Service Manual
Vacuum Cleaner
Model : RC-105
DAEWOO ELECTRONICS CO., LTD.
OVERSEAS SERVICE DEPT.

Advertisement

Table of Contents
loading

Related Manuals for Daewoo RC-105

Summary of Contents for Daewoo RC-105

  • Page 1 Service Manual Vacuum Cleaner Model : RC-105 DAEWOO ELECTRONICS CO., LTD. OVERSEAS SERVICE DEPT.

  • Page 2: Specifications

    CONTENTS 1. SPECIFICATIONS 2. CIRCUIT DIAGRAM 3. BODY DISASSEMBLY FLOW CHART 4. EXPLODED VIEW AND PARTS LIST ƒU TOTAL BODY ASSEMBLY ƒU BODY ASSEMBLY ƒU COVER ASSEMBLY ƒU MOTOR ASSEMBLY ƒU DUST METER ASSEMBLY ƒU DORD REEL ASSEMBLY ƒU HOSE LINE ASSEMBLY ( I ) ƒU HOSE LINE ASSEMBLY ( II ) ƒU HOSE LINE ASSEMBLY ( III ) ƒU PIPE ASSEMBLY ( I )

  • Page 3: Circuit Diagram

    2. CIRCUIT DIAGRAM -DIAC CONTROL YELLOW BLUE BLUE BLACK BLACK FILTER COIL WHITE WHITE 120µH, 12A LR-03 LP-03 104K HARNESS ASS'Y TRIAC MOTOR SM16JZ47 104K 100 1W DIAC THERMOSTAT YELLOW POWER CORD AC 250V, 7A 104K AC 125V, 12A POWER P.C.B VOLTAGE SLIDE VOLUME THERMOSTAT...

