Furuno CH-500 Installation Manual

Dual-frequencysearchlight sonar
Hide thumbs Also See for CH-500:
Table of Contents

Advertisement

Quick Links

See also: Operator's Manual
DUAL-FREQUENCY SEARCHLIGHT SONAR
Safety Instructions .............................................................................................................i
System Configuration .......................................................................................................iii
Equipment Lists.....................................................................................................................iv
1.MOUNTING............................................................................................................................ 1-1
1.1
Required Tools And Materials.......................................................................................................... 1-1
1.2
Control/Display Unit (Standalone Type) .......................................................................................... 1-2
1.3
Display Unit (Black Box Type) ......................................................................................................... 1-3
1.4
Control Unit (Black Box Type) ........................................................................................................ 1-6
1.5
Transceiver Unit............................................................................................................................... 1-9
1.6
Hull Unit ......................................................................................................................................... 1-10
1.7
External Monitor............................................................................................................................. 1-35
2. WIRING ............................................................................................................................... 2-1
2.1
Control/Display Unit (Standalone Type) .......................................................................................... 2-2
2.2
Display Unit (Black Box Type) ......................................................................................................... 2-3
2.3
Control Unit (Black Box Type) ........................................................................................................ 2-4
2.4
Transceiver Unit............................................................................................................................... 2-4
2.5
Hull Unit .......................................................................................................................................... 2-7
2.6
Auto Filter ........................................................................................................................................ 2-9
2.7
Input/Output Sentences (Nmea0183) ........................................................................................... 2-10
2.8
Input/Output Pgns (Nmea2000)................................................................................................... 2-10
3. CHECKING AND INITIAL SETTINGS ................................................................................ 3-1
3.1
Check Points After Installation......................................................................................................... 3-1
3.2
Language Setting............................................................................................................................. 3-2
3.3
Heading Alignment, Draft And Stroke Adjustments ......................................................................... 3-3
3.4
Checking Tx Frequency .................................................................................................................. 3-5
3.5
3.6
Motion Sensor Offset ....................................................................................................................... 3-6
3.7
Navigation Equipment Setup ........................................................................................................... 3-8
3.8
System Backup................................................................................................................................ 3-9
3.9
Color Settings ................................................................................................................................ 3-11
3.10 Automatic adjustment of the train direction.................................................................................... 3-11
3.11 Decreasing cavitation .................................................................................................................... 3-12
Appendix 1 Jis Cable Guide ....................................................................................... AP-1
Packing ListS....................................................................................................................... A-1
OUTLINE DRAWINGS.............................................................................................................. D-1
Interconnection Diagram ............................................................................................. S-1
All brand and product names are trademarks, registered trademarks or service marks of their respective holders.
Installation Manual
SEARCHLIGHT SONAR
Model
www.furuno.com
CH-500/CH-600

Advertisement

Table of Contents
loading

Related Manuals for Furuno CH-500

Summary of Contents for Furuno CH-500

  • Page 1 Installation Manual SEARCHLIGHT SONAR DUAL-FREQUENCY SEARCHLIGHT SONAR CH-500/CH-600 Model SAFETY INSTRUCTIONS ......................i SYSTEM CONFIGURATION .......................iii EQUIPMENT LISTS........................iv 1.MOUNTING..........................1-1 Required Tools and Materials......................1-1 Control/Display Unit (Standalone Type) ..................1-2 Display Unit (Black Box Type) ......................1-3 Control Unit (Black Box Type) ......................1-6 Transceiver Unit..........................
  • Page 2 7KH SDSHU XVHG LQ WKLV PDQXDO LV HOHPHQWDO FKORULQH IUHH )85812 $XWKRUL]HG 'LVWULEXWRU'HDOHU  $VKLKDUDFKR 1LVKLQRPL\D  -$3$1 $  0$5  3ULQWHG LQ -DSDQ $OO ULJKWV UHVHUYHG +  0$<   3XE 1R ,0(+ (70, &+&+           ...
  • Page 3 Water leakage can sink the vessel. Also confirm that the transducer will not loosen by ship’s vibration. The installer of the equipment is solely responsible for the proper installation of the equipment. FURUNO will assume no responsibility for any damage associated with improper installation.
  • Page 4 SAFETY INSTRUCTIONS CAUTION CAUTION Keep away from the raise/lower shaft WORKING WITH THE SONAR OIL of the hull unit when it is working. Precautions • Keep the oil away from eyes. Wear Injury may result if caught in the shaft. protective glasses when working with the oil.

