This Appendix provides a table which sums up the Programming Console operations. The table gives the op-
eration name and the function it performs.
Name
Password Input
Buzzer ON/OFF
Data Clear
I/O Table Register
I/O Table Change
Word Multiplier Enter
I/O Table Verify
I/O Table Read
I/O Table Transfer
Error Message Read
On-line I/O Unit Change
Address Designation
Program Input
Program Read
Program Search
Instruction Insert
Instruction Delete
Program Check
Debug Operation Enter
Address Execution
Debug Execution
Address Trace
Address Trace Read
Bit/Word Monitor
Three-word Monitor
Temporary Forced
Set/Reset
Hex/BCD Data Change
Binary Data Change
SV Change
SV Reset
Three-word Change
Appendix C

Programming Console Operations

Prompts the user for the access password.
Controls whether the buzzer will sound for keystroke inputs.
Used to erase data, either selectively or totally, from the Program Memory and the
IR, AR, HR, DM, and TC areas.
Registers the I/O after initial entry or subsequent amendments.
Allows Dummy Units to be registered in the table so that the table does not need to
be altered when Units are added.
Used to assign word multipliers to Remote I/O Master Units as required.
Checks the I/O Table against the actual arrangement of I/O Units.
Displays the Unit type, location, I/O word number, and word multiplier (where
applicable).
Copies the I/O table to RAM. This enables simultaneous writing of the table and
user program to EPROM.
Displays error messages in sequence, starting with the most severe messages.
Permissible Units can be mounted or removed while the CPU is operating.
Displays the specified address.
Used to edit or input program instructions.
Allows the user to scroll through the program address-by-address. In RUN and
MONITOR modes, status of bits is also given.
Searches a program for the specified data address or instruction.
Allows a new instruction to be inserted before the displayed instruction, or deletes
the displayed instruction (respectively).
Checks the completed program for three levels of syntax errors.
Places the Unit into debug mode.
Executes a program instruction-by-instruction starting from the current address.
Debugs the program from the current address to the first END(01).
Debugs a section of 250 instructions and stores the results in the Trace Memory.
Allows the user to scroll address-by-address through the contents of Trace Memory.
Displays the specified address whose operand is to be monitored. In RUN or MONTR
mode it will show the status of the operand for any bit or word in any data area.
Simultaneously monitors three consecutive words.
Set: Used to turn on bits or timers, or to increment counters currently displayed on
the left of the screen.
Reset: Used to turn off bits, or to reset timers or counters.
Used to change the value of the leftmost BCD or hexadecimal word displayed
during a Bit/Word Monitor operation.
Changes the value of 16-bit words bit-by-bit. Bits can be changed temporarily or
permanently to the desired status.
Alters the SV of a timer or counter either by incrementing or decrementing the
value, or by overwriting the original value with a new one.
Used to change the value of a word displayed during a 3-word Monitor operation.
Function Page
61
339
62
64
67
65
70
71
67
66, 244
69
75
76
75
82
83
79
244
246
248
249
250
252
259
255
257
262
263
260
335
