Hotpoint
Ultima
Freestanding
Dishwashers
with Bit100
Electronics
Models Covered:-
FDW80
FDW85
Note:
Models produced after June
2006 with DEA600 Electronics
see Manual 5407345
Advertisement
Table of Contents
Related Manuals for Hotpoint Ultima FDW85
Summary of Contents for Hotpoint Ultima FDW85
-
Page 1: Service Information
5412771 Issue 2 Aug. 2006 Hotpoint Ultima Freestanding Dishwashers with Bit100 Electronics Models Covered:- FDW80 FDW85 Note: Models produced after June Service 2006 with DEA600 Electronics see Manual 5407345 Information Indesit Company UK Ltd © 2006 Reg. Office: Peterborough PE2 9JB. Registered in London: 106725... -
Page 2: Table Of Contents
SAFETY NOTES & GENERAL SERVICING ADVICE 1. This manual is NOT intended as a comprehensive repair/maintenance guide to the appliance. 2. It should ONLY be used by suitably qualified persons having technical competence applicable product knowledge and suitable tools and test equipment. 3. -
Page 3: Technical Specification
TECHNICAL SPECIFICATIONS General Model Colour Commercial Code FDW80 P - Polar White 33187 FDW80 T - Sandstone 33188 FDW80 G - Graphite 33189 FDW85 A - Aluminium 33190 Country of Origin Italy Energy Class Washing Class Drying Class Noise Level 46 dB Dimensions Height 850 mm... -
Page 4: General Information
GENERAL INFORMATION All models are freestanding dishwashers, they provide a choice of 8 wash programmes to suit load requirements. An LED display control unit allows the selection of the wash programmes, time delay, extra dry and half load. The display indicates, with the use of symbols, the selected programme, the progress of the programme, if the time delay and half load options have been selected. -
Page 5: Water Hardness Table
WATER HARDNESS TABLE Water Hardness Salt Clarke Selector Salt Doses °fH mmol/l Consumption Degrees Position per 2 kg (grams/cycle) 0 - 14 0 - 17 0 - 1.7 14 - 36 18 - 44 1.8 - 4.4 36 - 71 45 - 89 4.5 - 8.9 >... -
Page 6: Console Panel
CONSOLE PANEL A. On/Off Button Display M. Model Button Press this button to turn the display on. Pressing this button selects the Auto Duo-Wash cycle, the Delayed Start, the B. Display Extra Drying and the Half Load. Displays the functions in progress N. -
Page 7: Programme Guide
PROGRAMME GUIDE Detergent Wash Cycle Cycle Selection Cycle Rinse Duration - Mins Cycle Instructions Description Pre-Wash (without extra & Wash drying) Very dirty dishes and pans Pre-wash with hot water at 5 + 25 g Intensive (not to be used for delicate 40°C items) Extended wash at 65°... -
Page 8: Component Description
COMPONENT DESCRIPTION Fill Valve The appliance has an electromagnetically operated solenoid valve, which is connected to the water supply. As the machine fills, a quantity of water is diverted into the fill tank for later use in the regeneration sequence. A typical fill sequence is as follows: The water turbine fills the dishwasher with 2 litres of water. - Page 9 Turbidity Sensor Situated in the hose between the circulation motor and heater. It consists of an infrared transmitter and receiver and it has two function within the dishwasher, identifying the soil level and the presence of rinse aid. The analogue value it produces is sent to the control module for processing. During a cycle, e.g.
- Page 10 Turbo Dry Fan & Condenser - Fitted to models before Serial Number 50214.0000 Mounted on the right hand side of the dishwasher, consisting of a condenser and fan. The fan creates a vacuum in the condensation chamber by sucking dry air (30% RH) from the side of the dishwasher and moist air (100%RH) from inside the dishwasher tub.
- Page 11 Rinse Aid Warning Indicator Situated next to the salt indicator, illuminates when the rinse aid reservoir requires refilling. The turbidity sensor achieves the detection of rinse aid, utilising the same principle as soil level detection. The final rinse water is measured 5 seconds before the rinse aid is dispensed and another reading is taken 1 minute after the rinse aid has been dispensed, The two readings are compared.
- Page 12 The are three types of filter cleaning cycles depending at which part of a programme the blockage is detected. The charts below show the filter cleaning sequence for the three possible situations that may occur. Example 1 - During Pre-Wash Rinse to 70°C Drain...
