Airless – Hochdruck Spritzgerät
Airless high-pressure spraying unit
Appareil de pulvérisation à haute
pression Airless
Apparecchio di verniciatura a spruzzo
Airless ad alta pressione
Super Finish 23 PLUS
2334 424
2341576
07 / 2014
Originalbetriebsanleitung
Betriebsanleitung
Operating manual
Mode d'emploi
Istruzioni per l'uso
2
34
65
97
2334 444
Advertisement
Table of Contents
Related Manuals for WAGNER Super Finish 23 PLUS
Summary of Contents for WAGNER Super Finish 23 PLUS
- Page 1 Betriebsanleitung Airless high-pressure spraying unit Operating manual Appareil de pulvérisation à haute Mode d'emploi pression Airless Apparecchio di verniciatura a spruzzo Istruzioni per l‘uso Airless ad alta pressione Super Finish 23 PLUS 2334 424 2334 444 2341576 07 / 2014...
-
Page 2: Table Of Contents
Application ________________________________ 38 11.1 Super Finish 23 PLUS accessories _______________ 53 Coating material ____________________________ 38 11.2 Spare parts list Super Finish 23 PLUS ___________ 58 2.2.1 Coating materials with sharp-edged additional 11.3 Spare parts list high-pressure filter _____________ 60 materials __________________________________ 38 11.4... -
Page 3: Safety Regulations For Airless Spraying
Super Finish 23 PLUS SAFETY REGULATIONS SAFETY REGULATIONS FOR DANGER OF INJURY FROM THE SPRAY JET AIRLESS SPRAYING Attention, danger of injury by injection! Never point the spray gun at yourself, other persons or animals. All local safety regulations in force must be observed. -
Page 4: Max. Operating Pressure
Super Finish 23 PLUS SAFETY REGULATIONS 1.12 MAX. OPERATING PRESSURE USE OF UNITS ON BUILDING SITES AND WORKSHOPS The permissible operating pressure for the spray gun, spray gun accessories, unit accessories and high-pressure hose The unit may only be connected to the mains network via a... -
Page 5: Work At Electrical Components
The front end must always point downwards in order to avoid cessory. sliding away. Super Finish 23 PLUS is made for jobs in the workshop and on If possible do not use the unit on an inclined surface since the the building site. -
Page 6: Filtering
The main area of application are thick layers of highly viscous coating material. At the Super Finish 23 PLUS unit a diaphragm pump takes in the coating materials and transports it via a high-pressure hose to the spray gun with the airless tip. Here the coating material atomizes since it is pressed through the tip core at a maximum pressure of 25 MPa (250 bar, 3625 psi). -
Page 7: Explanatory Diagram
Super Finish 23 PLUS DESCRIPTION OF UNIT EXPLANATORY DIAGRAM Tip guard with airless tip Spray gun High-pressure hose Connection for high-pressure hose Pressure gauge Pressure control valve Multifunction switch Symbols (shown in the recess of the switch): ON / Circulation... -
Page 8: Trolley Backfitting
1. Unscrew the screws (pos. 1) with the attached wrench (17 Degree of protection : IP 44 mm). 2. Tilt the shaft and align the Super Finish 23 PLUS in the Rated input of device: 1.3 kW required position: Max. operating pressure :... -
Page 9: Startup
Super Finish 23 PLUS STARTUP STARTUP HIGH PRESSURE HOSE AND SPRAY GUN 1. Screw the high pressure hose (9) onto the hose connec- UNIT WITH SUCTION SYSTEM tion 2. Screw the spray gun (10) onto the high pressure hose 1. Ensure that the sealing surfaces of the connections are 3. -
Page 10: Socket On Unit (Not Included In All Models)
It is possible, for example, to connect an agitator, a working lamp etc with a maximum of 1500 Watt. Always switch on the Super Finish 23 PLUS unit first and then the connected unit. Oth- erwise the fuse protection of 16 A inside the unit will react. -
Page 11: Spraying Technology
Never pull on the high-pressure hose to move the device. Make sure that the high-pressure hose cannot twist. This can be avoided by using a Wagner spray gun with a swivel joint and a hose system. When using the high-pressure hose while... -
Page 12: Cleaning The Unit
Super Finish 23 PLUS DISPLAYS AT THE UNIT / CLEANING THE UNIT CLEANING THE UNIT Warm water improves the cleaning effect in the case of water-dilutable coating materials. A clean state is the best method of ensuring operation with- out problems. After you have finished spraying, clean the unit. -
Page 13: Cleaning The Unit From The Outside
Super Finish 23 PLUS CLEANING THE UNIT CLEANING THE UNIT FROM THE OUTSIDE HIGH-PRESSURE FILTER 1. Switch off unit – set multifunction switch to (OFF). First unplug the power plug from the outlet. 2. Open the high-pressure filter and clean the filter insert. To... -
Page 14: Cleaning The Airless Spray Gun
Super Finish 23 PLUS CLEANING THE UNIT / SERVICING CLEANING THE AIRLESS SPRAY GUN SERVICING 1. Rinse the Airless spray gun with a suitable cleaning agent under lower operating pressure. GENERAL SERVICING 2. Clean the tip thoroughly with a suitable cleaning agent so that no suitable coating material rests remain. -
Page 15: Repairs At The Unit
Super Finish 23 PLUS REPAIRS AT THE UNIT Installation REPAIRS AT THE UNIT 1. Insert the inlet valve (2) into the trigger housing (1) and secure with the clasp (3). Ensure that the (black) seal (5) is Switch the unit off. -
Page 16: Outlet Valve
Super Finish 23 PLUS REPAIRS AT THE UNIT 10.3 10.4 OUTLET VALVE PRESSURE CONTROL VALVE 1. Use a 22 mm wrench to screw the outlet valve from the Only have the pressure control valve (1) re- paint section. placed by the customer service. -
Page 17: Replacing The Power Cable
Super Finish 23 PLUS REPAIRS AT THE UNIT 10.5 REPLACING THE POWER CABLE This may only be carried out by a skilled elec- trician. No liability is assumed for incorrect installation. Switch the unit off. Before all repair work: Unplug the power plug from the outlet. -
Page 18: Connection Diagram
Super Finish 23 PLUS REPAIRS AT THE UNIT 10.7 CONNECTION DIAGRAM A) SUPER FINISH 23 PLUS WITH SOCKET... - Page 19 Super Finish 23 PLUS REPAIRS AT THE UNIT B) SUPER FINISH 23 PLUS...
