Security System
VISTA-10
SE
THIS ISSUE INCLUDES THE NEW "QED" (QUICK ENROLLMENT
OF DEVICES) PROCEDURE FOR 5800 SERIES TRANSMITTERS
Installation Instructions • Installation Instructions • Installation Instructions
N7227V5 5/97
downloaded from: http://www.guardianalarms.net

Advertisement

Table of Contents
loading

Related Manuals for ADEMCO N7227V5

Summary of Contents for ADEMCO N7227V5

  • Page 1 Security System VISTA-10 THIS ISSUE INCLUDES THE NEW “QED” (QUICK ENROLLMENT OF DEVICES) PROCEDURE FOR 5800 SERIES TRANSMITTERS Installation Instructions • Installation Instructions • Installation Instructions N7227V5 5/97 downloaded from: http://www.guardianalarms.net...
  • Page 2 RECOMMENDATIONS FOR PROPER PROTECTION The following recommendations for the location of fire and burglary detection devices help provide proper coverage for the protected premises. Recommendations For Smoke And Heat Detectors With regard to the number and placement of smoke/heat detectors, we subscribe to the recommendations contained in the National Fire Protection Association's (NFPA) Standard #72 noted below.

  • Page 3: Table Of Contents

    TABLE OF CONTENTS Section 1. GENERAL DESCRIPTION ... 9 Section 2. INSTALLING THE CONTROL ... 11 Mounting the Cabinet ... 11 Installing the Lock (if used) ... 11 Installing the Control's Circuit Board Alone or (if used), With a 4204 Relay Unit... 11 Installing Control and RF Receiver Circuit Boards Together in the Cabinet...
  • Page 4 Section 5. WIRELESS (RF) ZONE EXPANSION (5700 & 5800 RF SYSTEMS), CONT’D To Either Temporarily or Permanently Remove a Zone From the System (5800 System) ... 37 Deleting a Transmitter Serial Number From a Zone in 56 Mode (5800 System) ... 37 Check-out Procedure for Wireless Zones ...
  • Page 5 Section 13. SEQUENTIAL MODE (For 5800 Series Wireless Transmitters) ... 61 Section 14. SYSTEM COMMUNICATION ... 64 Report Code Formats ... 64 Table of Contact ID Event Codes... 66 Communication Programming ... 66 Section 15. TESTING THE SYSTEM ... 71 Test Procedure ...
  • Page 6 LIST OF FIGURES Figure 1. Installing the Cabinet Lock ... 11 Figure 2. Installing The PC Board Alone, or (if used), With a 4204 Relay Unit... 12 Figure 3. Installing the PC Board & RF Receiver Together in the Cabinet ... 12 Figure 4.

  • Page 7: How To Use This Manual

    HOW TO USE THIS MANUAL This manual is written to accommodate both the new and the experienced installer of Ademco products. A general description of the entire system is located in the first section of this manual. This includes the various features available and the optional peripheral devices that the system can support.

  • Page 8: Conventions Used In This Manual

    CONVENTIONS USED IN THIS MANUAL MAIN SECTION TITLES ARE SHOWN IN REVERSE TYPE These notes include specific information which must be followed if you are installing this system for a UL Listed application. These notes include information that you should be aware of before continuing with the installation, and which, if not observed, could result in operational difficulties.

  • Page 9: Section 1. General Description

    Section 1. GENERAL DESCRIPTION The VISTA–10SE is a control that supports up to 22 zones, using basic hard-wired, and/or wireless, plus remote keypads. Basic Hardwired Zones Provides 6 basic hardwired zones having the following characteristics: (1–6) • Zones 1-6 response time is 300–500 milliseconds. •...
  • Page 10 Optional Output Relays • Up to 4 relays using one 4204 Relay Module. • Actions programmable to respond to zone activity or manual keypad entries. Optional Phone module • Supports the Ademco 4285 Phone module . • Provides access to the system via on premises or off-premises phones for Optional Long Range •...

  • Page 11: Section 2. Installing The Control

    Section 2. INSTALLING THE CONTROL This section provides instructions for mounting the control cabinet, and installing the cabinet lock (if used). Also included in this section are instructions for the following: • Installing the main PC board (and 4204 Relay Unit, if used). •...

