Page 1: Multifunction Ovens
Multifunction Ovens Manual for Installation, Use and Maintenance Customer Care Department • The Group Ltd. • Harby Road • Langar • Nottinghamshire • NG13 9HY T : 01949 862 012 F : 01949 862 003 E : service@cda.eu W : www.cda.eu... -
Page 2: Appliance Information
The CDA Group Ltd cannot be held responsible for injuries or losses caused by incorrect use or installation of this product. Please note that CDA reserve the right to invalidate the guarantee supplied with this product following incorrect installation or misuse of the appliance. -
Page 3: Before Using For The First Time
– Switch the empty oven ON at maximum temperature for about two hours to eliminate traces of grease and smell from the components. – Let the oven cool down, switch off the electrical supply, then clean the inside of the oven with a cloth soaked in water and neutral detergent and dry thoroughly. - Page 4 – Always use oven gloves when removing the shelves and food trays from the oven whilst hot. – Clean the oven regularly and do not allow fat or oils to build up in the oven base or trays. Remove spillages as soon as they occur.
-
Page 5: Control Panel
Please Note: This appliance incorporates a safety cooling fan which you will hear operating whenever the oven or grill are in use. The cooling fan may also operate when the oven is switched off. This fan is to reduce the external temperature of the appliance and cool the internal components. -
Page 6: Multifunction Oven
Multifunction Oven General Features As its name indicates, this is an oven that presents particular features from an operational point of view. In fact, it is possible to insert 7 different programmes to satisfy every cooking need. The 7 positions, thermostatically controlled, are obtained by 4 heating elements which are: –... -
Page 7: How To Use The Oven
The light will cycle on and off during cooking in line with the oven temperature. Function Selector Knob (Fig. 3) Rotate the knob clockwise to set the oven for one of the following functions. Oven Light By turning the function selector knob to this setting, the oven light will illuminate in the oven cavity. -
Page 8: Traditional Grilling
Caution: the oven door becomes very hot during operation. Keep children well out of reach. Defrosting Frozen Foods Only the oven fan comes on. Use with the thermostat knob set to “ ” - other positions have no effect. The food is thawed by ventilation without heating. - Page 9 The infrared grill element and the fan come on. The heat is dispersed mainly by radiation and the fan then distributes it all over the oven. Use with the oven door closed. The temperature can be regulated via the thermostat knob to between 50 °C and 225 °C.
-
Page 10: Cooking Advice
Regeneration Set the switch to position Bread becomes fragrant again if wet with a few drops of water and put into the oven for about 10 minutes at the highest temperature. Simultaneous Cooking of Different Foods With the function selector in position of food at the same time. - Page 11 – that the cooking time depends on the quantity and the type of foods. Use of the Grill – Preheat the oven for about 5 minutes with the door closed. – Introduce the food to be cooked, positioning the rack as close to the grill as possible.
-
Page 12: Clock And Timer With "Touch-Control" Keys
- Oven set for manual cooking “ ” ” and AUTO AUTO flashing - Automatic cooking being set “ ” and AUTO steady illumination - Oven set for automatic cooking, cooking taking place. “ ” key); ” Fig. 4... -
Page 13: Setting The Clock
” symbol is steady illuminated. Using the Timer You can use the timer at any time, even when the oven is not in use. The timer does not turn the oven off. The timer can be set for up to 23 hours and 59 minutes. -
Page 14: Automatic Cooking
The oven will switch off but is now set for automatic cooking. If you are already at home to turn the oven on and only want the oven to turn off automatically, start cooking as normal, then follow step 4 or step 5 to set a time to stop the oven. -
Page 15: Do's And Do Not's
– Do read the user instructions carefully before using the oven for first time. – Do allow the oven to heat for one and a half hours, before using for the first time, in order to expel any smell from the new oven insulation, without the introduction of food. -
Page 16: Care And Maintenance
Inside of Oven The oven should always be cleaned after use when it has cooled down. The cavity should be cleaned using a mild detergent solution and warm water. Suitable proprietary chemical cleaners may be used after first consulting with the manufacturers recommendations and testing a small sample of the oven cavity. - Page 17 CAUTION: Do not store flammable material in the oven. CAUTION: Do not use harsh abrasive cleaners or sharp metal scrapers to clean the oven door glass since they can scratch the surface, which may result in shattering of the glass.
