sie bei SSID03 die Standardeinstellungen. Die Standard-SSID (der Name des Netzwerks) ist ZyXEL03, die Standardeinstellung bei Security (Sicherheit) ist Security01 (Sicherheit01). Layer 2 Isolation (Layer-2- Isolierung) und MAC Filter sind standardmäßig auf Disable (Deaktivieren) eingestellt.
Page 24
5 Hier können Sie die Sicherheitseinstellungen für Ihr Drahtlosnetzwerk eingeben. Je nachdem, welchen Sicherheitstyp Sie im Feld Security Mode (Sicherheitsmodus) wählen, werden andere Felder angezeigt. Wählen Sie None (Keine), wenn Sie keinen Sicherheitsmodus verwenden möchten. In diesem Beispiel wird der Sicherheitsmodus WPA2-PSK verwendet.
Page 25
DEUTSCH Wenn die Wireless-Clients nicht mit dem Netzwerk kommunizieren können, stellen Sie sicher, dass die Clients und das NWA3550 dieselben Sicherheitseinstellungen verwenden.
Page 26
DEUTSCH 3.3 Konfigurieren der IP-Einstellungen 1 Wählen Sie die IP-Adresse des NWA3550s so, dass sie im selben Subnetz liegt wie das Netzwerk. Klicken Sie in der Navigationsleiste auf IP. Wenn Sie möchten, dass ein DHCP-Server des Netzwerks dem NWA3550 eine IP-Adresse zuweist, wählen Sie Get automatically from DHCP (Automatisch vom DHCP...
Page 27
Wenn Sie die IP-Adresse des NWA3550s ändern, müssen Sie beim nächsten Zugriff auf den Web-Konfigurator die neue IP-Adresse verwenden. Wenn Sie Get automatically from DHCP (Automatisch vom DHCP beziehen) wählen, müssen Sie beim DHCP-Server nachsehen, welche IP-Adresse er dem NWA3550 zuweist. Weitere Informationen dazu finden Sie in der Dokumentation des DHCP-Servers.
Page 28
Sie benötigen folgendes: 1 Eine Wand-/Masthalterung 2 Eine Gelenkhalterung 3 Eine Mastbefestigungsschiene 4 Drei Schrauben M8*110 5 Drei Unterlegscheiben M8 6 Drei Federscheiben M8 4.1.2 Zusammensetzen der Montagehalterung 1 Befestigen Sie die Wand-/Masthalterung mit einer Schraube M8*110, einer Unterlegscheibe M8, einer Federscheibe M8 und einer Mutter M8 an der Gelenkhalterung.
Page 29
1 Richten Sie die Montagehalterung an den Löchern auf der Rückseite des NWA3550 aus. Führen Sie vier Schrauben M5*12 in die Löcher ein, und ziehen Sie die Schrauben und die Unterlegscheiben M5 mit einem Schraubenschlüssel fest. 2 Setzen Sie die Montagehalterung an einen Mast.
Page 30
Achten Sie beim Bohren der Löcher darauf, keine in der Wand verlegten Kabel oder Rohre zu beschädigen. 3 Führen Sie die Dübel in die Löcher. Die mitgelieferten Schrauben und Dübel sind in erster Linie für Betonwände vorgesehen. Besteht die Wand aus anderem Material, müssen Sie u. U. andere Schrauben und Dübel verwenden.
Page 31
Im Benutzerhandbuch finden Sie eine Liste aller kompatiblen Antennen. Schritte zum Ansehen von Produktzertifizierung(en) 1 Besuchen Sie www.zyxel.com. 2 Wählen Sie auf der ZyXEL-Homepage aus der Liste der Produkte Ihr Produkt aus. 3 Wählen Sie auf dieser die Zertifizierung aus, die Sie gerne angezeigt haben möchten. DEUTSCH...
Vista previa Esta Guía de instalación rápida le muestra cómo instalar y configurar el NWA3550 (marcado como AP en el ejemplo de abajo) para permitir a los clientes inalámbricos acceder de forma segura a su red inalámbrica. Vea su Guía del usuario para más información.
