4/21/03 4:21 PM Page 3 INTRODUCTION The Atlas XL Universal Remote Control by Universal Electronics is our latest generation universal remote con- trol.Its sophisticated technology allows you to consolidate up to four of your original home entertainment remote con- trols into one easy-to-use product.Moreover, it’s packed with advanced features such as: •...
Atlas XL Eng/Sp Manual 4/21/03 4:21 PM Page 4 FEATURES AND FUNCTIONS Use the illustration below to locate features on the Atlas XL Universal Remote Control. Then study the Key Charts (on the next two pages) to learn how they function.
Atlas XL Eng/Sp Manual 4/21/03 4:21 PM Page 5 Key Charts Use SETUP for all programming sequences. Press POWER once to turn on or off a home entertainment device. Press AUD, VCR, TV, or CBL once to select a home entertainment device to control.
Page 6
Atlas XL Eng/Sp Manual 4/21/03 4:21 PM Page 6 FEATURES AND FUNCTIONS Key Charts (continued) Use VOL+ (or VOL-) to raise (or lower) the audio volume. Use FAV to cycle through your favorite channels stored in your cable converter. Use CH+ (or CH-) to select the next higher (or lower) channel.
Atlas XL Eng/Sp Manual 4/21/03 4:21 PM Page 7 INSTALLING BATTERIES ❶ ❷ ❸ On the back of the remote control, push the tab and lift off the battery cover. Locate the two (2) enclosed AA batteries. Match the + and – marks with those in the battery case, then insert them.
4/21/03 4:21 PM Page 8 PROGRAMMING DEVICE CONTROL The Atlas XL Universal Remote Control is preprogrammed to operate the cable converter provided by your cable service provider, an RCA TV, an RCA VCR, and a Pioneer audio receiver. To control devices other than the default brands, perform the following steps;...
Page 9
Atlas XL Eng/Sp Manual 4/21/03 4:21 PM Page 9 Repeat steps 1 through 4 for each device you want the remote control to control. For future reference, write down each working device code in the following boxes: AUD Code VCR Code...
Atlas XL Eng/Sp Manual 4/21/03 4:21 PM Page 10 PROGRAMMING TV/VCR COMBO CONTROL If you own a TV/VCR Combo, perform the following instructions to control this device: Turn on your TV/VCR Combo and insert a video cassette. On the remote control, press VCR once.
SEARCHING FOR YOUR CODE If your home entertainment device does not respond to the Atlas XL Universal Remote Control after trying all of the codes listed for your brand, or if your brand is not listed at all, try searching for your code.
4:21 PM Page 12 CHECKING THE CODES If you have set up the Atlas XL Universal Remote Control using the Searching For Your Code procedure (on the pre- vious page), you may need to find out which four-digit code is operating your equipment. For example, to find out which code is operating your TV: On the remote control, press TV once.
Atlas XL Eng/Sp Manual 4/21/03 4:21 PM Page 13 PROGRAMMING CHANNEL CONTROL LOCK By default, the remote control’s channel-control capabilities are locked to the cable converter. The affected keys* are 0 ~ 9, CH+, CH-, ENTER, and LAST. This will guarantee that you do not inadvertently change a channel on your TV or VCR.
4:21 PM Page 14 USING THE MASTER POWER KEY The Atlas XL Universal Remote Control has a unique fea- ture that allows you to sequentially turn on or off up to four of your home entertainment devices with a single key press.
4:21 PM Page 15 REASSIGNING DEVICE KEYS The Atlas XL Universal Remote Control can be set up to control a second TV, PVR, DVD player, or VCR, or any combination of up to four home entertainment devices. For example, to have the unit control a TV, a Cable Con-...
4/21/03 4:21 PM Page 16 USING MACROS With programming, the MACRO key on your Atlas XL Universal Remote Control can be setup to perform repetitive, time-consuming operations through the press of a single key. A macro can be used to control a home theater operation,...
Atlas XL Eng/Sp Manual 4/21/03 4:21 PM Page 17 NOTE: To store three channels onto the MACRO key, repeat the six steps on the left two more times, substituting a new favorite channel in step 5 (e.g., 7 - 2 for channel 72).