- Page 13 Example 3 - During Rinse Rinse to 70°C Jog-type rinse 10 mins If the sensor contacts open for at least 5 Drain and fill secs, after point 1 the rinse is repeated. 6.5 litres If the sensor contacts open during the 2nd rinse (for at least 5 secs), after point 1 the dishwasher shows the filter cleaning alarm.
- Page 14 SPECIAL FILTER CLEANING CYCLE FLOW CHART Cycle start Drain + 1st fill 2.5l filled in-cycle via the turbine Pressure switch / filter Check cleaning alarm AL 05 pressure switch The DW fills 4.2l during the 1st prerinse (approx. 0.5l extra, taking into account water 2 litres filled via the TURBINE deposited on dry dishes);...
-
Page 15: Installation Instructions
INSTALLATION INSTRUCTIONS Choose where you want to install your dishwasher, you can even place it so that its sides or back panel are side by side with furniture or up against the wall. The dishwasher is provided with water supply and drain hoses, which can be directed towards the left or right to facilitate appropriate installation. - Page 16 SERVICING NOTES & DISMANTLING INSTRUCTIONS SAFETY NOTES:- ENSURE THAT THE MACHINE IS UNPLUGGED BEFORE DISMANTLING. BEWARE OF SHARP EDGES ON METAL PANELS AND PRESSED PARTS. A. Top Cover Remove the two screws at the rear securing the top. Slide the top forward to remove. B.
- Page 17 Door Latch & Switch Remove the console as in (F). Disconnect the wiring from the microswitch. Remove the 2 screws securing the door latch to the console. Replace in reverse order. LCD Module Remove the console as in (F). Remove the ribbon cables. Remove the 2 screws securing the module to the console.
- Page 18 N. Turbidity Sensor Remove the base panel as in (B). Remove the heater as in (M). Slacken the hose clip securing the sensor hose to the circulation motor. See (L8). Remove the retaining screw from the connector block on the sensor and remove the connector, making special note of the orientation of the plug, as it is not keyed.
- Page 19 S. Sump Assembly Remove the lower basket, filters and lower spray arm. Fig. 1 Fig. 2 Insert Special Tool (Part Number 5600269) into the sump retaining ring as in Figs. 1 and 2 above. Turn the tool anti-clockwise to remove the sump retaining ring. The sump retaining tool can also be used to assist in refitting the sump retaining ring.
-
Page 20: Fault Codes & Diagnostics
FAULT CODES & DIAGNOSTICS If an error is detected in programme, the programme will be terminated and one of the following errors will be displayed on the LCD. Fault Fault Possible Cause(s) Code AL 01 Overflow (water in base Leak from water line. pan). - Page 21 Possible Reasons For Fault Code Displayed Note: - Always carry out an earth insulation test before using the fault guide, an earth fault on a component or damaged wiring may display fault codes not related to the component signalled, e.g. an earth fault on the element can display A02.
- Page 22 Time out for filling. The module has not detected turbine rotation with the inlet valve energised. • Check the taps are turned on and that the fill hoses are not kinked. • Check the inlet valve coil (4k ohms approximately) and wiring to valve and edge connector on module.
-
Page 23: Test Programme
TEST PROGRAMME The following test programme can be used if a fault is suspected within the appliance. There are two test that can be carried out - a 5 minute and a 20 minute test. Each of the two tests performs the same functional check of components with the 20 minute test heating the water to 55°C, verifying the operation of the heater and thermistor. - Page 24 • If the machine has a low resistance to Earth the timer card may become confused and LEDs may not display and the machine may not start. • If a new timer card has been fitted and will not come off the test cycle, check: - 1.
-
Page 25: Sequence Chart
SEQUENCE CHART PREWASH Drain and reset alternating wash valve to Position 0 30'' Open Fill 2 litres static via water turbine Verify Pressure Switch Closed Closed Fill 2.7 Litres & Circulate Circulate 20'' Circulate Alternating Valve Position 1 & Verify Pressure Sensor Closed Circulate Alternating Valve Position 1 &... - Page 26 Circulate in Alternating Valve Position 1 Circulate in Alternating Valve Position 1 Circulate in Alternating Valve Position 1 X 120'' Circulate in Alternating Valve Position 1 Drain 60'' Drain and reset alternating wash valve to Position 0 15'' Open Fill 2 litres static via water turbine Verify Pressure Switch Closed Closed Fill 2 Litres via water turbine &...
-
Page 27: Wiring Diagram