Page 33
1 Conectar el hardware 1 Utilice un cable Ethernet para conectar el puerto Ethernet (frente al zócalo de corriente) en el inyector de corriente MS-POE-IJ (A en la figura) al puerto Ethernet del NWA3550. 2 Utilice un cable Ethernet para conectar el otro puerto Ethernet (junto al zócalo de corriente) a un ordenador para la configuración inicial.
Page 34
Si el LED no se enciende, compruebe sus conexiones y verifique si los cables están dañados. Si el LED continúa apagado, contacte con su vendedor. 2 Acceder al Configurador Web Utilice Internet Explorer 6.0 o superior o Netscape Navigator 7.0 o una versión superior con JavaScript activado y el bloqueo de anuncios desactivado.
Page 35
Si no puede acceder al configurador Web, compruebe que las direcciones IP y máscaras de subred del NWA3550 y del ordenador estén en el mismo rango de dirección IP (ver Sección 2.1). 2 Haga clic en Login (Acceso) (la contraseña predeterminada 1234 ya está...
Page 36
4 Haga clic en Apply (Aplicar) para cambiar el certificado predeterminado de fábrica para mayor seguridad; por otro lado, haga clic en Ignore (Ignorar) para proceder si no desea cambiar el certificado en este momento. 5 Aparecerá la pantalla STATUS. 3 Configure el NWA3550 3.1 Ajustar la configuración del sistema 1 Haga clic en SYSTEM (SISTEMA) en el panel de navegación.
Page 37
2 Aparecerá la pantalla SYSTEM > General. System Name (Nombre del sistema) es para identificar el NWA3550 en su red. Elija un nombre identificativo o deje el predeterminado. Domain Name (Nombre de dominio): Escriba un nombre de dominio si su ISP requiere uno para la autenticación.
Page 38
3.2 Ajustar la configuración inalámbrica 1 Haga clic en WIRELESS (INALÁMBRICO) en el panel de navegación. Aparecerá la siguiente pantalla. Las estaciones inalámbricas y el NWA3550 deben utilizar la misma configuración SSID, ID de canal y cifrado para la comunicación inalámbrica.
Page 39
3 Haga clic en la ficha SSID. Aparecerá la siguiente pantalla. Asegúrese de que la configuración de SSID03 tenga sus valores predeterminados. El SSID (nombre de la red) predeterminado es ZyXEL03, su configuración de Security (Seguridad) predeterminada es Security01. Layer 2 Isolation (Aislamiento de capa 2) y MAC Filter (Filtro MAC) están...
Page 40
5 Aquí es donde puede introducir la configuración de seguridad para su red inalámbrica. Los campos que rellene se diferencian según el tipo de seguridad que seleccione en el campo Security Mode (Modo de seguridad). Seleccione None (Ninguno) si no desea utilizar la seguridad inalámbrica.
Page 41
Ajustar la configuración IP 1 Necesita configurar la dirección IP de su NWA3550 para que estén en la misma subred que su red. Haga clic en IP en el panel de navegación. Seleccione Get automatically from DHCP (Obtener automáticamente de DHCP) si desea que un servidor DHCP de su red asigne una dirección IP al NWA3550.
Page 42
El NWA3550 ya está listo para conectarse a su switch o router. Puede hacerlo ahora o una vez colocadas las antenas y montado el NWA3550. Si el NWA3550 no puede comunicarse con la red, compruebe que el NWA3550 utiliza una dirección IP en la misma subred que el switch / router. 4 Instalar el Hardware Complete los siguientes pasos para instalar el NWA3550 en un poste o en la pared.
Page 43
Necesita lo siguiente: 1 Un soporte para poste o pared 2 Un soporte articulado 3 Una barra de montaje en poste 4 Tres tornillos M8*110 5 Tres arandelas M8 6 Tres arandelas con muelle M8 4.1.2 Montar el soporte de montaje 1 Utilice un tornillo M8*110, una arandela M8, una arandela con muelle M8 y una tuerca M8 para colocar el soporte de pared o poste en el soporte articulado.
