OPERATION AND PARTS MANUAL
SERIES
MODELS
WBH-16EAWD
WBH-16EAWDF
POWER BUGGY
(B&S VANGUARD 18 HP GASOLINE ELECTRIC START)
Revision #2 (09/12/19)
THIS MANUAL MUST ACCOMPANY THE EQUIPMENT AT ALL TIMES.

Advertisement

Table of Contents
loading

Related Manuals for MULTIQUIP Whiteman Series

Summary of Contents for MULTIQUIP Whiteman Series

  • Page 1 OPERATION AND PARTS MANUAL SERIES MODELS WBH-16EAWD WBH-16EAWDF POWER BUGGY (B&S VANGUARD 18 HP GASOLINE ELECTRIC START) Revision #2 (09/12/19) THIS MANUAL MUST ACCOMPANY THE EQUIPMENT AT ALL TIMES.
  • Page 2 We sell worldwide for the brands: Genie, Terex, JLG, MultiQuip, Mikasa, Essick, Whiteman, Mayco, Toro Stone, Diamond Products, Generac Magnum, Airman, Haulotte, Barreto,...

  • Page 3: Proposition 65 Warning

    PROPOSITION 65 WARNING PAGE 2 — WBH-16EAWD POWER BUGGY • OPERATION AND PARTS MANUAL — REV. #2 (09/12/19)

  • Page 4: Table Of Contents

    TABLE OF CONTENTS WBH-16EAWD Component Drawings Power Buggy Nameplate and Decals Assembly ....44–45 Hydraulic Drive Assembly ........ 46–47 Proposition 65 Warning ........... 2 Hydraulic Pump Assembly ....... 48–49 Table of Contents ............. 3 Hydraulic Dump Assembly ......50–51 Safety Information ..........5–11 Manifold Assembly...........
  • Page 5 NOTES PAGE 4 — WBH-16EAWD POWER BUGGY • OPERATION AND PARTS MANUAL — REV. #2 (09/12/19)

  • Page 6: Safety Information

    SAFETY INFORMATION Do not operate or service the equipment before reading Potential hazards associated with the operation of this the entire manual. Safety precautions should be followed equipment will be referenced with hazard symbols which at all times when operating this equipment. may appear throughout this manual in conjunction with Failure to read and understand the safety safety messages.
  • Page 7 „ NEVER use accessories or attachments that are not „ Avoid wearing jewelry or loose fi tting clothes that may recommended by Multiquip for this equipment. Damage snag on the controls or moving parts as this can cause to the equipment and/or injury to user may result.
  • Page 8 SAFETY INFORMATION POWER BUGGY SAFETY CAUTION „ ALWAYS inspect the surface over which you will travel. DANGER Look for holes, drop-offs and obstacles. Look for rough „ Engine fuel exhaust gases contain poisonous carbon and weak spots on docks, ramps or fl oor. Look for oil monoxide.
  • Page 9 SAFETY INFORMATION „ DO NOT operate the power buggy at excessive speeds. „ DO NOT stand in front or along side the buggy when Reckless operation may cause accidents and severe discharging a load. injury. Slow down when approaching people, wet areas, „...
  • Page 10 SAFETY INFORMATION „ ALWAYS use extreme caution when working with ENGINE SAFETY fl ammable liquids. WARNING „ DO NOT fi ll the fuel tank while the engine is running „ DO NOT place hands or fingers inside or hot. engine compartment when engine is „...
  • Page 11 SAFETY INFORMATION „ ALWAYS recharge the battery in a well-ventilated TRANSPORTING SAFETY environment to avoid the risk of a dangerous concentration NOTICE of combustible gases. „ ALWAYS shutdown engine before transporting. „ If the battery liquid (dilute sulfuric acid) comes into contact with clothing or skin, „...
  • Page 12 SAFETY INFORMATION ENVIRONMENTAL SAFETY/DECOMMISSIONING EMISSIONS INFORMATION NOTICE NOTICE Decommissioning is a controlled process used to safely This equipment conforms with applicable Environmental retire a piece of equipment that is no longer serviceable. Protection Agency (EPA) and California Air Resources If the equipment poses an unacceptable and unrepairable Board (CARB) emission regulations.

