Figure 16: TC-9102 Controller Wiring -
TC-9102 Controller
52
51
50
24
23
22
21
Internal
20
Connections
15
14
(Min. 0.8 mm diameter wire)
*Only for modules with 3-speed fan override (see ordering codes).
**Model TM-9160 only.
Figure 17: TC-9102 Controller Wiring to Room Command
Module with Integral NTC Sensor
TC-9102
Controller
52
51
50
24
23
22
21
Internal
20
Connections
15
14
(Min. 0.8 mm diameter wire)
*Only for modules with 3-speed fan override (see ordering codes).
0 to 10 VDC Fan Control
TM-9150/TM-9160
Room Command Module
51
23
22
21/24
20
15
14
Max. 50 m
TM-9170 Room
Command Module
51
23
22
21/24
NTC Sensor
(Unit Mounted)
15
14
Max. 50 m
3-Speed Fan
Override*
Remote
Set Point**
Common
NTC Sensor
Mode LED
Occupancy Button
tc2wwntc
3-Speed Fan
Override*
Remote
Set Point
Common
Mode LED
Occupancy Button
tc2wontc