  • Page 4: Wiring Diagram

    WIRING DIAGRAM -DIAC CONTROL SLIDE VOLUME P.C.B CORD REEL MOTOR Thermostat POWER CORD -DC CONTROL SLIDE VOLUME P.C.B CORD REEL MOTOR POWER CORD Thermostat...
  • Page 5 3. BODY DISASSEMBLY FLOW CHART 1. Open the cover ¤Łand push the snap fit ¤ºof the cover ¤ as shown the above figure ¤º , remove the cover ¤ . 2. After removing the cover ¤ . Remove the dust cover ¤Łand handle ¤Ø . As shown the above figure ¤ . 3.
  • Page 6 4. EXPLODED VIEW AND PARTS LIST TOTAL BODY ASSEMBLY...
  • Page 7 PART NAME PART CODE SPECS. Q¡ ¡ fl fl TY NOTE BODY AS 3620402100 105H, R-00, PP ROLLER 3620401900 705H, R-00, PP ROLLER 3620402610 105H, R-01 2HOLE ADAPTER 3620403100 705H, R-01 2HOLE ADAPTER 3620403000 105H, R-01, 2ROLLER 2HOLE ADAPTER, FELT 3620402800 705H, R-01, 2ROLLER 2HOLE ADAPTER...
  • Page 8 PART NAME PART CODE SPECS. Q¡ ¡ fl fl TY NOTE 3629502510 NORMAL BRUSH INSERT BLOWER PIPE AS 3624403100 ABS INSERT (AS) 3624400710 ABS BUTTON (EA) 3624405300 ABS BUTTON (EA) 3624404600 BLOWER (AS) 3624405000 TELESCOPIC (AS) 3624404500 STEEL (EA) PIPE AS 3624400610 ABS BUTTON (EA) 3624404400...
  • Page 9 BODY (DOWN) ASSEMBLY...
  • Page 10 PART NAME PART CODE SPECS. Q¡ ¡ fl fl TY NOTE BODY AS 3620401400 RC-105 ROLLER 3624700800 1 PIECE 3624701500 COVER ROLLER & ROLLER 2 PIECE BRACKET ROLLER 4569C20041 ROLLER 4568A54020 POM+PVC SCREW TAPPING 7121401211 T2S PAN 4X12 MFZN WASR SPERL 4509M12080 SCR1 1.6X6.4X12.5 MFZN...
  • Page 11 PART NAME PART CODE SPECS. Q¡ ¡ fl fl TY NOTE 3962510210 230V, 1000W HARNESS DMI 3962610300 240V, 1000W HARNESS DMI ABSORBER MOTOR 4569C10071 PU FOAM 3620901300 NR BACK 3620901600 3620901800 TRANS POWER 5EPU351450 230V 50HZ SEMKO DC CONTROL SCREW TAPPING 7121401411 T2S PAN 4X14 MFZN SEMKO DC CONTROL...
  • Page 12 COVER ASSEMBLY...
  • Page 13 PART NAME PART CODE SPECS. Q¡ ¡ fl fl TY NOTE COVER AS 3621404100 ABS BODY SCREW TAPPING 7121402011 T2S PAN 4X20 MFZN BUTTON 3626600900 SPRING 3625101800 HSW3 DUST METER AS 3629700700 ASSY COVER 3621407700 ABS MIDDLE SILK HANDLE 3622600200 COVER 3621404300 ABS DUST...
  • Page 14 MOTOR ASSEMBLY PART NAME PART CODE SPECS. Q¡ ¡ fl fl TY NOTE CAP FRONT 3620901200 CR FOAM MOTOR UNIVERSAL 3962130200 100V, 1000W HARNESS OS 3962220200 110V, 1000W HARNESS OS 3962330300 220V, 1000W HARNESS OS 3962510200 230V, 1000W HARNESS OS 3962610200 240V, 1000W HARNESS OS 3962130301...
  • Page 15 DUST METER ASSEMBLY PART NAME PART CODE SPECS. Q¡ ¡ fl fl TY NOTE VALVE DM 3625400100 LDPE PACKING DM 3624000400 S-PVC DUST METER 4560F23030 DUST METER 4560F23060 HOUSING 4560F23010 SPRING 3625100700 ELBOW 3627100300 PVC DM...
  • Page 16 CORD REEL ASSEMBLY...
  • Page 17 PART NAME PART CODE SPECS. Q¡ ¡ fl fl TY NOTE SCREW TAPPING 7121401411 T2S PAN 4X14 MFZN BRACKET CR 3620600600 HARNESS 3622707700 HO+Y-TER+FUSE(T15A)+T85 JAPAN 3622706620 HO+Y-TER+T85 220V 3622707000 HO+Y-TER+FUSE(T12A)+T85 110V 3622706610 HO+Y-TER+T85 SEMKO 3622707010 HO+Y-TER+FUSE(T10A)+T85 JAPAN 3622707020 HO+Y-TER+FUSE(T10A) SCREW TAPPING 7121400611 T2S PAN 4X6 MFZN TERMINAL...
  • Page 18 HOSE LINE ASSEMBLY ( I )