  • Page 5: System Configuration

    Display Unit Transceiver Unit RU-1746B-2 Controller MU-121C CH-503 CH-256 100/110/220/ 230 V AC, 1ø, 50/60 Hz 12-24 V DC Control Unit CH-502 (CH-500)/ CH-602 (CH-600) Loudspeaker CA-151S-ASSY External monitor* Navigational Equipment/ Remote (MU-150HD or Fish Finder/ Controller market equivalent) Heading Sensor/...

  • Page 6: Equipment Lists

    Code No. Remarks CH-502/MU-121C For CH-500, standalone type Control/Display Unit CH-602/MU-121C For CH-600, standalone type CH-502 For CH-500, black box type Control Unit CH-602 For CH-600, black box type Display Unit MU-121C Supplied for black box type. Transceiver CH-503 Unit...
  • Page 7 EQUIPMENT LISTS Hull Unit Name Type Code No. Remarks CH-5041 400 mm stroke Raise/Lower Drive Unit CH-5051 250 mm stroke CH-5048 For 8 inch retraction tank Complete Soundome Assembly CH-5046 For 6 inch retraction tank For CH-5048, 1.17/1.97 m soun- 000-030-337 dome shaft, included liquid gasket CH-5081...
  • Page 8 EQUIPMENT LISTS Option Name Type Code No, Remarks CH-502 For CH-500 Control Unit CH-602 For CH-600 Display Unit MU-121C Remote Controller CH-256 Loudspeaker CA-151S-ASSY Rectifier RU-1746B-2 Bracket Assem- OP06-24 001-458-030 For desktop mount of display unit bly with Knobs Flush Mount Kit...
  • Page 9 EQUIPMENT LISTS Name Type Code No, Remarks FRU-WH-B-05M 001-471-570 For external KP connection, 5 m Cable for External FRU-WH-B-10M 001-471-580 For external KP connection, 10 m MJ-A10SPF0022-050+ 001-471-540 For sub control unit connection, 5 m Cable between Transceiver and For sub control unit connection, MJ-A10SPF0022-100+ 001-471-550 Control...
  • Page 10 EQUIPMENT LISTS This page is intentionally left blank. viii...

  • Page 11: Mounting

    MOUNTING NOTICE Do not apply paint, anti-corrosive sealant or contact spray to coating or plastic parts of the equipment. Those items contain organic solvents that can damage coating and plastic parts, especially plastic connectors. Required Tools and Materials Prepare the following tools in advance for this installation. Name Specification/Remarks Phillips-head...

  • Page 12: Control/Display Unit (Standalone Type)

    1. MOUNTING Control/Display Unit (Standalone Type) There are two configurations for control unit and display unit installation; standalone or black box type. Desktop mount is available for standalone type. For how to install the control unit and display unit separately, see section 1.3 (display unit) and section 1.4 (control unit).

  • Page 13: Display Unit (Black Box Type)

    1. MOUNTING 3. Connect the cables to the control/display unit, referring section 2.1. Note: Place the unit face-down on a soft, clean surface to prevent the damage to the LCD. 4. Set the unit in the bracket, then fasten the knobs. Display Unit (Black Box Type) The display unit can be mounted on a desktop or flush mounted in a console.
  • Page 14 1. MOUNTING Procedure 1. Secure the bracket to the mounting location, using four self-tapping screws ( 5 20). Self-tapping screw (Ø5×20, 4 pcs) Bracket 2. Secure the fixing bracket to the display unit, using four binding screws (M4 10). Note: Place the unit face-down on a soft, clean surface to prevent the damage to the LCD.
  • Page 15 1. MOUNTING 5. Set the unit in the bracket, then fasten the knobs. Knob (2 pcs) Bracket washer (2 pcs) 1.3.2 Flush mounting Prepare the optional flush mount kit (type: OP06-25, code no,: 001-458-040) for flush mounting the display unit. The included items in OP06-25 are listed in the following table.