  • Page 12: Figure 2. Installing The Pc Board Alone, Or (If Used), With A 4204 Relay Unit

    4204 Relay Unit 1. Insert self-tapping screws (provided) in two adjacent raised cabinet tabs. (if installed in cabinet) 2. Hang the unit on the screw heads via two of the slotted holes at the rear of 3. The 4204's cover can be left off if the unit's DIP switch is set with its DETAIL B SIDE VIEW OF LONG MOUNTING CLIPS...

  • Page 13: Installing Control And Rf Receiver Circuit Boards Together In The Cabinet

    the Control and RF Receiver Circuit Boards Together in the Cabinet Installing 1. Hang two short (black) mounting clips (provided with receiver) on the raised cabinet tabs, as shown in Detail B in Figure 3. 2. Insert the top of the receiver board (removed from its own case as de- scribed in its instruc tions) into the slots at the top of the cabinet, as shown in Detail A in Figure 3.

  • Page 14: Wiring The Ac Transformer

    Wiring The AC Transformer No. 1321 Wire the No. 1321 transformer to terminals 1 and 2 on the control board. See wiring table below for wire gauge to use. Distance of Transformer From the Control Panel Wiring to the AC Transformer must not exceed 250 feet using 16 gauge wire. Do not plug the transformer into the AC outlet until you are instructed to do so later in the manual.

  • Page 15: Section 3. Installing Remote Keypads

    Section 3. INSTALLING REMOTE KEYPADS This section lists the wired keypads that may be used and provides instructions for wiring and mounting the keypads. A preliminary check-out procedure is also provided to ensure that the connected keypads are functioning properly in the system. Keypads That May Be Used •...

  • Page 16: Mounting The Keypads

    Figure 5. Keypad Connections To The Control Board Mounting the Keypads 1. Make sure addressable type keypads (4137AD, 5137AD, 6128, 6137, 6138, and 6139) are set to non-addressable mode (address 31), which is the factory default setting. Refer to the instructions provided with the keypad for address setting procedure.

  • Page 17: Preliminary Check-Out Procedure

    Figure 6. Using A Supplementary Power Supply For Keypads Preliminary Check-out Procedure If you want to check that the system is working before connecting field wiring from zones and devices, do the following: 1. Temporarily connect a 1000 ohm end-of-line resistor across each of the basic hard-wire zones 1–6, as shown in the Summary of Connections diagram.

  • Page 18: Basic Hard-Wired Zones 1-6

    Section 4. BASIC HARD-WIRED ZONES 1–6 This section provides general information for the hard-wired zones in the system, plus specific instructions for installing 4-wire smoke/combustion detectors. Also included is a procedure for programming the hard-wired zones. Installing the Hard-Wired Zones Common Characteristics for Zones 1–6 •...

  • Page 19: Compatible 4-Wire Smoke/Combustion Detectors

    Compatible System Sensor 4-Wire Smoke/Combustion Detectors 1412 2412 2412TH A77–716B 2112/24T Programming Hard-Wired Zones 1. With at least one 2-line Alpha keypad (5137AD or 6139) connected to the keypad terminals on the control, power up the system temporarily. If you had previously connected the AC transformer to the control panel, you need only plug in the transformer (to 120VAC outlet) to power up the system.

  • Page 20: Programming Panic Keys

    You must enter “00” as the zone type for any hard-wired zones that are not used. 02 Report Code 1st 03 2nd 12 Typical summary display Zn ZT – RC 02 03 – 3C Program Alpha? 0 = No 1 = Yes Enter Zn Num.

  • Page 21: Check-Out Procedure For Hard-Wired Zones 1-6

    When you have programmed all the hard-wired zones and Panic keys satisfactorily, exit entering [ 0] [ 0] as the next zone number. Then exit the programming mode by keying 99. See the special notes below, then proceed to the check-out procedure that follows.

