All manuals and user guides at all-guides.com
Service Manual
Vacuum Cleaner
Model: RC-6003F
DAEWOO ELECTRONICS CO., LTD.
http : //svc.dwe.co.kr
S/M No. : RC-600-EF0
RC-6004F
RC-6004B
RC-6005B
Dec. 2000

Advertisement

Table of Contents
loading

Related Manuals for Daewoo RC-6003F

Summary of Contents for Daewoo RC-6003F

  • Page 1 All manuals and user guides at all-guides.com S/M No. : RC-600-EF0 Service Manual Vacuum Cleaner Model: RC-6003F RC-6004F RC-6004B RC-6005B DAEWOO ELECTRONICS CO., LTD. http : //svc.dwe.co.kr Dec. 2000...

  • Page 2: Table Of Contents

    All manuals and user guides at all-guides.com CONTENTS 1. SPECIFICATIONS ......................2 2. EXTERNAL VIEWS ......................2 2-1. ASSEMBLY ............................2 2-2. MODEL RC-6003F, RC-6004F, RC-6005B ..................2 3. DIAGRAM 3-1. WIRING DIAGRAM .......................... 2 3-2. CIRCUIT DIAGRAM ........................2 4. TROUBLE SHOOTING GUIDE ..................2 5.

  • Page 3: Specifications

    All manuals and user guides at all-guides.com 1. SPECIFICATIONS Model RC-6003F RC-6004F RC-6004B RC-6005B Rated Voltage AC 230V AC 230V AC 230V AC 230V Frequency 50/60Hz 50/60Hz 50/60Hz 50/60Hz Input Watt MAX 1300W MAX 1400W MAX 1400W MAX 1500W Weight(Body) 4.1Kg...

  • Page 4: External Views

    All manuals and user guides at all-guides.com 2. EXTERNAL VIEWS 2-1. ASSEMBLY MODEL PART NAME RC-6003F RC-6004F RC-6004B RC-6005B A - DUST METER B - SWITCH BUTTON C - CORD REWIND BUTTON D - POWER CORD E - CLEANING TOOL(Dusting Tool)

  • Page 5: Model Rc-6003F, Rc-6004F, Rc-6005B

    All manuals and user guides at all-guides.com 2-2. MODEL RC-6003F, RC-6004F, RC-6004B, RC-6005B...

  • Page 6: Diagram

    All manuals and user guides at all-guides.com 3. DIAGRAM 3-1. WIRING DIAGRAM MODEL : RC-6003F, RC-6004F (DEG) MODEL : RC-6004B, RC-6005B...
  • Page 7 All manuals and user guides at all-guides.com MODEL : RC-6003F, RC-6004F (DEPOL)

  • Page 8: Circuit Diagram

    All manuals and user guides at all-guides.com 3-2. CIRCUIT DIAGRAM MODEL : RC-6003F, RC-6004F (DEG) MODEL : RC-6004B, RC-6005B...
  • Page 9 All manuals and user guides at all-guides.com MODEL : RC-6003F, RC-6004F (DEPOL)

  • Page 10: Trouble Shooting Guide

    All manuals and user guides at all-guides.com 4. TROUBLE SHOOTING GUIDE TROUBLE CAUSE COUNTERMEASURE FILTER BAG(PAPER OR CLOTH) CHANGE IT WITH NEW ONE IS FULL WITH DUST OR REMOVE THE DUST SUCTION POWER REMOVE OBSCTACLE CLOGGING OR TEAR IN HOSE IS WEAK OR REPLACE THE HOSE REPLACE THE MOTOR...
  • Page 11 All manuals and user guides at all-guides.com TROUBLE CAUSE COUNTERMEASURE BROKEN REEL SPRING REPLACE IT (SEE 5-3) OF CORD REEL POWER CORD IS NOT WOUND UP POWER CORD BROKE AWAY REPAIR(SEE 5-3) FROM THE BOBBIN CAUTION - BE CAREFUL WHEN BREAKING UP THE CORD REEL, THE REEL SPRING MAY SPRING OUT OF THE SPRING COVER.