  • Page 16: Control Unit (Black Box Type)

    1. MOUNTING 3. Connect the cables to the unit, referring section 2.2. 4. Set the unit to the mounting hole, then secure the unit with four self-tapping screws ( 5 20). Self-tapping screw (Ø5×20, 4 pcs) Mounting hole Mounting hole Control Unit (Black Box Type) The control unit can be mounted on a desktop or flush mounted in a console.
  • Page 17 1. MOUNTING 1.4.1 Desktop mounting Prepare the optional tabletop mount kit* (type: FP06-01601, code no: 001-458-100) for flush mounting the display unit. The items included in FP06-01601 are listed in the following table. *: Supply depends on configuration purchased. Name Type Code No.
  • Page 18 1. MOUNTING 5. Set the control unit to the control mounting base, then tightly fasten the two bolts that were fastened loosely at step 2. When you set the control unit, align the two notches on the control unit to the bolts fastened at step 2.

  • Page 19: Transceiver Unit

    1. MOUNTING 2. Secure the control fixing fixture to the control unit, using two hex. head slot bolts (M4 12). Hex. head slot bolt (M4×12, 2 pcs) Control fixing fixture 3. Connect the cables to the unit, referring section 2.3. 4.

  • Page 20: Hull Unit

    1. MOUNTING • A magnetic compass will be affected if the unit is placed too close to the magnetic compass. Observe the compass safe distances at the front of this manual to prevent interference to a magnetic compass. • Secure the unit so that the cable entrance faces downward. Procedure Self-tapping screw (Ø5×20, 4 pcs)
  • Page 21 1. MOUNTING • Select an area where propeller noise, cruising noise, bubbles and interference from turbulence are minimal. Generally, the point at 1/3 to 1/2 of the ship’s length from the bow or near the keel is the best. If the hull unit cannot be installed on the keel, the center of the retraction tank should be within 1 meter of the keel to prevent a rolling effect.
  • Page 22 1. MOUNTING 1.6.2 Retraction tank A typical mounting method is shown in the outline drawing at the back of this manual (DWG No.: C1316-T01). Consult with the ship’s owner, dockyard and user to deter- mine the appropriate mounting method. Pay attention to safety (strength, watertight- ness) first, followed by ease of maintenance and inspection.
  • Page 23 1. MOUNTING • Fit a doubling plate (a plate to reinforce the Retraction tank hull plate) of 600 mm or more diameter to the outside of the hull plate (see the figure to the right). For the doubling plate, use the Hull plate same material and thickness as hull plate.
  • Page 24 1. MOUNTING • Install a fairing plate to the bottom hull where the transducer projects to protect the transducer from the water pressure. The fairing plate should contact the frame of the hull plate. For the fairing plate, use the same material and thickness as the hull plate. Wooden or plastic material can also be used.
  • Page 25 1. MOUNTING For small FRP hulls For small FRP hulls, the retraction tank should be 2 degrees against ship’s draft. This creates high water pressure in the tank because of the resistance at the rear of the tank well. To solve this problem, attach a fin to the hull the location shown in the fol- lowing figure.
  • Page 26 1. MOUNTING 1.6.3 Assembling and mounting of hull unit for CH-5048 The hull unit is shipped disassembled as parts. Assemble the hull unit as shown in the following procedure. The following procedure is for the CH-5048 (transducer for 8-inch diameter tank). For the procedure for the CH-5046 (transducer for 6-inch diameter tank), see section 1.6.4.
  • Page 27 1. MOUNTING 4. After fully screwing the main shaft into the soundome neck, unscrew it by four turns and apply the supplied sealant (LOCTITE NO.575) to the threads. Apply the sealant (LOCTITE NO.575). Wrench Soundome shaft Transducer cable Pipe wrench Grasp the soundome neck with a wrench, and tighten the shaft with a pipe wrench.
  • Page 28 1. MOUNTING Reference data for existing FPR retraction tank: The following table is reference data for existing FRP retraction tank. It shows the relationship between the retraction tank length and necessary shim thick- ness. The shim thickness indicates the thickness for one side. For example, when cutting the 1,800 mm tank to 800 mm, the tank inside diameter is 191.25 mm, shim thickness is 2.5 mm as shown in the following table.
  • Page 29 1. MOUNTING 8. Apply liquid gasket (TB1121 or TB1184) to the inside of the tank guide, then fasten the tank guide at the neck of the soundome, referring the following figure. Hex. nut : Apply liquid gasket (TB1121 or TB1184) to the both side of the tank guide.