  • Page 22: Wireless (Rf) Zone Expansion (5700 & 5800 Rf Systems)

    Section 5. WIRELESS (RF) ZONE EXPANSION (5700 AND 5800 RF SYSTEMS) This section provides the following information: • Wireless systems available. • Installing the wireless receiver. • Installing the 5800TM Module. • Programming for the wireless receiver. • Setup and installation of the wireless transmitters (5700 or 5800 series). •...

  • Page 23: Transmitter Battery Life

    The supervision for a particular transmitter in the 5800 system may be turned off by entering it as a "UR" (unsupervised RF) type, as described later. 5800 series transmitters have built-in tamper protection and will cause a “CHECK” condition to be annunciated if covers are removed. Each transmitter is also supervised for low battery and will transmit a low bat- tery signal to its receiver, with the battery having at least 30 days of life remain- ing.

  • Page 24: Installing The 5800Tm Module

    NOTE: WHEN CIRCUIT BOARD IS MOUNTED IN CONTROL’S CABINET, GROUNDING LUGS (2) PROVIDED MUST BE INSERTED IN LEFT-HANDTER- MINALS OF ANTENNA BLOCKS AND SECURED TO CABINET (SEE RECEIV- ER’S AND CONTROLS INSTRUCTIONS) MOUNTING INTERFERENCE HOLES INDICATOR TO RELEASE CIRCUIT BOARD, REMOVE SCREWS (2) AND BEND BACK TABS (S) Figure 8.

  • Page 25: Setting The Dip Switches On 5700 Series Wireless Transmitters

    Setting the DIP Switches Set the DIP switches on each 5700 series transmitter to the appropriate on 5700 Series zone/ID number and House ID. Refer to the Compatible 5700 Series Transmitters Transmitters table on a following page in this section for zone numbers and programming information for each particular transmitter.

  • Page 26: Dip Switch Tables For 5700 Rf System Wireless Devices

    DIP SWITCH TABLES FOR 5700 RF SYSTEM WIRELESS DEVICES HOUSE ID 5701 PANIC TRANSMITTER SWITCH SETTING FOR ALL DEVICES EXCEPT 5716 HOUSE ID (1 SHOWN) DIP SWITCH POSITION DEVICE 1 2 3 4 5 6 — — — — — —...

  • Page 27: Compatible 5700 Series Transmitters

    Compatible 5700 Series Transmitters Model Product 5701 Panic Transmitter 5706 Photoelectric Smoke Detector 5711 Slimline Door/ Window Transmitter 5715WH Universal Transmitter 5716 Door/Window 5716WM Transmitter 5742 Audio Discriminator 5743 Dual Technology Glassbreak Detector 5775 PIR Detector 5727 Wireless Keypad 5827BD Wireless Keypad (usable in a 5700 System) 5799...

  • Page 28: Programming The Control For A 5700 Wireless System

    Programming the Control For a 5700 Wireless System 1. With at least one two-line Custom English keypad wired and set to address 31 (default), power up the system temporarily by plugging the AC transformer (previously wired to the control) into a 120VAC outlet. 2.
  • Page 29 Data field 22 RF SYSTEM TYPE, must have been programmed for a 5700 RF system (“1”). Also, the House ID should have been entered in field 24, and all 5700 transmitters set to the same House ID. 4. Press 56. (Zone Programming Mode) Use this mode to program zone numbers, zone types, and alarm report codes for all 5700 wireless zones that are going to be used in the system.

  • Page 30: Go/Nogo Test

    Typical summary display Zn ZT – RC In: 20 03 – 3C RF: P r o g r a m A lph a ? 0 = No 1 = Ye s 0 En te r Zn Nu m . ( 0 0 = Q u it) Special Notes on Zone •...

  • Page 31: 5800 Series Transmitter Setup

    • If the keypad does not beep, re-orient or move the transmitter to another location. Usually a few inches in either direction is all that is required. 3. Mount the transmitter according to the instructions provided with the transmitter. 4. Exit the GO/NO GO test mode by entering Installer Code + (OFF ). You should now proceed to “Check-Out Procedure for Wireless Zones”...

