Wolf WKED2 Specification Sheet

Approved by ______________________
Date: _____________________________
NSF listed. UL listed. UL listed to Canadian safety standards.
SPECIFY VOLTAGE AND PHASE WHEN ORDERING.
F-39245 (03/08)
DOUBLE SECTION FULL FEATURED

ELECTRIC CONVECTION OVEN

Item #_____________ C.S.I. Section 11420
BASIC MODEL:
Double section electric convection oven
WKED2
KEY FEATURES:
Stainless steel front, sides, top and legs.
Independently operated stainless steel doors with double
pane windows.
25 total KW.
/ H.P. two speed oven blower-motor.
1
2
Moisture vent damper control.
Side mounted solid state temperature controls adjust from
150° to 500°F.
60 minute timers with audible alarm.
Oven cool switch for rapid cool down.
Porcelain enamel on steel oven interiors.
Five nickel plated oven racks with eleven rack positions per
section.
One year limited parts and labor warranty.
OPTIONAL FEATURES:
Five hour timer in place of 60 minute timer.
Casters.
480 volt, 60 Hz, 3 phase.
220/380 volt, 50 Hz, 1 phase, 3 wire.
220/380 volt, 50 Hz, 3 phase, 4 wire.
240/415 volt, 50 Hz, 3 phase, 4 wire.
ACCESSORIES:
Extra oven rack(s).
Stainless steel drip pan.
DESCRIPTION:
Double section electric convection oven, Wolf Model No.
WKED2. Stainless steel front, sides, top and legs. Independently
operated stainless steel doors with double pane windows.
Non-sag insulation applied to the top, rear, sides, bottom and
doors. Porcelain enamel on steel oven interiors measure 29"w
x 22 1 / "d x 20"h. Two interior oven lights per section. Five nickel
8
plated oven racks per section measure 28
position nickel plated rack guides with positive rack stops per
section. Each section heated by electric solid sheath elements
rated at 12.5 KW. Furnished with a two speed
blower-motor per section. Side mounted solid state temperature
controls adjust from 150° to 500°F. 60 minute timers with
audible alarm. Oven cool switch for rapid cool down. 208 or 240
volt, 60 Hz, 1 or 3 phase.
Exterior dimensions: 40"w x 42
measurement includes door handles.
Wolf Range Company
Division of ITW Food Equipment Group LLC
(800) 366-9653
www.wolfrange.com
/ " x 20 / ". Eleven
1 1
4 2
/ H.P. oven
1
2
/ "d x 70"h on 8" legs. Depth
1
4
