- Page 1 Double Ovens CD 900 CD 906 Users Operating Instructions Before operating this oven, please read these instructions carefully...
- Page 2 Dear Customer Thank you for choosing one of our appliances, carefully designed and built by our specialist staff and thoroughly tested to satisfy your cooking requirements. We suggest that you read this Instruction Booklet so that you will understand fully how to operate your appliance. Please keep the booklet handy.
-
Page 3: Important Precautions And Recommendations
IMPORTANT PRECAUTIONS AND RECOMMENDATIONS After having unpacked the appliance, check to ensure that it is not damaged. In case of doubt, do not use it and consult your supplier or a professionally qualified technician. Packing materials (i.e. plastic bags, polystyrene foam, nails, packing straps, etc.) should not be left around within easy reach of children, as they may cause serious injuries. - Page 4 Use and Care USING THE TOP AND THE BOTTOM OVEN FOR THE FIRST TIME You are advised to carry out the following operations: Clean the inside of the two ovens with a cloth soaked in water and neutral detergent and dry thoroughly. Hang the wire racks on the oven sides (Figure 1a and 1b).
- Page 5 TOP OVEN GENERAL FEATURES This is a conventional oven with 2 cooking options, thermostatically controlled. TOP OVEN OPERATING PRINCIPLES Heating and cooking in the CONVENTIONAL oven are achieved as follows: a. by normal convection The heat is produced by the upper and lower heating elements. b.by radiation The heat is irradiated by the infra red grill element.
- Page 6 Double oven Models: CD 900, CD 906 Temperature Temperature light light Figure 3 Function Thermostat Thermostat Function Digital electronic selector selector programmer (Bottom oven only)
-
Page 7: Temperature Selector Knob
Figure 4 Figure 5 TEMPERATURE SELECTOR FUNCTION SELECTOR KNOB (fig. 5) KNOB (fig. 4) This only sets the cooking temperature Rotate the knob clockwise to set the and does not switch the oven on. oven for one of the following functions. Rotate clockwise until the required temperature is reached (from 50 to 225°C). - Page 8 GRILLING The infrared grill element comes on. The heat is dispersed by radiation. Use with the thermostat set between 50° and 225°C and the oven door closed. For cooking hints, see the below chapter “GRILLING and AU GRATIN”. Recommended for: Intense grilling, browning, cooking au gratin and toasting etc.
- Page 9 Figure 6 Figure 7 FUNCTION SELECTOR KNOB TEMPERATURE SELECTOR KNOB (fig. 6) (fig. 7) Cook by turning the control knob until The light above the function selector the indicator on it is in line with the will illuminate when the oven is function required.
-
Page 10: Cooking With A "Fan" Oven
GRILLING Grill with the door closed and do not use the grill for longer than 30 minutes at any one time. The grill temperature is variable and can be set between 50 and 200 °C. Before using the grill, pre-heat for about five minutes. The grill element will become bright red in colour. - Page 11 GRILLING Turn the function selector control knob to position . Pre-heat grill for about 5 minutes, the infra red grill element in the top of the oven will become bright red in colour. Place the grill pan with the food brushed with a little oil, in the most convenient position (usually in the highest position, close to the infra-red grill).
- Page 12 Electronic programmer The electronic programmer is a device that groups together the following functions: – 24 hour clock with illuminated display – Timer (up to 23 hours and 59 minutes) – Programme for automatic oven cooking – Programme for semi-automatic oven cooking. Description of the buttons: Automatic cooking taking place Timer...
-
Page 13: Electronic Clock
ELECTRONIC CLOCK ELECTRONIC TIMER (fig. 11) The programmer is equipped with an The timer programme consists only of a electronic clock with lighted numbers buzzer which may be set for a which indicate hours and minutes. maximum period of 23 hours and 59 Upon immediate connection of the minutes. -
Page 14: Automatic Oven Cooking
AUTOMATIC OVEN COOKING 3.Set the temperature and the cooking programme by using the switch and To cook food automatically in the oven, thermostat knobs of the oven (see it is necessary to: specific chapters). 1.Set the length of the cooking time 2.Set the end of the cooking time Now the oven is programmed and 3.Set the temperature and the oven... -
Page 15: Semi - Automatic Cooking
At the end of cooking, the oven and SEMI - AUTOMATIC COOKING symbol will turn off, the AUTO This is used to automatically switch off will flash and a buzzer will sound; that the oven after the desired cooking time can be stopped by pushing any of the has elapsed. - Page 16 Cleaning and Maintenance BEFORE CALLING FOR ASSISTANCE If your oven will not work, make sure that: Electricity is being supplied (check your fuse box; circuit breaker, etc.) and plug fuse. The appliance is properly plugged in. GENERAL Installation, and any demonstration, information or adjustments are not included in the warranty.
-
Page 17: Removing The Oven Door
REMOVAL OF THE INNER GLASS Figure 18 DOOR PANEL The inner glass door panel can easily be removed for cleaning by unscrewing the two screws (figure 18). During re-assembly, ensure that the inner glass is correctly aligned and do not over tighten the screws. -
Page 18: Do's And Do Not's
DO’S AND DO NOT’S Do always grill with the oven door closed. Do always remove the detachable handles when using the grill pan. Do read the user instructions carefully before using the oven for the first time. Do allow the oven to heat for one and a half hours, before using for the first time, in order to burn off any protective oils. -
Page 19: How To Install Your Oven
HOW TO INSTALL YOUR OVEN You need the following housing area to fit your oven correctly. The double oven is designed to fit into a cabinet of 600 mm width. The double oven can be built in the kitchen units, but you must ensure that it is pro- perly ventilated. -
Page 20: Installation
Installation CAUTION: This appliance must be installed according to these instructions. ELECTRICAL REQUIREMENTS Connection to the mains must be carried out by qualified personnel in accordance with current regulations. The appliance must be connected to the mains checking that the voltage corresponds to the value given in the rating plate and that the electrical cable sections can withstand the load specified on the plate. -
Page 21: Replacing The Power Supply Cable
CONNECTING THE FEEDER CABLE Remove the two screws that hold shield A behind the oven. Open completely the cable clamp C Insert the feeder cable (type H05 RR-F) of minimum 6 mm section into the cable save P . Connect the phase and earth cables to terminal B according figure 23. The wires of this appliance must be coloured in accordance with the following code: GREEN AND YELLOW - EARTH BLUE - NEUTRAL... - Page 22 700 W Grill element 2100 W Botton element 1100 W Bottom oven (Multifunction) Grill element 2500 W Fan element 2500 W CDA continually strive to improve our products. For this reason we reserve the right to change specifications without prior notice.