  • Page 13: Specifications (Buggy)

    SPECIFICATIONS (BUGGY) Table 1. Specifications (Power Buggy) Models WBH-16EAWD/ WBH-16EAWDF Maximum Weight Capacity 2,500 lbs. (1,134 kg) (Dual Wheels) Operating Weight 1,485 lbs. (673.5 kg.) Bucket/Tub Capacity 16 cu. ft. Water Level (.59 cu. yd.) Bucket/Tub Material Polyethylene Drive Hydrostatic Speed Up to 7.25 mph.

  • Page 14: Specifications (Engine)

    SPECIFICATIONS (ENGINE) Table 2. Specifications (Engine) Model Briggs and Stratton Vanguard Type Twin Cylinder, Overhead Valve, Air Cooled Bore X Stroke 2.82 x 2.75 in. (71.88 x 69.85 mm) Displacement 34.7 cu. in. (570 cc) Maximum Power 18.0 hp (3,600 rpm) 31.70 ft-lbs.

  • Page 15: Dimensions

    DIMENSIONS Table 3. Dimensions Reference Dimension Letter in. (mm) 45.47 (1,155) 51.0 (1,295) 8.50 (216) 103 (2,612) 44 (1,117) Figure 1. WBH16EAWD Dimensions PAGE 14 — WBH-16EAWD POWER BUGGY • OPERATION AND PARTS MANUAL — REV. #2 (09/12/19)

  • Page 16: General Information

    GENERAL INFORMATION The MQ Whiteman Power Buggy, Model WBH-16EAWD The operator controls the forward and reverse machine (recoil/electric start) is intended for the transportation of travel by manually shifting the control valve which directs concrete, concrete spreading and spot pouring. In addition, the hydraulic fluid flow to the two drive wheel motors.

  • Page 17: Components

    COMPONENTS 9. Travel Lever — When the travel lever is pushed forward, the buggy will travel in the forward direction. Placing the travel lever in the backward position will cause the buggy to travel in the reverse direction. Center position is neutral. 10.

  • Page 18: Basic Engine

    BASIC ENGINE Figure 3. Briggs & Stratton Vanguard 18HP Engine 1. Air Filter — Prevents dirt and other debris from 8. Electric Starter — Starts engine when ignition key is entering the fuel system. Release the latches on rotated to the ON position. the sides of the air filter cover to gain access to filter 9.

  • Page 19: Inspection

    INSPECTION BEFORE STARTING 1. Read safety information at the beginning of manual. 2. Clean the machine, removing dirt and dust, particularly the engine cooling air inlet, carburetor and air cleaner. 3. Check the air filter for dirt and dust. If air filter is dirty, Figure 5.
  • Page 20 INSPECTION BATTERY When connecting battery do the following: 1. NEVER connect the battery cables to the battery This unit is of negative ground, DO NOT connect in reverse. terminals when the ignition is in the ON position (start). ALWAYS maintain battery fluid level between the specified marks.
  • Page 21 INSPECTION DUMP CYLINDER CHECK 1. Check the power buggy's dump cylinder as outlined in the operation section of this manual. 2. Make sure that both zerk fittings for the dump cylinder have been lubricated. HYDRAULIC OIL CHECK 3. Visually read the hydraulic sight glass (Figure 8) to see if the hydraulic oil level is low.