  • Page 32: Compatible 5800 Series Transmitters

    Compatible 5800 Series Transmitters Model Product 5801 Wireless Panic Transmitter 5802 Pendant (Personal Emergency Transmitter) 5802CP Belt Clip (Personal Emergency) 5802MN Miniature (Personal Emergency Transmitter) 5804 Wireless Key Transmitter 5806 Wireless Photoelectric 5807 Smoke Detectors 5808 Wireless Photoelectric Smoke Detector 5816 Door/Window Transmitter:...

  • Page 33: Programming The Rf Transmitters (5800 Rf Systems)

    Compatible 5800 Series Transmitters (Continued) Model Product 5819 Shock Processor Transmitter 5827 Wireless Keypad 5827BD Wireless Two-Way Keypad (used with 5800TM) 5850 Glass Break Detector (GBD) 5890 PIR Detector 5899 Magnets Programming the RF Transmitters (5800 RF Systems) 1. With at least one 2-line Alpha keypad connected to the keypad terminals, 2.

  • Page 34: Enrolling 5800 Transmitters Into The System

    24. RF HOUSE ID CODE The House ID identifies a 5827 or 5827BD Wireless keypad if it is used (enter 01–31). The wireless keypads should be set to the same ID. If no wireless keypad is to be used, leave as “00”. Enrolling 5800 Transmitters Into The System There are two methods that may be used to enroll transmitters.
  • Page 35 A display will appear, showing a summary of that zone's programming. ZN ZT – RC I n : L If the zone is not programmed, the display will appear as shown here. If 1 0 0 0 – 0 0 RF : 1 checking a zone's programming, and it is programmed satisfactorily, press [#] to back up one step and enter another zone number, if desired.
  • Page 36 The system will enroll the serial number of the first transmitter heard, 10 Input S/N: add the loop number entered to this serial number, display the serial A002-4064 and loop numbers, and cause the keypad to beep twice. If the serial and loop number combination is already present in the system, a single long beep will be heard from the keypad.

  • Page 37: To Either Temporarily Or Permanently Remove A Zone From The System (5800 System)

    To Either Temporarily Or Permanently Remove A Zone From The System (5800 System). 1. Enter the programming mode: 2. Enter the zone number and press [ ]. A summary display will appear. 3. Press [ ] again. 2 0 Zo n e T ype No t Use d 2 0 De le te Zo n e ? 1 = Ye s...
  • Page 38 Go/No Go Test Before mounting transmitters permanently, conduct Go/No Go tests to verify (5700/5800 adequate signal strength and reorient or relocate transmitters if necessary. RF Systems) During this mode, wireless receiver gain is reduced by 50%. Testing in this mode assists in determining good mounting locations for the transmitters and verifies that the RF transmission has sufficient signal amplitude margin for the installed system.

  • Page 39: Section 6. Relay Output Devices

    Section 6. RELAY OUTPUT DEVICES Relay Device Basics Relays are programmable switches that can be used to perform many different functions. They can be used to turn lights on and off, control sounders, or for status indications. In this system, each relay must be programmed as to how to act (ACTION), when to activate (START), and when to deactivate (STOP).
  • Page 40 The letter(s) in parentheses after each function described below, such as (A) after ACTION, are those that appear in the various summary displays of programmed data during programming. ACTION (A) The "ACTION" of the relay is how the relay will respond when it is activated by the "START"...

  • Page 41: Programming Output Relays

    STOP (STP): 1. RESTORE ZONE LIST (ZL). If a "ZONE LIST" is used as 1. ZONE TYPE/SYSTEM OPERATION (ZT). Instead of using Programming Output Relays 1. With at least one 2-line Alpha keypad (5137AD or 6139) connected to the keypad terminals on the control, power up the system temporarily. If you had previously connected the AC transformer to the control panel, you need only plug in the transformer (to 120VAC outlet) to power up the system.
  • Page 42 Output Relay Displays Upon pressing 80, this screen will appear. Enter the Relay Number 01, 02, Enter Relay No. 03, or 04 for a 4204 (or 00 to end these entries). Press the [ ] key to (00 = Quit) continue.

  • Page 43: Example Of Output Relay Programming

    The display then returns again to the first screen so that the next relay number to be programmed can be entered, or enter [0][0] to end relay programming. Previously entered data can be reviewed by pressing [#] [8] [0]. After the relay number is chosen, press [ ] to go to the next screens.

