Electrical Parts List - Sony STR-DE845 Service Manual

NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts speci-
fied in the diagrams or the components used
on the set.
• -XX and -X mean standardized parts, so they
may have some difference from the original
one.
• RESISTORS
All resistors are in ohms.
METAL: Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F: nonflammable
• Abbreviation
AUS : Australian model MY : Malaysia model
CH : Chinese model SP
CND : Canadian model
Ref. No. Part No. Description
1-676-982-11 5.1 IN BOARD
***********
< CAPACITOR >
C323 1-128-825-11 CERAMIC
< CONNECTOR >
CNS301 1-695-093-11 SOCKET, CONNECTOR 9P
< JACK >
J307 1-794-269-11 JACK, PIN 6P (5.1CH INPUT)
< RESISTOR >
R323 1-249-417-11 CARBON
R324 1-249-417-11 CARBON
R325 1-249-417-11 CARBON
R327 1-249-441-11 CARBON
R328 1-249-441-11 CARBON
R329 1-249-441-11 CARBON
R373 1-249-417-11 CARBON
R374 1-249-417-11 CARBON
R375 1-249-439-11 CARBON
R377 1-249-441-11 CARBON
R378 1-249-441-11 CARBON
R379 1-249-436-11 CARBON
**************************************************************
1-676-990-11 AC BOARD
********
1-533-223-11 HOLDER, FUSE
< CAPACITOR >
C901 1-127-880-11 CERAMIC
C902 1-127-880-11 CERAMIC
C905 1-126-768-11 ELECT
< CONNECTOR >
0 CNJ90 1-251-417-11 OUTLET, A. C. (AC OUTLET) (AUS)
0 CNJ90 1-251-718-11 OUTLET (2 GANG), AC (AC OUTLET)
0 CNJ90 1-785-285-11 OUTLET, AC (1P) (AC OUTLET) (MY, SP)
CNV807 1-568-106-11 PIN, CONNECTOR 4P (E)
CNV901 1-564-321-00 PIN, CONNECTOR 2P
SECTION 6

ELECTRICAL PARTS LIST

• Items marked "*" are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when order-
ing these items.
• SEMICONDUCTORS
In each case, u: µ, for example:
uA. . : µA. .
uPB. . : µPB. .
uPD. . : µPD. .
• CAPACITORS
uF: µF
• COILS
uH: µH
: Singapore model
Remark
2200PF 5% 50V
1K 5% 1/4W
1K 5% 1/4W
1K 5% 1/4W
100K 5% 1/4W
100K 5% 1/4W
100K 5% 1/4W
1K 5% 1/4W
1K 5% 1/4W
68K 5% 1/4W
100K 5% 1/4W
100K 5% 1/4W
39K 5% 1/4W
0.022uF 10% 50V
0.022uF 10% 50V
2200uF 20% 16V
(US, CND, E, CH, PX)
uPA. . : µPA. .
uPC. . : µPC. .
Ref. No. Part No. Description
* CNV902 1-565-792-11 PIN, CONNECTOR 2P
< DIODE >
D901 8-719-024-99 DIODE 11ES2-NTA2B
D902 8-719-024-99 DIODE 11ES2-NTA2B
D903 8-719-024-99 DIODE 11ES2-NTA2B
D904 8-719-024-99 DIODE 11ES2-NTA2B
D905 8-719-911-19 DIODE 1SS133T-72
D906 8-719-911-19 DIODE 1SS133T-72
D907 8-719-911-19 DIODE 1SS133T-72
< TERMINAL >
* EB901 1-537-738-11 TERMINAL, EARTH (US, CND)
< FUSE >
0 F901
1-533-311-11 FUSE, GLASS CYLINDRICAL (DIA.5)
0 F901
1-532-504-51 FUSE
0 F903
1-532-749-11 FUSE
< TRANSISTOR >
Q901 8-729-119-78 TRANSISTOR
< RESISTOR >
R901 1-202-725-00 SOLID
R902 1-249-429-11 CARBON
R903 1-249-425-11 CARBON
< RELAY >
RY901 1-755-298-11 RELAY
< TRANSFORMER >
0 T902 1-435-281-11 TRANSFORMER, POWER (US, CND)
0 T902 1-435-282-11 TRANSFORMER, POWER (MY, SP, AUS, CH)
0 T902 1-435-283-11 TRANSFORMER, POWER (E, PX)
**************************************************************
5.1 IN AC
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
Les composants identifiés par une
marque 0 sont critiquens pour la
sécurité.
Ne les remplacer que par une pièce
portant le numéro spécifié.
Remark
8A 125V (US, CND)
T4AL 250V
(EXCEPT US, CND)
T2.5AL 250V
(EXCEPT US, CND, E, PX)
2SC2785TP-HFE
3.3M 10% 1/2W
(US, CND)
10K 5% 1/4W
4.7K 5% 1/4W
59
