Johnson Controls TM9V C Series Installation Manual page 42

Gas Side
Gas Type Natural Gas
LP Gas Conversion Kit Part # Used
Inlet Gas Pressure (in. w.c.")
Calculated input in btuh - clock the gas meter in high fire (Nat Gas Only)
Burner flame inspected -- flames are blue and extending directly into the primary heat exchanger cells
Air Side: System External Static Pressure
Supply static before indoor coil (in w.c.")
Return Static (in w.c.") before filter
Total External Static Pressure
Air Side: Heating (PSC)
Low Heat Blower Speed Selected
High Heat Blower Speed Selected
Temperature rise in degrees F measured in low fire
Temperature rise in degrees F measured in high fire
Air Side: Heating (Variable Speed ECM)
Heat Speed Selected
Temperature rise in degrees F measured in Low fire
Temperature rise in degrees F measured in high fire
Air Side: Cooling (PSC)
Low Cool Blower Speed Selected
High Cool Blower Speed Selected
Cooling CFM delivery (use Blower Performance Data Chart)
Air Side: Cooling (Variable Speed ECM)
COOL Speed Selected
ADJUST Setting
DELAY Setting
Air Side: Continuous Fan (PSC)
Blower Speed Selected
Air Side: Continuous Fan (Variable Speed ECM)
Blower (5-Speed) Selected
Blower (3-Speed) Selected
Cycle Test
Operate the furnace through several heating cycles from the thermostat, noting and correcting any problems
Operate the furnace through continuous fan cycles from the thermostat, noting and correcting any problems
Operate the furnace through cooling cycles (as applicable), noting and correcting any problems
Clean Up
Installation debris disposed of and furnace area cleaned up?
Owner Education
Give owner the owner's manual provided
Explain operation of system to equipment owner
Explain the importance of regular filter replacement and equipment maintenance
Explain thermostat use and programming (if applicable) to owner
Subject to change without notice. Published in U.S.A
Copyright © 2019 by Johnson Controls. All rights reserved.
LP Gas (Requires LP conversion kit)
Low Fire Manifold Gas Pressure (in. w.c.")
Supply static after indoor coil (in w.c.")
Return Static (in w.c.") after filter (furnace side)
Red (Low) Yel (Med Low)
Red (Low) Yel (Med Low)
A B C
Red (Low) Yel (Med Low)
Red (Low) Yel (Med Low)
A B C
A B C
A B C
Lo Heat HI Heat
Lo Cool HI Cool
L (Low) M (Med)
York International Corp.
Norman, OK 73069
LP Conversion Kit Installed By
High Fire Manifold Gas Pressure (in. w.c.")
Blue (Med/Med High)
Blue (Med/Med High)
Other Jumpers
D
De-humidistat
Heat Pump
Blue (Med/Med High)
Blue (Med/Med High)
Hi Low
D
D
D
Lo Cool Hi Cool
Hi Heat o L o L H H e e t a t a VSG
H (High)
5005 York Drive
Black (High)
Black (High)
Yes No
Yes No
Black (High)
Black (High)
5750149-UIM-D-1219
Supersedes: 5750149-UIM-C-1019
