Wolf WKGD1 Specifications

Model WKGD1
CSA design certified.
NSF listed.
Approved by ______________________
Date: _____________________________
SPECIFY TYPE OF GAS AND FINISH WHEN ORDERING.
SPECIFY ALTITUDE WHEN ABOVE 2,000 FT.
F-39222 (3/08)
Item #_____________ C.S.I. Section 11420
FULL FEATURED GAS
CONVECTION OVEN
BASIC MODEL:
WKGD1 Single section gas convection oven
KEY FEATURES:
Stainless steel front, sides and top.
Painted legs.
Stainless steel doors with double pane windows.
44,000 BTU/hr. burner.
Electronic spark igniter.
/ H.P. two speed oven blower-motor. 120/60/1 with 6' cord
1
2
and plug. 9 amps.
Solid state temperature control adjusts from 150° to 500°F.
60 minute timer with audible alarm.
Oven cool switch for rapid cool down.
Porcelain enamel on steel oven interior.
Five nickel plated oven racks with eleven rack positions.
/ " rear gas connection with gas pressure regulator and
3
4
safety solenoid system.
One year limited parts and labor warranty.
OPTIONAL FEATURES:
Stainless steel legs.
Stainless steel open stand with storage rack.
Five hour timer in place of 60 minute timer.
Roast & Hold control.
Casters.
ACCESSORIES:
Extra oven rack(s).
Stainless steel drip pan.
Flexible gas hose with quick disconnect and restraining
device.
SPECIFICATIONS:
Single section gas convection oven, Wolf Model No. WKGD1.
Stainless steel front, sides, top and painted legs. Independently
operated stainless steel doors with double pane windows.
Non-sag insulation applied to the top, rear, sides, bottom and
doors. Porcelain enamel on steel oven interior measures 29"w
x 22 / "d x 20"h. Two interior oven lights. Five nickel plated oven
1
8
racks measure 28
guides with positive rack stops. One 44,000 BTU/hr. burner.
Electronic spark igniter. Furnished with a two speed
oven blower-motor. Solid state temperature control adjusts
from 150° to 500°F. 60 minute timer with audible alarm. Oven
cool switch for rapid cool down. 120 volt, 60 Hz, 1 ph power
supply required. 6' cord and plug. 9 amps total draw.
Exterior dimensions: 40"w x 42
Depth measurement includes door handles.
/ " x 20 / ". Eleven position nickel plated rack
1 1
4 2
/ "d x 56 /
1 3
4
Wolf Range Company
Division of ITW Food Equipment Group LLC
(800) 366-9653
www.wolfrange.com
/ H.P.
1
2
"h on 25 / " legs.
3
4 4