  • Page 22: Operation

    OPERATION 4. If starting a cold engine, push the choke lever inward CAUTION (Figure 12) to the CLOSED position. DO NOT attempt to operate the power buggy until the Safety Information, General Information, and Inspection sections of this manual have been read and thoroughly understood.
  • Page 23 OPERATION 7. Place the ignition key (Figure 15 ) in the START position 3. After the engine has started and warmed, slowly pull and hold it until the engine starts. When the engine the choke lever outward to the OPEN position. starts, release the key, allowing it to return back to the 4.
  • Page 24 OPERATION PARKING BRAKE/DIRECTION LEVER TRACTION ASSIST SYSTEM SWITCH Before the power buggy can be put into operational use, When using the power buggy, it might become necessary to it is best to perform a test run to make certain that all engage the traction assist system to provide a temporary components are functioning properly.
  • Page 25 OPERATION TRAVELING STEERING 1. With the engine running and parking brake released, To steer the buggy, use the handle bar in front of the place the direction lever (Figure 19) in the forward operator platform. direction. 1. To turn left when traveling in the forward direction, turn 2.
  • Page 26 OPERATION TRAVELING ON A SLOPE 1. When traveling on a slope, it is necessary to determine the grade of the path. The WBH16EAWD can travel up, down on a maximum grade of 10% (6°). DO NOT travel on steeper slopes. To determine the % grade of your path of travel, use the formula and graph in Figure 24.
  • Page 27 OPERATION SHUTDOWN (NORMAL) NOTICE Correct shutdown is important to safe operation. Follow DO NOT activate dump mechanism (tub/bucket) if these general steps: buggy is facing down hill. The possibility exist of the buggy tipping over causing equipment damage and 1. Come to a full stop. severe bodily harm.

  • Page 28: Maintenance

    MAINTENANCE Table 5. Engine Maintenance Schedule EVERY 6 EVERY BEFORE FIRST EVERY 2 DESCRIPTION MONTHS YEAR OPERATION EACH MONTH OR YEARS OR OR 100 OR 300 25 HRS. 500 HRS. HRS. HRS. Check Engine Oil Change Engine Oil Filter Replace Every 100 Hrs.
  • Page 29 MAINTENANCE When performing any maintenance on the power buggy AIR CLEANER (100 HOURS) or engine, follow all safety messages and rules for safe Thoroughly remove dirt and oil from the engine and operation stated at the beginning of this manual. control area.
  • Page 30 MAINTENANCE CHANGING ENGINE OIL (100 HOURS) 6. To clean the paper air filter (Figure 30), tap the filter element several times on a hard surface to remove 1. Drain the engine oil when the oil is warm as shown in dirt, or blow compressed air [not to exceed 30 psi (207 (Figure 32).
  • Page 31 MAINTENANCE IN-LINE FUEL FILTER (200 HOURS) SPARK PLUG ADJUSTMENT 1. Place the fuel tank ON/OFF valve lever (Figure 34) in the 1. Make sure the engine is cool before servicing the OFF position. spark plugs. 2. Disconnect the spark plug caps. Check for dirt and remove any dirt from around the spark plug area.
  • Page 32 MAINTENANCE ADDING HYDRAULIC OIL 5. Use the tub support rod to support the tub, then turn the engine OFF. 1. Check the hydraulic oil level in the hydraulic oil tank, 6. Remove the two bolts that secure the access by reading the hydraulic oil sight glass (Figure 38) cover(Figure 40) to the buggy frame.
  • Page 33 9. Replace hydraulic oil after every 200 hours of operation. NOTICE The reservoir capacity is 5.3 gallons (20.4 liters). The Contact Multiquip's Service Department should any hydraulic oil filter should be changed each time the problems develop with the hydraulic drive motors hydraulic oil is changed.
  • Page 34 MAINTENANCE CHASSIS LUBRICATION PUMP CONTROL LEVER ADJUSTMENT This power buggy is equipped with five zerk fittings Inspect the speed control return springs. The tension should (Figure 45). Lubricate these zerk fittings each day before be sufficient to allow lever to snap back when released. operating the buggy.
  • Page 35 MAINTENANCE TIRES/WHEELS/LUG NUTS Table 7. Tire Torque Requirements First Pass Second Pass Third Pass Tires and wheels are very important and critical components Wheel Size FT-LBS FT-LBS FT-LBS of the buggy. When specifying or replacing the wheels, it is important that the wheels, tires, and axle are properly 480 x 8 in.

