GAS CONVECTION
OVENS
MODELS
VC4GS
ML-126610
VC4GD
ML-126611
VC4GC
ML-136494
VC6GS
ML-126612
VC6GD
ML-126613
VC6GC
ML-136495
For additional information on Vulcan-Hart or to locate an authorized parts
and service provider in your area, visit our website at www.vulcanhart.com
VULCAN-HART
DIVISION OF ITW FOOD EQUIPMENT GROUP, LLC
WWW.VULCANHART.COM
REPLACEMENT PARTS
P.O. BOX 696, LOUISVILLE, KY 40201-0696
CATALOG OF
TEL. (800) 814-2028
FORM 43031 Rev. C (Aug. 2007)
Advertisement
Table of Contents
Related Manuals for Vulcan-Hart ML-126610
Summary of Contents for Vulcan-Hart ML-126610
-
Page 1: Replacement Parts
VC6GS ML-126612 VC6GD ML-126613 VC6GC ML-136495 For additional information on Vulcan-Hart or to locate an authorized parts and service provider in your area, visit our website at www.vulcanhart.com VULCAN-HART DIVISION OF ITW FOOD EQUIPMENT GROUP, LLC WWW.VULCANHART.COM CATALOG OF REPLACEMENT PARTS P.O. - Page 2 17 THRU 20 23-24-25 27-28 29 THRU 32 21-22 11-12 9-10 34-35 OVEN PANELS - 2 - PL-55991...
- Page 3 ILLUS. PART NO. PL-55991 00-424840-00002 Panel – Back (SST) (Optional) ... 1 00-424153-000G1 Back – Panel Assy..1 00-405016-00001 Cord – Electric Supply (120 V. Only) ... 1 00-423289-000G1 Motor Mount ... 1 00-411289-00004 Spacer – Fan Housing ... 4 SC-120-15 Mach.
-
Page 4: Door Assembly
GAS CONVECTION OVENS REPLACEMENT PARTS 1 THRU 4 12-13 14 THRU 17 10-11 21-22 25-26 28-29 PL-55992-1 DOOR ASSEMBLY (SIMULTANEOUSLY OPENING DOORS) - 4 -... - Page 5 (SIMULTANEOUSLY OPENING DOORS) ILLUS. PART NO. PL-55992-1 00-356562-00001 Handle – Door ... 1 00-356563-00003 Grip – Front ... 1 00-356563-00004 Grip – Rear ... 1 SC-113-98 Mach. Screw 10-24 x SC-041-01 Cap Screw WL-019-37 Lockwasher 00-356550-00001 Latch – Friction ... 1 00-421913-00002 Shell –...
-
Page 6: Thru
7-8-9 Old Style Mounted to Door DOOR ASSEMBLY (LEFT HAND DOOR SHOWN) (INDEPENDENTLY OPENING DOORS) Mounted to Upper “C” Channel See Page 16 10-11 14-15 12-13 - 6 - 16 THRU 19 Old Style Shown Page 16 23-24 PL-55997-1... - Page 7 (INDEPENDENTLY OPENING DOORS) ILLUS. PART NO. PL-55997-1 00-358728-00001 Handle – End Piece (Prior to November 2005) ... 1 SC-041-01 Cap Screw WL-019-37 Lockwasher 00-357929-00002 Handle – Door (Includes Items 1, 5 & 6) (November 2005 to Present) ... 1 SC-113-98 Self-Tapping Screw etc.
- Page 8 GAS CONVECTION OVENS REPLACEMENT PARTS GAS PIPING AND FLAME CHAMBER - 8 -...
-
Page 9: Vc4Gs
GAS PIPING AND FLAME CHAMBER ILLUS. PART NO. PL-55993-1 00-423819-00003 Pipe – Weldment Gas Inlet ... 1 00-423828-00006 Tube – Flex (30") ... 1 00-425433-00001 Fan – Clip ... 1 00-424940-00001 Fan – Cooling (120 V.) ... 1 00-424940-00002 Fan – Cooling (230 V.) ... 1 SD-034-52 Self-Tapping Screw 8-32 x 1 Hex Washer Hd., Type T ... -
Page 10: Vc4Gd
38-39 VC4GC & VC6GC ELECTRICAL COMPONENT PANELS 19-20 21-22 31-32 16-17 VC4GD & VC6GD (W/O ROAST & HOLD) - 10 - 9-10 PL-55994-1... - Page 11 ILLUS. PART NO. PL-55994-1 00-417934-000G1 Porcelain - Block Assy..1 SD-034-52 Self-Tapping Screw 8-32 x 1 Hex Washer Hd., Type T ... 1 00-411500-00012 Transformer (120 V.) (24 V. Output) ... 1 00-411500-00013 Transformer (208-240 V.) (24 V. Output) ... 1 SD-032-07 Self-Tapping Screw 10-24 x 00-423760-00001...
- Page 12 26-27 23-24 ELECTRICAL COMPONENT PANEL (W/ROAST & HOLD) - 12 - 10-11 15-16 18-19 PL-55995...
-
Page 13: Lug - Grounding (With Set Screw)
ILLUS. PART NO. PL-55995 00-417934-000G1 Porcelain – Block Assy..1 SD-034-52 Self-Tapping Screw 8-32 x 1 Hex Washer Hd., Type T ... 1 00-421758-000G1 Transformer (120 V.) (24 V. Output) ... 1 00-421758-000G2 Transformer (208-240 V.) (24 V. Output) ... 1 SD-032-07 Self-Tapping Screw 10-24 x SD-034-52... -
Page 14: Control Panels
GAS CONVECTION OVENS REPLACEMENT PARTS CONTROL PANELS - 14 -... - Page 15 ILLUS. PART NO. PL-55996-2 00-340324-00008 Switch ... 1 00-354575-00002 Light - Indicator (110-120V.) ... 1 00-354575-00001 Light Indicator (200-240V.) ... 1 00-354575-00004 Light - Indicator ... 1 00-411242-00001 Knob ... 1 00-353613-00002 Temperature Control Board (ML-126611) (ML-126613) ... 1 00-411242-00001 Knob ...
-
Page 16: Thru
GAS CONVECTION OVENS REPLACEMENT PARTS 4 THRU 6 10-11 13 THRU 16 17-18-19 PL-55998-2 OVEN PANELS 26 - 27 New RH CAVITY SIDE - 16 -... -
Page 17: Bearing - Door Shaft
ILLUS. PART NO. PL-55998-2 00-424141-00002 Top (SST) (VC4) ... 1 00-424229-00002 Top (SST) (VC6) ... 1 00-421799-00001 Top – Front ... 1 00-353484-00001 Plate – Retainer ... 2 SC-053-46 Mach. Screw NS-038-08 Lock Nut 00-347080-00002 Bearing – Door Shaft ... 2 00-353482-00001 Spacer ... -
Page 18: Recommended Spare Parts
GAS CONVECTION OVENS REPLACEMENT PARTS RECOMMENDED SPARE PARTS PART NO. NAME OF PART AMT. 00-353589-00001 Thermocouple (“D” Models) ... 2 00-410841-00018 Combo Valve (Nat. Gas) (RobertShaw) ... 2 00-410841-00019 Combo Valve (L.P. Gas) (RobertShaw) ... 2 00-497269-00001 Combo Valve (Nat. Gas) (White Rogers) ... 2 00-497269-00002 Combo Valve (L.P.