  • Page 44: 4285 Phone Module

    Section 7. 4285 PHONE MODULE This section provides instructions for mounting the 4285 Phone module, wiring the Phone module and for programming the system for phone access via the Phone module. Installing the Phone module General Information The 4285 Phone module is an add-on accessory for the VISTA–10SE that permits access to the security system via a Touch-tone phone (either on premises or by a call-in when away).

  • Page 45: Caller Id Units

    1. Make 12V (+) and (–) and data in and data out connections from the Phone module to the control, using the connector cable supplied with the Phone module (see Figure 10). Color Lead GREEN BLACK YELLOW 2. Insert the keyed connector at the other end of the connector cable into the mating header on the Phone module (see diagram on next page for location of the header).

  • Page 46: Figure 10. 4285 Phone Module Wiring Connections

    1. Wire the 4285 Phone module exactly as shown, using a direct-connect cord and RJ31X jack. 2. If Touch-tones are not heard when pressing keys following phone access to the security system via an on-premises phone , try reversing the pair of wires connected to terminals 3 & 4 on the 4285, and the pair of wires connected to terminals 17 &...

  • Page 47: Programming The Control For Phone Access

    Programming The Control For Phone Access 1. With at least one addressable keypad (but set to the non-addressable mode, address 31) connected to the keypad terminals on the control, power up the system temporarily. If you had previously connected the AC transformer to the control panel, you need only plug in the transformer (to 120VAC outlet) to power up the system.

  • Page 48: Checking The Operation Of The 4285 Phone Module

    Checking the Operation of the 4285 Phone module To Check Phone module Operation From an On-Premises Phone 1. Pick up phone and enter the programmed 2-digit phone code (entered in field system status report should automatically start. See the User’s Guide accompanying the Phone module for detailed information regarding the nature of the status report, if necessary.

  • Page 49: Section 8. External Sounders

    Section 8. EXTERNAL SOUNDERS This section provides a list of compatible sounders, connection information for an external sounder and programming procedures for those options that affect the operation of external sounders. Compatible Sounders Ademco AB-12M 10” Motorized Bell & Box Ademco 1011BE12M 10”...

  • Page 50: Sounder Connections

    This control complies with NFPA requirements for temporal pulse sounding of fire notification appliances. Temporal pulse sounding for a fire alarm consists of the following: 3 pulses – pause – 3 pulses – pause – 3 pulses. . . repeated. Sounder Connections The VISTA–10SE provides a 12 VDC output which can power external alarm sounders (bells or sirens, see compatible sounders listed previously).

  • Page 51: Section 9. Long Range Radio

    Section 9. LONG RANGE RADIO General Information Check availability of Model 7720PLUS or 7820 long range radio. If output to long range radio is selected, all messages that are programmed to go to the primary telephone line receiver will also be sent to the 7720PLUS or 7820 long range radio.

  • Page 52: Audio Alarm Verification (Aav) Unit

    Section 10. AUDIO ALARM VERIFICATION (AAV) General Information An Audio Alarm Verification (AAV) module, such as the Eagle 1241, is an add- on accessory that permits voice dialog between an operator at a central station and a person at the alarm installation, for the purpose of alarm verification. Alarm reports must be programmed for the primary phone number to enable this feature.

  • Page 53: Figure 13. Connection Of Aav Unit When Not Using A 4285 Phone Module

    TERMINALS ON CONTROL REFER TO AAV MODULE INSTRUCTIONS FOR CONNEC- TIONS TO AUDIO SPEAKERS AND MICROPHONE INPUT TRIGGER RING Figure 13. Connection Of AAV Unit When Not Using A 4285 Phone module GRAY (RING) 4285 BROWN (TIP) TERMINALS 17 18 ON CONTROL REFER TO AAV MODULE...

  • Page 54: Section 11. Final Power Up

    Section 11. FINAL POWER UP In previous sections, you made temporary power connections for the purpose of programming and testing. This section provides information about final power-up procedures and battery size calculations. Earth Ground Connections The designated earth ground terminal (21) must be terminated in a good earth ground for the lightning transient protective devices in this product to be effective.