  • Page 36: Troubleshooting

    TROUBLESHOOTING Troubleshooting (Power Buggy) Symptom Possible Problem Solution Adjust speed control cable. Replace cable if Speed control cable out of adjustment? necessary Hydraulic oil level low.? Check hydraulic oil level. Add oil if necessary. Loss of Power. Contaminated hydraulic oil fi lter? Replace hydraulic oil fi lter.
  • Page 37 TROUBLESHOOTING Troubleshooting (Engine) Symptom Possible Problem Solution Spark plug bridging? Check gap, insulation or replace spark plug. Carbon deposit on spark plug? Clean or replace spark plug. Short circuit due to defi cient spark plug Check spark plug insulation, replace if worn. insulation? Improper spark plug gap? Set to proper gap.

  • Page 38: Troubleshooting

    TROUBLESHOOTING Troubleshooting (Engine) - continued Symptom Possible Problem Solution Air cleaner dirty? Clean or replace air cleaner. Improper level in carburetor? Check fl oat adjustment, rebuild carburetor. Weak in power, compression is proper and does not misfi re. Defective spark plug? Clean or replace spark plug.

  • Page 39: Hydraulic System Diagram

    HYDRAULIC SYSTEM DIAGRAM PAGE 38 — WBH-16EAWD POWER BUGGY • OPERATION AND PARTS MANUAL — REV. #2 (09/12/19)

  • Page 40: Hydraulic Hose Connections

    HYDRAULIC HOSE CONNECTIONS HYDRAULIC PUMP HYDRAULIC OIL TANK DUMP CYLINDER HYDRAULIC OIL FILTER DUMP VALVE WBH-16EAWD POWER BUGGY • OPERATION AND PARTS MANUAL — REV. #2 (09/12/19) — PAGE 39...
  • Page 41 We sell worldwide for the brands: Genie, Terex, JLG, MultiQuip, Mikasa, Essick, Whiteman, Mayco, Toro Stone, Diamond Products, Generac Magnum, Airman, Haulotte, Barreto,...

  • Page 42: Traction Assist Wiring Diagram

    TRACTION ASSIST WIRING DIAGRAM PAGE 40 — WBH-16EAWD POWER BUGGY • OPERATION AND PARTS MANUAL — REV. #2 (09/12/19)

  • Page 43: Wiring Diagram (Engine)

    WIRING DIAGRAM (ENGINE) WBH-16EAWD POWER BUGGY • OPERATION AND PARTS MANUAL — REV. #2 (09/12/19) — PAGE 41...

  • Page 44: Explanation Of Code In Remarks Column

    A blank entry generally indicates that the item is not sold “Not Sold Separately” — Indicates that an item cannot separately or is not sold by Multiquip. Other entries will be purchased as a separate item and is either part of an be clarifi ed in the “Remarks”...