Page 44
1 Alinee el soporte de montaje con los agujeros de la parte trasera del NWA3550. Inserte cuatro tornillos M5*12 en los agujeros y utilice una llave para apretar los tornillos con las arandelas M5. 2 Coloque el soporte de montaje alrededor de un poste.
Page 45
Procure evitar dañar los tubos o cables situados en el interior de la pared al perforar los agujeros para los tornillos. 3 Inserte los conectores de obra en la pared. Los tornillos incluidos y los conectores de obra son para el uso con ciertas paredes.
Page 46
Procedimiento para ver la(s) certificación(es) del producto 1 Vaya a www.zyxel.com. 2 Seleccione su producto de la lista desplegable en la página inicial de ZyXEL para ir a la página de ese producto. 3 Seleccione la certificación que desee visualizar en esta página.
Présentation Ce guide de mise en route rapide indique comment installer et configurer le NWA3550 (marqué d'un AP dans l'exemple ci-dessous) pour permettre aux clients sans fil d’accéder en toute sécurité à votre réseau câblé. Consultez votre Guide de l'utilisateur pour plus d'informations.
1 Connecter le matériel 1 Utilisez un câble Ethernet pour connecter le port Ethernet (face à la prise d'alimentation) sur l'injecteur d'alimentation MS-POE-IJ inclus (A dans la figure) au port Ethernet du NWA3550. 2 Utilisez un câble Ethernet pour connecter l'autre port Ethernet (à côté de la prise d'alimentation) à...
Page 50
Si la LED ne s'allume pas, vérifiez vos connexions et vérifiez si vos câbles ne sont pas endommagés. Si la LED est toujours éteinte, contactez votre vendeur. 2 Accéder au configurateur Web. Utilisez Internet Explorer 6.0 et plus récent ou Netscape Navigator 7.0 et des versions plus récentes avec JavaScript activé...
Page 51
Si vous ne pouvez pas accéder au Configurateur Web, vérifiez que les adresses IP et les masques de sous-réseau du NWA3550 et de l’ordinateur sont dans la même plage d’adresse IP (voir la Section 2.1). 2 Cliquez sur Login (Ouvrir une session) (le mot de passe par défaut 1234 est déjà...
Page 52
4 Cliquez sur Apply (Appliquer) pour remplacer le certificat d'usine par défaut pour renforcer la sécurité ; vous pouvez aussi cliquer sur Ignore (Ignorer) pour continuer si vous ne voulez pas changer le certificat maintenant. 5 L’écran STATUS (ETAT) apparaît. 3 Configurer le NWA3550 3.1 Configurer les paramètres du système 1 Cliquez sur System (SYSTÈME) dans le panneau de navigation.
Page 53
2 L'écran System (SYSTÈME) >General (Général) apparaît. System Name (Nom du système) sert à identifier le NWA3550 sur votre réseau. Choisissez un nom distinctif, ou laissez celui-ci à sa valeur par défaut. Domain Name (Nom de domaine): Entrez un nom de domaine si votre FAI en demande un pour authentification.
Page 54
3.2 Configurer les paramètres sans fil 1 Cliquez sur WIRELESS (SANS FIL) dans le panneau de navigation. L’écran suivant apparaît. Les stations sans fil et le NWA3550 doivent utiliser le même SSID, ID de canal et paramètres de cryptage pour la communication sans fil. WLAN Interface (Interface WLAN): Vérifiez que WLAN1 est sélectionné.
Page 55
3 Cliquez sur l'onglet SSID. L’écran suivant apparaît. Le SSID03 (le nom du réseau) par défaut le SSID03 est ZyXEL03 et son paramètre de Security (Sécurité) par défaut est Security01 (Security01). Si les paramètres sont différent, ou si vous voulez changer le SSID, sélectionnez SSID03 et cliquez sur Edit (Editer) pour changer les...
