Pin definitions

There are eight wires on a standard UTP/STP cable and each wire is color-
coded. The following shows the pin allocation and color of straight and crossover
cable connection:
Figure 3: Straight-through cable
1 White/Orange
2 Orange
3 White-Green
4
5 White/Blue
6 Green
7 White/Brown
8 Brown
Figure 4: Cross-over cable
1 White/Orange
2
3 White-Green
4
5 White/Blue
6
7 White/Brown
8
Please make sure your connected cables have the same pin assignment and
color as above before deploying the cables in your network.
14
Blue
Orange
Blue
Green
Brown
White/Orange
Orange
White-Green
Blue
White/Blue
Green
White/Brown
Brown
White/Orange
Orange
White-Green
Blue
White/Blue
Green
White/Brown
Brown
