RUGGEDCOM RSL910
Installation Guide
Figure 6: Terminal Block Wiring
1. Positive/Live (+/L) Terminal    2. Negative/Neutral (-/N) Terminal    3. Surge Ground Terminal    4. Braided Ground Cable
Connecting High AC/DC Power
1
2
3
Installing the Device
4
Chapter 2
13
