- Page 1 How to remove Jammed Paper B840/ES8140 Rev.1...
-
Page 2: Paper Jams
Paper Jams Paper jams occasionally occur due to paper misfeeding from a paper tray or at any point on the paper path through the printer. When a jam occurs, the printer immediately stops and the Alert LED on the Status Panel informs you of the event. For example: This document explains how to clear them quickly and simply. - Page 3 Error codes and Location Refer to the table below to find the location of the paper jam Error Code Location on Printer Refer to Page Duplex Unit Duplex Unit Multi Purpose Tray Duplex Unit Multi Purpose Tray Inside Printer Inside Printer/Paper Exit Inside Printer Inside Printer Inside Printer...
- Page 4 Error Code 372, 380, 390, 391 & 400 A paper jam has occured near the Multi Purpose Tray 1. Open the Multi Purpose Tray. 4. Slowly pull out the jammed paper in the direction of the arrow. 2. Push the blue handle, located in the centre, upward and open the front cover.
- Page 5 Error Code 382 A paper jam has occured near the exit 1. Press the release button to open the top Note: If paper has jammed at the paper exit and cover. you can see it inside the top cover (inside the printer), pull the jammed paper from the inside of the printer.
- Page 6 Error Code 381, 382, 383, 385 & 389 A paper jam has occured inside the printer 1. Press the release button to open the top 4. Cover the removed toner cartridge. cover. 5. When you can see the top edge of the 2.
- Page 7 6. When you cannot see the top edge nor 9. Hold the transfer roller by its left rotating bottom edge of the jammed paper move the shaft and remove it. When it is removable, lift paper foward in the direction of the arrow. the gear at the right side of the fuser simultaneously.
- Page 8 Error Code 370, 371 & 373 A paper jam has occured in the duplex unit 1. Pinch and lift the jam release lever of the 3. The cassette cover becomes detached duplex unit to open the duplex unit cover. when the duplex unit is removed. 2.
- Page 9 Error Code 392 & 393 A paper jam has occured in paper tray 2/tray 3 1. Pull out the paper cassette tray. 4. Push the blue handle, located in the centre, upward and open the front cover. 2. Remove the jammed paper. 5.
-
Page 10: Turning Off The Printer
Turning off the printer 1. Before turning off the printer, be sure to shut down by using the following procedure. Note: Pressing the OFF (O) side of the power switch suddenly, may cause the printer to be inoperable and could damage the printer. 2. -
Page 11: Printing A Menu Map
Printing a menu map 1. Print a status information page to make sure the printer runs normally. 2. Check the printer option installation, printer menu settings and consumable usage by using the menu map. 3. Load A4 paper in a tray. 4.
