Connections - Infinity TSS-Sub1200 Service Manual

TSS-Sub1200
subwoofer
S
UBWOOFER
If you have a Dolby
processor with a low-frequency-effects (LFE)
or subwoofer output:
15'
subwoofer
cable
included
Set line-level/LFE switch to "LFE."
C
ONNECTIONS
® Digital or DTS ® receiver/
SUBWOOFER OR
LFE OUTPUT
LEVEL
Max
Min
LFE NORMAL
PHASE
0˚ 180˚
80Hz
CROSSOVER
FREQUENCY
150Hz
50Hz
L R
LINE LEVEL IN
For LFE use L or R
ON OFF
POWER
®
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
NRTL/C
WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK,
CSA22.2
DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.
UL1492
AVERTISSEMENT: POUR PRÉVENIR LES RISQUES D'INCENDIE OU
DE CHOC ÉLECTRIQUE, ÉVITER D'EXPOSER CET APPAREIL A LA
PLUIE OU A L'HUMIDITÉ.
If your receiver/processor does not contain
a Dolby Digital or DTS processor but has a
subwoofer output:
Set line-level/LFE switch to "Normal."
N N O O T T E E : If your receiver/processor has only one sub out,
you may use either the L or R input.
®
