Fujitsu PRIMERGY BX600 S3 Hardware Manual

Fujitsu PRIMERGY BX600 S3 Hardware Manual

Blade server system unit
Hide thumbs Also See for PRIMERGY BX600 S3:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Service Manual Supplement, Operating Manual
Areas Covered
Before Reading This Manual
This section explains the notes for your safety and conventions used in this manual. Make
sure to read this section.
Chapter 1 Component Names and Functions
This chapter explains the component names and functions of the server.
Chapter 2 Security
This chapter explains the security features that are provided in order to protect the server
hardware and software from theft.
Chapter 3 Standard Operations
This chapter explains such standard operations as turning the server ON/OFF and inserting
and ejecting floppy disks.
Chapter 4 Installing Options
This chapter explains how to install and remove various options to the Chassis.
Chapter 5 Maintenance
This chapter explains how to perform daily maintenance and the maintenance information.
Chapter 6 Technical Information
This chapter explains the specifications and operational notes of the Chassis and optional
devices.
PRIMERGY BX600 S3 Blade Server System Unit Hardware Guide
1

Advertisement

Table of Contents
loading

Related Manuals for Fujitsu PRIMERGY BX600 S3

Summary of Contents for Fujitsu PRIMERGY BX600 S3

  • Page 1 PRIMERGY BX600 S3 Blade Server System Unit Hardware Guide Areas Covered Before Reading This Manual This section explains the notes for your safety and conventions used in this manual. Make sure to read this section. Chapter 1 Component Names and Functions This chapter explains the component names and functions of the server.
  • Page 2 Note that data protection is not guaranteed when repairs are performed. It is the customer's responsibility to maintain backup copies in advance. In case of data loss, Fujitsu assumes no liability for data maintenance or restoration and damages that occur as a result of the data loss for any reason, except for items covered under warranty.
  • Page 3 PRIMERGY BX600 S3 Blade Server System Unit Hardware Guide Contents This manual supports operation of the PRIMERGY BX600 S3 Blade Server System Unit. When operating with other Chassis, refer to the relevant manuals in the Fujitsu PRIMERGY website (http:// primergy.fujitsu.com).
  • Page 4 ■ DVD-ROM Drive Descriptions In this manual, a DVD-ROM drive is described as CD/DVD drive. ■ Entering Commands (Keys) Command entries are displayed in the following way: • In the spaces indicated with the "↑" mark, press the [Space] key once. •...
  • Page 5 PRIMERGY BX600 S3 Blade Server System Unit Hardware Guide ■ Abbreviations The following expressions and abbreviations are used throughout this manual. In this manual, information other than the OS being used is also provided. Product names Expressions and abbreviations PRIMERGY BX600...
  • Page 6 Red Hat and all Red Hat-based trademarks and logos are trademarks or registered trademarks of Red Hat, Inc. in the United States and other countries. Other product names used are trademarks or registered trademarks of their respective manufacturers. Other products are copyrights of their respective manufacturers. Copyright FUJITSU LIMITED 2008 Screen shot(s) reprinted with permission from Microsoft Corporation.

  • Page 7: Table Of Contents

    PRIMERGY BX600 S3 Blade Server System Unit Hardware Guide Contents Chapter 1 Component Names and Functions 1.1 Server (Front View) ........10 1.2 Server (Rear View) .
  • Page 8 Chapter 5 Maintenance 5.1 Cleaning ..........62 5.1.1 Cleaning the Chassis .

  • Page 9: Chapter 1 Component Names And Functions

    Chapter 1 Component Names and Functions This chapter explains the component names and functions of the server. 1.1 Server (Front View) ......1.2 Server (Rear View) .

  • Page 10: Server (Front View)

    Chapter 1 Component Names and Functions 1.1 Server (Front View) The following are the component names of the server (front view). * The Server Blade diagram shown in this manual shows one possible setup pattern. Server blade slots 1 – 10 Front maintenance LED ( ) This is where Server Blades, Storage Blades, or dummy This works in conjunction with the rear maintenance...
  • Page 11 PRIMERGY BX600 S3 Blade Server System Unit Hardware Guide Hard disk status LED ( KVM select LED ( 1 0 KVM select switch Displays the status of the hardware disk unit installed where the LED is positioned. Selects the keyboard/display/mouse.

  • Page 12: Server (Rear View)

    Chapter 1 Component Names and Functions 1.2 Server (Rear View) The following are the component names of the server (rear view). [Default] 4 3 2 KVM module slot Rear maintenance switch ( ) One KVM module is installed. It can be replaced with Pressing this switch turns the front and rear maintenance an optional advanced KVM module.
  • Page 13 PRIMERGY BX600 S3 Blade Server System Unit Hardware Guide [When FC Pass-Thru Blade and advanced KVM module is installed] 11 12 13 * For device options not described in this manual, refer to the manuals supplied with each option. 1 3 Fibre Channel connector...
  • Page 14 Chapter 1 Component Names and Functions 1 9 DC Power LED 2 5 Management Blade error LED It lights depending on the status of the DC power of the It lights or blinks when a Management Blade error PSU as follows. occurs as follows.