  • Page 45: Suggested Spare Parts

    SUGGESTED SPARE PARTS WBH16EAWD POWER BUGGY B&S VANGUARD 18 HP GASOLINE ENGINE 1 to 3 units 1 to 3 units Qty. Description Qty. Description 1....508667 ....FILTER, HYDRAULIC OIL 3....496018S ....SPARK PLUG 1....EM16477 ....CAP, HYDRAULIC OIL TANK 3....691959 ....KEY, IGNITION 1....18035 ....PUMP, HYDRAULIC 3....808167 ....GRIP, STARTER 1....18051 ....COUPLING, ENGINE SHAFT 1....66574 ....ROPE, STARTER...
  • Page 46 NAMEPLATE AND DECALS ASSY. WARNING CRUSH AREA 18247 TRAVEL NEUTRAL MODEL SERIAIAL NO. LIFT 513608 LIFT 18245 WARNING HOT SURFACE AREA 18248 LIFT 513608 MQ Whiteman Safety Instructions Operate at safe speeds only Read operators manual before operating Place in neutral before starting No unauthorized untrained operators No riders GASOLINE ONLY...
  • Page 47 NAMEPLATE AND DECALS ASSY. PART NO. PART NAME QTY. REMARKS 18247 DECAL, CRUSH WARNING DECAL, TRAVEL LEVER DIRECTION .....1..MOLDED INTO FUEL TANK COVER PLATE, SERIAL NUMBER........1..CONTACT DISCOUNT-EQUIPMENT 491757 RIVET, I.D. PLATE 18248 DECAL, HOT SURFACE WARNING 512446 DECAL, WBH-16 AWD 18252 DECAL, MQ WHITEMAN 18245...
  • Page 48 HYDRAULIC DRIVE ASSY. VIEW FROM OPERATOR’S PLATFORM DIRECTIONAL VALVE SEAL KIT DRIVE MOTOR LEFT DRIVE MOTOR RIGHT DRIVE MOTOR PNEUMATIC NOTES: REFERENCE HYDRAULIC HOSE CONNECTION SECTION. FOAM FILLED PAGE 46 — WBH-16EAWD POWER BUGGY • OPERATION AND PARTS MANUAL — REV. #2 (09/12/19)
  • Page 49 HYDRAULIC DRIVE ASSY. PART NO. PART NAME QTY. REMARKS 513598 HOSE, MANIFOLD 18265M HOSE, MANIFOLD 513606 HOSE, RH HYDRAULIC MOTOR 511810 ADAPTER, ELBOW 513605 HOSE, LH HYDRAULIC MOTOR 512189 ADAPTER, T-CONNECTOR 492527 NUT, HEX 1/2"-20 18029 WHEEL ..............4....PNEUMATIC TIRE 18029F WHEEL, DRIVE ASSY.
  • Page 50 HYDRAULIC PUMP ASSY. HYDRAULIC PUMP DIRECTION VALVE SEAL KIT DIRECTIONAL VALVE HYDRAULIC OIL FILTER DUMP VALVE NOTES: REFERENCE HYDRAULIC HOSE CONNECTION SECTION. REFERENCE HYDRAULIC OIL TANK ASSEMBLY. REFERENCE DUMP VALVE ASSEMBLY. REFERENCE HYDRAULIC DRIVE ASSEMBLY ITEMS 1 AND 2 FOR HOSE PART NUMBERS PAGE 48 —...
  • Page 51 HYDRAULIC PUMP ASSY. PART NO. PART NAME QTY. REMARKS 18035 PUMP, HYDRAULIC 511808 ADAPTER, STRAIGHT 3365 ADAPTER, STRAIGHT 18256M HOSE, PUMP TO DUMP VALVE 18258M HOSE, FILTER TO PUMP 18261M HOSE, PUMP TO TANK 513599 HOSE, PUMP TO DIRECTION VALVE 512190 ADAPTER, STRAIGHT 18257M...

  • Page 52: Hydraulic Pump Assembly

    HYDRAULIC DUMP ASSY. DUMP CYLINDER SEAL KIT DUMP CYLINDER DUMP VALVE NOTES: REFERENCE HYDRAULIC HOSE CONNECTION SECTION. REFERENCE HYDRAULIC PUMP ASSEMBLY ITEM 4 FOR HOSE PART NUMBER. REFERENCE HYDRAULIC PUMP ASSEMBLY ITEM 9 FOR HOSE PART NUMBER. REFERENCE HANDLE/FOOT DUMP CONTROLS ASSEMBLY ITEM 8 FOR DUMP VALVE PART NUMBER.
  • Page 53 HYDRAULIC DUMP ASSY. PART NO. PART NAME QTY. REMARKS 18022 CYLINDER, HYDRAULIC DUMP 18022SK SEAL KIT, DUMP CYLINDER 491705 ZERK FITTING 511803 ADAPTER, ELBOW 18020 HOSE, DUMP VALVE TO HYD. PISTON 511804 ADAPTER, ELBOW MALE 512234 ADAPTER, ELBOW 511806 ADAPTER, STRAIGHT 506191 ADAPTER, ELBOW WBH-16EAWD POWER BUGGY •...
  • Page 54 MANIFOLD ASSY. SEAL KIT SEAL KIT SOLENOID SOLENOID CARTRIDGE CONTROL CARTRIDGE PAGE 52 — WBH-16EAWD POWER BUGGY • OPERATION AND PARTS MANUAL — REV. #2 (09/12/19)

