Securing the Fixed Mounting Plate
This sturdy plate can be used to mount the scanner in a number of
positions; either for new installations or to add to an existing system.
C
o
u
t n
New Installation
1. Determine the mounting location. The plate allows flexible, yet sturdy
mounting to a countertop, table, wall, or even under a counter. While
deciding on the best position, you might want to keep in mind the
best way to route the scanner cable (you may need to drill a hole for
it).
2. Using two of the screws provided in the kit, securely fasten them
down through the plate in the position desired.
© 2009 - 2013 Datalogic ADC, Inc
Fixed Mounting Plate Instructions
r e
o t
p
820061314 (Rev. B)
Under Counter
Magellan
W
a
l l
TM
1100i
November 2013