  • Page 30 1. MOUNTING Pipe cap Pipe cap Soundome shaft Soundome shaft 3 mm Transducer cable Tighten the pipe cap for gap of approx. 3 mm. • 1.17/1.97 m soundome shaft: Pass two flat washer, gasket and cable gland through the transducer cable, then fasten the cable gland to the shaft. Note: If the 1.17/1.97 m soundome shaft is shortened, attach the optional wa- terproof attachment kit (OP06-27) to the top of the soundome shaft, see section 1.6.5.
  • Page 31 1. MOUNTING Note: After attaching the cotton re- tainer, confirm that the gap between Cotton retainer 7 to 9 mm the cotton retainer and flange assem- Grease bly is 7 to 9 mm. If water leaks around cotton the cotton retainer, the grease cotton may not be attached correctly.
  • Page 32 1. MOUNTING 17. Fill the soundome with supplied super sonar oil until the scribe line (6 cm below the top of the dome). Note: Use only the specified sonar oil. Use of other sonar oils may affect the per- formance. CAUTION WORKING WITH THE SONAR OIL Precautions...
  • Page 33 1. MOUNTING 19. Clean the supplied gasket, retraction tank flange, and flange assembly. 20. Apply approx. 1 mm thickness of liquid gasket (TB1121 or TB1184) to the retrac- tion tank flange. For the application area, see the following figure. Note: Do not apply liquid gasket to the gasket. If applied, clean the gasket with a waste cloth.
  • Page 34 1. MOUNTING 1.6.4 Assembling and mounting of hull unit for CH-5046 The hull unit is shipped disassembled as parts. Assemble the hull unit as shown in the following procedure. The following procedure is for the CH-5046 (transducer for 6-inch diameter tank). For the procedure for the CH-5048 (transducer for 8-inch diameter tank), see section 1.6.3.
  • Page 35 1. MOUNTING 3. Set the transducer to the soundome, aligning the screw holes. Note: When the soundome is installed in a low ambient temperature, the soun- dome may shrink and become difficult to fit to the transducer. To prevent this, warm the soundome in water of approx.
  • Page 36 1. MOUNTING 2) Insert two screw drivers with a blade width of 7 to 10 mm in the slits on the soundome, then rotate them in the opposite directions of each other. The transducer should pushed up by the width of the blade. 3) Attach the two supplied attachment plates to the transducer at the locations directly above the slits of the soundome.
  • Page 37 1. MOUNTING 6. Remove the hex. bolt, hex. nut, spring washer, two flat washer, and trunnion pin from the flange assembly, then mount the raise/lower driver unit on the main body flange, using the removed materials. Raise/lower drive unit Hex. nut Flat washer Flat washer Flange...
  • Page 38 1. MOUNTING 11. Apply liquid gasket (TB1121 or TB1184) to the inside of the shaft fixture, then fas- ten the shaft fixture to the soundome shaft temporarily. Hex. nut Flat washer : Apply liquid gasket (TB1121 or TB1184) to the both side of the tank guide.
  • Page 39 1. MOUNTING 14. Pass the soundome shaft through the flange assembly U-nut Pipe retainer and shaft retainer. Torque: Flat 20 to 25 N•m 15. Fasten two supplied hex. washer bolts, flat washers, and U- 15 mm Hex. bolt nuts to the shaft retainer to 1 to 2 mm (M10×35) secure the soundome shaft.
  • Page 40 1. MOUNTING Cable gland Flat washer Cable gland Soundome shaft 3 mm Soundome Tighten the cable gland Gasket shaft for gap of approx. 3 mm. Transducer cable 19. Insert the supplied grease cotton (V8133L) to the flange assembly as follows: The grease cotton is supplied with the flange assembly.
  • Page 41 1. MOUNTING 21. Apply approx. 1 mm thickness of liquid gasket (TB1121 or TB1184) to the retrac- tion tank flange. For the application area, see the following figure. Note: Do not apply liquid gasket to the gasket. If applied, clean the gasket with a waste cloth.
  • Page 42 1. MOUNTING 1.6.5 Waterproof attachment kit (option) Attach the optional waterproof attachment kit (OP06-27) to the soundome shaft as fol- lows: 1. Temporarily install the waterproofing attachment on the top of the soundome shaft and drill holes for socket-set screws as follows: 30 mm Push in fully.
  • Page 43 1. MOUNTING 1.6.6 Checking manual raise/lower of transducer Raise/lower the transducer manually to check the raise/lower function after installing the hull unit. 1. Turn the hull unit (raise/lower control unit) off. CAUTION Turn off the power switch on the hull unit before manually raising or lowering the transducer.
  • Page 44 1. MOUNTING 1.6.7 How to mount the raise/lower control unit separately (not recommended) The raise/lower control unit is pre-attached to the hull unit. The motion sensor is built into the raise/lower control unit. Normally, install the hull unit without removing the raise/lower control unit, to keep the performance of the motion sensor.

