- Page 3 ▶ Make a note in one of the following tables of the designation and serial number printed on the type identification plate. ▶ Always quote this information when you contact a Hilti representative or Hilti Service to enquire about the product.
-
Page 4: Table Of Contents
▶ Remove the battery if the tool is to remain unused for a long period of time. Electrical ▶ Although the device complies with the strict requirements of the applicable directives, Hilti cannot entirely rule out the possibility of interference to the device caused by powerful electromagnetic radiation, possibly leading to incorrect operation. - Page 5 2.2 Use and care of battery-powered tools ▶ Use only the Hilti batteries specified for use with this product. ▶ Observe the special guidelines applicable to the transport, storage and use of Li-ion batteries. ▶ Check that the product is switched off before fitting the battery.
- Page 6 3 Description 3.1 Accessories Battery PSA 81 AC adapter PUA 81 English Printed: 19.08.2016 | Doc-Nr: PUB / 5070470 / 000 / 01...
- Page 7 & 3.2 Intended use Use the PSA 80 only to power the Hilti PS 200 S Ferroscan and the PS 200 M monitor. Charge the PSA 80 battery with the PUA 80 charger. Use the PSA 81 battery only to power the Hilti PS 1000 X-Scans. Charge the PSA 81 (01 and 02) battery only with the PUA 81 AC adapter or the PUA 82 motor vehicle power adapter.
-
Page 8: Psa 81
The error message can have the following causes: • Voltage too high • Short circuit • Voltage too low • Temperature is outside the charging temperature range • Wrong charger is connected • Electronic fault While charging, the LEDs show the following statuses: Status Meaning 3 LEDs light, 1 LED blinks. -
Page 9: Psa 81
PSA 80 PSA 81 (01 and 02) PSA 81 (05) Charging temperature 0 ℃ …40 ℃ 0 ℃ …40 ℃ 0 ℃ …40 ℃ Weight 0.3 kg 0.3 kg 0.3 kg Min. number of charging cy- 500 (typically) •/• •/• cles PSA 82 PSA 83... - Page 10 5 Operation 5.1 Inserting the battery PSA 80 ▶ Hold the battery end cap so that it is facing you and the large groove on the battery is on the left. ▶ Slide the battery into the battery compartment. ▶ Turn the end cap clockwise until it engages. PSA 81 English Printed: 19.08.2016 | Doc-Nr: PUB / 5070470 / 000 / 01...
- Page 11 ▶ Push the battery in until it engages securely. ▶ Check that the battery is securely seated in the tool. PSA 82 English Printed: 19.08.2016 | Doc-Nr: PUB / 5070470 / 000 / 01...
- Page 12 ▶ Insert the battery at an angle into the battery compartment. ▶ Push the battery into the battery compartment until it is heard to engage. ▶ Check that the battery is securely seated in the tool. PSA 83 English Printed: 19.08.2016 | Doc-Nr: PUB / 5070470 / 000 / 01...
- Page 13 ▶ Insert the end of the battery in the battery compartment. ▶ Push the battery into the battery compartment until it is heard to engage. ▶ Push the small slider on the back toward the battery compartment. ▶ Check that the battery is securely seated in the tool. 5.2 Removing the battery PSA 80 English...
- Page 14 ▶ Turn the end cap counterclockwise. ▶ Remove the battery from the tool. Note Remove the battery only when the tool is switched off. Data may otherwise be lost. PSA 81 English Printed: 19.08.2016 | Doc-Nr: PUB / 5070470 / 000 / 01...
- Page 15 ▶ Push the catch together. ▶ Remove the battery. Note Remove the battery only when the tool is switched off. Data may otherwise be lost. PSA 82 English Printed: 19.08.2016 | Doc-Nr: PUB / 5070470 / 000 / 01...
- Page 16 ▶ Press the spring catch in. ▶ Remove the battery. Note The battery can be exchanged while the tool is in operation. The built-in backup battery is capable of powering the tool for approx. 5 minutes. PSA 83 English Printed: 19.08.2016 | Doc-Nr: PUB / 5070470 / 000 / 01...
- Page 17 ▶ Push the small slider on the back away from the battery compartment. ▶ Push the large slider toward the small slider. ◁ The battery is lifted. ▶ Remove the battery. 5.3 Charging the battery PSA 80 English Printed: 19.08.2016 | Doc-Nr: PUB / 5070470 / 000 / 01...
- Page 18 ▶ Make sure the system to be charged is standing securely. ▶ Remove the battery. → page 11 ▶ Connect the supply cord and the battery to the PUA 80 charger. ◁ The battery is charging Note Charge the battery for at least 14 hours before using it for the first time. ▶...
- Page 19 ▶ Make sure the system to be charged is standing securely. ▶ Remove the battery. → page 11 ▶ Connect the PUA 81 AC adapter to the battery. ◁ The battery is charging Note Charge the battery for at least 2 hours before using it for the first time. Alternatively, you can use the motor vehicle power adapter to charge the PUA 82 battery.
- Page 20 ▶ Remove the battery. → page 11 ▶ Connect the PUA 85 19V charger to the battery. ◁ The battery is charging. Note Charge the battery for at least 2 hours before using it for the first time. Alternatively, you can use the PUA 82 motor vehicle power adapter or the PUA 81 AC adapter to charge the battery.
- Page 21 PSA 82 ▶ Make sure the system to be charged is standing securely. ▶ Remove the battery. → page 11 ▶ Insert the battery in the PSA 85 charger. ◁ The battery is charging ▶ When the battery is fully charged, remove the battery from the charger. ▶...
- Page 22 To help ensure safe and reliable operation, use only genuine Hilti spare parts and consumables. Spare parts, consumables and accessories approved by Hilti for use with the product can be found at your local Hilti Center or online at: www.hilti.com 7 Disposal Most of the materials from which Hilti tools and appliances are manufactured can be recycled.