4:21 PM Page 18 CHANGING VOLUME LOCK On the Atlas XL Universal Remote Control,Global Volume Lock is set to TV,so you can control TV volume while in the TV, VCR,or Cable mode.If desired, you can still perform Individual Volume Unlock on a selected device to set its volume control for independent operation.
Atlas XL Eng/Sp Manual 4/21/03 4:21 PM Page 19 To Lock Volume Control To One Mode (Global Volume Lock): NOTE: The audio mode’s volume controls are active regardless of Volume Lock settings. However, if you lock the volume controls to the AUD mode, you will have control of the audio device’s volume...
Atlas XL Eng/Sp Manual 4/21/03 4:21 PM Page 20 TROUBLESHOOTING (continued) PROBLEM: No volume on a second TV. SOLUTION: Follow instructions in Changing Volume Lock (see page 18). PROBLEM: CH+ , CH – , and LAST do not work for your RCA TV.
ADDITIONAL INFORMATION This product does not have any user-serviceable parts. Opening the case, except for the battery cover, may cause permanent damage to your Atlas XL Universal Remote Control. Copyright 2003 by Universal Electronics Inc.No part of this publication may be reproduced,transmitted,transcribed,...
4:21 PM Page 23 INTRODUCCIÓN El Control Remoto Universal Atlas XL de Universal Electronics es el control remoto universal de la más reciente generación. Su sofisticada tecnología le permite consolidar hasta cuatro de los controles remotos originales de los componentes del entreten- imiento de su hogar en un solo producto fácil de usar.
4:21 PM Page 24 CARACTERÍSTICAS Y FUNCIONES Use la ilustración de abajo para localizar las características en su Control Remoto Universal Atlas XL. Despues estudie las Tablas De Las Teclas (en las siguientes tres páginas) para que aprenda cómo funcionan.
Atlas XL Eng/Sp Manual 4/21/03 4:21 PM Page 25 Tablas De Las Teclas Use SETUP (Configuración) para todas las secuencias de programación. Presione POWER una vez para encender o para apagar un dispositivo del entretenimiento en el hogar. Presione AUD, VCR, TV, o CBL una vez...
Page 26
Atlas XL Eng/Sp Manual 4/21/03 4:21 PM Page 26 CARACTERÍSTICAS Y FUNCIONES Tablas De Las Teclas (continuación) Use VOL+ o VOL- para subir o bajar el volumen. Use FAV (Favoritos) para repasar sus canales favoritos guardados en su convertidor de cable.
Atlas XL Eng/Sp Manual 4/21/03 4:21 PM Page 27 Use TV/VCR para ver televisión o programas de vídeo. Para los amplifi- cadores/receptores, use esta tecla para la entrada o salida de señales. INSTALACIÓN DE LAS BATERÍAS ❶ ❷ ❸ En la parte de atrás del control remoto, presione la lengüeta y levante la tapa de la batería para quitarla.
Page 28 PROGRAMACIÓN DEL CONTROL DEL DISPOSITIVO (APARATO) El Control Remoto Universal Atlas XL está preprogramado para operar el convertidor de cable provisto por su abastecedor de servicio de cable, un televisor RCA, una videograbadora (VCR) RCA, y un receptor de audio Pioneer.
Page 29
Atlas XL Eng/Sp Manual 4/21/03 4:21 PM Page 29 Repita los pasos 1 al 4 por cada dispositivo que quiera controlar con el control remoto. Para referencia futura, anote cada uno de los códigos de dispositivo que funcionan en los cuadrados de abajo: Código AUD...
Atlas XL Eng/Sp Manual 4/21/03 4:21 PM Page 30 PROGRAMACIÓN DEL CONTROL DE UN APARATO COMBINADO TELEVISOR/VIDEOGRABADORA (TV/VCR) Si tiene un aparato combinado Televisor/Videograbadora, lleve a cabo las siguientes instrucciones para controlar el dispositivo: Encienda su aparato combinado TV/VCR e inserte un videocasete.