- Page 18 WARNING: Ensure the appliance is switched off before replacing the lamp to avoid the possibility of electric shock. – Let the oven cavity and the heating elements to cool down; – Switch off the electrical supply; – Remove the protective cover C (fig. 5);...
- Page 19 Assembling and Dismantling of the Side Runner Frames – Assemble the wire racks to the oven walls using the 2 screws (Fig. 6). – Slide the tray and rack into the runners (Fig. 7). The rack must be fitted so that the safety catch, which stops it sliding out, faces the inside of the oven.
-
Page 20: Oven Door
When removing and replacing the inner glass, the door should be held still by one person (fig. 8). A second person should gently remove the glass (fig. 10). To clean the inner pane of the oven door on both sides operate as follows: – Open the oven door. - Page 21 – Reassemble the seal G in the correct way (fig. 14) by hooking the no. 3 fixing hooks in the proper holes. Fig. 12 The oven door has a sealed gasket in the top part. It is normal the opened gap between the top edge of the inner glass and the sealed gasket.
-
Page 22: Advice For The Installer
Always disconnect the appliance from the electrical supply before carrying out any maintenance operations or repairs. • The walls surrounding the oven must be made of heat-resistant material. • Taking care NOT to lift the oven by the door handle. - Page 23 60 cm. Installation requires a compartment as illustrated in figures 16 and 17. On the lover side, the oven must lay on supports standing the oven weight. Note: please consider the side opening of the door (either right of left hinged, dependent on model) when installing the oven.
- Page 24 To ensure internal ventilation, aeration channels must be provided as illustrated in the figures 18 and 19. 50 mm 30 mm Fig. 18 Fig. 19...
-
Page 25: Fixing The Oven
Fixing the Oven Introduce the oven into the furniture opening and fix it with screws (not supplied) as figure 20. It is essential that the oven rests on a surface which will support its weight, as the screw fixing is only complementary. - Page 26 – To avoid damage to the lower trim please note the following instructions. – The lower trim is designed to allow for good air circulation and the correct opening of the oven door. – To ensure the trim is not damaged due to the appliance being placed on the floor, the appliance should be suitably supported as in below illustrations.
-
Page 27: Mains Electricity Connection
Mains Electricity Connection Incorrect installation may be dangerous and the manufacturer can not be held responsible. Warning! This appliance must be earthed The manufacturer declines all responsibility for any problem caused by failure to observe this rule. THIS APPLIANCE MUST BE CONNECTED TO THE MAINS SUPPLY BY A COMPETENT PERSON, USING FIXED WIRING VIA A DOUBLE POLE SWITCHED FUSE SPUR OUTLET AND PROTECTED BY A 13A FUSE. - Page 28 Connection of the Power Supply Cable Unhook the terminal board cover by inserting a screwdriver into the two hooks “A” (fig. 23). Open the cable gland by unscrewing screw “F” (fig. 24), unscrew the terminal screw and remove the cable. The new supply cable, of suitable type and section, is connected to the terminal board following the diagram of fig.
-
Page 29: Appliance Servicing
Appliance Servicing CDA provide a quality and effective after-sales service to cover all your servicing needs. Please attach your receipt to this page for safekeeping. Please help us to help you by having the following information available when booking a service-call: 1. - Page 30 After the first year and within five years, the parts will be supplied free of charge provided that the repair is carried out by an agent authorised by CDA and the labour will be charged at the commercial rate applicable at the time of repair.
- Page 32 Customer Care Department • The Group Ltd. • Harby Road • Langar • Nottinghamshire • NG13 9HY T : 01949 862 012 F : 01949 862 003 E : service@cda.eu W : www.cda.eu...
