- Page 1 S/M No. : RC - 300 - 2F0 Service Manual Vacuum Cleaner Model: RC-300 DAEWOO ELECTRONICS CO., LTD. http : //svc.dwe.co.kr...
-
Page 2: Specifications
1. SPECIFICATIONS MODEL RC-300 RATED VOLTAGE / FREQUENCY 230V / 50Hz INPUT WATT 1200W(MAX) WEIGHT(BODY) 3.7kg DIMENSION (L H D) 354 240 262 mm CORD LENGTH POWER CONTROL BODY ON/OFF DUST METER MECHANICAL HOSE NON-CURRENT 1.5m EXTENSION PIPE 2 PLASTICS “WIDE SUCTION BRUSH, DUSTING BRUSH,”... -
Page 3: Wiring Diagram
2. DIAGRAM 2-1. WIRING DIAGRAM (VDE) (GENERAL) SWITCH SWITCH BLACK BLACK WHITE WHITE WHITE WHITE MOTOR MOTOR WHITE WHITE BLACK BLACK CORD REEL CORD REEL BLUE BLUE 2-2. CIRCUIT DIAGRAM (VDE) (GENERAL) ON/OFF ON/OFF 7A250VAC T85 7A250VAC T85 CAPACITOR 0.22µF/275VAC 230V/50Hz 230V/50Hz MOTOR... -
Page 4: Disassembling And Treatment
4. DISASSEMBLING AND TREATMENT 4-1. CLEANER ASSEMBLY 1) While standing the handle(1), unscrew the 2(+) screws. Lift the dust cover assembly(2). 2) Separate the case filter. Unscrew the 4(+) screws. 3) Rotate and lift the body cover assembly(4). -
Page 5: Cord Reel Assembly
4-2. CORD REEL ASSEMBLY 1) Take the cord reel out of the body cover. 2) Unscrew the screw and separate the bobbin from the bracket and check the contacts between the Y terminals. At this time, the bobbin is rotated counterclockwise due to the preserved winding. 3) If the reel spring is broken, unscrew the 2 screws and replace it. -
Page 6: Exploded View And Parts List
5. EXPLODED VIEW AND PARTS LIST 5-1. BODY ASSEMBLY PART NAME PART CODE SPEC. Q TY BODY 3620406300 ROLLER BACK 3624703400 ROLLER FRONT 3624703600 SHAFT ROLLER 3624901000 SWRM BRACKET ROLLER 3620601500 HOLDER FILTER 3623004000 SPRING HOLDER 3625106000 SK-5 GASKET 3624004800 RUBBER FOAM FILTER-IN 3621904200... -
Page 7: Body Cover Assembly
5-2. BODY COVER ASSEMBLY PART NAME PART CODE SPEC. Q TY COVER BODY 3621416900 LEVER CR 3623702000 PC LEXAN 121 SPRING LEVER 3625104300 HSW3 FRAME STOPPER 4565A35070 POLY ACETAL STOPPER CR 4569C35082 SWITCH PUSH 3629002000 “7A/250V, (SKT)” HARNESS 3622710000 RECEP+WIRE (BK) 3622709600 RECEP+WIRE (WH), VDE HARNESS... - Page 8 BRACKET CR 3620601600 TERMINAL Y AS 3628709500 Y TER+WIRE(BK) 3628709400 Y TER+WIRE(WH), VDE TERMINAL Y AS 3628709410 Y TER+WIRE(WH), GENERAL SCREW TAPPING 7121400611 T2S PAN 4X6 MFZN PCB AS 3624307600 RC-300 230V/50Hz, VDE SCREW TAPPING 7121401411 T2S PAN 4X14 MFZN...
-
Page 9: Dust Cover Assembly
5-4. DUST COVER ASSEMBLY PART NAME PART CODE SPEC. Q TY COVER DUST 3621417900 ABS KR-2870 CLAMP COVER 3621202000 ABS KR-2870 SPRING CLAMP 3625106400 HSW3 HOUSING DM 3626100300 GPPS DUST METER 3629702100 CAP DM 3620903500 LDPE SPRING DM 3625106300 SCREW TAPPING 7121401411 T2S PAN 4X14 MFZN COVER TOP... -
Page 10: Hose Assembly
5-5. HOSE ASSEMBLY PART NAME PART CODE SPEC. Q TY ADAPTER PIPE 3629101700 HOLDER HOSE 4569A71021 RING HOSE 3624600200 HOSE 3623206300 “EVA, 1.8M” PIPE HOSE 3624408200 PACKING HOLE 3624005900 EVA SPONGE VALVE AIR 3625400400... -
Page 11: Wide Suction Brush Assembly
5-6. WIDE SUCTION BRUSH ASSEMBLY PART NAME PART CODE SPEC. Q TY BODY BRUSH 3620406400 COVER BRUSH 3621417200 NECK BRUSH 3628001600 PIPE BRUSH 3624408300 ROLLER-B BRUSH 3624703000 ROLLER-F BRUSH 3624703100 SHAFT ROLLER 3624900900 PICKER LITTER 3627000700 SCREW TAPPING 7171401411 TT2 PAN 4X14 MFZN... -
Page 12: Extension Pipe And Nozzles
5-7. EXTENSION PIPE AND NOZZLES PART NAME PART CODE SPEC. Q TY PIPE EXTENSION 3624408500 HOLDER NOZZLE 3623004200 NOZZLE CREVICE 3628100600 BRUSH DUSTING 3629305000 PP+NYLON NOZZLE UPHOLSTERY 3628100700 PP+PICKER LITTER...