  • Page 55: Making The Battery Connections

    Making the Battery 1. Use the battery standby formula (shown on previous page) to select the Connections appropriate battery for the installation. Remember, when calculating the battery size needed, you must add the 100mA drawn by the control itself to the total Auxiliary current draw in the worksheet below.

  • Page 56: Alpha Descriptor Programming

    ALPHA DESCRIPTOR PROGRAMMING This section provides instructions for programming Alpha descriptors This is recommended for systems using Alpha keypads, and necessary if a 4285 Phone module is used. Alpha descriptors cannot be displayed on fixed-word keypads. If using a 4285 Phone module, select from those words in the Alpha Vocabulary list (on a following page) shown in boldface type.
  • Page 57 4. Press “0” (No).* The system will then If a descriptor was not entered previously Default Descriptor for zone 1, the default descriptor for zone ZN 0 1 ZO NE 0 1 1 will be displayed. Note that no entries can be made. Entries can be made only when the display contains a flashing cursor, which signifies the “entry mode”.

  • Page 58: Alternate Method For Programming Zone Descriptors

    Alternate Method For Programming Zone Descriptors 1. Perform steps 1 through 5 of the previous method. 2. Note that the first letter of the alphabet appears after the zone number, When entering the Zone Descriptors using this method, the keypad keys perform following functions:...

  • Page 59: Adding Custom Words

    4. For selection of the next word (e.g., DOOR), repeat step 3, as follows: 5. When all desired words have been entered, press [8] to store the 6. Enter NN, where NN is the next zone that you want to review or for which Adding Custom Words (will not be annunciated by 4285 Phone module) You can add up to five installer-defined words can be added to the built-in vo- cabulary.

  • Page 60: Alpha Vocabulary List (For Entering Zone Descriptors)

    NOTE : Some rarely-used words appearing in previously published lists have been deleted from the list below. Use only this list for selecting zone descriptors. (Word Space) • 057 DOOR • 059 DOWN • 060 DOWNSTAIRS • 001 DRAWER • 002 ALARM •...

  • Page 61: Sequential Mode

    Section 13. SEQUENTIAL MODE (for 5800 Series Wireless Transmitters) (Use this mode only after all other zone information has been programmed, including transmitter loop numbers). There are two methods of enrolling – you can enroll each transmitter into the system as you are entering the zone information in field 56 (the procedure will be found in the WIRELESS (RF) ZONE EXPANSION section), or you can enroll all the transmitters in information has been entered in field 56.
  • Page 62 5. This prompt is displayed when the system has found the next zone 10 Input S/N: which needs to be enrolled. Axxx xxxx The system will respond to the first serial number transmitted. A serial number may be enrolled by one of two methods: a) Enter the 7 digit serial number printed on the transmitter b) Activate the transmitter by faulting or restoring the input you wish to If you do not wish to enroll the zone displayed, press the [#] key on...
  • Page 63 7. The system will search for the next zone that does not have a serial number associated with it. If one is found, the prompt in step 5, along with the appropriate zone number, will be displayed. Follow steps 5 and 6 for the remaining wireless zones.

  • Page 64: Section 14. System Communication

    Section 14. SYSTEM COMMUNICATION This section provides an explanation of formats this system accommodates for reporting alarms and other system conditions to the central station. The process of a successful transmission consists of both the method of communication between the control panel and the central station receiver and the actual way the information is sent and displayed at the central station.
  • Page 65 Report Alarm Trouble Bypass AC Loss Low Batt Open Close Test Restore Alarm AC Restore LoBat Res. Trouble Res. Bypass Res. Where: Where: SSS or SSSS = Subscriber ID A = Alarm Code–1st digit Z = Typically Zone Number*–2nd digit T t = Trouble Code (1st &...

