Installing/Removing Power Modules - Siemens SIMATIC NET RUGGEDCOM RSG2488F Installation Manual

7.
Installing a Module
To install a line module, do the following:
1.
2.
3.
4.
5.
6.
7.
4.3

Installing/Removing Power Modules

The RUGGEDCOM RSG2488F supports dual redundant power supply modules.
RUGGEDCOM RSG2488F
Installation Manual, 11/2019, C79000-G8976-1351-05
Connect power to the device.
Make sure power to the device has been disconnected and wait approximately
two minutes for any remaining energy to dissipate.
[Optional] If the device is installed in a rack, remove it from the rack.
Remove the current module from the slot.
Insert the new module into the slot.
1
2
Module
1
Chassis
2
Screw
3
Figure 4.3 Installing a Module
Tighten the screws to secure the module.
[Optional] If necessary, install the device in the rack.
Connect power to the device.
4.3 Installing/Removing Power Modules
3
Modules
33
