Installer's Guide
High Efficiency Single Stage Upflow / Horizontal
and Downflow / Horizontal Gas-Fired, Direct Vent
Condensing Furnaces
*UX1B040A9H21B
*UX1B060A9H31B
*UX1B080A9H31B
*UX1C100A9H41B
*UX1D120A9H51B
*__First letter may be "A" or "T"
ALL phases of this installation must comply with NATIONAL, STATE AND LOCAL CODES
IMPORTANT — This Document is customer property and is to remain with this unit.
*UX1-H
Please return to service information pack upon completion of work.
UPFLOW
UPFLOW/HORIZONTAL
*DX1B040A9H21B
*DX1B060A9H31B
*DX1B080A9H31B
*DX1C100A9H31B
*DX1D120A9H51B
DOWNFLOW/HORIZONTAL
1 8 - CD2 2 D1 - 5
*DX1-H
DOWNFLOW
A341624P08
Advertisement
Related Manuals for Trane AUX1B040A9H21B
Summary of Contents for Trane AUX1B040A9H21B
- Page 1 1 8 - CD2 2 D1 - 5 Installer’s Guide High Efficiency Single Stage Upflow / Horizontal and Downflow / Horizontal Gas-Fired, Direct Vent Condensing Furnaces *UX1B040A9H21B *DX1B040A9H21B *UX1B060A9H31B *DX1B060A9H31B *UX1B080A9H31B *DX1B080A9H31B *UX1C100A9H41B *DX1C100A9H31B *UX1D120A9H51B *DX1D120A9H51B *__First letter may be “A” or “T” ALL phases of this installation must comply with NATIONAL, STATE AND LOCAL CODES IMPORTANT —...
- Page 2 Installer’s Guide SAFETY SECTION The following safety practices and precautions must be WARNING followed during the installation, servicing, and operation of this CARBON MONOXIDE POISONING HAZARD furnace. Failure to follow the steps outlined below for each appliance 1. Use only with the type of gas approved for this furnace. connected to the venting system being placed into operation Refer to the furnace rating plate.
-