Page 56
5 C'est l'endroit où vous pouvez enter les paramètres de sécurité pour votre réseau sans fil. Les champs que vous avez remplis diffèrent en fonction des types de sécurité que vous sélectionnez dans le champ Security Mode (Mode Sécurité). Sélectionnez None (Aucun) si vous ne voulez pas utiliser la sécurité...
Page 57
FRANÇAIS 3.3 Configurer les paramètres IP 1 Vous devez paramétrer l'adresse IP de votre NWA3550 afin qu'elle se trouve dans le même masque de sous-réseau que votre réseau. Cliquez sur IP dans le panneau de navigation. Sélectionnez Get automatically from DHCP (Obtenir automatiquement à...
Page 58
Si vous changez l’adresse IP du NWA3550, vous devrez utiliser la nouvelle adresse IP la prochaine fois que vous accéderez au configurateur web. Si vous sélectionnez Get automatically from DHCP (Obtenir automatiquement à partir de DHCP), consultez votre serveur DHCP pour déterminer l'adresse IP qu'il a attribuée au NWA3550. Consultez la documentation de votre serveur DHCP pour plus d'informations.
Page 59
Vous avez besoin des éléments suivants : 1 Un support mural/de mât 2 Un support d'articulation 3 Une barre de montage de mât 4 Trois vis M8*110 5 Trois rondelles M8 6 Trois rondelles frein M8 4.1.2 Assemblage du support de fixation 1 Utilisez une vis M8*110, une rondelle M8, une rondelle frein M8 et un écrou M8 pour fixer le support mural /de mât au support d'articulation.
Page 60
1 Alignez le support de fixation avec les trous situés au dos du NWA3550. Insérez quatre vis M5*12 dans les trous et à l'aide d'une clé serrez les vis avec les rondelles 2 Placez le support de fixation autour d'un mât.
Page 61
Faites attention à ne pas endommager les tuyaux ou les fils encastrés dans le mur lorsque vous percez les trous pour les vis. 3 Insérez les chevilles de maçonnerie dans le mur. Les vis et les chevilles de maçonnerie incluses sont destinées principalement à...
Page 62
1 Allez à www.zyxel.com. 2 Sélectionnez votre produit sur la liste du menu déroulant de la page d'accueil de ZyXEL pour accéder à la page de ce produit. 3 Sélectionnez la certification que vous désirez consulter dans cette page.
Cenni generali La presente guida introduttiva fornisce informazioni sull'impostazione e la configurazione di NWA3550 (contrassegnato AP nell'esempio sotto) per consentire ai clienti wireless di accedere in modo sicuro alla rete cablata. Consultare la propria Guida utente per ulteriori informazioni. È possibile che occorra reperire le informazioni sul proprio accesso a Internet.
1 Collegamento dell'hardware 1 Utilizzare un cavo Ethernet per collegare la porta Ethernet (opposta alla presa di alimentazione) sull'iniettore di alimentazione MS-POE-IJ incluso (A nella figura) alla porta Ethernet dell'NWA3550. 2 Utilizzare un cavo Ethernet per collegare l'altra porta Ethernet (accanto alla presa di alimentazione) a un computer per la configurazione iniziale.
Page 66
Se il LED non si accende, controllare i collegamenti e verificare l'eventuale presenza di danni sui cavi. Se il LED è ancora spento, rivolgersi al venditore. 2 Accedere allo strumento di configurazione Web Utilizzare Internet Explorer 6.0 o versione successiva oppure Netscape Navigator 7.0 o versione successiva con JavaScript abilitato e bloccaggio dei pop-up disabilitato.
Page 67
Se non è possibile accedere allo strumento di configurazione Web, verificare che gli indirizzi IP e le subnet mask di NWA3550 e del computer siano nel medesimo intervallo di indirizzi IP (vedere Sezione 2.1). 2 Fare clic su Login (Login) (la password predefinita 1234 è...