  • Page 15: Chapter 2 Security

    Chapter 2 Security This chapter explains the security features that are provided in order to protect the server hardware and software from theft. 2.1 Hardware Security ......2.2 Software Security .

  • Page 16: Hardware Security

    Chapter 2 Security 2.1 Hardware Security Lock the rack door to protect the hardware in the rack from theft. Do not lose the rack key. If the key is lost, contact an office listed in the "Contact Information" of "Start Guide".

  • Page 17: Software Security

    PRIMERGY BX600 S3 Blade Server System Unit Hardware Guide 2.2 Software Security A password can be set to prevent unauthorized use of the server. If a password is set, people who do not know the correct password cannot use the server.
  • Page 18 Chapter 2 Security...
  • Page 19 Chapter 3 Standard Operations This chapter explains such standard operations as turning the server ON/OFF and inserting and ejecting floppy disks. 3.1 Opening the Rack Door ......3.2 Turning On the Server .

  • Page 20: Chapter 3 Standard Operations

    Chapter 3 Standard Operations 3.1 Opening the Rack Door This section explains how to open the front and rear doors of the 40U standard rack. Refer to the manual provided with the rack for procedures on opening other rack doors. ■...
  • Page 21 PRIMERGY BX600 S3 Blade Server System Unit Hardware Guide ■ Opening the Rear Door Turn the rack key to unlock and pull the rack handle up. Turn the handle in the direction of the arrow and pull. Turn and pull Unless you are inserting/ejecting media or turning the power on/off, keep the door closed.

  • Page 22: Turning On The Server

    When operating the device outside of this operating environment, the server may operate improperly, damage data etc. When operating the device outside of this operating environment, Fujitsu cannot be held responsible for any related damage, malfunction, or loss of data, etc.
  • Page 23 PRIMERGY BX600 S3 Blade Server System Unit Hardware Guide When turning on the chassis' main power, the Storage Blade works in conjunction with connected Server Blade power operations. Normally, the power of the Storage Blade and Server Blade are turned on at the same time. The Server Blade's power may turn on approximately 15 seconds after the Storage Blade's power turns on.

  • Page 24: Turning Off The Server

    Chapter 3 Standard Operations 3.3 Turning Off the Server • Follow the procedure below to turn off the server. Data can be lost if this procedure is not followed correctly. • In the event of smoke or sparks, immediately unplug the power plug from the outlet. Failure to do so may lead to a fire or electric shock.
  • Page 25 PRIMERGY BX600 S3 Blade Server System Unit Hardware Guide Power off the display and peripheral devices. The server can be remotely turned on/off from the management terminal using Management Blade. →"BX600 Management Blade Hardware Guide" The power supply of each Server Blade can be turned off remotely from the management terminal using the attached ServerView software.

  • Page 26: Inserting And Ejecting A Floppy Disk

    Chapter 3 Standard Operations 3.4 Inserting and Ejecting a Floppy Disk Inserting and ejecting a floppy disk is described below. 3.4.1 Cautions Note the following points when handling floppy disks. • Do not expose the floppy disk to any fluids. •...

  • Page 27: Inserting And Ejecting A Floppy Disk

    PRIMERGY BX600 S3 Blade Server System Unit Hardware Guide 3.4.2 Inserting and Ejecting a Floppy Disk ■ Inserting the Floppy Disk Use the display/USB expansion cable and connect a floppy disk drive to the Server Blade. →"Start Guide" Insert the floppy disk drive from the side with the shutter.

  • Page 28: Cd/Dvd Drive

    Chapter 3 Standard Operations 3.5 CD/DVD Drive This manual describes the points to note when handling a CD/DVD drive or CD/DVD. For details about inserting/ejecting the CD/DVD, refer to the manual supplied with the CD/DVD drive. This server does not support CD-R/RW write. 3.5.1 Cautions Note the following points to prevent failure.
  • Page 29 PRIMERGY BX600 S3 Blade Server System Unit Hardware Guide • Do not attach stickers or similar to the label side. Doing so may cause rotational eccentricity and abnormal vibrations. • When a CD/DVD is moved from a cold place to a warm place, moisture condensation on the CD/ DVD surface can cause data read errors.

  • Page 30: Kvm Switch

    Chapter 3 Standard Operations 3.6 KVM Switch The inputs/outputs of the keyboard/display/mouse (KVM) of various Server Blades are connected to the KVM connector of the KVM module or advanced KVM module installed in the Chassis using the KVM switch in the Chassis. Perform KVM switching operations using one of the following methods.
  • Page 31 Chapter 4 Installing Options This chapter explains how to install and remove various options to the Chassis. 4.1 Options ........4.2 Installing Server Blades/Storage Blades .