  • Page 66: Table Of Contact Id Event Codes

    TABLE OF CONTACT ID EVENT CODES Code Definition Fire Alarm Duress Alarm, 24-hour Silent Alarm, 24-hour Audible Panic Alarm, Perimeter, Burg. Alarm, Interior, Burg. Alarm, Entry/Exit, Burg. Alarm, Day/Night, Burg. Alarm, 24 Hour Auxiliary AC Power Low System Battery/Battery Test Fail Expansion Module Fail Long Range Radio Trouble Fire Loop Trouble...
  • Page 67 Press Press 46 Press Can only be used if Primary reporting format is Ademco Contact ID. If reporting to Pager, choose from 6, 7, 8, or 9, as desired. Entries 6 through 9 will send a report to a pager (in addition to the selected primary phone number), but you must enter the pager number as the secondary phone number in field 42.
  • Page 68 Example 1. Pager displays: This indicates that Subscriber No. 1234’s system is reporting an Alarm (911), due to zone 4 being faulted (004). Example 2. Pager displays: This indicates that Subscriber No. 1234’s system is reporting an opening (001) by User 5 (005). Note that no restore reports are sent to the pager.
  • Page 69 Press 63 LOW BAT REPORT CODE This will be sent when a low battery condition exists in the system’s standby battery. Note: Connection to the standby battery is checked every 3 minutes (CSFM requirement). Press 64 TEST REPORT CODE This is sent periodically to test that the communicator and phone lines are operational (frequency of report is selected in field 51).
  • Page 70 Press 74 LOW BAT RESTORE REPORT CODE This is sent when a system low battery condition is restored to normal. Press 75 RF XMTR. LOW BATTERY RESTORE CODE This is sent when a transmitter that previously sent in a low battery message has sent a message indicating it no longer has a low battery condition.

  • Page 71: Section 15. Testing The System

    Section 15. TESTING THE SYSTEM Test Procedure After installation is completed, the System should be carefully tested, as follows: 1. With the System in the disarmed state, check that all zones are intact. If a NOT READY message is displayed, press the [ ] key to display the faulted zone(s).

  • Page 72: To The Installer

    To test the wireless part of the system and the RF Receiver, perform the two following tests: Transmitter Sniffer Mode and Go/NoGo Test Mode . TRANSMITTER SNIFFER MODE Make sure the system is disarmed before trying to enter this mode. Key Installer code + # + 3.

  • Page 73: Section 16. System Operation

    Section 16. SYSTEM OPERATION Security Codes Installer Code The installer programs the 4-digit Installer Code initially as part of the programming procedure. The factory default Installer code is "4-1-1-1", but may be changed in field 20. Note: The Installer Code is defined as User #1. The Installer code is the only code that can allow re-entry into programming mode.

  • Page 74: Keypad Functions

    Keypad Functions General Note that if you enabled QUICK ARM (field 21), the [#] key can be pressed Information instead of entering the security code, for any of the arming procedures (Away, Stay, Instant, Maximum, etc.). The security code is always required, however, when disarming the system.

  • Page 75: Panic Keys

    Panic Keys There are three individual panic keys or, on some keypads, panic key pairs. If programmed, they can be used to manually initiate alarms and send a report to the central station. Each key (or key pair) can be individually programmed for 24-hour Silent, Audible, Personal or Fire Emergency responses.

  • Page 76: Trouble Conditions

    • The " interior zone occurs within two minutes after the end of an exit delay. In any of the previous cases, use a second OFF sequence (code plus OFF key) to clear the display. Trouble Conditions (See Troubleshooting Guide also) General The word "CHECK"...

  • Page 77: Section 17. Troubleshooting Guide

    Section 17. TROUBLESHOOTING GUIDE SYMPTOM 1. Transmitter signal not 1a. Transmitter or 4281/5881 not properly pow- received at 4281/5881. 1b. If Transmitter is 5827/5827BD , house ID 1c. Transmitter located too for from 4281/5881. 1d. Metal shielding between transmitter and 1e.
  • Page 78 TROUBLESHOOTING GUIDE SYMPTOM 7. Intrusion alarm for no ap- 7d. Magnetic contacts improperly connected or parent reason. (continued) 7e. Entry door programmed as “Instant” 8. Repeated low battery signal. 8a. Transmitter located where temperature 8b. Poor quality or unspecified battery in 8c.