Page 68
4 Fare clic su Apply (applica) per sostituire il certificato predefinito di fabbrica per una maggiore sicurezza. In alternativa fare clic su Ignore (ignora) per procedere se non si desidera cambiare ora il certificato. 5 Viene visualizzata la schermata STATUS (stato). 3 Configurare NWA3550 3.1 Configura le impostazioni del sistema 1 Fare clic su SYSTEM (SISTEMA) nel pannello di navigazione.
Page 69
2 Appare la schermata SYSTEM (SISTEMA) > Genera (Generale). System Name (nome sistema) consente di identificare NWA3550 sulla rete. Scegliere un nome distintivo o lasciare quello predefinito. Domain Name (Nome dominio): immettere un nome di dominio se il proprio ISP ne richiede uno per l'autenticazione.
Page 70
Configura impostazioni Wireless 1 Fare clic su WIRELESS (WIRELESS) nel pannello di navigazione. Appaiono le schermate seguenti. Le stazioni wireless e NWA3550 devono utilizzare lo stesso SSID, ID di canale e impostazione di crittografia per consentire la comunicazione wireless. WLAN Interface (Interfaccia WLAN): Assicurarsi che sia selezionato WLAN1. Operating Mode (Modalità...
Page 71
ITALIANO 3 Selezionare la scheda SSID. Appaiono le schermate seguenti. Verificare che le impostazioni per SSID03 siano ai rispettivi valori predefiniti. Il SSID (il nome della rete) predefinito è ZyXEL03, l'impostazioni Security (sicurezza) predefinita è Security01. Layer 2 Isolation (isolamento Livello 2) e MAC Filter (filtro MAC) sono impostati su Disable...
Page 72
5 In questo campo è possibile immettere le impostazioni di sicurezza della rete wireless. I campi compilati variano a seconda del tipo di sicurezza selezionata nel campo Security Mode (Modalità di sicurezza). Selezionare None (Nessuno) se non si desidera utilizzare la sicurezza wireless.
Page 73
3.2 Configura impostazioni IP 1 È necessario impostare l'indirizzo IP di NWA3550 per essere nella stessa subnet della rete. Fare clic su IP nel pannello di navigazione. Selezionare Get automatically from DHCP (ottieni automaticamente da DHCP) per consentire a un server DHCP presente in rete di assegnare un indirizzo IP a NWA3550.
Page 74
Se NWA3550 non può comunicare con la rete, verificare che NWA3550 stia utilizzando un indirizzo IP sulla stessa subnet dello switch / router. 4 Installazione dell'hardware Completare le procedure seguenti per installare l'NWA3550 su un supporto o a parete. 4.1 Montaggio dell’hardware In generale, la posizione migliore per il punto di accesso è...
Page 75
1 Una staffa per parete/supporto 2 Una staffa di articolazione 3 Una barra di montaggio per supporto 4 Tre viti M8*110 5 Tre rondelle M8 6 Tre rondelle elastiche M8 4.1.2 Assemblaggio della staffa di montaggio 1 Utilizzare una vite M8*110, una rondella M8, una rondella elastica M8 e un dato M8 per attaccare la staffa da parete/supporto alla staffa di articolazione.
Page 76
2 Collocare la staffa di montaggio attorno al supporto. Allineare la barra di montaggio su supporto con i fori che si trovano sulla staffa per parete/supporto. Inserire due viti M8*110 nei fori e utilizzare una chiave per serrare le viti con le rondelle M8 e le rondelle elastiche M8.
Page 77
4 Allineare la staffa di montaggio con i fori che si trovano dietro l'NWA3550. Inserire quattro viti M5*12 nei fori e utilizzare una chiave per serrare le viti con le rondelle 5 Installare le quattro viti di montaggio a parete attraverso i fori sulla staffa per parete/supporto nei tasselli per fissare la staffa di montaggio sulla parete.
