Graco E-Flo EP G Series Repair Parts

Graco E-Flo EP G Series Repair Parts

4-ball pumps with sealed or open wet cup lowers
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Repair - Parts
®
E-Flo
Pumps
with Sealed or Open Wet Cup Lowers
Piston pumps for high-volume paint circulation applications.
For professional use only.
Important Safety Instructions
Read all warnings and instructions in this manual.
Save these instructions.
See page 3 for model information, including maximum working pressure. See page 4 for approvals.
4-Ball
ti27597a
E-Flo 4000 Pump Shown
3A3386E
EN
ti27591a

Advertisement

Table of Contents
loading

Related Manuals for Graco E-Flo EP G Series

Summary of Contents for Graco E-Flo EP G Series

  • Page 1 Repair - Parts ® E-Flo 4-Ball Pumps 3A3386E with Sealed or Open Wet Cup Lowers Piston pumps for high-volume paint circulation applications. For professional use only. Important Safety Instructions Read all warnings and instructions in this manual. Save these instructions. See page 3 for model information, including maximum working pressure.

  • Page 2: Table Of Contents

    Electrical Diagrams ......10 Graco Information ......50 Repair .

  • Page 3: Models

    Models Models E-Flo 4-Ball Piston Pumps Check your pump’s identification plate (ID) for the 6-digit part number of your pump. Use the following matrix to define the construction of your pump, based on the six digits. For example, Pump Part No. E P 2 1 D 0 represents electric power (E), pump (P), 230/460V motor (2), sensor circuit installed (1), 1000 cc lower with an open wet cup (D), and no stand installed (0).

  • Page 4: Approvals

    Approvals Approvals The E-Flo Pump meets requirements of the following approval agencies. Refer to the individual components for other specific hazardous location listings. Component Description Approvals Mechanical Pump Ex h IIB T3 Gb ATEX (for pump Models EP1XXX and EP3XXX) Ex de IIC T4 Gb - CESI 05 ATEX 110X Motor UL/CSA...

  • Page 5: Warnings

    Warnings Warnings The following warnings are for the setup, use, grounding, maintenance, and repair of this equipment. The exclama- tion point symbol alerts you to a general warning and the hazard symbols refer to procedure-specific risks. When these symbols appear in the body of this manual or on warning labels, refer back to these Warnings. Product-specific hazard symbols and warnings not covered in this section may appear throughout the body of this manual where applicable.
  • Page 6 Warnings EQUIPMENT MISUSE HAZARD Misuse can cause death or serious injury. • Do not operate the unit when fatigued or under the influence of drugs or alcohol. • Do not exceed the maximum working pressure or temperature rating of the lowest rated system com- ponent.

  • Page 7: Pressure Relief Procedure

    Pressure Relief Procedure Pressure Relief Flushing Procedure Follow the Pressure Relief Procedure when- ever you see this symbol. To avoid fire and explosion, always ground equipment and waste container. To avoid static sparking and injury from splashing, always flush at the lowest possi- ble pressure.

  • Page 8: Troubleshooting

    Troubleshooting Troubleshooting 1. Follow the Pressure Relief Procedure, page 7. 2. Check all possible problems and solutions before disassembling pump. PROBLEM CAUSE SOLUTION Pump does not operate. Insufficient power supply. Verify that power supply meets require- ments. See Performance Charts, page No flow rate input to VFD.
  • Page 9 Troubleshooting PROBLEM CAUSE SOLUTION Erratic flow or pressure. Pump cavitation; suction/supply line leak. Check and repair. Exhausted fluid supply. Refill and reprime pump. Restricted fluid supply to pump. Ensure all valves are fully open. Held open or worn ball check valves. Check and repair.

