Tripp Lite SMX1500LCD Owner's Manual

Important Safety Instructions
SAVE THESE INSTRUCTIONS
The manual contains instructions and warnings that should be followed during the installation, operation and storage of this product.
Failure to heed these warnings will void your warranty.
UPS Location Warnings
• The UPS is designed for indoor use only in a controlled environment,
away from excess moisture, temperature extremes, conductive
contaminants, dust or direct sunlight.
• For best performance, maintain an indoor temperature between 0º C
and 40º C.
• Leave adequate space around all sides of the UPS for proper
ventilation.
• Do not mount unit with its front or rear panel facing down (at any
angle). Mounting in this manner will seriously inhibit the unit's internal
cooling, eventually causing product damage not covered under
warranty.
UPS Connection Warnings
• Connect the UPS directly to a properly grounded AC power outlet. Do
not plug the UPS into itself; this will damage the UPS.
• Do not modify the UPS plug, and do not use an adapter that
eliminates the UPS ground connection.
• Do not use extension cords to connect the UPS to an AC outlet.
• If the UPS receives power from a motor-driven AC generator, the
generator must provide clean, filtered, computer-grade output.
• The mains outlet supplying power to the UPS should be near the UPS
and easily accessible.
• To remove the UPS from the supply mains, the AC plug serves as a
disconnect device.
Owner's Manual
SMX1500LCD
Digital UPS System
Series Number: AGSM5510
Not suitable for mobile applications.
Español 8 • Français 15 • Русский 22 • Deutsch 29
1111 W. 35th Street, Chicago, IL 60609 USA • www.tripplite.com/support
Copyright © 2019 Tripp Lite. All rights reserved.
Equipment Connection Warnings
• Use of this equipment in life support applications where failure of this
equipment can reasonably be expected to cause the failure of the life
support equipment or to significantly affect its safety or effectiveness
is not recommended.
• Do not connect surge protectors or extension cords to the output of
the UPS. This might damage the UPS and will void the surge protector
and UPS warranties.
Battery Warnings
• The UPS does not require routine maintenance. Do not open the UPS
for any reason. There are no user-serviceable parts inside.
• Batteries can present a risk of electrical shock and burn from high
short-circuit current. Observe proper precautions. Do not dispose of
the batteries in a fire. Do not open the UPS or batteries. Do not short
or bridge the battery terminals with any object. Unplug and
turn off the UPS before performing battery replacement. Use tools
with insulated handles. There are no user-serviceable parts inside
the UPS. Battery replacement should be performed only by
authorized service personnel using the same number and type of
batteries (Sealed Lead-Acid). The batteries are recyclable.
Refer to your local codes for disposal requirements or visit
http://www.tripplite.com/support/recycling-program for recycling
information. Tripp Lite offers a complete line of UPS System
Replacement Battery Cartridges (R.B.C.).Visit Tripp Lite on the Web at
http://www.tripplite.com/products/battery-finder/ to locate the specific
replacement battery for your UPS.
• Do not attempt to add external batteries to the UPS.
1