Page 78
Procedura per visualizzare le certificazioni di un prodotto 1 Aprire la pagina www.zyxel.com. 2 Selezionare il prodotto dall'elenco di riepilogo a discesa nella Home Page di ZyXEL per passare alla pagina del prodotto in questione. 3 Selezionare da questa pagina la certificazione che si desidera visualizzare.
Обзор В кратком руководстве пользователя будет рассказано, как подключить и настроить NWA3550 (помеченный AP в приведенном ниже примере) для безопасного доступа беспроводных клиентов к проводной сети. Обратитесь к полной версии руководства для получения дополнительной информации. Вам может понадобиться ваша информация для доступа к сети Интернет.
Page 81
1 Подключение оборудования 1 При помощи кабеля Ethernet подключите порт Ethernet (напротив, ввода питания) на поставляемом сетевом адаптере MS-POE-IJ (обозначен A на рисунке) к порту Ethernet NWA3550. 2 Чтобы получить возможность конфигурировать устройство подключите другой Ethernet-порт (рядом с разъемом питания) к компьютеру, используя соответствующий кабель.
Page 82
Если светодиод не загорается, проверьте надежность подключений и состояние шнура. Если индикатор все еще не горит, обратитесь в службу технической поддержки ZyXEL. 2 Доступ к веб-конфигуратору Используйте Internet Explorer версии 6.0 и выше или Netscape Navigator версии 7.0 и выше с активированным JavaScript и...
Page 83
3 Измените пароль входа в систему, введя новый, и нажмите на Apply (Применить). Запишите новый пароль и храните его в надежном месте. Если вы изменили пароль, а потом его забыли, то вам придется переустановить NWA3550. Oбратитесь в службу технической поддержки ZyXEL. РУССКИЙ...
Page 84
4 Щелкните на Apply (Применить), чтобы изменить заводскую установку сертификата для улучшения безопасности. Если вы не хотите изменять сертификат сейчас, щелкните на Ignore (Пропустить). 5 Появится окно STATUS (Состояние). 3 Конфигурирование NWA3550 3.1 Настройка системных параметров 1 Щелкните на SYSTEM (СИСТЕМА) на панели навигации. РУССКИЙ...
Page 85
РУССКИЙ 2 Появится окно SYSTEM (СИСТЕМА) > General (Общие). System Name (Системное имя) используется для идентификации NWA3550 в вашей сети. Введите необходимое имя устройства или оставьте предложенное по умолчанию. Domain Name (Имя домена): Введите имя домена, если ваш провайдер требует этого...
Page 86
3.2 Настройка параметров беспроводной сети 1 Щелкните на WIRELESS (БЕСПРОВОДНАЯ) на панели навигации. Появится следующее окно. Для успешного соединения беспроводная станция и NWA3550 должны иметь одинаковые SSID, идентификатор канала и настройки шифрования. WLAN Interface (выбор радиоинтерфейса): Убедитесь, что выбран WLAN1 (радиоинтерфейс...
Page 87
РУССКИЙ 3 Щелкните на вкладке SSID. Появится следующее окно. Убедитесь, что настройки SSID03 установлены в значения по умолчанию. В качестве SSID по умолчанию (имя сети) установлено ZyXEL03. Его настройкой Security (Безопасность) по умолчанию является Security01. По умолчанию параметры Layer 2 Isolation (Блокировка...
Page 88
РУССКИЙ 4 Щелкните на вкладке Security (Безопасность). Убедитесь, что выбрана Security01, и щелкните на Edit (Редактировать).
Page 89
РУССКИЙ 5 Здесь вы можете ввести настройки безопасности вашей беспроводной сети. Вносимые вами изменения в настройки должны соответствовать типу безопасности, выбранному в поле Security Mode (Режим безопасности). Выберите None (Нет), если вы не хотите использовать беспроводную безопасность. В этом примере используется...
