Sony STR-DE845 - Fm Stereo/fm-am Receiver Dimensions

STR-DE845
RM-LJ302 REMOTE CONTROL
5/8" 1 3/4 "
1 1/8"
ANTENNA
AM.
COAXIAL
FM
PH
NOTE:
WHERE THERE ARE CLOSE TOLERANCES INVOLVED IN CABINET BUILDING
OR APPLICATIONS WHICH REQUIRE A GREAT DEGREE OF PRECISION WE
RECOMMEND THAT THE PRODUCT ITSELF BE USED TO MAKE THE ACTUAL
MEASUREMENTS.
IN THE DESIGN OR MANUFACTURE OF ENCLOSURES .
Consumer Integrated Systems • Park Ridge, New Jersey 07656 • FAX (201) 986 3062 • b2b.sel.sony.com
Features and specifications subject to change without notice. • Non-metric weights and measurements are approximate.
DESCRIPTION:
DIMENSIONS
(WHD):
WEIGHT:

FRONT VIEW

R FM102.7MHz A3
12 1/4 "
SIDE VIEW
14 7/8 "
1 3/4 "

BACK VIEW

OPTICAL
FRONT REAR CNT COAX
5.1 INPUTS SUB
DIGITAL
WOOFER
CTRL-S VIDEO CTRL-S S-VIDEO S-VIDEO CTRL-S CTRL-S S-VIDEO
IN OUT IN IN IN OUT OUT
MONITOR
CD
MD/DAT TV/SAT DVD VIDEO 2
SONY WILL NOT BE RESPONSIBLE FOR INACCURACIES
Dolby Digital
Receiver
17" x 6 1/4" x 14 7/8"
Approx 27 lbs
17"
12 7/8"
7 3/8"
SPEAKERS
+
B A
-
FRONT REAR CENTER
4 -16 ohms 8 -16 ohms
S-VIDEO
OUT IN
CONTROL A1 ll
VIDEO 1
POWER
REQUIREMENTS:
POWER
CONSUMPTION:
5 3/4"
6 1/4"
1 3/4 " 5/8"
1/2"
2 " 5/8"
AUDIO
OUT
SUB WOOFER
4 8
IMP Selector
AC OUTLET
SWITCHED
120V
60H
280
Watts