-
Page 20: Remedy In Case Of Faults
Super Finish 23 PLUS REPAIRS AT THE UNIT 10.8 REMEDY IN CASE OF FAULTS TYPE OF MALFUNCTION WHAT ELSE? POSSIBLE CAUSE MEASURES FOR ELIMINATING THE MALFUNCTION Unit does not start Multifunction switch No voltage applied Check voltage supply can not switched on... -
Page 21: Spare Parts And Accessories
Super Finish 23 PLUS SPARE PARTS AND ACCESSORIES SPARE PARTS AND ACCESSORIES 11.1 SUPER FINISH 23 PLUS ACCESSORIES Accessories: ITEM DESIGNATION ORDER NO. ITEM. DESIGNATION ORDER NO. Spray gun AG-14 0502 166 Tip extension (stainless steel) Length 15 cm 0556 051... - Page 22 Super Finish 23 PLUS SPARE PARTS AND ACCESSORIES Airless tip table Wagner without tip without tip TradeTip 3 tip F thread (11/16 - 16 UN) G thread (7/8 - 14 UN) up to 270 bar for Wagner spray guns for Graco/Titan spray guns (27 MPa) Order no.
- Page 23 Super Finish 23 PLUS SPARE PARTS AND ACCESSORIES All of the tips in the table below are supplied together with the appropriate gun fi lter. Application Tip marking Spray Bore Spraying Gun fi lter Order no. angle inch / mm...
- Page 24 Super Finish 23 PLUS SPARE PARTS AND ACCESSORIES 2SpeedTip The innovative changeover nozzle from WAGNER combines two nozzle cores into one nozzle. 2 Speed Tip holder Order no. 0271065 Tip table Object size Painting material Lacquer (L) Emulsion (D) Filler (S)
-
Page 25: Spare Parts List Super Finish 23 Plus
Super Finish 23 PLUS SPARE PARTS AND ACCESSORIES 11.2 SPARE PARTS LIST SF 23 PLUS ITEM ORDER-NO DESIGNATION 9905 113 Oval head screw 5x10 9950 242 Seal 0340 339 Inlet 2342 535 Label 2334 383 Inlet valve trigger housing 2343 666... - Page 26 Super Finish 23 PLUS SPARE PARTS AND ACCESSORIES Spare parts diagram SF 23 PLUS...
-
Page 27: Spare Parts List High-Pressure Filter
Super Finish 23 PLUS SPARE PARTS AND ACCESSORIES 11.3 11.4 SPARE PARTS LIST HIGH-PRESSURE FILTER SPARE PARTS LIST TROLLEY ITEM ORDER NO. DESIGNATION ITEM ORDER NO. DESIGNATION 2343 670 Trolley assy. (SF 23 PLUS) 0097 121 High-pressure filter HF- 01 compl. -
Page 28: Spare Parts List Frame
Super Finish 23 PLUS SPARE PARTS AND ACCESSORIES 11.5 11.6 SPARE PARTS LIST FRAME SPARE PARTS LIST SUCTION SYSTEM (RIGID) ITEM ORDER NO. DESIGNATION ITEM ORDER NO. DESIGNATION 2343 637 Frame complete 2342 879 Suction system assy.. 9900 118 Hexagon screw M8x30... -
Page 29: Spare Parts List Hopper 5L
Super Finish 23 PLUS SPARE PARTS AND ACCESSORIES 11.7 11.8 SPARE PARTS LIST HOPPER 5L SPARE PARTS LIST HOPPER WITH TOPCLEAN ITEM ORDER-NO DESIGNATION ITEM ORDER-NO DESIGNATION 0341 265 Hopper 5l, assy. 0341 268 Hopper 5l with TopClean, assy. 0340 901... -
Page 30: Testing Of The Unit
The guarantee certificate is valid as confirmation, as is the Wagner or one of our dealers will take back your used Wagner waste electrical or electronic equipment and will dispose of original purchase document that carries the date of the pur- it for you in an environmentally friendly way. - Page 31 Super Finish 23 PLUS NOTES claims must be made immediately, or at the latest within a The above regulations manage the legal relationship to us period of 2 weeks. concludingly. Additional claims, in particular for damages and The authorised specialist shop that delivered the device is enti- losses of any type, which occur as a result of the product or tled to accept guarantee claims.
- Page 32 Super Finish 23 PLUS...
- Page 33 Super Finish 23 PLUS...
- Page 34 Super Finish 23 PLUS SERVICE EUROPA EUROPA-SERVICENETZ / EUROPEAN SERVICE NETWORK / RÉSEAU DE SERVICE APRÈS-VENTE EN EUROPE RETE DI ASSISTENZA EUROPEA / EUROPA – SERVICENETWERK J. Wagner Ges.m.b.H. Wagner Spraytech Wagner Spraytech (UK) Limited Ottogasse 2/20 Scandinavia A/S The Coach House 2333 Leopoldsdorf Helgeshøj Allé...
