Electrical Parts List - Infinity TSS-Sub1200 Service Manual

TSS-Sub1200
subwoofer
TSS-1200 120V ELECTRICAL PARTS LIST
Part Number Qty
Capacitors
032-270393-300ZR 1
034-100625-300ZS 1
034-220525-301ZS 5
034-330515-000ZS 1
034-330525-300ZR 1
034-330615-300ZS 2
034-470415-301ZS 1
034-470515-307ZR 1
035-100393-301ZR 1
035-220393-300ZR 1
038-100363-300ZR 2
031-100144-103AZS 1
031-100184-100AZS 2
031-100244-100AZS 7
031-100343-100AZS 2
031-100344-100AZS 18 GS SMD
031-220243-103AZS 1
031-220344-300AZS 3
031-330444-300ZS 1
031-470244-102AZS 2
031-470344-100AZS 1
031-560243-100AZS 2
031-820343-101AZS 1
032-820244-200ZR 1
033-470464-270ZS 1
033-680464-270ZS 1
034-100525-300ZS 1
034-330780-300ZR 2
034-470515-200ZR 1
035-100393-301ZR 1
035-100443-300ZR 2
035-470293-300ZR 1
039-100384-100ZR 1
032-100484-200ZS 2
Semiconductors
051-000600-100ZR 1
051-222200-100ZR 1
051-290700-100ZR 2
054-000100-100ZR 5
054-007200-100ZR 3
054-007400-100ZR 2
054-008406-000ZR 1
054-008407-000ZR 3
054-008408-000ZR 2
054-008409-000ZR 1
054-011400-100ZR 1
054-033904-100ZR 8
054-033906-100ZR 4
054-045580-100ZS 1
054-414803-100ZS 23 GS SMD DIODE: LL4148 MINI-MELF
054-540100-100ZR 3
051-000600-100ZR 1
Description
GR Mylar cap. (ESK) 0u27/63V J (R) P:5
GS electrolytic cap. 100uF/25V M (R)6.3x11 P:5
GS Elect. Cap. 22uF/25V M (R)5x11 P:5
GS elctrolytic cap. 33uF/16V M (R)0511 P:5
GR electrolytic cap. 33uF/25V M (R)0511 P:5
GS Electrolytic cap. 330uF/16V M (R)0812 P:5
GS electrolytic cap. 4u7/50V M (R)0511 P:5
GR electro cap. LOW ESR 85℃ESR<5Ω 47uF/16V M
GR Mylar cap. (ESK) 0u1/63V J P:5 ESK063S10JT
GR PE cap. 0u22/63V J P:5
GR MPE cap. P:5 0u1/100V J
GS SMD 0u001/50V K 0805 X7R
GS SMD 0u01/250V K 0805 X7R
GS SMD Ceramic cap. 0u01/50V K 0805 X7R
GS SMD 100pF/50V J 0805 NPO
0u1/50V K 0805 X7R
GS SMD 0u022/50V J 0805 X7R
GS SMD 220pF/50V K 0805 NPO
GS SMD 3300pF/50V K 0805 X7R
GS SMD 0u047/50V K 0805 X7R
GS SMD 470pF/50V K 0805 X7R
GS SMD 56pF/50V J 0805 NPO
GS SMD 820pF/50V J 0805 NPO
GR mylar cap. 0u082/100V K (R)
GS NPE cap.1K 4u7/100V K10 (R)1015 GNE
GS NPE cap. 6u8/100V K10 (R)1020 GNE
GS Eletrolytic cap. 10uF/25V M (R)0511 P:5
GR electrolytic cap. 85℃ 3300uF/80V M (R)22x48
GR electro cap. 47uF/16V M (R)0511 P:2.5
GR mylar cap. (ESK) 0u1/63V J P:5 PN:ESK063S10JT
GR mylar cap. (ESK) 1uF/63V J P:5 PN:ESK063W10JT
GR PE cap. 0u047/63V J P:5
GR Safety cap.(0u1/250V) HQX0.1K275VACx2
GS END mylar cap. 1uF/250V K P:15
GR Transistor NPN MPSW06RLRA TO-92 (ON)
GR Transistor NPN (ON) MPS2222ARLRAR TO-92
GR Transistor PNP (ON) MPS2907A RLRAR TO-92
GR GS SMD DIODE: ES1D 200V 1A (PANJIT)
SMD IC TL072CDR SO-8 DUAL OP-AMP
SMD IC TL074CDR QUAD OP-AMP
GR SMD ZENER DIODE:
GR SMD ZENER DIODE:
GR SMD ZENER DIODE:
GR SMD ZENER DIODE:
GR SMD Transistor DTC114TKA SMT3 (ROHM
GR SMD (TRANSISTOR) MMBT3904LT1G SOT23
GR SMD Transistor (ON) MMBT3906LT1G SOT23
GS SMD IC:(OP) NJM4558M-DUAL OP-AMP
GR SMD Transistor PNP (ON SEN) MMBT5401 SOT-23
GR Transistor NPN MPSW06RLRA TO-92 (ON)
BZX84C10-7-F SOT-23
BZX84C15-7-F SOT-23
BZX84C5V6-7-F SOT-23
BZX84C3V0-7-F SOT-23
13
Reference Designator
C29
C64
C4,9,41,50,53
C39
C1
C12,78
C2
C65
C28,
C27,
C68,69
C79
C3,7
C66,67,5,10C,33,45,51,
C36,58
C11,42-44,46-49,52,54,55,60,63,
71,74,77,81,82,
C40
C20,21,19
C34
C62,59
C80
C57,61
C56
C30
C73
C72
C35
C6,8
C37
C2A
C25,26,
C1A,
CXAC1
C70,C70B
Q16
Q21
Q19,23
D5,26,29,33,38
U5,6,8,
U2,3
D35
D6,7,9
D36,37
D25
Q7
Q11,14,13,5,8,25,9,27
Q6,10,12,15
U4
D1-4,8,27,30,31,34,39, 11,14,16,17,20-22,
18,19,28,32,44,45,
Q20,24,26
Q2