  • Page 79: Contacting Technical Support

    CONTACTING TECHNICAL SUPPORT PLEASE, Before you call Technical Support, be sure you: • READ THE INSTRUCTIONS! • Check all wiring connections. • Determine that the power supply and/or backup battery are supplying proper voltages. • Verify your programming information where applicable. •...

  • Page 80: Section 18. Specifications & Accessories

    Section 18. SPECIFICATIONS & ACCESSORIES Specifications VISTA–10SE 1. Physical: SECURITY CONTROL 2. Electrical: 3. Communication: 4. Maximum Zone Resistance: Zones 1–6 = 300 ohms excluding EOLR. 5. Zone Response: 4127 1. Physical: REMOTE KEYPAD 2. Electrical: 3. Interface Wiring: To control panel's keypad connection points. 4137AD &...
  • Page 81 6127 1. Physical: REMOTE KEYPAD 2. Electrical: 3. Interface Wiring: Same as 4127. 6128 1. Physical: REMOTE KEYPAD 2. Electrical: 3. Interface Wiring: Same as 4127. 6137 1. Physical: REMOTE KEYPAD 2. Electrical: 3. Interface Wiring: Same as 4127. 6138 & 6139 1.

  • Page 82: Accessories (Compatible Devices)

    Accessories (Compatible Devices) No. 1321 No. 1321CN Sounders Ademco AB-12M 10” Motorized Bell & Box Ademco 1011BE12M 10” Motorized Bell & Box Ademco 702 Outdoor Siren Ademco 719 2-Channel Siren Ademco 747 Indoor Siren Ademco 747UL Indoor Siren Ademco 744 Siren Driver Ademco 745X3* Voice Siren Driver...

  • Page 83: Regulatory Agency Statements

    REGULATORY AGENCY STATEMENTS FEDERAL COMMUNICATIONS COMMISSION (FCC) Part 15 STATEMENT This equipment has been tested to FCC requirements and has been found acceptable for use. The FCC requires the following statement for your information: This equipment generates and uses radio frequency energy and if not installed and used properly, that is, in strict accordance with the manufacturer's instructions, may cause interference to radio and television reception.
  • Page 84 1. This is a "Grade A" residential system. 2. The 4285 Phone module and 7720PLUS or 7820 Long Range Radios have not been UL tested and cannot, therefore, be used in a UL installation. 3. The Entry Delay (field 38) cannot be greater than 45 seconds for UL installations. 4.
  • Page 85 CANADIAN DEPARTMENT OF COMMUNICATIONS (DOC) STATEMENT NOTICE The Canadian Department of Communications label identifies certified equipment. This certification means that the equipment meets certain telecommunications network protective, operational and safety requirements. The Department does not guarantee the equipment will operate to the user's satisfaction. Before installing this equipment, users should ensure that it is permissible to be connected to the facilities of the local telecommunications company.

  • Page 86: Limitations Of This Alarm System

    THE LIMITATIONS OF THIS ALARM SYSTEM While this System is an advanced design security system, it does not offer guaranteed protection against burglary, fire or other emergency. Any alarm system, whether commercial or residential, is sub ject to compromise or failure to warn for a variety of rea sons. For example: •...
  • Page 87 BATTERY FUSE (e.g. ADEMCO No. 90-12) GEL LEAD ACID TYPE. FOR REPLACEMENT BATTERY NORMALLY NEED NOT BE USE SAME VALUE REPLACED FOR AT LEAST 3 YRS. BATTERY CAPACITY FOR EMERGENCY STANDBY USE AT LEAST 4 HOURS. Wireless Bidirectional Keypad) – BLACK BATTERY CHARGING...

  • Page 88: Limited Warranty

    ADEMCO LIMITED WARRANTY Alarm Device Manufacturing Company, a Division of Pittway Corporation, and its divisions, subsidiaries and affiliates ("Seller"), 165 Eileen Way, Syosset, New York 11791, warrants its products to be in conformance with its own plans and specifications and to be free from defects in materials and workmanship under normal use and service for 24 months from the date stamp control on the product or, for products not having an Ademco date stamp, for 12 months from date of original purchase unless the installation instructions or catalog sets forth a shorter period, in which case the shorter...