  • Page 55: Manifold Assembly

    MANIFOLD ASSY. PART NO. PART NAME QTY. REMARKS 18045 MANIFOLD BLOCK 3322 ADAPTER, ELBOW 3365 ADAPTER, STRAIGHT 509103 ADAPTER 513548 ADAPTER, STRAIGHT 18159 ADAPTER 18147 ADAPTER 18161 ADAPTER 25539 ADAPTER 18134 ORIFICE 18174 SOLENOID, CARTRIDGE 18174SK SEAL KIT, SOLENOID, CARTRIDGE 18034 NUT, SOLENOID 18093...
  • Page 56 PUMP AND COUPLING ASSY. Engine HYDRAULIC PUMP NOTES: ITEMS 2A THROUGH 2D NOT INCLUDED WITH ITEM 2. FRAME 2 APPLY BLUE LOCTITE PAGE 54 — WBH-16EAWD POWER BUGGY • OPERATION AND PARTS MANUAL — REV. #2 (09/12/19)
  • Page 57 PUMP AND COUPLING ASSY. PART NO. PART NAME QTY. REMARKS 492472 SCREW, ALLEN HEAD 3/8"-16 X 3/4" 18051 COUPLING, ENGINE SHAFT ......1....INCLUDES ITEM W/# 18051RS SPIDER, URETHANE 492356 SCREW, 1/4" X 3/4" GRD 5 492622 WASHER, LOCK 1/4" EM923057 WASHER, FLAT 3/4" ..........1....REPLACES P/N 504451 18112 EM923057 WASHER, FLAT 1/4"...
  • Page 58 TUB ASSY. PAGE 56 — WBH-16EAWD POWER BUGGY • OPERATION AND PARTS MANUAL — REV. #2 (09/12/19)
  • Page 59 TUB ASSY. PART NO. PART NAME QTY. REMARKS 18004 TUB, PLASTIC, 16 CU. FT. 492313 SCREW, HHC 3/8"-16 X 1-1/2" 512193 WASHER, FLAT 3/8" LARGE 490957 RING, SNAP 18130 PIN, HYD. PISTON CROSS 18129 PIN, TUB FRAME CROSS 0202 SCREW, HHC 5/16"-18 X 1" ZINC ....4....REPLACES P/N 492364 492597 WASHER, FLAT 9.5 X 22.2 492583...
  • Page 60 PANEL ASSY. PAGE 58 — WBH-16EAWD POWER BUGGY • OPERATION AND PARTS MANUAL — REV. #2 (09/12/19)
  • Page 61 PANEL ASSY. PART NO. PART NAME QTY. REMARKS 503978 POP RIVET AM-56 511474 FASTENER, ACCESS DOOR 18008 DOOR, ACCESS 492355 SCREW, 1/4" NC X 1/2" GRD 5 492597 WASHER, FLAT 3/8" 18141 COVER, RIGHT/SIDE ENGINE 492364 SCREW, HHC 5/16"-18 X 1" 492582 NUT, NYLOC 5/16"-18 801026...
  • Page 62 BRAKE ASSY. PAGE 60 — WBH-16EAWD POWER BUGGY • OPERATION AND PARTS MANUAL — REV. #2 (09/12/19)
  • Page 63 BRAKE ASSY. PART NO. PART NAME QTY. REMARKS 511762 SCREW, HHC 1/2"-13 X 8" 511698 CLEVIS, ASSY. BRAKE 492574 NUT, HEX 3/8"-24 NF 18111 PEDAL, BRAKE WASHER, FLAT 1/2" 492584 NUT, NYLOC 1/2"-13 18167 SPRING, BRAKE PEDAL 18307 SPRING, BRAKE BAND, BRAKE ...........2....NOT SOLD SEPARATELY LINING, BRAKE ..........2....NOT SOLD SEPARATELY 503723...