Page 90
Если беспроводные клиенты не могут соединиться с сетью, убедитесь, что они используют одинаковые с NWA3550 настройки беспроводной безопасности. 3.3 Конфигурирование настроек IP 1 Вы должны установить на вашем NWA3550 IP-адрес с маской подсети вашей сети. Щелкните на IP на навигационной панели. Выберите...
Page 91
Если вы изменяете IP-адрес NWA3550, то следует использовать именно его для дальнейшего конфигурирования устройства. Если вы выбираете Get automatically from DHCP (Получать автоматически от DHCP), проверьте назначение DHCP-сервером IP-адреса для NWA3550. Дополнительные сведения приведены в документации к серверу DHCP. 2 Если вы изменили IP-адрес вашего компьютера в пункт 2.1, верните его к предыдущей...
Page 92
В комплект поставки NWA-3550 входят: 1 Один кронштейн для стены/стойки 2 Один поворотный кронштейн 3 Одна крепежная рейка для стойки 4 Три винта M8*110 5 Три шайбы M8 6 Три пружинные шайбы M8 4.1.2 Сборка крепежного кронштейна 1 Присоедините кронштейн для крепежа на стену/стойку к поворотному кронштейну...
Page 93
1 Совместите крепежный кронштейн с отверстиями на задней панели NWA3550. Вставьте четыре винта M5*12 в отверстия и затяните их ключом вместе с шайбами М5. 2 Разместите крепежный кронштейн на стойке. Совместите крепежную рейку стойки с отверстиями в кронштейне для стены/стойки. Вставьте четыре винта M8*110 в...
Page 94
Будьте внимательны: не повредите кабели и трубы внутри стены при просверливании отверстий. 3 Вставьте дюбеля в отверстия. Входящие в комплект поставки дюбеля и шурупы предназначены для использования в бетонных стенах. В зависимости от материала вашей стены вам могут понадобиться другие шурупы и дюбеля. 4 Совместите...
Page 95
Список совместимых антенн можно найти в руководстве пользователя. Процедура просмотра сертификата(сертификатов) продукта 1 Посетите сайт www.zyxel.ru. 2 Выберите ваш продукт из выпадающего списка на домашней странице ZyXEL и перейдите на его страницу. 3 Выберите на этой странице нужный вам сертификат. РУССКИЙ...
Översikt Denna snabbstartguide visar hur du installerar och konfigurerar NWA3550 (märkt AP i exemplet nedan) så att trådlösa klienter kan få åtkomst till ditt kabelnätverk på ett säkert sätt. Se bruksanvisningen för mer information. Eventuellt behöver ha tillgång till uppgifterna för din Internet uppkoppling. När du ska installera ditt trådlösa nätverk måste du: 1 Ansluta maskinvara.
1 Ansluta maskinvara 1 Använder en Ethernet-sladd för att ansluta Ethernet-porten (mittemot strömuttaget) på den medföljande MS-POE-IJ-ströminjektorn (A i figuren) till NWA3550:s Ethernet-port. 2 Använder en Ethernet-sladd för att ansluta den andra Ethernet-porten (bredvid strömuttaget) till en dator för initial konfiguration. 3 Anslut ströminjektorn till en lämplig strömkälla med den medföljande strömsladden.
Page 98
2 Få åtkomst till webbkonfigurator Använd Internet Explorer version 6.0 och senare eller Netscape Navigator version 7.0 och senare med JavaScript aktiverat och popup-blockering inaktiverad. 2.1 Ställa in datorns IP-adress Skriv ner datorns befintliga IP-inställningar innan du ändrar dem. Först måste du ställa in datorn att använda en statisk IP-adress i intervallet 192.168.1.3 - 192.168.1.254 och sätt subnetmask på...
Page 99
2 Klicka på Login (standardlösenordet 1234 är redan angivet). 3 Ändra inloggningslösenordet genom att ange ett nytt lösenord och klicka på Apply (verkställ). Var noga med att anteckna det nya lösenordet och att förvara det på ett säkert ställe. Om du ändrar lösenordet och sedan glömmer bort det, måste du återställa NWA3550.
