General Description
The MAX2385/MAX2386 evaluation kits (EV kits) simpli-
fy evaluation of the MAX2385/MAX2386. The EV kits
allow the evaluation of the CDMA and GPS low-noise
amplifiers (LNA), as well as the CDMA and GPS down-
converter mixers, without the use of any additional sup-
port circuitry. The signal inputs and outputs use SMA
connectors to simplify the connection of RF test equip-
ment.
The MAX2385/MAX2386 EV kits are assembled with an
associated IC and incorporate input and output match-
ing components optimized for RF frequencies from
832MHz to 870MHz and an IF frequency of 110MHz.
DESIGNATION
QTY
1000pF ±10% ceramic capacitors
C1, C42
2
(0402)
Murata GRM36X7R102K050A
7.0pF ±0.1pF ceramic capacitors
C3, C4, C39,
4
(0402)
C40
Murata GRM36COG070B050A
0.5pF ±0.1pF ceramic capacitors
C5, C6, C13,
5
(0402)
C37, C38
Murata GRM36COG0R5B050A
100pF ±5% ceramic capacitors
C7, C8, C22,
C24, C30,
7
(0402)
C34, C35
Murata GRM36COG101J050A
0.01µF 10% ceramic capacitors
C9, C26
2
(0402)
Murata GRM36X7R103K016A
3.0pF ±0.1pF ceramic capacitor
C12
1
(0402)
Murata GRM36COG030B050A
6.8nF ±10% ceramic capacitors
C16, C23,
4
C29, C33
Murata GRM36COG682B050A
2.2pF ±0.1pF ceramic capacitor
C19
1
(0402)
Murata GRM36COG2R2B050A
2.0pF ±0.1pF ceramic capacitors
C25, C32
2
Murata GRM36COG020B050A
UCSP is a trademark of Maxim Integrated Products, Inc.
________________________________________________________________ Maxim Integrated Products
For pricing, delivery, and ordering information, please contact Maxim/Dallas Direct! at
1-888-629-4642, or visit Maxim's website at www.maxim-ic.com.
MAX2385/MAX2386 Evaluation Kits
DESCRIPTION
o +2.7V to +3.6V Operation
o 50Ω SMA Inputs and Outputs on RF, IF, and LO
Ports for Easy Testing
o All Matching Components Included
o Fully Assembled and Tested
Ordering Information
PART
TEMP. RANGE
MAX2385EVKIT
-40°C to +85°C
MAX2386EVKIT
-40°C to +85°C
DESIGNATION
QTY
22µF ±10% tantalum capacitor,
C case
C27
1
AVX TAJC226K016
1.8pF ±0.1pF ceramic capacitor
(0402)
C28
1
Murata GRM36COG1R8B050A
J1, J2, J3, J5,
SMA edge mounts
7
J9, J11, J12
EFJohnson 142-0701-801
SMA PC mounts
J4, J7, J10
3
EFJohnson 142-0701-201
JU1, JU2,
1
4
JU3, JU8
Digi-Key S1012-36-ND
1
JU4–JU7
4
Digi-Key S1012-36-ND
Shunts
JU1–JU9
9
Digi-Key S9000-ND
L2, L3, L10,
180nH 5% inductors
4
L11
Toko 1608-FSR18J
2.7nH ±0.3nH inductor
L4
1
Toko 1608-FS2N7S
5.6nH ±0.3nH inductors
L5, L6
2
Toko 1608-FS5N6S
22nH ±2% inductor
L7
1
Murata LQW1608A22NG00
3.9nH ±0.3nH inductor
L8
1
Toko 1608 FS3N9S
Features
IC PACKAGE
✕
5
4 UCSP™
✕
5
4 UCSP™
Component List
DESCRIPTION
✕
2 headers (0.1in centers)
✕
3 headers (0.1in centers)
1