  • Page 64 STEERING AND CONTROLS ASSY. HYDROSTATIC PART OF MOTOR 43 1 BASE 1 28 NOTES: BEARING, ITEM 28 AND BUSHING STEERING ITEM 43 ARE LOCATED INSIDE MOTOR STEERING AXLE. REFERENCE HYDRAULIC HOSE CONNECTION SECTION. PAGE 62 — WBH-16EAWD POWER BUGGY • OPERATION AND PARTS MANUAL — REV. #2 (09/12/19)
  • Page 65 STEERING AND CONTROLS ASSY. PART NO. PART NAME QTY. REMARKS 506088 SCREW, HHC 1/4"-20 X 3/8" 492369 SCREW, HHC 5/16"-18 X 2-1/4" 18183 ROD-END, THROTTLE CABLE 492582 NUT, NYLOC 5/16"-18 EM504505 WRAP, TIE ............2....REPLACES P/N 504505 18242 HANDLE BAR ............1....REPLACES P/N 18282 18044 SWITCH, TRACTION ASSIST 15081...
  • Page 66 CHASSIS ASSY. PAGE 64 — WBH-16EAWD POWER BUGGY • OPERATION AND PARTS MANUAL — REV. #2 (09/12/19)
  • Page 67 CHASSIS ASSY. PART NO. PART NAME QTY. REMARKS 492583 NUT, NYLOC 3/8" 492598 WASHER, FLAT 3/8" 492313 SCREW, HHC 3/8"-16 X 1-1/2" 503112 SCREW, HHC 3/8"-16 X 2-3/4" 492375 SCREW, HHC 3/8"-16 X 12 492356 SCREW, HHC 1/4" NC X 3/4" GRD 5 492622 WASHER, LOCK 1/4"...
  • Page 68 HANDLE/FOOT DUMP CONTROLS ASSY. SEAL KIT DUMP VALVE REFERENCE HYDRAULIC DUMP ASSY. PAGE 66 — WBH-16EAWD POWER BUGGY • OPERATION AND PARTS MANUAL — REV. #2 (09/12/19)
  • Page 69 HANDLE/FOOT DUMP CONTROLS ASSY. PART NO. PART NAME QTY. REMARKS 492401 SCREW, HHC 1/2"-13 X 4 503119 NUT, NYLOC 3/16" 18121 KNOB, LEVER 18065 LEVER, DUMP VALVE 512185 SCREW, HHC 1/4"-20 X 1-3/4" 492622 WASHER, FLAT 1/4" 512183 SCREW, HHC 3/16"-24 X 1-1/4" 18064 VALVE, DUMP ...........1....INCLUDES ITEMS W/$ 18064SK...
  • Page 70 HYDRAULIC OIL TANK ASSY. PAGE 68 — WBH-16EAWD POWER BUGGY • OPERATION AND PARTS MANUAL — REV. #2 (09/12/19)
  • Page 71 HYDRAULIC OIL TANK ASSY. PART NO. PART NAME QTY. REMARKS 520461 RETAINER 801791 O-RING 520460 COVER 520343 O-RING 510717 BOLT, 1/2" NC X 1-3/4" EM16477 CAP, HYDRAULIC OIL TANK 18125 TANK, HYDRAULIC OIL 492376 SCREW, HHC 3/8" X 1-1/4" 492598 WASHER, FLAT 3/8"...
  • Page 72 BATTERY ASSY. PAGE 70 — WBH-16EAWD POWER BUGGY • OPERATION AND PARTS MANUAL — REV. #2 (09/12/19)