  • Page 45: External Monitor

    1. MOUNTING External Monitor The portrait type monitor MU-150HD or a commercial monitor can be used for the ex- ternal monitor. The transceiver unit outputs the HDMI video signal only. When you use the monitor (ex. MU-150HD), whose input interface is DVI-D, prepare the optional HDMI-TO-DVI-A-L=5.3/10.3M cable, to convert the HDMI video signal to DVI-D.
  • Page 46 1. MOUNTING This page is intentionally left blank. 1-36...

  • Page 47: Wiring

    (Japanese Industrial Standards) cables. If not available locally, use the equivalent. See the cable guide in the Appendix for how to select equivalent cables. Transceiver Unit CH-503 Control/Display Unit (Rear) Remote Controller MU-121C/CH-502 (CH-500) CH-256 MU-121C/CH-602 (CH-600) 06P0288 06P0289 IV-2sq.
  • Page 48 2. WIRING Control/Display Unit (Standalone Type) Connect the cables to the connector on the rear side of the control/display unit, refer- ring to the following figure. Note: When the optional remote controller is not connected, do not remove the con- nector cover on the REM port.
  • Page 49 2. WIRING Display Unit (Black Box Type) Connect the cables to the connector on the rear side of the display unit, referring to the following figure. From left: • POWER/CONT port • HDMI port • CONT port Flat washer* • Ground terminal Spring washer* Wing nut*...
  • Page 50 2. WIRING Control Unit (Black Box Type) Connect the cables to the connector on the rear side of the control unit, referring to the following figure. Note: When the optional remote controller is not connected, do not remove the con- nector cover on the REM port.
  • Page 51 2. WIRING Note: When you reattach the cable fixing plates, the plate which has the notch (cable fixing plate 1) should be attached to the right side. Notch Internal wiring of the transceiver unit DIGI Board 06P0288 Secure the cables with the cable clams.
  • Page 52 2. WIRING Access point on the Cable Cable from transceiver unit FRU-CCCAF-18-05/10M-B DIGI board 06P0288: Display unit POWER port (J112) and CONT port (J111) FRU-NMEA-PMM-01 DIGI board 06P0288: J118 Navigation equipment (NMEA2000) MJ-A10SPF0022-050+/100+ DIGI board 06P0288: J115 No.2 control unit FRU-WH-B-05/10M DIGI board 06P0288: J124 External KP...
  • Page 53 2. WIRING To output the KP signal from the transceiver unit to external equipment, make the con- nection as follows. Also, change the DIP switch (S8-4) on the DIGI board 06P0288, according to the logic signal of the external equipment. The transceiver unit outputs the KP signal while the power is turned on.
  • Page 54 2. WIRING Cable clamp Rubber sleeve Lock nut PRA board 06P0291 Terminal opener Fasten the drain wire of the power cable to the cable fixing plate. The screw for the drain wire is pre-attached to the cable fixing plate. FLT board 06P0292 How to connect wires to WAGO connector Press downward.