BÚSQUEDA DE SU CÓDIGO Si el dispositivo de su entretenimiento en el hogar no responde al Control Remoto Universal Atlas XL después de tratar todos los códigos listados para su marca, o si su marca no aparece en la lista, haga la siguiente prueba para buscar su código.
4:21 PM Page 32 VERIFICACIÓN DE LOS CÓDIGOS Si configuró el Control Remoto Universal Atlas XL usando el procedimiento de la sección Búsqueda De Su Código (en la página anterior), tal vez tenga que averiguar cuál código de cuatro dígitos es el que está operando su equipo. Por ejemplo, para descubrir cuál es el código que opera su televisor:...
Atlas XL Eng/Sp Manual 4/21/03 4:22 PM Page 33 PROGRAMACIÓN DEL BLOQUEO DEL CONTROL DE CANALES Como valor de fábrica, la capacidad del control remoto para controlar los canales está bloqueada por el convertidor de cable. Las teclas afectadas* son 0 ~ 9, CH+, CH-, ENTER, y LAST. Esto garantizará...
4:22 PM Page 34 USO DE LA TECLA DE ENCENDIDO MAESTRO El Control Remoto Universal Atlas XL tiene una característica única que le permite encender o apagar en secuencia hasta cuatro de los dispositivos de su entretenimiento en el hogar con sólo presionar una tecla.
Page 35 REASIGNACIÓN DE LAS TECLAS DEL DISPOSITIVO El Control Remoto Universal Atlas XL se puede configurar para que controle un segundo TV, PVR, reproductor DVD, o VCR, o cualquier combinación de hasta cuatro dispositivos de entreten- imiento en el hogar. Por ejemplo, para lograr que la unidad cont-...
UTILIZACIÓN DE MACROS Durante la programación, la tecla MACRO de su Control remoto universal Atlas XL puede ser configurada para realizar funciones repetitivas y lentas presionando una sola vez la tecla. Un macro puede ser utilizado para controlar el funcionamiento de un home theater (cine en casa), para configurar un canal o para otras múltiples funciones que usted quiera controlar con...
Atlas XL Eng/Sp Manual 4/21/03 4:22 PM Page 37 Eliminación De Macros: En el control remoto, presione y mantenga presionado SETUP hasta que el dispositivo seleccionado en último lugar parpadee dos veces.A continuación, suelte el botón SETUP. Presione 9-9-5. La tecla del dispositivo seleccionado en último lugar parpadeará...
Page 38 CAMBIO DEL BLOQUEO DEL VOLUMEN En el Control Remoto Universal Atlas XL, el Bloqueo Global Del Volumen está fijado a la TV, de tal manera que se puede controlar el volumen del televisor mientras se está en el modo TV, VCR, o Cable.
Atlas XL Eng/Sp Manual 4/21/03 4:22 PM Page 39 Para Bloquear El Control De Volumen A Un Modo (Bloqueo Global Del Volumen): NOTA: Los controles de volumen del modo de audio están activos inde- pendientemente de las fijaciones en el Bloqueo de Volumen. Sin embargo, si usted bloquea los controles de volumen al modo AUD, tendrá...
Atlas XL Eng/Sp Manual 4/21/03 4:22 PM Page 40 LOCALIZACIÓN DE FALLAS (continuación) PROBLEMA: No hay volumen en un segundo televisor. SOLUCIÓN: Siga las instrucciones en Cambio Del Bloqueo Del Volumen (vea la página 38). PROBLEMA: CH+, CH-, y LAST (Último) no funcionan en su televisor RCA.
Atlas XL Eng/Sp Manual 4/21/03 4:22 PM Page 48 MANUFACTURER’S CODES (CÓDIGOS DEL FABRICANTE) Setup Codes For TV/VCR Combos, Continued (Códigos De Configuración Para Aparatos Combinados Televisor/Videograbadora, Continuación): 0035 (for TV use 0051), 0048 (for TV use 0093), 0060 (for TV use 0047), 0240...
