Daewoo RC-800 Service Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

RC800S0001
VACUUM CLEANER
Model : RC-800'S
DEC. 2004

Advertisement

Table of Contents
loading

Related Manuals for Daewoo RC-800

Summary of Contents for Daewoo RC-800

  • Page 1 RC800S0001 VACUUM CLEANER Model : RC-800'S DEC. 2004...

  • Page 2: Table Of Contents

    CONTENTS Page 1. SPECIFICATIONS & EXTERNAL VIEWS ----------- 2. DIAGRAM ----------------------------------------------------- 2-1. WIRING DIAGRAM 2-2. CIRCUIT DIAGRAM 3. TROUBLE SHOOTING GUIDE -------------------------- 4. DISASSEMBLING AND TREATMENT 4-1. CLEANER ASSEMBLY --------------------------------------- 4-2. BODY ASSEMBLY -------------------------------------------- 4-3. CASE MOTOR ASSEMBLY --------------------------------- 4-4. CORDREEL ASSEMBLY ------------------------------------ 4-5.

  • Page 3: Specifications & External Views

    EVA 1.5M HOSE ASSEMBLY MAIN NOZZLE Slim Brush PIPE Telescopic (Steel) Crevice Nozzle & Upholstery Nozzle NOZZLE 1-2. EXTERNAL VIEWS RC-800 항 목 A - Cord Rewind Button ○ B - Handle Grip ○ C - Telescopic Steel ○ D - Main Nozzle ○...

  • Page 4: Diagram

    2. DIAGRAM 2-1. WIRING DIAGRAM 2-2. CIRCUIT DIAGRAM...

  • Page 5: Trouble Shooting Guide

    3. TROUBLE SHOOTING GUIDE TROUBLE CAUSE COUNTERMEASURE SUCTION POWER FILTER BAG(PAPER)/DUST BOX IS CHANGE IT WITH NEW ONE (See 4-1) IS WEAK FULL WITH DUST REMOVE THE DUST IN DUST BOX FILTER PRE IS CLOGGY WITH DUST REMOVE THE DUST (See 4-1) CLOGGING OR TEAR IN HOSE REMOVE OBSTACLE OR REPLACE THE HOSE (See 4-5)

  • Page 6: Disassembling And Treatment

    4. DISASSEMBLING AND TREATMENT 4-1. CLEANER ASSEMBLY 1) Open the cover dust(1) and check the paper bag whether it is fulled or not. 2) Open the cover dust(1), unscrew the 4 screws(2). Lift the hadle(5), unscrew the 2 screws(2). Lift the cover assembly(4) up. 3) Check the connection between the terminals of motor, CR assembly, hose grip and PCB(8).

  • Page 7: Body Assembly

    4-2. BODY ASSEMBLY 1) Unscrew the 2 screws(7), take the socket(6) out of the body(1) 2) Check the breaking of the leads(2,3). 3) Check the gap between the body(1) and the rubber packing(4). 4) Check the movement of the paper bag sensor(5). 5) Check the filter whether it is cloggy with dust or not.

  • Page 8: Case Motor Assembly

    4-3. CASE MOTOR ASSEMBLY 1) Unscrew the 2 screws(1), take the cap motor(2) out of the case motor(3). 2) Take the motor(4) out of the case motor(3). 3) Check the motor(4) whether it is burnt out or not. 4) Check the connection between the motor and the leads. 5) After check the trouble of parts, assemble them into a motor assembly in the reverse order.

  • Page 9: Cordreel Assembly

    4-4. CR ASSEMBLY 1) Take the cordreel assembly out of the body assembly. 2) Unscrew the screw(2). 3) Separate the bobbin(4) from the bracket(1) and check the contacts between the Y terminals(3) and the ring type terminals(9). 4) Check the lever spring(6). 5) If the roller brake(7) is worn out and separate the lever(8) from the bracket(1), then replace the roller brake(7).

  • Page 10: Hose Assembly

    4-5. HOSE ASSEMBLY 1) Unscrew the 2 screws(26), lift cover(25) up. Check the knob(16), the slide volume(13) and the breaking of connections(20). 2) Check the button(27). 3) Unscrew the screw(23), lift the cover(22) up. Check the connection of lead(20) and contacts between the leads(2) and ring type terminals(19).

  • Page 11: Brush Assembly

    4-6. BRUSH ASSEMBLY 1) Unscrew the 4 screws(14), the screw(11) and take the pipe(9), the neck(6) out of the body(1). Check the cloggy dust in the pipe(9) and the neck(6). 2) Check the stopper spring. Check the roller(3,4)

  • Page 12: Exploded View And Parts List

    5. EXPLODED VIEW AND PARTS LIST 5-1. BODY ASSEMBLY (3620412110)
  • Page 13 7128401212 SCREW TAPPING T2S WAS 4X12 MFZN BK 3624707000 ROLLER BACK ASSY(PP+SBS) 3621436010 COVER ROLLER ABS + PAINTING 3628715000 TERMINAL CASE AS ASSY(RC-800), TER+WIRE+PRESW(75K) 7121301211 SCREW TAPPING T2S PAN 3X12 MFZN 3624008900 PACKING SOCKET 3628302100 PROTECTOR PVC-S 3629802100 SOCKET 7121401412...