  • Page 55: Auto Filter

    The auto filter functions automatically by inputting the following data from a GPS. • VTG sentence • HDG, HDT, THS, VHW, Gpatt*, or HDM sentence *: FURUNO proprietary sentence Notice for connecting a GPS Connect a GPS to this equipment, keeping in mind the following points.If you do not observe the following points, this equipment may not detect fish echoes properly.

  • Page 56: Input/Output Sentences (Nmea0183)

    Ver. 1.5/2.0/3.0/4.0 Water Speed and Heading Ver. 1.5/2.0/3.0/4.0 Pitch and Roll Ver. 1.5/2.0/3.0/4.0 Time and date Ver. 1.5/2.0/3.0/4.0 GPatt FURUNO proprietary sentence pireq FURUNO proprietary sentence Output sentences Target Latitude and Longitude Ver. 3.0/4.0 pidat FURUNO proprietary sentence Input/Output PGNs (NMEA2000) This equipment can input/output following PGNs: Note: The NMEA0183 format data has higher priority than NMEA2000 format data.
  • Page 57 Set & Drift, Rapid Update 130310 Environmental Parameters 130311 Environmental Parameters 130312 Temperature 130316 Temperature, Extended Range 130577 Direction Data 130821 FURUNO Proprietary PGN Output PGNs Data Sending Cycle 059392 ISO Acknowledgement Non-periodic 059904 ISO Request Non-periodic 060928* ISO Address Claim...
  • Page 58 2. WIRING This page is intentionally left blank. 2-12...

  • Page 59: Checking And Initial Settings

    CHECKING AND INITIAL SETTINGS Check Points After Installation Check the following points in the dockyard after installation: Item Check point, Rating Retraction tank level • The retraction tank is installed on the keel, or is located within 1 meter of the keel.

  • Page 60: Language Setting

    3. CHECKING AND INITIAL SETTINGS Item Check point, Rating Direction of the bow • The bow mark on the transducer and flange assembly should be faced to mark the ship’s bow. If not faced to the bow, target echoes may not be dis- played correctly.

  • Page 61: Heading Alignment, Draft And Stroke Adjustments

    : Select : Change Menu: Apply : Select : Change Menu: Apply For CH-600 For CH-500 3. Press on the cursorpad to select [COM2] on the menu bar. 4. Press to move the cursor inside the menu. Menu COM1 COM2 HOR.
  • Page 62 3. CHECKING AND INITIAL SETTINGS 8. Press several times to move the cursor to the menu bar. 9. Press several times to select [System] on the menu bar. 10. Press to move the cursor inside the menu. Menu COM1 COM2 HOR.

  • Page 63: Checking Tx Frequency

    3. CHECKING AND INITIAL SETTINGS 15. Press to select [Hull Unit Stroke]. 16. Press to set the stroke length of the hull unit. 17. Press the MENU key to apply the settings. 18. Press the MENU key to close [System Menu]. Checking TX Frequency Check the TX frequency after completing the installation.

  • Page 64: Setting For Synchronizing Transmission With Other Equipment (External Kp)

    Toggle TX power level. Toggle TX power level. : Select : Change Menu: Apply : Select : Change Menu: Apply For CH-500 For CH-600 3. Press several times to select [TX Rate]. 4. Press to open the setting window. TX Rate 5. Press several times to select [EXT.].
  • Page 65 : Change Menu: Apply : Select : Change Menu: Apply For CH-500 For CH-600 5. Press several times to select [Roll Offset]. When the raise/lower control unit is not separated from the hull unit, go to step 11 6. Press to open the setting window.

