Installing a Power Module
To install a power module, do the following:
1.
2.
3.
4.
RUGGEDCOM RSG2488F
Installation Manual, 11/2019, C79000-G8976-1351-05
If equipped, remove the existing module.
Insert the module into the empty slot.
2
1
Screws
1
Power Supply
2
Chassis
3
Figure 4.6 Installing a Power Module
Hand-tighten the screws to secure the power module to the chassis.
Turn on power to the device and confirm the module is receiving and supplying
power. This is indicated by the LEDs on the module.
LED
O
I
4.3 Installing/Removing Power Modules
State
Green The module is supplying power
Green The module is receiving power
3
Description
Modules