  • Page 73 BATTERY ASSY. PART NO. PART NAME QTY. REMARKS 505500 WINGNUT 512557 BATTERY CABLE, NEGATIVE 511250 BATTERY CABLE, POSITIVE 512555 BATTERY SUPPORT BRACKET EM923057 WASHER, FLAT 1/4" ..........6....REPLACES P/N 492596 2101402 WASHER, LOCK 1/4" ........2....REPLACES P/N 492622 508480 BATTERY SUPPORT PLATFORM 492357 BOLT 3/16"...
  • Page 74 FUEL TANK ASSY. (STEEL) NOTICE Beginning year 2012 with evaporative system. TO ENGINE CARBURETOR AIR FILTER INLET PORT 3/16” 3/16” 5.5 IN. 140 MM 3/16” HOSE REDUCER 1/4” O FF 1/4” 1/4” 3.1 FT. 945 MM PURGE PORT TANK PORT REF.
  • Page 75 FUEL TANK ASSY. (STEEL) PART NO. PART NAME QTY. REMARKS 520820 CAP, FUEL (EPA) 2" DIA. 802006 FUEL TANK NECK SEAL 800845 COVER, FUEL TANK, FRONT, PLASTIC 521392 COVER, FUEL TANK, REAR, PLASTIC 492356 SCREW, 1/4" X 3/4" GRD 5 492622 WASHER, LOCK 1/4"...
  • Page 76 FUEL TANK ASSY. (PLASTIC) PAGE 74 — WBH-16EAWD POWER BUGGY • OPERATION AND PARTS MANUAL — REV. #2 (09/12/19)
  • Page 77 FUEL TANK ASSY. (PLASTIC) PART NO. PART NAME QTY. REMARKS EM923343 WASHER, LOCK 5/16" EM492299 SCREW, HHC 5/16"-18 X 1/2" EM923023 WASHER, FLAT 5/16" 18166 CAP, FUEL 4" DIA. 506208 CLAMP, FUEL HOSE 19633 SEAL, FUEL TANK GROMMET 20795 VALVE, FUEL SHUT-OFF 512192 HOSE, FUEL EM20763...
  • Page 78 ENGINE MOUNTING ASSY. PAGE 76 — WBH-16EAWD POWER BUGGY • OPERATION AND PARTS MANUAL — REV. #2 (09/12/19)
  • Page 79 ENGINE MOUNTING ASSY. PART NO. PART NAME QTY. REMARKS 3564470394G1 ENGINE, B&S 18HP VANGUARD 492581 NUT, NYLOC 5/16" EM923023 WASHER, FLAT 3/8" ..........4....REPLACES P/N 505679 513593 90° FITTING 513594 ADAPTER PLUG 492368 SCREW, 5/16" NC X 2" GRD 5 ......1....GROUND CONNECTION 2105162 SCREW, 5/16"...

  • Page 80: Engine Service Parts

    ENGINE SERVICE PARTS PAGE 78 — WBH-16EAWD POWER BUGGY • OPERATION AND PARTS MANUAL — REV. #2 (09/12/19)
  • Page 81 ENGINE SERVICE PARTS PART NO. PART NAME QTY. REMARKS 394018S AIR FILTER 272490S PRE-CLEANER 692318 IGNITION SWITCH, W/KEY 691959 IGNITION KEY SET 845125 IN-LINE FUEL FILTER 496018S SPARK PLUG, CHAMPION 66574 ROPE, STARTER 808167 GRIP, STARTER 842921 OIL FILTER WBH-16EAWD POWER BUGGY • OPERATION AND PARTS MANUAL — REV. #2 (09/12/19) — PAGE 79...
  • Page 82 We sell worldwide for the brands: Genie, Terex, JLG, MultiQuip, Mikasa, Essick, Whiteman, Mayco, Toro Stone, Diamond Products, Generac Magnum, Airman, Haulotte, Barreto,...