  • Page 66: Navigation Equipment Setup

    3. CHECKING AND INITIAL SETTINGS 9. Press to open the setting window. +0.0° Pitch Offset (-10.0~+10.0 ° ) Detect Val : - - Compensated value appears here. 10. Press to adjust the offset value. Calculate the offset value for [Pitch Angle], using the values measured at step 1. •...

  • Page 67: System Backup

    3. CHECKING AND INITIAL SETTINGS 6. Setup the following menu items, referring to the table below. Menu item Description [CSE. Data] Selects heading data source, navigator or gyrocompass, to draw ship’s track. For heading sensor of gyrocompass connec- tion select [Gyro]. [Nav.
  • Page 68 Backup saved with the following names. CH-500_AllSettings_XX.dat CH-600_AllSettings_XX.dat Menu: Close Menu: Close For CH-500 For CH-600 9. Press the MENU key to close [System Menu]. 3.8.2 How to load the system data 1. Press the MENU key to open the menu.

  • Page 69: Color Settings

    3. CHECKING AND INITIAL SETTINGS 8. Press the MENU key to apply the settings. When [External] is selected at step 7, the file selection window appears. Press to select the backup file, then press MENU key. File name for backup data. File name for backup data.

  • Page 70: Decreasing Cavitation

    3. CHECKING AND INITIAL SETTINGS 3.11 Decreasing cavitation When operating with high water temperatures, cavitation can occur in the soundome assembly and the signal level can be subsequently decreased during high frequency transmission. In this case, change the DIP switch (S8-6) on the DIGI board 06P0288 to ON, referring to "External KP connection"...

  • Page 71: Appendix 1 Jis Cable Guide

    EX: TTYCYSLA - 4 MPYC - 4 TTYCSLA-4 # of cores Designation type Designation type # of twisted pairs The following reference table lists gives the measurements of JIS cables commonly used with Furuno products: Cable Core Cable Core Diameter Diameter...

  • Page 72: Appendix 2 How To Make The Retraction Tank For Wooden Vessel

    APPENDIX 2 HOW TO MAKE THE RETRACTION TANK FOR WOODEN VESSEL These instructions show how to make the retraction tank for a wooden vessel. Retraction tank (conceptual drawing) Necessary components for the retraction tank Prepare the components shown in the table below for the retraction tank. The dimensions in the table are recommended values.
  • Page 73 APPENDIX 2 HOW TO MAKE THE RETRACTION TANK FOR WOODEN VESSEL Name Material Thickness Remarks Flange-1 SS400 More than Inside diameter: Same as the outside di- 20.0 mm ameter of the fixing pipe.Outside diameter: 343 mm 8 × Ø23 45° 45°...
  • Page 74 APPENDIX 2 HOW TO MAKE THE RETRACTION TANK FOR WOODEN VESSEL Name Material Thickness Remarks Flange-2 SS400 More than Inside diameter: Max. 259 mm, 12.0 mm Min. Pipe O.D + 20 mm Outside diameter: 343 mm 45° 8 × Ø14 I.D: Inside diamater Pipe O.D: Outside diameter of the PVC pipe Angle-2...
  • Page 75 APPENDIX 2 HOW TO MAKE THE RETRACTION TANK FOR WOODEN VESSEL Welding the components Before assembling the retraction tank, weld the components to create the flange assembly 1 and • Flange assembly 1 Weld the fixing pipe and four angle-1 to the flange-1. After welding, mask the thread groove of the fixing pipe, then apply anticorrosive coating to the flange assembly 1.
  • Page 76 APPENDIX 2 HOW TO MAKE THE RETRACTION TANK FOR WOODEN VESSEL How to assemble the retraction tank To assemble the retraction tank, prepare the installation materials shown in the following table. Name Material Type Hex. Bolt SUS304 M12 20 - 25 SUS304 M12 25 or more Hex.
  • Page 77 APPENDIX 2 HOW TO MAKE THE RETRACTION TANK FOR WOODEN VESSEL 3. Apply marine sealant to the threads of the PVC pipe, then screw the PVC pipe into the flange assembly. PVC pipe PVC pipe Flange Flange asssembly asssembly Apply marine sealant to Apply marine sealant to the threads.