  • Page 12: Disassembling And Treatment

    All manuals and user guides at all-guides.com 5. DISASSEMBLING AND TREATMENT 5-1. CLEANER ASSEMBLY 1) TAKE THE GRILL OUT OF THE COVER BODY. 2) TAKE THE COVER TOP OUT OF THE COVER BODY BY USING AN AWL. 3) SEPARATE THE COVER DUST ASSEMBLY FROM THE COVER BODY. 4) UNSCREW THE 4 SCREWS(2) THEN LIFT THE COVER BODY UP FROM THE BODY ASSEMBLY.

  • Page 13: Motor Assembly

    All manuals and user guides at all-guides.com 5-2. MOTOR ASSEMBLY 1) TAKE THE MOTOR ASSEMBLY OUT OF THE BODY. 2) CHECK THE MOTOR(1) (WHETHER THE MOTOR IS BURNT OUT OR NOT).

  • Page 14: Cord Reel Assembly

    All manuals and user guides at all-guides.com 5-3. CORD REEL ASSEMBLY...
  • Page 15 All manuals and user guides at all-guides.com 1) TAKE THE CORD REEL OUT OF THE BODY. 2) UNSCREW THE SCREW(14) AND SEPARATE THE BOBBIN(1) FROM THE BRACKET(9) AND CHECK THE CONTACTS BETWEEN THE Y TYPE TERMINALS AND THE RING TYPE TERMINALS(3, 4).

  • Page 16: Cover Dust Assembly

    All manuals and user guides at all-guides.com 5-4. COVER DUST ASSEMBLY 1) UNSCREW THE 2 SCREWS(6) AND SEPARATE THE SOCKET(4) FROM THE COVER DUST(1).

  • Page 17: Cover Body Assembly

    All manuals and user guides at all-guides.com 5-5. COVER BODY ASSEMBLY 1) CHECK THE CONNECTIONS BETWEEN THE PCB ASSY(2) AND THE WIRE. 2) CHECK THE PCB ASSY(2). 3) CHECK THE SWITCH(4).

  • Page 18: Exploded View And Parts List

    All manuals and user guides at all-guides.com 6. EXPLODED VIEW AND PARTS LIST 6-1. CLEANER ASSEMBLY 1) MODEL RC-6003F, RC-6004F...
  • Page 19 All manuals and user guides at all-guides.com PART NAME PART CODE SPECS. Q TY BODY AS 3620409900 ASSY ASSY MOTOR 3620015400 ASSY(RC-6003F) ASSY MOTOR 3620014600 ASSY(RC-6004F) CORD REEL AS 3629507700 ASSY(DEG) CORD REEL AS 3629507730 ASSY(DEPOL) COVER BODY AS 3621428000...
  • Page 20 All manuals and user guides at all-guides.com 2) MODEL RC-6004B...
  • Page 21 All manuals and user guides at all-guides.com PART NAME PART CODE SPECS. Q TY BODY AS 3620409900 ASSY ASSY MOTOR 3620014600 ASSY CORD REEL AS 3629507700 ASSY COVER BODY AS 3621427800 ASSY SCREW TAPPTITE 7171402011 TT2 PAN 4X20 MFZN COVER DUST AS 3621427600 ASSY FILTER EXHAUST...
  • Page 22 All manuals and user guides at all-guides.com 3) MODEL RC-6005B...
  • Page 23 All manuals and user guides at all-guides.com PART NAME PART CODE SPECS. Q TY BODY AS 3620410100 ASSY ASSY MOTOR 3620014800 ASSY CORD REEL AS 3629507700 ASSY COVER BODY AS 3621428800 ASSY SCREW TAPPTITE 7171402011 TT2 PAN 4X20 MFZN COVER DUST AS 3621427600 ASSY FILTER EXHAUST...

