Product Identification And Scope Of Delivery; Product Identification And Type Plate; Scope Of Delivery - Bosch Rexroth IndraControl XFE 01.1 Series Operating Instructions Manual

Extension Modules Profibus, RT-
Ethernet, Sercos, CAN

2 Product identification and scope of delivery

2.1 Product identification and type plate

1
MNR: R911172531 -AA0
17
FW: 101
16
15
14
13
12
"IND.CONT.EQ"
32FB
2700729
1 Word mark
2 Part number
3 Device name
4 State of revision
5 Functional index
6 Plant number
7 Serial number
8 Serial number as barcode
9 Date of manufacture (yyWww)
10 CE conformity marking
Fig. 2-1: Exemplary type plate

2.2 Scope of delivery

Extension module
●
Bus base
●
24 V power connector XA-CN01
●
DOK-CONTRL -XFE**EXTMOD-IT04-EN-P
Product identification and scope of delivery
2 3 4 5 6
IndraControl S20
7260
FI: 001
Bosch Rexroth AG, Bgm.-Dr.-Nebel-Str. 2
DE-97816 Lohr Hotline: +49 9352 405060
Made in Germany
U DC 24 V
N
I 0.6 A
N
I-V-C-B-T-V
11
16 channels
Wire Range 24-16
II 3G TÜV 16 ATEX 7949 U
Ex ec IIC Gc IECEx TUR 16.0049 U
19
7 8
SN: 7260007123456BC
CERTIFIED
18
11 Company address
12 Underwriters Laboratories Inc. mark
13 Check digit
14 Nominal current
15 Nominal voltage
16 Manufacturing country
17 Software release
18 QR code
19 Explosion protection marking
