Infinity TSS-Sub1200 Service Manual page 16

TSS-Sub1200
subwoofer
Part Number Qty
024-680498-120ZS 6
024-680598-120ZS 6
024-820598-120ZS 1
020-000098-400ZS 4
020-220497-120ZS 1
021-100401-120ZS 1
021-220202-120ZS 1
021-240405-020ZS 4
022-500003-020ZS 1
026-200595-269ZS 1
026-500495-005ZS 1
Miscellaneous
044-100100-000ZS 2
041-115001-000ZR 1
043-300101-000ZR 1
043-324300-000ZR 1
043-560200-000ZR 1
043-840100-000ZR 1
072-010305-000ZS 1
073-050001-000ZS 2
074-030002-000ZR 2
074-300018-000ZR 1
077-100102-100ZR 1
093-105202-300ZR 1
025-010300-000ZR 1
042-010147-000ZR 1
061-020000-000ZS 2
061-400014-000BZR 4
061-700044-000ZR 3
063-010012-000ZR 4
063-321101-000ZR 1
063-531808-000ZR 1
073-011006-400ZR 2
073-032315-601ZS 1
074-020018-000ZR 1
086-021818-005ZR 1
230V VERSION DIFFERENCES
086-021818-030BZR 1
093-205201-320ZR 1
042-010148-000ZR 1
Description
GS SMD 6K8 1/8W J 0805
GS SMD 68K 1/8W J 0805
GS SMD 82K 1/8W J 0805
GS Carbon Film Resistor 0R 1/8W
GS Carbon film resistor 2K2 1/4W J
GS MOF Resistor 1K 1W J INK MO-100
GS MOF resistor 22R 2W(S) J MB TYPE 15x8
GS MOF Resistor 2K4/5WS J 17x6 KINK
GS Resistor KNP 0R05 3WS J FK TYPE
GS VR PN:RD163121R03D-20KBx2(EJ) FREQUENCY
GS VR 5K PN:RD163111R22B-5K15A-EJ LEVEL
GS SMD FERRITE BEAD PN:321611 600R/100MHz 1206
GR BEAD COIL PN:YT-10911
GR INDUCTOR PN:YT-10033 30uH
GR INDUCTOR 324uH YT-10778
GR INDUCTOR 56uH YT-10779
GR Inductor PN:YT-14389 84uH TSS1100/230V
GS RCA JACK PN:B217BK 2P
GS FUSE CLIP P/N:CT-FH1206
GR TOGGLE SW PN:L101-T2B4QE PHASE, LFE
GR RELAY PN:943-1C-48D
GR PN:JS-1001-02 P:2.5 2P
GR FUSE:UL GSL(2AG) FUSE:2A,250V,5*20mm
GR Thermister PN:NTSE103KZ072 K L:50mm
GR Transformer PN:YT-15250 (TSS1100/120V)
GS Knob ABS HTS-10/20 20x15m/m UL94V-0 BLK
GR RUBBER FOOT ID:6.2 OD:11.5 t:2mm 55 BLK
GR Mica 13x18mm TO-220
GR Bracket for Transistor P/N:TRK-1
GR Panel 322x105.7x15mm BLK ABS-94V0
GR bucket (PB-10/12) ABS 322x105.7x146.5mm BLK (94VO)
GR BRACKET 16x34mm t:0.8mm
GS HeatSink 70x58x20mm Alum. (PB-12)
GR ROCKER SW (POWER) PN:RF1003-BB4-0
GR Power Cord NISPT-2 18AWGx2 L:1830mm 105C+T187
Power Cord VDE 6 feet long
Fuse VBSUTE 1.25A/250V 5mm*20mm
GR Transformer YT-15251
Reference Designator
R46,91,40-43
R33,34A,31,50,52,66
R69
C22-24,31,
R11
R103
R10
R6,9,R7A,R9A
R104
VR2
VR1
FB1,FB2
L5
L2
L4
L1
L3
CONN1
SW5,SW6
K1
CONN3A
F1
TH1
PT1
LEVEL, CROSSOVER
for Q4,18,22
ICx4
PANELx2
F1
PT1
15
