INSTALLATION GUIDE
SCXI -1314T TEDS Bridge Sensor
™
Terminal Block
Conventions
»
This guide describes how to install and use the SCXI-1314T terminal block
with the SCXI-1520 module and hardware Transducer Electronic Data
Sheet (TEDS)-enabled bridge sensors (IEEE-P1451.4 Class 2).
The SCXI-1314T terminal block works with the SCXI-1520 universal
strain/bridge sensor module to conveniently connect hardware TEDS smart
sensors using RJ-50 10 position/10 conductor (10p10c) modular plugs.
There are 10 pins arranged in eight modular jacks. Each jack corresponds
to one of the eight channels available on the SCXI-1520. For a complete
description of the use and operation of the SCXI-1520 module, refer to the
SCXI-1520 User Manual.
The following conventions are used in this manual:
The » symbol leads you through nested menu items and dialog box options
to a final action. The sequence File»Page Setup»Options directs you to
pull down the File menu, select the Page Setup item, and select Options
from the last dialog box.
This icon denotes a note, which alerts you to important information.
When this icon is marked on the product, refer to the Read Me First: Safety
and Radio-Frequency Interference document, shipped with the product, for
precautions to take.
When symbol is marked on a product, it denotes a warning advising you to
take precautions to avoid electrical shock.
When symbol is marked on a product, it denotes a component that may be
hot. Touching this component may result in bodily injury.