  • Page 24: Body Assembly

    All manuals and user guides at all-guides.com 6-2. BODY ASSEMBLY 1) MODEL RC-6003F, 6004F, 6004B (3620409900)
  • Page 25 All manuals and user guides at all-guides.com PART NAME PART CODE SPECS. Q TY BODY 3620409400 ROLLER BACK 3624704900 BRACKET ROLLER 3620601500 ROLLER FRONT 3624703600 SHAFT ROLLER 3624901000 SWRM SCREW TAPPING 7128401212 T2S WAS 4X12 MFZN BK HOLDER BRUSH 3623005500 SCREW TAPPING 7121401412 T2S PAN 4X14 MFZN BK...
  • Page 26 All manuals and user guides at all-guides.com 2) MODEL RC-6005B (3620410100)
  • Page 27 All manuals and user guides at all-guides.com PART NAME PART CODE SPECS. Q TY BODY 3620409400 ROLLER BACK 3624704900 BRACKET ROLLER 3620601500 ROLLER FRONT 3624703600 SHAFT ROLLER 3624901000 SWRM SCREW TAPPING 7128401212 T2S WAS 4X12 MFZN BK HOLDER BRUSH 3623005500 SCREW TAPPING 7121401412 T2S PAN 4X14 MFZN BK...

  • Page 28: Cover Assembly

    All manuals and user guides at all-guides.com 6-3. COVER ASSEMBLY 1) COVER DUST ASSEMBLY(3621427600) PART NAME PART CODE SPECS. Q TY COVER DUST 3621426600 CLAMP COVER 3621202700 SPRING CLAMP 3625106400 HSW3 SOCKET 3629801400 SEALER SOCKET 3622301300 EVA, 2T SCREW TAPPING 7121301211 T2S PAN 3X12 MFZN DUST METER AS...
  • Page 29 All manuals and user guides at all-guides.com 2) COVER BODY ASSEMBLY (3621428000) MODEL : RC-6003F, RC-6004F (DEG) PART NAME PART CODE SPECS. Q TY COVER BODY 3621426500 PCB AS 3624307620 ASSY SCREW TAPPING 7121401411 T2S PAN 4X14 MFZN SWITCH PUSH...
  • Page 30 All manuals and user guides at all-guides.com 3) COVER BODY ASSEMBLY (3621427700) MODEL : RC-6003F, RC-6004F (DEPOL) PART NAME PART CODE SPECS. Q TY COVER BODY 3621426500 TERMINAL AS 3622713310 ASSY SWITCH PUSH 3629002000 7A/250V(SKT) BUTTON SWITCH 3626605500 SPRING BUTTON...
  • Page 31 All manuals and user guides at all-guides.com 4) COVER BODY ASSEMBLY (3621427800) MODEL : RC-6004B PART NAME PART CODE SPECS. Q TY COVER BODY 3621426500 PCB AS 3624312200 ASSY SCREW TAPPING 7121401411 T2S PAN 4X14 MFZN SWITCH PUSH 3629002000 7A/250V(SKT) BUTTON SWITCH 3626605500 SPRING BUTTON...
  • Page 32 All manuals and user guides at all-guides.com 4) COVER BODY ASSEMBLY (3621428800) MODEL : RC-6005B...
  • Page 33 All manuals and user guides at all-guides.com PART NAME PART CODE SPECS. Q TY COVER BODY 3621426500 PCB CONTROL AS 3624312200 ASSY SCREW TAPPING 7121401411 T2S PAN 4X14 MFZN SWITCH PUSH 3629002000 7A/250V(SKT) BUTTON SWITCH 3626605500 SPRING BUTTON 3625104300 HSW3 BUTTON CR 3626605600 PCB POWER CONTROL AS...

  • Page 34: Motor Assembly

    All manuals and user guides at all-guides.com 6-4. MOTOR ASSEMBLY PART NAME PART CODE SPECS. Q TY 3962511401 230V 1100W DMI, RC-6003F MOTOR UNIVERSAL 3962511500 230V 1200W DMI, RC-6004 3962511620 230V 1300W DMI, RC-6005B PACKING MOTOR 3624007300 ABSORBER SOUND 4569C10071...

