ASSEMBLY AND INSTALLATION GUIDE
SCXI -1384K Custom Terminal
Block Kit
Introduction
Note
Common matrix terminology describes matrixes by the number of rows by the
number of columns they contain. For example, four rows by 16 columns would be written
as 4 × 16.
This guide describes how to assemble your custom terminal block, make
signal connections, and install your custom terminal block.
The SCXI-1384K custom terminal block installs in front of the SCXI-1129
module. This terminal block allows you to easily turn the SCXI-1129
module into a high-density matrix configuration designed to meet your
needs.
You can use the SCXI-1384K custom terminal block with the SCXI-1129
module to create a custom matrix without any extra wiring except for
connecting your signals to the rows and columns of the matrix. You can also
combine the rows and/or columns to create many different matrix
configurations. Refer to Chapter 2, Using the SCXI-1129, in the SCXI-1129
User Manual for more information.
The SCXI-1384K custom terminal block has solder terminals that provide
access to each of the four 4 × 16 matrixes. Also, connections for scanner
advanced and external trigger signals are available.
Visit
ni.com/instruments
for information on other switching solutions.

Advertisement

Table of Contents
loading

Summary of Contents for National Instruments SCXI-1384K

  • Page 1 Introduction The SCXI-1384K custom terminal block installs in front of the SCXI-1129 module. This terminal block allows you to easily turn the SCXI-1129 module into a high-density matrix configuration designed to meet your needs.
  • Page 2: Getting Started

    This font is also used for the proper names of disk drives, paths, directories, programs, subprograms, subroutines, device names, functions, operations, variables, filenames and extensions, and code excerpts. Getting Started To assemble and use your SCXI-1384K custom terminal block, you need the following items: ❑ SCXI-1384K custom terminal block kit –...
  • Page 3: Safety Information

    Category I refers to a signal level such as voltages of an isolation transformer secondary on a PWB. © National Instruments Corporation SCXI-1384K Custom Terminal Block Kit...
  • Page 4 If necessary, return the device to National Instruments for service and repair to ensure that its safety is not compromised. Do not operate this equipment in a manner that contradicts the information specified in this document. Misuse of this equipment could result in a shock hazard.
  • Page 5 × 3 Insulator Foam Tape 1 10-32 3/4 Inch Screws 4 Lower Strain-Relief Bar 2 Upper Strain-Relief Bar Figure 1. Strain-Relief Parts Locator Diagram © National Instruments Corporation SCXI-1384K Custom Terminal Block Kit...
  • Page 6: Assembling The Front Panel

    Secure the strain-relief assembly to the front panel with two 4-40 nuts. 1 Strain-Relief Assembly 4 4-40 Nuts × 5 Front Panel 2 4-40 3/8 Inch Screws 3 Safety Ground Lug Figure 2. Connecting the Strain-Relief Assembly and Front Panel SCXI-1384K Custom Terminal Block Kit ni.com...
  • Page 7: Installing The Front Panel

    Adhere front graphical overlay to front panel as shown in Figure 3. 1 Front Graphical Overlay 4 Base 2 Front Panel Assembly 5 Insulator 3 #6 Sheet Metal Screws Figure 3. Installing the Front Panel Assembly © National Instruments Corporation SCXI-1384K Custom Terminal Block Kit...
  • Page 8 Attach the 180-position connector to the side of the PCB with the solder terminals. Solder each pin of the180-position connector to the PCB. 1 PCB 2 180-Position Connector Figure 4. Attaching the Mating Connector SCXI-1384K Custom Terminal Block Kit ni.com...
  • Page 9: Connecting Signals

    4 180-Position Connector 7 #6 Sheet Metal Screws 2 Base 5 PCB 8 Rear Panel 3 Extrusion Rails 6 Thumbscrews 9 Snap-On Top Cover Figure 5. SCXI-1384K Custom Terminal Block Final Assembly © National Instruments Corporation SCXI-1384K Custom Terminal Block Kit...
  • Page 10 6 Scanner Advanced Output (SCANADV) Solder Terminal 3 Safety Ground Lug 7 External Trigger Input (EXTRIGIN) Solder Terminal 4 5 V Reference 8 Column Connection Solder Terminals Figure 6. SCXI-1384K Custom Terminal Block Signal Connections SCXI-1384K Custom Terminal Block Kit ni.com...
  • Page 11: Installing The Terminal Block

    Secure the top cover to the rear panel with one sheet metal screw. Installing The Terminal Block To connect your SCXI-1384K custom terminal block to the SCXI-1129 module front connector, complete the following steps: Connect the module front connector to its mating connector on the terminal block.
  • Page 12: Specifications

    To obtain the DoC for this product, click Declaration of Conformity at This website lists the DoCs by ni.com/certification. product family. Select the appropriate product family, followed by your product, and a link SCXI-1384K Custom Terminal Block Kit ni.com...
  • Page 13: Technical Support Resources

    Sweden 46 (0) 8 587 895 00, Switzerland 41 56 2005151, Taiwan 886 02 2377 2222, Thailand 662 278 6777, Turkey 90 212 279 3031, United Kingdom 44 (0) 1635 523545 © National Instruments Corporation SCXI-1384K Custom Terminal Block Kit...
  • Page 14 National Instruments, NI, ni.com, and LabVIEW are trademarks of National Instruments Corporation. Refer to the Terms of Use section on ni.com/legal for more information about National Instruments trademarks. Other product and company names mentioned herein are trademarks or trade names of their respective companies. For patents covering National Instruments products, refer to the appropriate location: Help»Patents in your software, the patents.txt file on your CD, or ni.com/patents.
