- Page 1 SERVICE MANUAL VACCUM CLEANER MODEL NAME : RC-1780GA...
-
Page 2: Table Of Contents
CONTENTS 1. SPECIFICATIONS…………………………………………………………………… 2 Pages 3 Pages 2. EXTERNAL VIEWS…………………………………………………………………… 3 Pages …………………………………………………………………… 2-1. ASSEMBLY 4 Pages 2-2. MODEL RC-L381(Variable Control)………………………………………………………… 5 Pages 3. DIAGRAM…………………………………………………………………………… 5 Pages ……………………………………………………………… 3-1. WIRING DIAGRAM 4. TROUBLE SHOOTING GUIDE……………………………………………………… 6 Pages 8 Pages 5. EXPLODED VIEW AND PARTS LIST……………………………………………… 8 Pages ………………………………………………………………... -
Page 3: Specifications
1.SPECIFICATIONS MODEL CL-178 RATED VOLTAGE AC 220-240V FREQUENCY 50/60Hz INPUT WATT MAX 1400W WEIGHT 2.6Kg DIMENSION(LXHXD) 312mm×230mm×214mm CORD LENGTH POWER CONTROL Body Variable Dust Meter Mechanical Extension Pipe Telescopic Tube Nozzle Rug And Floor Brush Upholstery Brush Crevice Nozzle... -
Page 4: External Views
2. EXTERNAL VIEWS 2-1. ASSEMBLY MODEL PART NAME CL-178 ㅇ A - DUST METER ㅇ B - SWITCH BUTTON ㅇ C - CORD REWIND BUTTON ㅇ D - POWER CORD ㅇ E - EXTENSION PIPE ㅇ F - HOSE HANDLE ㅇ... - Page 5 2-2. MODEL CL-178...
-
Page 6: Model Rc-L381(Variable Control)
3. DIAGRAM 3-1. WIRING DIAGRAM ■ MODEL : CL-178 (Variable Control) There potentiometer... -
Page 7: Trouble Shooting Guide
4. TROUBLE SHOOTING GUIDE TROUBLE CAUSE COUNTERMEASURE SUCTION POWER FILTER BAG(PAPER OR CLOTH) CHANGE IT WITH NEW ONE IS WEAK IS FULL WITH DUST OR REMOVE THE DUST GOLGGLING OR TEAR IN HOSE REMOVE OBSCTACLE OR REPLACE THE HOSE DEFECTIVE MOTOR REPLACE THE MOTOR (SEE 5-4) CLEANER DOS... - Page 8 TROUBLE CAUSE COUNTERMEASURE POWER CORD IS BROKEN REEL SPRING REPLACE IT (SEE 5-5) NOT WOUND UP OF CORD REEL POWER CORD BROKE AWAY REPAIR (SEE 5-5) FROM THE BOBBIN ※ CAUTION : BE CAREFUL WHEN BREAKING UP THE CORD REEL, THE REEL SPRING MAY SPRING OUT OF THE SPRING COVER.
-
Page 9: Exploded View And Parts List
5. EXPLODED VIEW AND PARTS LIST 5-1.BASE ASSEMBLY... -
Page 10: Base Assembly
LIST OF BASE ASSEMBLY PART CODE PART NAME SPECS. Q`YT DAEWOO CHUNLAN BASE ASSEMBLY cloth dustbag CLPB-CL151-E01 CLOTH dustbag holder spring CLPB-CL150-A26 CARBON SPRING STEEL/BLACK inter filter CLPB-CL150-E04 EXPLODED SPONGE dustbag holder CLPB-CL178-A12 inlet bracket CLPB-CL150-A42 base CLPB-CL151-A01 front wheel... -
Page 11: Dust Cover Assembly
5-2.DUST COVER ASSEMBLY... - Page 12 LIST OF FRONT COVER ASSEMBLY PART CORD PART NAME SPECS. Q`YT DAEWOO CHUNLAN FRONT COVER ASSEMBLY front cover CLPB-CL178-A04 ABS front cover lock CLPB-CL178-A05 ABS lock spring CARBON SPRING STEEL/BLACK suction holder CLPB-CL178-A07 ABS spring ST4.0x12PH/A spring ST4x8PH/T airflow tube...
- Page 13 5-3.BACK COVER...
-
Page 14: Back Cover Assembly
LIST OF BACK COVER ASSEMBLY PART CORD PART NAME SPECS. Q`YT DAEWOO CHUNLAN BACK COVER ASSEMBLY rear cover CLPB-CL178-A01 button spring CARBON SPRING STEEL/BLACK on/off button CLPB-CL178-A02 knob CLPB-CL178-A10 cord rewinder button CLPB-CL178-A03 spring ST4x8PH/T fixup wheel holder CLPB-CL151-A10 fixup wheel... -
Page 15: Motor Assembly
5-4.MOTOR ASSEMBLY ② ① ③ PART CORD PART NAME SPECS. Q`YT DAEWOO CHUNLAN 1 motor 220-240V/1200-1400W/EFL 2 motor sealing ring CLPB-CL151-C01 RUBBER 3 motor holder CLPB-CL152-C07 RUBBER... -
Page 16: Cord Rewinder Assembly
5-5.CORD REWINDER ASSEMBLY... - Page 17 LIST OF CORD REEL ASSEMBLY PART CODE PART NAME SPECS. Q`YT DAEWOO CHUNLAN CORD REEL ASSEMBLY spring ST3.5x10PH/A(1PC) cord rewinder holder CLPB-CL151-A09 butterfly patch holder CLPB-JX050-B03 BRASS+PHOSPHOR BRONZE spring ST4X8PH/T(2PCS) big cuprum ring CLPB-JX050-B02 brass small cuprum ring CLPB-JX050-B01 brass...