  • Page 35: Cord Reel Assembly

    All manuals and user guides at all-guides.com 6-5. CORD REEL ASSEMBLY(3629507700) MODEL : RC-6003F, 6004F (DEG), RC-6004B, RC-6005B...
  • Page 36 All manuals and user guides at all-guides.com PART NAME PART CODE SPECS. Q TY BOBBIN 3629200600 HOLDER TERMINAL 4565A36020 PC (V-0) TERMINAL 4565A36034 C2600P-1/2H T=0.3 TERMINAL 4565A36024 C2600P-1/2H T=0.3 CORD POWER 3621302500 250V16A,H05VVH2F,6M SCREW TAPPING 7121301411 T2S PAN 3X14 MFZN SPRING AS 3625102005 SUS30-EH+COVER,3800MM...
  • Page 37 All manuals and user guides at all-guides.com 6-6. CORD REEL ASSEMBLY(3629507730) MODEL : RC-6003F, 6004F (DEPOL)
  • Page 38 All manuals and user guides at all-guides.com PART NAME PART CODE SPECS. Q TY BOBBIN 3629200600 HOLDER TERMINAL 4565A36020 PC (V-0) TERMINAL 4565A36034 C2600P-1/2H T=0.3 TERMINAL 4565A36024 C2600P-1/2H T=0.3 CORD POWER 3621302500 250V16A,H05VVH2F,6M SCREW TAPPING 7121301411 T2S PAN 3X14 MFZN SPRING AS 3625102005 SUS30-EH+COVER,3800MM...

  • Page 39: Hose Assembly

    All manuals and user guides at all-guides.com 6-7. HOSE ASSEMBLY(3623206210) PART NAME PART CODE SPECS. Q TY PIPE ADAPTER 3629101700 HOSE 3623206300 EVA 1.6M (NON-CURRENT) HOLDER HOSE 4569A71021 PIPE HOSE 3624408200 VALVE AIR 3625400400 CUFF HOSE 3626800200 LDPE PACKING HOSE 3624005900 SPONGE...

  • Page 40: Brush Assembly

    All manuals and user guides at all-guides.com 6-8. BRUSH ASSEMBLY 1) MODEL RC-6003F, RC-6004F(3629304920)
  • Page 41 All manuals and user guides at all-guides.com PART NAME PART CODE SPECS. Q TY BODY BRUSH 3620406400 ROLLER-F BRUSH 3624703100 SHAFT ROLLER 3624900900 PICKER LITTER 3622700700 PIPE BRUSH 3624408300 NECK BRUSH 3628001600 ROLLER-B BRUSH 3624703000 COVER BRUSH 3621417200 SCREW TAPPTITE 7171401411 TT2 PAN 4X14 MFZN...
  • Page 42 All manuals and user guides at all-guides.com 2) MODEL RC-6004B, RC-6005B (3629308300)
  • Page 43 All manuals and user guides at all-guides.com PART NAME PART CODE SPECS. Q TY COVER BRUSH 3621420800 PIPE BRUSH 3624412800 NECK BRUSH 3628002100 DUCT BRUSH 3629306300 SWEEPER BRUSH 3629306400 SHAFT SWEEPER 3624901400 HSW3 BUTTON BRUSH 3626604400 SCREW TAPPING 7128408011 T2S 4X8 SPRING BUTTON 3625107300 SK-5, T=0.3...

  • Page 44: Pipe Assembly

    All manuals and user guides at all-guides.com 6-8. PIPE ASSEMBLY 1) MODEL RC-6003F (3624408600) PART NAME PART CODE SPECS. Q TY PIPE EXTENSION 3624408600 2) MODEL RC-6004F, RC-6004B (3624409000) PART NAME PART CODE SPECS. Q TY PIPE STEEL 3624409000 SPC T=0.7(LD=32.6)
  • Page 45 All manuals and user guides at all-guides.com DAEWOO ELECTRONICS CO., LTD. 686, AHYEON-DONG MAPO-GU SEOUL, KOREA C.P.O. BOX 8003 SEOUL, KOREA TELEX: DWELEC K28177-8 CABLE: “DAEWOOELEC” TEL: 02) 360-7806 FAX: 02) 360-7877 http://svc.dwe.co.kr PRINTED DATE JAN.2001...