  • Page 19 PART NAME PART CODE SPECS. Q¡ ¡ fl fl TY NOTE PIPE 3624402900 TERMINAL AS 3628705700 TERMINAL +WIRE SPRING 3625101700 HSW3 BUTTON 3626601000 COVER 3621404600 SCREW TAPPING 7121300812 T2S PAN 3X8 MFZN BK COVER HOSE 4565A70040 TAPE VINYL 2TU00019BK 19MM BLACK HOSE 4565A71001 PVC+SWRS 1.32M...
  • Page 20 HOSE LINE ASSEMBLY ( II )
  • Page 21 PART NAME PART CODE SPECS. Q¡ ¡ fl fl TY NOTE PIPE 3624402900 TERMINAL AS 3628705700 TERMINAL +WIRE SPRING 3625101700 HSW3 BUTTON 3626601000 COVER 3621404600 SCREW TAPPING 7121300812 T2S PAN 3X8 MFZN BK COVER HOSE 4565A70040 TAPE VINYL 2TU00019BK 19MM BLACK HOSE 4565A71001 PVC+SWRS 1.32M...
  • Page 22 HOSE LINE ASSEMBLY ( III )
  • Page 23 PART NAME PART CODE SPECS. Q¡ ¡ fl fl TY NOTE PIPE 3624402900 TERMINAL AS 3628705700 TERMINAL +WIRE SPRING 3625101700 HSW3 BUTTON 3626601000 COVER 3621404600 SCREW TAPPING 7121300812 T2S PAN 3X8 MFZN BK HOSE 3623202900 PVC-S/SWRS 1.3M 3623202920 1.5M 3623202930 1.8M TAPE VINYL 2TU00019BK...
  • Page 24 PIPE ASSEMBLY ( I-1 ) PART NAME PART CODE SPECS. Q¡ ¡ fl fl TY NOTE COVER 3621401000 BUTTON 3626600200 SPRING 3625100500 HSW3 PIPE 3624400500...
  • Page 25 PIPE ASSEMBLY ( I-2 ) PART NAME PART CODE SPECS. Q¡ ¡ fl fl TY NOTE COVER 3621401000 BUTTON 3626600200 SPRING 3625100500 HSW3 PIPE 3624400500 HOLDER 3623000500 SCREW TAPPING 7121401411 T2S PAN 4X14 MFZN...
  • Page 26 PIPE ASSEMBLY ( II ) PART NAME PART CODE SPECS. Q¡ ¡ fl fl TY NOTE PIPE EXTENSION 4560F75030 HOLDER PIPE 3623002200 SCREW TAPPING 7121401411 T2S PAN 4X14 MFZN...
  • Page 27 PIPE ASSEMBLY ( III ) PART NAME PART CODE SPECS. Q¡ ¡ fl fl TY NOTE PIPE 3624403500 HDPE+SPC SPACER 3625000400 EVA POAM T=1.5 HOLDER PIPE 3623001900 SCREW TAPPING 7121401411 T2S PAN 4X14 MFZN...
  • Page 28 PIPE ASSEMBLY ( IV ) PART NAME PART CODE SPECS. Q¡ ¡ fl fl TY NOTE PIPE 3624403600 PP T=2.5 SPACER 3625000400 EVA POAM T=1.5 HOLDER PIPE 3623001900 SCREW TAPPING 7121401411 T2S PAN 4X14 MFZN...
  • Page 29 SUCTION BRUSH ASSEMBLY ( I )
  • Page 30 PART NAME PART CODE SPECS. Q¡ ¡ fl fl TY NOTE BUTTON 3626600700 COVER 3612403400 ABS+PVC SCREW TAPPING 7121401411 T2S PAN 4X14 MFZN SCREW TAPPING 7121300812 T2S PAN 3X8 MFZN BK COVER 3621402600 PIPE 3624401400 HOOK 3623100100 ABSORBER 3620101900 PVA FOAM NECK 3628000400 SCREW TAPPING...
  • Page 31 SUCTION BRUSH ASSEMBLY ( II )
  • Page 32 PART NAME PART CODE SPECS. Q¡ ¡ fl fl TY NOTE BODY BRUSH 4560F90010 COVER PIPE 4560F90080 ROLLER PIPE 4560F90020 PIN ROLLER 4560F90110 SWRM ROLLER BRUSH 4560F90090 PIN ROLLER 4560F90120 SWRM HOLDER PIPE BRUSH 4568B91001 ASSY LEVER BRUSH 4560F90040 SPRING 4568B90050 HSW3 PIPE BRUSH...
  • Page 33 SUCTION BRUSH ASSEMBLY ( III )
  • Page 34 PART NAME PART CODE SPECS. Q¡ ¡ fl fl TY NOTE PIPE BRUSH 3624402400 NECK 3628000700 HOOK 3623100100 COVER BRUSH 3621405400 ROLLER COVER AIR 3621406200 PIN SHAFT 3624900400 SWRM+MFZN ROLLER 3624701000 PA+TPE RING E 7402004011 ER-4 MFZN CAP ROLLER 3620901500 PIPE LEVER BRUSH 3623700800 PLATE BRUSH AS...
  • Page 35 NOZZLE ASSEMBLY PART NAME PART CODE SPECS. Q¡ ¡ fl fl TY NOTE BRUSH MULTI AS 4560A67000 ASSY BODY BRUSH 4560A67111 BRUSH MULTI AUX 4560A67121 PP+NYLON NOZZLE CREVICE 4568A24020 NOZZLE CREVICE 3628100400 ABS+NYLON NOZZLE 3628100300 NOZZLE 3628100100...