Page 100
5 Skärmen STATUS visas. 3 Konfigurera NWA3550 3.1 Konfigurera systeminställningar 1 Klicka på SYSTEM i navigationspanelen. SVENSKA...
Page 101
Skärmbilden SYSTEM > General (system - allmänt) visas. System Name (systemnamn) identifierar NWA3550 i ditt nätverk. Välj ett beskrivande namn, eller låt standardnamnet stå kvar. Domain Name (domännamn): Ange ett domännamn om din Internet-leverantör (ISP) fordrar ett sådant för autentisering. I annat fall kan du låta detta vara tomt eller ställa in det på...
Page 102
3.2 Konfigurera trådlösa inställningar 1 Klicka på WIRELESS (trådlös) i navigationspanelen. Följande skärm visas. De trådlösa stationerna och NWA3550 måste använda samma SSID, kanal-ID och krypteringsinställningar för trådlös kommunikation. WLAN Interface (WLAN-gränssnittet): Kontrollera att WLAN1 är valt. Operating Mode (driftläge): Kontrollera att läget Access Point (accesspunkt) är valt. 802.11 Mode (802.11-läge): Välj den trådlösa standard som du vill att ditt nätverk ska använda.
Page 103
3 Klicka på fliken SSID. skärmbild Följande visas. Kontrollera att inställningarna för SSID03 har sina standardvärden. Standard-SSID (namnet på nätverket) är ZyXEL03, dess standardinställning för Security (säkerhet) är Security01. Layer 2 Isolation (lager 2- isolering) och MAC Filter är inställda på Disable (inaktivera) som standard.
Page 104
5 Här kan du ange säkerhetsinställningar för ditt trådlösa nätverk. Vilka fält du fyller i beror på vilken typ av säkerhet du valt i fältet Security Mode (säkerhetsläge). Välj None (inget) om du inte vill använda trådlös säkerhet. I detta exempel används säkerheten WPA2-PSK, enligt vilken alla trådlösa klienter måste använda...
Page 105
3.3 Konfigurera IP-inställningar 1 Du måste ställa in NWA3550s IP-adress på samma subnet som ditt nätverk. Klicka på IP i navigationspanelen. Välj Get automatically from DHCP (hämta automatiskt från DHCP) om du vill låta en DHCP- server i ditt nätverk tilldela en IP-adress till NWA3550.
Page 106
4 Installera maskinvaran Slutför följande procedurer för att installera NWA3550 på ett stativ eller en vägg. 4.1 Montera maskinvara I allmänhet ligger den bästa placeringen för åtkomstpunkten i centrum av det avsedda trådlösa täckningsområdet. För bättre prestanda, montera NWA3550 högt upp på en plats utan hindrande föremål.
Page 107
1 Använd en M8*110-skruv, en M8-bricka, en M8-fjäderbricka och en M8-mutter för att ansluta vägg/stativfästet till ledfästet. 4.1.3 Stativmontering 1 Passa in monteringsfästet med hålen baktill på NWA3550. Sätt in fyra M5*12- skruvar i hålen och använd en hylsnyckel för att dra åt skruvarna med M5-brickor. 2 Placera monteringsfästet runt ett stativ.
Page 108
3 Justera NWA3550, sladdar och antenner för rätt inriktning. 4.1.4 Väggmontering 1 Välj en plats utan hindrande föremål på en stadig vägg. 2 Placera vägg/stativfästet på väggen för att markera hur långt ifrån varandra skruvarna ska placeras. Borra fyra hål för tegelpluggarna. Se upp så...
Page 109
Procedur för att visa en produkts certifikat 1 Gå till www.zyxel.com. 2 Välj din produkt från rullgardinslistrutan på ZyXELs hemsida för att gå till denna produkts sida. 3 Välj det certifikat du vill titta på från denna sida. Mer produkthjälp finns på http://www.support.zyxel.se. SVENSKA...
