Chapter 2 — Installation
Print Mechanism
The print mechanism features a high-performance thermal printhead
with quick-mount fi ttings to facilitate replacement.
Pressure
arm
Thermal printhead
Tear bar
Locking handle
Label stop sensor
position adjustment screw
(hidden inside locking
handle)
10
EasyCoder PX6i User's Guide (IPL version)
Pressure arm
locking knob
Printhead
pressure
adjustment
knob
Edge
guide
Printhead lift
lever
