Daewoo RC-350 Service Manual

Hide thumbs Also See for RC-350:
Table of Contents

Advertisement

Quick Links

Download this manual
Service Manual
Vacuum Cleaner
Model: RC-350
Caution

: In this Manual, some parts can be changed for improving, their
performance without notice in the parts list. So, if you need the
latest parts information,please refer to PPL(Parts Price List) in
Service Information Center (http://svc.dwe.co.kr).
DAEWOO ELECTRONICS CO., LTD.
S/M No. : C3500KVEF0

Advertisement

Table of Contents
loading

Related Manuals for Daewoo RC-350

Summary of Contents for Daewoo RC-350

  • Page 1 : In this Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the latest parts information,please refer to PPL(Parts Price List) in Service Information Center (http://svc.dwe.co.kr). DAEWOO ELECTRONICS CO., LTD.

  • Page 2: Table Of Contents

         SPECIFICATIONS ..........................2 DIAGRAM ............................3 1. WIRING DIAGRAM ............................3 2. CIRCUIT DIAGRAM............................. 3 TROUBLE SHOOTING GUIDE ......................4 DISASSEMBLING AND TREATMENT ....................5 1. CLEANER ASSEMBLY..........................5 2. CORD REEL ASSEMBLY..........................6 EXPLODED VIEW AND PARTS LIST....................7 1.

  • Page 3: Specifications

    SPECIFICATIONS MODEL RC-350 R AT ED V O LTA G E /F R EQ U E N CY 230V /50Hz INP U T W AT T 1300W (M A X ) W E IG H T(B O D Y) 3.7kg...

  • Page 4: Diagram

    DIAGRAM 1. W IRIN G D IAGR AM 2. CIR CUIT DIAGRAM S /W 100 O H M TR IA C 0.15uP 275V D IA C 0.1uP 275V A C 47 O H M Y E L LO W M O TO R 1/4W B LU E P CB...

  • Page 5: Trouble Shooting Guide

    TROUBLE SHOOTING GUIDE TRO UBLE CAUSE CO UNTERMEASURE FILTER BAG(PAPER OR CLOTH) IS CHANGE IT WITH NEW ONE FULL WITH DUSH SUCTION POWER IS WEEK REMOVE OBSTACLE OR CLOGGING OR TEAR IN HOSE REPLACE THE HOSE DEFECTIVE MOTOR REPLACE THE MOTOR BREAKING IN POWER CORD REPAIR (AT BLADE TIP OR ROOT OF CORD)

  • Page 6: Disassembling And Treatment

    DISASSEMBLING AND TREATMENT 1. CLEANER ASSEMBLY 1) W hile standing the handle(1), unscrew the 2(+) screw. Lift the dust cover assem bly(2). 2) Seperate the case filter. Unscrew the 4(+) screw. 3) Rotate and lift the body cover assem bly(4).

  • Page 7: Cord Reel Assembly

    DISASSEMBLING AND TREATMENT 2. CORD REEL ASSEMBLY 1) Take the cord reel out of the body cover. 2) Unscrew the screw and separate the bobbin from the bracket and check the contacts between the Y term inals. At this tim e, the bobbin is rotated counterclockw ise due to the preserved winding. 3) If the reel spring is broken, unscrew the 2 screws and replace it.

  • Page 8: Exploded View And Parts List

    EXPLODED VIEW AND PARTS LIST 1. BODY ASSEMBLY PART N AME CODE S PEC Q’TY B O D Y 3620406300 RO LLER B A CK 3624703410 RO LLE R F R O NT 3624703600 SH A F T R O LLER 3624901000 S W RM B RA C K ET R O LLE R...

  • Page 9: Body Cover Assembly

    EXPLODED VIEW AND PARTS LIST 2. BODY COVER ASSEMBLY PA RT NAM E CO DE SPEC Q ’TY C O VE R B O D Y 3621416950 LEV E R CR 3623702000 S P R IN G LEV E R 3625104300 HS W 3 F RA M E S TO P P E R...

  • Page 10: Cord Power Assembly

    EXPLODED VIEW AND PARTS LIST 3. CORD POWER ASSEMBLY PART N AME CO DE SPEC Q’TY B O BB IN 3629200600 H O LD E R TE R M IN A L 4565A 36020 P C (V-0) T E R M IN A L 4565A 36024 C 2600P -1/2H T 0.3 T E R M IN A L...

  • Page 11: Dust Cover Aqssembly

    EXPLODED VIEW AND PARTS LIST 4. DUST COVER AQSSEMBLY PART N AME CODE SPEC Q’TY CO V E R D U S T 3621417000 A B S K R -2870 S O CK E T 3629800600 A B S K R -2870 CLA M P C O V ER 3621202000 A B S K R -2870...

  • Page 12: Hose Assembly

    EXPLODED VIEW AND PARTS LIST 5. HOSE ASSEMBLY PART NAME CODE SPEC Q’TY A D A PT ER P IPE 3629101700 H O LD E R H O S E 4569A 71021 RIN G H O S E 3624600200 H O S E 3623206300 E VA 1.8M CU F F HO S E...

  • Page 13: Wide Suction Brush Assembly

    EXPLODED VIEW AND PARTS LIST 6. WIDE SUCTION BRUSH ASSEMBLY P ART NAM E CODE SPEC Q’TY B O DY B R US H 3620406400 C O V ER B R US H 3621417200 N E CK B R US H 3628001600 P IP E B R US H 3624408300...

  • Page 14: Extension Pipe And Nozzles

    EXPLODED VIEW AND PARTS LIST 7. EXTENSION PIPE AND NOZZLES PART NAM E C ODE SPEC Q’TY P IP E EX T E N SIO N 3624408500 B R U S H D U ST IN G 3629305000 P P+N Y LO N H O LD ER N O Z Z LE 3623004200 P IC K ER LIT TE R...
  • Page 15 DAEWOO ELECTRONICS CO., LTD 686, AHYEON-DONG MAPO-GU SEOUL, KOREA C.P.O. BOX 8003 SEOUL, KOREA TELEX : DWELEC K28177-8 CABLE : “DAEWOOELEC” E-mail : G7F00E@web.dwe.co.kr FAX : 02) 360-8184 TEL: 02) 360-8179~8180 PRINTED DATE : NOV. 1998...
