Factory-Set
Parameters
Comfort Set Point Heating
Comfort Set Point Cooling
Prop. Band Heating
Integral Time Heating
Standby Bias Heating
Night Bias Heating
Prop. Band Cooling
Integral Time Cooling
Standby Bias Cooling
Night Bias Cooling
Heating Valve Stroke (PAT)
Heating Valve Cycle (DAT)
Heating Stage 1 Load (2St)
Cooling Valve Stroke (PAT)
Cooling Valve Cycle (DAT)
Cooling Stage 1 Load (2St)
Fan On/Off Differential
Fan always On in Comfort
Min. Fan Output (0-10 VDC)
Low Limit Set Point
Low Limit Differential
Winter Compensation
Winter Set Point
Winter Authority Slope
Winter Authority Limit
Summer Compensation
Summer Set Point
Summer Authority Slope
Summer Authority Limit
Room Temp Filter Const.
Remote S.P.Filter Const.
Common Set Point
Unit Mount Sensor
28
Technical Bulletin—TC-9102
Table 3: Factory-Set Parameters
20°C
-1 K
22°C
+1 K
-2 K
4 minutes
-2 K
-4 K
+2 K
4 minutes
+2 K
+4 K
60 seconds
300 seconds
50 %
60 seconds
300 seconds
50 %
1 K
No
50 %
12°C
2 K
Disabled
10°C
-0.1
-3 K
Disabled
24°C
0.2
5 K
10 seconds
60 seconds
0°C
No
Note 1:
Controllers are delivered from the factory with the RED
jumper "IN" and the BLUE jumper "OUT" unless otherwise
specified.
Note 2:
When the Remote Set Point is +/-3 K, the Common Set Point
may be set to the desired mean room temperature (e.g. 21°C)
and the Comfort Set Point Heating and Comfort Set Point
Cooling set as biases of -1K and +1K, respectively.
+/-3 K Remote Set Point. See Note 2.
12-28°C Remote Set Point
+/-3 K Remote Set Point. See Note 2.
12-28°C Remote Set Point
-1 K when RED jumper OUT. See Note 1.
Disabled when BLUE jumper OUT. See Note 1.
+1 K when RED jumper OUT. See Note 1.
Disabled when BLUE jumper OUT. See Note 1.
+/- 1% Dead Band
5% minimum On/Off
5% differential
+/- 1% Dead Band
5% minimum On/Off
5% differential
Yes = Fan On in zero energy band in Comfort.
Requires Outdoor Air Temp via Bus when enabled.
Requires Outdoor Air Temp via Bus when enabled.
Valid range = -3 to 28. See Note 2.
Yes = Hard wired temperature sensor is used and
TM-9180 is connected.