  • Page 14: Case Motor Assembly

    5-2. CASE MOTOR ASSEMBLY (3621107800)
  • Page 15 3627901500 NR CASE MOTOR 3621107000 PP ABSORBER SOUND 3620113000 SPONGE T10 CAP MOTOR 3620904600 PP FILTER 3621909000 PE 3T SCREW TAPPING 7121401411 T2S PAN 4X14 MFZN PCB POWER CONTROL 3624315110 RC-800 220V/60HZ,PRESSURE 10 SCREW TAPPING 7121401411 T2S PAN 4X14 MFZN...

  • Page 16: Cordreel Assembly

    5-3. CORDREEL ASSEMBLY (3629508500)
  • Page 17 PART NAME PART CODE SPECS. Q'YT BOBBIN 3629200700 PP HOLDER TERMINAL 4565A36020 PP(5101SW,V-0) TERMINAL 4565A36024 C2600P-1/2H T0.3 TERMINAL 4565A36034 C2600P-1/2H T0.3 CORD POWER 3621304400 250V7A HVCTFK DUAL 6.5M SCREW TAPPING 7121401011 T2S PAN 4X10 MFZN SHAFT REEL 3624902300 PC SPRING AS 3625102020 SUS301-EH+COVER,5500MM SCREW TAPPING 7121300811 T2S PAN 3X8 MFZN...

  • Page 18: Cover Assembly

    5-4. COVER ASSEMBLY (3621438410)
  • Page 19 PART NAME PART CODE SPECS. Q'YT COVER DUST 3621436210 ABS + PAINTING CLAMP COVER 3621203400 ABS SPRING CLAMP COVER 3625110600 HSW3 HANDLE FRONT 3622603410 ABS+PAINT DECORATOR 3621600810 ABS + AL COATING SCREW TAPPING 7121401211 T2S PAN 4X12 MFZN COVER DUST INNER 3621436310 ABS + SILK PRINT DUST METER AS 3629704400 ASSY...

  • Page 20: Hose Assembly

    5-5. HOSE ASSEMBLY (3623207800)
  • Page 21 PART NAME PART CODE SPECS. Q'TY ADAPTER 3629101900 TERMINAL AS 3628710200 TERMINAL+WIRE(YL) TERMINAL AS 3628710400 TERMINAL+WIRE(BR) CLAMP ADAPTER 3621200900 SPRING 3625102900 HSW3 COVER ADAPTER 3621405900 SCREW TAPPING 7121301012 T2S PAN 3X10,BK HOSE 3623206700 EVA 1.5M CLAMP HOSE A 3623004500 CLAMP HOSE B 3623004600 EVA 1.5M HANDLE ADAPTER L...

  • Page 22: Pipe Assembly

    5-6. PIPE ASSEMBLY (3624411910) PART NAME PART CODE SPECS. Q'TY PIPE STEEL IN 3624411220 SPC T=0.7 PIPE STEEL OUT 3624411320 SPC T=0.7 GUIDE PIPE 3622503800 COVER UP 3621422500 COVER DOWN 3621422600 SHAFT PIPE 3624900810 STS 304-B SPRING PIPE 3625105200 HSWR PACKING PIPE 3624003910 LDPE...

  • Page 23: Brush Assembly

    5-7. BRUSH ASSEMBLY (3629308050)
  • Page 24 PART NAME PART CODE SPECS. Q'YT BODY BRUSH 3620409500 BRUSH 3629307710 ROLLER BRUSH 3624705200 ABS+PA SHAFT ROLLER 3624900900 PICKER LITTER 3627000700 PIPE BRUSH 3624412600 PIPE COVER 3624412550 ABS+CROME SCREW TAPPING 7121301211 T2S PAN 3X12 MFZN NECK BRUSH 3628002500 COVER NECK 3621425800 SCREW TAPPING 7128401012...
  • Page 25 TROUBLE CAUSE COUNTERMEASURE BROKEN REEL SPRING REPLACE IT (See 5-4) OF CORD REEL POWER CORD IS NOT WOUND UP POWER CORD BROKE AWAY REPAIR (See 5-4) FROM THE BOBBIN BE CAREFUL WHEN BREAKING UP THE CORD REEL, THE CAUTIO REELSPRING MAY SPRING OUT OF THE SPRING COVER.