  • Page 10: Electrical Diagrams

    Electrical Diagrams Electrical Diagrams . 1 shows components which must be installed in a . 2 shows components approved for installation in a non-hazardous location. hazardous location, and F . 3 shows detail views of hazardous location components. 12 Gauge Alpha Wire P/N V16012/equiv. 16 Gauge MTW Wire.
  • Page 11 Electrical Diagrams SEE DETAIL +$=$5'286 $5($ A, page 12 Alpha Wire P/N M16107LW/equiv. 6(( 6+((7  '(7$,/ 326,7,21 6(1625 7'& *5((1 1$085 %/$&. 6(1625 :+,7( ,6 6(1625 %/$&. &,5&8,7 %2$5' 35(6685( %/$&. 75$16'8&(5 /2&$/ &21752/ &20 75,3 5(6(7 5816723 /2&$/5(027( 6(&85( ',6$%/( 9  %/8   *$ 07: :,5(...
  • Page 12 Electrical Diagrams DETAIL A HAZARDOUS (CLASSIFIED) LOCATION CLASS I, DIV. 1, GROUP C & D, T3 (FM ONLY) GROUP II, CATEGORY 2 - ZONE 1, GAS (ATEX ONLY) CLASS I, DIV. 1, GROUP C & D T3 (CANADA) INSTALLED ON PUMP ASSEMBLY NON-HAZARDOUS AREA INSTALLED IN E-FLO JUNCTION BOX ONLY...

  • Page 13: Repair

    Repair Repair Fluid Section NOTE: Manifold Gasket Kit 15H878 is available to 5. See F . 5. Place a 3/4 in. wrench on the slider pis- replace the sanitary gaskets at the inlet and outlet mani- ton (9) flats (just above the coupling nut), to keep folds.
  • Page 14 Repair 9. Disconnect the fluid inlet and outlet lines from the 11. Loosen the clamps (18) at the inlet and outlet mani- pump. Plug the ends to prevent fluid contamination. folds (17). Remove the manifolds and gaskets (16). 10. See F .
  • Page 15 Repair Reassembly 6. Install a black o-ring (41) on the plug (45). Screw the plug into the inlet manifold (17) and torque to 15-20 1. See F . 6. Install the coupling nut (14) on the ft-lb (21-27 N•m). lower’s piston rod (PR). 7.
  • Page 16 Repair Slider Cylinder Rebuild Kit 15H874 NOTE: Slider Cylinder Rebuild Kit 15H874 includes parts to rebuild one slider cylinder assembly. Order two kits to rebuild both slider cylinder assemblies. Use all the new parts in the kit. The kit includes manual 311599. 1.
  • Page 17 Repair Slider Cylinder Collector Kit 247341 NOTE: Slider Cylinder Collector Kit 247341 includes parts to install two slider cylinder collectors. Use all the new parts in the kit. The kit includes manual 311607. ti9539a . 10. Install Collector 1. Perform the Disassembly procedure on page 13. 8.

  • Page 18: Electrical Section

    Repair Electrical Section NOTE: Sensor Circuit Kit 24J305 is available to add the 5. See F . 11. Remove six screws (12), the circuit optional sensor circuit to a pump. Use all the new parts board cover (34), and the gasket (33). in the kit.
  • Page 19 (44) and unscrew the adapter (42) from the information found on the new label (L): transducer port (P). Remove the transducer (25a) • For systems using the Graco ACS Module, see from the port. the ACS manual 3A0006. 12. See F .
  • Page 20 Make a record of it. NOTE: To calibrate the transducer in systems using the c. Navigate to Pr 20.34 and enter the recorded Graco ACS Module, see the ACS manual 3A0006. average value of Pr 20.33. Pressure sensor information (Pr 20.34, 20.35, and 4.
  • Page 21 Repair TDC Sensor Kit 15H877 13. Reconnect the TDC cable (25b) to J2 on the circuit board (25c). NOTE: TDC Sensor Kit 15H877 replaces the TDC sen- 14. Reconnect the transducer cable (25a) to J1 on the sor. Use all the new parts in the kit. The kit includes circuit board (25c).
  • Page 22 Repair Position Sensor NOTE: If the adapter (78) was removed, apply thread lubricant and torque to 75-80 ft-lb (102-108 N•m). NOTE: The Position Sensor (80) measures motor posi- 9. Install the new position sensor (80) into the adapter tion by detecting holes in the motor coupler (28). The (78) and secure with the sleeve (79).
  • Page 23 Repair 28 (Ref) 1 (Ref) Connect Field Wires here ti17643a 44 (Ref) Position Sensor Parts and Location - Position Sensor  %51 326,7,21  %/8 6(1625 Wires 7'&  %51 1$085  %/8 6(1625 ,6 6(1625 ti16890b &,5&8,7 5(' %2$5' *51 35(6685( :+7 ...

