Importance administering point on the safety

2A 125V
F42
LVA10215-A3
1-4
CN25
B309
WR26
Q21
D27
D26
Q22 Q23
R23
R24
C26
R25
C24
C23
D24 D22
D23
D21
F41
1A 125V
Caution: For continued protection against risk of
fire, replace only with same type 1A/125V for
F41, 2A/125V for F61, F62 and F42, 8A/ 125V for F21.
This symbol specifies type of fast operating fuse.
Precaution: Pour eviter risques de feux, remplacez
le fusible de surete de et F41 comme le meme type
que 1A/125V, et 2A/125V pour F61, F62 et F42,
8A/125V pour F21. Ce sont des fusibles suretes qui
functionnes rapide.
LVA10215-A2
RY21
F21
B511
J21
LVA10215-A4
F61
2A 125V
F62
^
