Graco E-Flo SP D200S Installation And Parts Manual

Supply systems
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Installation - Parts
®
E-Flo
Supply Systems
For transferring or dispensing sealants, adhesives, or other medium to high viscosity
fluids. For professional use only.
Not approved for use in explosive atmospheres or hazardous locations.
D60 3 inch dual post
20 liter (5 gallon), 30 liter (8 gallon),
60 liter (16 gallon) sizes
150 psi (1.0 MPa, 10 bar) Maximum Air Inlet Pressure
D200 3 inch dual post
200 liter (55 gallon) size
150 psi (1.0 MPa, 10 bar) Maximum Air Inlet Pressure
D200S 6.5 inch dual post
200 liter (55 gallon) size
125 psi (0.9 MPa, 9 bar) Maximum Air Inlet Pressure
See page 4 for model information, including maximum
working pressure and approvals.
The Graco Control Architecture Electric Components
are Listed in Intertek's Directory of Listed Products.
Important Safety Instructions
Read all warnings and instructions in this
manual and in related manuals before
using the equipment. Save all
instructions.
SP
3A6331C
EN