  • Page 24: Drive Section

    Repair Drive Section Slider Bearing Kit 15H882 6. Remove the 2-piece shield (72) by inserting a screwdriver straight into the slot, and using it as a lever to release the tab. Repeat for all tabs. Do not NOTE: Slider Bearing Kit 15H882 includes parts to use the screwdriver to pry the shields apart.
  • Page 25 Repair 10. See F . 18. Rotate the crank arm (4) to allow it to 14. Slide the piston (9) and connecting rod (7) into the be removed from the output shaft (OS). cylinder (2). 11. Pull the crank arm/connecting rod/slider piston 15.
  • Page 26 Repair Drive Linkage Rebuild Kit 15H873 NOTE: Drive Linkage Rebuild Kit 15H873 includes parts to rebuild one drive linkage assembly. Order two kits to rebuild both drive linkage assemblies. Use all the new parts in the kit. The kit includes manual 311598. NOTE: Replace the wrist pin bearings (7a) in the con- necting rod annually.
  • Page 27 Repair Crank Arm Kit 15H883 6. Assemble the crank arm (4) to the connecting rod (7) with two retaining rings (6), oriented as shown. NOTE: Crank Arm Kit 15H883 is available. Order two 7. Ensure that the joints between the bearings (8) align kits to rebuild both crank arm assemblies.

  • Page 28: Motor/Gear Reducer

    Repair Motor/Gear Reducer Motor Removal NOTE: A faint clicking may be heard while the motor is running. This is normal and is due to necessary clear- ances between the coupler (28), motor shaft, and motor key. If the intensity increases significantly over time, it could indicate the coupler is wearing and should be replaced.
  • Page 29 Repair Motor/Coupler is Difficult to Remove NOTE: Use this procedure only if, after performing steps 1-3 on page 28, the motor does not come off the gear reducer easily. NOTE: During the following procedure, if the coupler becomes separated from the motor shaft but remains stuck on the input shaft, use the 15J827 coupler removal tool (T) as shown in F .
  • Page 30 Repair Motor Installation 4. Tighten setscrews to 66-78 in-lb (7.4-8.8 N•m). ® Apply antiseize lubricant (LPS -04110 or equiva- NOTE: A NEMA 182/184 TC Frame is required to mate lent) to bore of coupling. with gear reducer. If the pump is purchased without a motor you must order a kit to mate with the gear ®...
  • Page 31 Repair Gear Reducer Seal Kit 15H871 cavity with Part No. 107411 Grease. Install the input seal (109) with the lip facing in, until the seal con- tacts the shoulder of the gear reducer housing. NOTE: Gear Reducer Seal Kit 15H871 and Output Remove the tape.
  • Page 32 Repair 11. Install the two output seals (116) as follows: Remove the tools. Take three measurements 120° apart, from the surface of the seal to the a. Place tape over the output shaft keyway, to pre- face of the housing (H). The three measure- vent damage to the new seals.
  • Page 33 Repair Gear Reducer Replacement Kit 10. On pumps with the sensor circuit: a. See F . 29. Disconnect the transducer cable Disassembly (25a) from J1 on the circuit board (25c). Remove and retain the ferrite (76). NOTE: The Gear Reducer Kit is available to replace the entire gear reducer.
  • Page 34 Repair Units with a sensor circuit must use the Torque to 15-20 ft-lb (21-27 N•m). Apply antiseize lubricant to screw (5) conductive strain relief (74a) to ensure threads. Torque key-side screw to proper grounding of the IS field wire. 210-230 ft-lb (283-310 N•m) first, then Torque to 66-78 in-lb (7.4-8.8 N•m).
  • Page 35 Repair Reassembly 10. On pumps with the sensor circuit: a. Remove the plug from the TDC sensor port at NOTE: Kit 15H886 includes a motor coupler (28), already installed in the gear reducer. The coupler fits all the back of the circuit board cavity. Clean any NEMA 182/184 TC Frame electric motors.
  • Page 36 Repair 74a* ti8725b ti17640a Circuit Board Location Circuit Board Wire Connections 28 (Ref) 1 (Ref) Connect Field Wires here ti17643a 44 (Ref) Position Sensor Parts and Location Position - Sensor  %51 326,7,21  %/8 Wires 6(1625 7'&  %51 1$085  %/8 6(1625...
  • Page 37 Repair Thread the IS field wire through the conductive strain relief (74a). Connect the TDC wires to J2, the transducer wires to J3, and the position sen- sor wires to the two terminal blocks (46). See . 31 and the Electrical Diagrams, page 10. k.