  • Page 78: Appendix 3 How To Install The Retraction Tank For Wooden Vessel

    APPENDIX 3 HOW TO INSTALL THE RETRACTION TANK FOR WOODEN VESSEL Install the retraction tank for wooden vessel (prepared in APPENDIX 2) as shown here. Installation location considerations Discussion and agreement are required with the dockyard and ship owner in deciding the location for the retraction tank (hull unit).
  • Page 79 APPENDIX 3 HOW TO INSTALL THE RETRACTION TANK FOR WOODEN VESSEL • Install a flow rectification component to the hull where the transducer projects. Install a fairing or stainless plate as the flow rectification component. See the next page to select a faring or stainless plate.
  • Page 80 APPENDIX 3 HOW TO INSTALL THE RETRACTION TANK FOR WOODEN VESSEL Recommended dimensions for the faring • Length (bow-stern direction): R. P + 100 mm or more (700 mm or more recommended) • Length (both sides direction): Pipe O.D + 100 mm or more •...
  • Page 81 APPENDIX 3 HOW TO INSTALL THE RETRACTION TANK FOR WOODEN VESSEL Mounting hole and installation of the flow rectification component 1. Select the installation location referring to "Installation location considerations" on page AP-8. For the location of the mounting hole, consider the following points: •...
  • Page 82 APPENDIX 3 HOW TO INSTALL THE RETRACTION TANK FOR WOODEN VESSEL Installation of the tank reinforcement structure Install the tank reinforcement structure to prevent the retraction tank from coming off and vibrating. Fix the tank reinforcement structure to the ribs or ship’s superstructure. Tank reinforcement structure Tank reinforcement structure (conceptual drawing) Create the tank reinforcement structure considering the structure of the hull.
  • Page 83 APPENDIX 3 HOW TO INSTALL THE RETRACTION TANK FOR WOODEN VESSEL How to install the retraction tank 1. Set the retraction tank to the tank reinforcement structure and mounting hole. 2. Loosen the bolts fixing the flange (8 locations, 16 pcs), then adjust the flange of the retraction tank so that it is parallel with the waterline.
  • Page 84 APPENDIX 3 HOW TO INSTALL THE RETRACTION TANK FOR WOODEN VESSEL 7. Use a hair dryer or the like to dry the mounting hole, then apply the adhesive to the contact areas between the retraction tank and mounting hole. Apply the adhesive both to the retraction tank and mounting hole. 8.
  • Page 111 27/May/2016 H.MAKI 27/May/2016 H.MAKI...
  • Page 112 10/Jan/2017 H.MAKI...
  • Page 113 10/Jan/2017 H.MAKI...
  • Page 114 14/Jul/2017 H.MAKI...
  • Page 115 D-10 18/Dec/2017 H.MAKI...
  • Page 116 Takahashi T Takahashi T Takahashi T Takahashi T...
  • Page 118 D-13...
  • Page 119 D-14 8/May/2013 H.MAKI...
  • Page 120 D-15 13/Dec/2018 H.MAKI...
  • Page 121 D-16 26/Jun/2014 H . M A KI...
  • Page 122 D-17...
  • Page 123 D-18...
  • Page 124 D-19...
  • Page 125 D-20 3/Sep/2013 H.MAKI...
  • Page 126 D-21...
  • Page 127 D-22...
  • Page 128 D-23 7/Jul/2017 H.MAKI...
  • Page 129 (+) (-) AUX_SIG_OUT_LF キ 整流器 EXT_SW ﾐﾄﾞﾘ GRN RECTIFIER RU-1746B-2 ダイ ORG AUX_SIG_OUT_HF アカ RED IV-2sq. IV-2sq. 注記 ＊１）造船所手配。 DRAWN TITLE CH-500/600 ＊２）オプション。 T.YAMASAKI 16/Apr/2019 CHECKED 名称 サーチライトソナー/2周波サーチライトソナー H.MAKI 16/Apr/2019 NOTE APPROVED 相互結線図 17/Apr/2019 H.MAKI *1: SHIPYARD SUPPLY. SCALE MASS NAME *2: OPTION.
