- Page 1 SK310 Single Ovens Installation, Use and Maintenance Customer Care Department • The Group Ltd. • Harby Road • Langar • Nottinghamshire • NG13 9HY T : 01949 862 012 F : 01949 862 003 E : customer.care@cda.eu W : www.cda.eu www.cda.eu...
- Page 2 Keep the oven door closed whilst grilling. Appliance information: Please enter the details on the appliance rating plate below for reference, to assist CDA Customer Care in the event of a fault with your appliance and to register your appliance for guarantee purposes.
- Page 3 Appliance Model Serial Number CE Declarations of Conformity: This oven has been designed, constructed and marketed in compliance with safety requirements of EEC Directive 2006/95/EEC (Low voltage) and requirements of EMC Directive 2004/108/EEC. This appliance has been manufactured to the strictest standards and complies with all applicable legislation, including Electrical safety (LVD) and Electromagnetic interference compatibility (EMC).
- Page 4 Important • Read the user instructions carefully before using the oven for the first time. • Follow the instructions for first use of the oven. • Clean the oven regularly. • Remove spills as soon as they occur. • Always use oven gloves when removing shelves and trays from the ovens.
-
Page 5: First Use Of The Oven
• Do not attempt to repair the internal workings of your oven. • Do not cover the oven floor with aluminium foil. First Use of the Oven First use • The decorative metal finish of this appliance has been coated with a preservative to protect it during transport and storage. -
Page 6: Oven Controls And Use
Please note: • This oven has been fitted with a cooling fan to achieve maximum efficiency and to maintain low surface temperatures. The cooling fan will switch on automatically when the oven switches on. It is normal for the cooling fan to run for an hour or more after use, depending on the duration, temperature and type of cooking programme used. - Page 7 (Fig. 1). Fig. 1 SK110 & SK210 Defrost (Shelf position 3, 4 or 5) Using the fan only this oven function circulates the air around the oven cavity, speeding up the natural defrost process (1kg takes approximately one hour, depending on the type of food).
- Page 8 Fanned Grill (Grill pan position 1, 2 or 3) This function uses the fan to circulate the heat from the grill element around the food. The temperature can be set between 50 ° C and 250 ° C. Full Grill (Grill pan position 1, 2 or 3) This function radiates the heat from the grill element.
- Page 9 SK310 Defrost (Shelf position 3, 4 or 5) Using the fan only this oven function circulates the air around the oven cavity, speeding up the natural defrost process (1kg takes approximately one hour, depending on the type of food). Fan Oven (Shelf position 4 or 5) Using the circular element and the fan with a temperature between 50°C and 250°C, this cooking function blows the air into and around the oven cavity.
- Page 10 Warming Oven (Shelf position 5 or 6) Using heat produced only by the bottom element, this natural heat is perfect for dough proving and blind- baking. Fan Assisted Oven (Shelf position 3, 4 or 5) Using the circular element and the fan with a temperature between 50 °...
- Page 11 Programming the Oven (SK210 & SK310 Only) Please note: • The alert beep will cut off after two minutes if it is not switched off 1 Cooking time manually. indicator 2 End of cooking time indicator Setting the clock 3 Minute minder The clock is preset to 12:00, and will indicator 4 Current time indicator...
- Page 12 To set the minute minder: • Touch repeatedly until the minute minder indicator flashes. • Then touch to select the required duration for the minute minder. When the correct duration shows on the display, either touch or wait for approximately five seconds. The minute minder indicator will remain lit to confirm the minute minder is on.
- Page 13 Semi-automatic cooking The oven can be set to switch off automatically at a preset time up to a maximum of 10 hours. To set a semi-automatic cooking programme: • Select the oven function and temperature (the oven will switch on). •...
- Page 14 seconds. The cooking time and end of cooking time indicators will remain lit to confirm the automatic programme is on. • The oven will switch off until the automatic programme starts. When the programme starts, the cooking time indicator will switch off •...
-
Page 15: Care And Maintenance
Proprietary stainless steel cleaners are available. We recommend the CDA E-Cloth available from the CDA Sales Team for cleaning stainless steel surfaces as this has been designed to prolong the finish of your appliance. - Page 16 Suitable proprietary chemical cleaners may be used after first consulting with the manufacturer’s recommendations and testing a sample on a small area of the oven cavity. Abrasive cleaning agents or scouring pads/cloths should not be used on the cavity surface. Oven door glass As the oven door is double glazed, the inner glass may be removed for cleaning both the inner glass and the inside face of the outer...
-
Page 17: Oven Door
Oven Door Removing the Oven Door The oven door can easily be removed as follows: • Open the door to the full extent (Fig. Fig. 4 • Open the lever A completely on the left and right hinges (Fig. 5). •... - Page 18 Changing the bulb - Lateral lights (SK310 Only) • Remove all shelves and the grill pan from the oven. • Gently unclip the side rack from its lower locating stud and unhook its top to remove it. Note: No tools are required and the stud should not be removed. •...
- Page 19 Changing the bulb - Back light (SK110 & SK210 Only) Unscrew the protective cover. We recommend that you wash and dry the glass cover at this point. Carefully remove the old bulb and insert the new bulb suitable for high temperatures (300ºC) having the...
-
Page 20: Installation
Installation Important If the oven is being installed into a built under oven housing unit ensure that the front rail at the top of the unit is not installed as it could restrict ventilation. Ensure that air can flow freely around the housing area. If the oven is being installed into a fully enclosed built-under oven housing unit it may be necessary to cut a small slot in the top of the plinth fitted under the unit. - Page 21 housing should not be free standing but be secured to the wall and/or adjacent fittings. How to install your oven You will need the following housing area to fit your oven correctly. The oven is designed to fit into a cabinet of 600mm width. The oven can be built in or built under the kitchen units, but you must ensure that it is properly ventilated.
-
Page 22: Electricity Supply To Your Oven
Electricity Supply to DOUBLE POLE SWITCHED FUSE SPUR OUTLET Your Oven Warning! this appliance must be earthed. This appliance must be connected by a competent person, using fixed wiring via a double pole switched fused spur outlet, protected by a 13A fuse. We recommend that the appliance is connected by a qualified electrician, who is a member of the N.I.C.E.I.C. - Page 23 Energy consumption required to heat a MJ/cycle : Gas cavity standardised load in a gas‐fired cavity of an kWh/cycle oven during a cycle in conventional mode per cavity (gas final energy) Energy consumption required to heat a MJ/cycle : Gas cavity standardised load in a gas‐fired cavity of an kWh/cycle oven during a cycle in fan‐forced mode per cavity (gas final energy) E & O E. All instructions, dimensions and illustrations are provided for guidance only. CDA reserve the right to change specifications without prior notice.
- Page 24 Group Ltd. • Harby Road • Langar • Nottinghamshire • NG13 9HY T : 01949 862 012 F : 01949 862 003 E : customer.care@cda.eu W : www.cda.eu T : 01949 862 012 F : 01949 862 003 E : customer.care@cda.eu W : www.cda.eu www.cda.eu...