  • Page 38: Parts

    Parts Parts Drive Section 19b and 19d 19a and 19c 74a or 74b 25a (Ref) ti28032b 28 (Ref) 1 (Ref) 35 (Ref) 44 (Ref) ti17643a ti16890b 44 (Ref) Position Sensor Parts and Location Detail of Sensor Conduit 3A3386E...

  • Page 39: Fluid Section - Sealed 4-Ball

    Parts Fluid Section - Sealed 4-Ball ti28033a 3A3386E...

  • Page 40: Fluid Section - Open Wet Cup

    Parts Fluid Section - Open Wet Cup ti28033a 3A3386E...

  • Page 41: Common Parts

    Parts Common Parts Ref. Ref. Part No. Description Part No. Description 17K657 LOWER, 1000 cc, Sealed; see page 43 15H886 KIT, 75:1 gear reducer; E-Flo for applicable models; see 333022 2000/3000/4000 only; see 311615 17K658 LOWER, 1500 cc, Sealed; see page 43 289550 KIT, 75:1 gear reducer;...
  • Page 42 Parts Parts designated n/a are not available separately. Ref. Part No. Description Parts included in Drive Linkage Rebuild Kit 15H873 (pur- 120710 KEY, square; 0.25 x 1.75 in.; for ATEX chase separately). Order two kits to rebuild both drive link- 5 HP motor (19b) only age assemblies.

  • Page 43: Model-Specific Parts

    Parts Model-Specific Parts NOTE: A checkmark () indicates an item is used on your pump. Shaded boxes indicate that an item is not used. Motor Kit (19) Sensor Coupler/Motor Pump Part Lower Circuit Mounting Kit Floor Stand Kit 255226 255225 289552 289551 Series...
  • Page 44 Parts Motor Kit (19) Sensor Coupler/Motor Pump Part Lower Circuit Mounting Kit Floor Stand Kit 255226 255225 289552 289551 Series (22) (25) (28) (69) EP10A0  17K657  EP10A1  17K657   EP10B0  17K658  EP10B1  17K658 ...
  • Page 45 Parts Motor Kit (19) Sensor Coupler/Motor Pump Part Lower Circuit Mounting Kit Floor Stand Kit 255226 255225 289552 289551 Series (22) (25) (28) (69) EP20A0  17K657  EP20A1  17K657   EP20B0  17K658  EP20B1  17K658 ...

  • Page 46: Gear Reducer

    Parts Gear Reducer NOTE: To replace the entire gear reducer, order one of Ref. the following kits: Part No. Description 109* SEAL, input shaft • 15H886 Gear Reducer Replacement Kit, for E-Flo 15H525 CAP, fill 2000/3000/4000. See manual 311615. SIGHTGLASS, 116* SEAL, output •...

  • Page 47: Performance Charts

    Performance Charts Performance Charts Pressure and Flow Capability of E-Flo Family with 50 Hz psi (MPa, Motor 500 (3.50, 35.0) Key: 450 (3.15, 31.5) E-Flo 1500 E-Flo 2000 400 (2.80, 28.0) E-Flo 3000 350 (2.41, 24.1) E-Flo 4000 300 (2.10, 21.0) 250 (1.72, 17.2) 200 (1.4, 14.0) 150 (1.03, 10.3)

  • Page 48: Technical Data

    Fluid Inlet and Outlet Size 2 quarts 1.9 liters Gear Reducer Oil Capacity ISO VG220 grade oil ISO VG220 grade oil Required Gear Reducer Lubricant (Graco Part No. 288414) (Graco Part No. 288414) 550 lbs. Weight 249 kg Electric Motor EPxxGx and EPxxHx...
  • Page 49 Technical Data California Proposition 65 CALIFORNIA RESIDENTS WARNING: Cancer and reproductive harm – www.P65warnings.ca.gov. 3A3386E...

  • Page 50: Graco Standard Warranty

    With the exception of any special, extended, or limited warranty published by Graco, Graco will, for a period of twelve months from the date of sale, repair or replace any part of the equipment determined by Graco to be defective.
