NOTE:
Use the following device code digits to control
a specific device:
0 = Cable/STB
1 = TV
2 = DVD/VCR
3 = Audio
For example, to search for a code for your TV:
1. Turn on your TV.
2. On the remote control, press TV once; it blinks
once. Then press and hold SET UP until the TV
key blinks twice.
3. Enter 9 9 1. The TV key blinks twice.
4. Press 1 (the device code digit for your TV).
The TV key blinks twice. Aim the remote
control at the TV and press PWR once.
5. Press and release the CH+ key continuously,
then stop when the TV turns off.
NOTE:
In the search mode, the remote control sends
IR codes from its library to the selected
device, starting with the most popular code
first.
6. Press PWR. The TV should turn on, then press
SET UP to lock in the code.
NOTE: If the TV does not turn on during step 6, then
slowly press and release CH- to go back
through the codes, then press SET UP when
the TV turns on.
7. To search for the codes of your other devices,
repeat steps 1 through 5, but substitute the
appropriate key (e.g., AUX, DVD, CBL, or STB)
for the device you are searching for.

CHECKING THE CODES

If you have set up the C4000 and S4000 Remote Controls
by searching for your device code (on the previous
page), you may need to find out which five-digit code is
operating your equipment.
www.urcsupport.com
13