  • Page 32: Chapter 4 Installing Options

    Chapter 4 Installing Options 4.1 Options It is possible to install the following blades and PSUs to the Chassis. For details about device options not shown in this manual, refer to each option manual. [Front] Server Blade/Storage Blade Switch Blade/GbE Pass-Thru Blade, etc. [Rear] Switch Blade/ GbE Pass-Thru Blade/...
  • Page 33 PRIMERGY BX600 S3 Blade Server System Unit Hardware Guide • Before handling options, first touch a metal part of the Chassis to discharge static electricity. • Do not touch the circuitry on boards. Hold the brackets or the edges of the circuit boards.

  • Page 34: Installing Server Blades/Storage Blades

    Chapter 4 Installing Options 4.2 Installing Server Blades/Storage Blades This section explains how to install/remove Server Blades and Storage Blades. For this server, even when the power supply of the Chassis is turned on, it is possible to install/remove (hot-swap/hot-plug) Server Blades. For details about a Server Blade, refer to each Server Blade's "User's Guide", and for details about a Storage Blade, refer to "SX650 Storage Blade Hardware Guide".

  • Page 35: How To Install And Remove

    PRIMERGY BX600 S3 Blade Server System Unit Hardware Guide ■ Server Blade installation location When the Server Blade is installed to the Server Blade slot, the port of the Server Blade is connected to each port of the Network Blade through the mid plain in the Chassis. Decide the slot to which to install the Server Blade according to the network configuration.
  • Page 36 Chapter 4 Installing Options Remove the Server Blade/Storage Blade. 1. Push the release latches outwards while pressing the green parts to unlock the lock. 2. Pull the Server Blade/Storage Blade and remove. Use both hands to pull out the Server Blade/ Storage Blade.
  • Page 37 PRIMERGY BX600 S3 Blade Server System Unit Hardware Guide Install the Server Blade/Storage Blade. 1. Open the release latches and insert the Server Blade/Storage Blade until it stops. 2. When inserted, close the release latches to complete insertion. Release latches Before installing the Server Blade/Storage Blade, check there is no dust in the blade connector.

  • Page 38: Lan Connection In The Chassis

    Chapter 4 Installing Options 4.2.3 LAN Connection in the Chassis This section explains the LAN connection in the Chassis for Server Blades and LAN Network Blades. The LAN ports for Server Blades and LAN Network Blades are connected as follows in the Chassis. Decide the slot to which to install the Server Blade or LAN Network Blade according to the network configuration.
  • Page 39 PRIMERGY BX600 S3 Blade Server System Unit Hardware Guide ■ For the combination of BX620 S4 Server Blade and PG-SW107 • Network Blade slot 1 (NET1) Server blade Network blade port number Slot number Port number...
  • Page 40 Chapter 4 Installing Options • Network Blade slot 2 (NET2) Server blade Network blade port number Slot number Port number...

  • Page 41: Fibre Channel Connection In The Chassis

    PRIMERGY BX600 S3 Blade Server System Unit Hardware Guide 4.2.4 Fibre Channel Connection in the Chassis This section explains the LAN connection in the Chassis for Server Blades and FC Network Blades. When a Fibre Channel Expansion Board is installed in the Server Blade and FC Network Blade has been installed in the Chassis, the Server Blade and Fibre Channel port of the FC Network Blade are connected as follows in the Chassis.

  • Page 42: Installing Network Blades

    Chapter 4 Installing Options 4.3 Installing Network Blades This section explains how to install/remove Network Blades. For this server, even when the power supply of the Chassis is turned on it is possible to install/remove (hot-swap/hot-plug) Network Blades. For Network Blades not shown in this manual, refer to each Network Blade manual. 4.3.1 Installing/Removing LAN Network Blades This section explains how to install/remove LAN Network Blades.
  • Page 43 PRIMERGY BX600 S3 Blade Server System Unit Hardware Guide ● LAN Network Blade installation location [Rear of the chassis] Network blade Network blade slot 2 slot 1 Network blade Network blade slot 3 slot 4 *: PRIMERGY BX600 Switch Blade (1Gbps) (PG-SW107) can only be installed in slot 1 and 2.
  • Page 44 Chapter 4 Installing Options ■ How to remove LAN Network Blade Touch a metal part of the Chassis to discharge static electricity. Remove all LAN cables connected to the LAN Network Blade. Remove the LAN Network Blade. The figure shows an example for Switch Blade. 1.
  • Page 45 PRIMERGY BX600 S3 Blade Server System Unit Hardware Guide ■ How to install LAN Network Blades Touch a metal part of the Chassis to discharge static electricity. Remove the Network Blade/ dummy Switch Blade. Remove any blade installed to the slot for installation.

  • Page 46: Installing/Removing Fc Network Blades

    Chapter 4 Installing Options 4.3.2 Installing/Removing FC Network Blades This section explains how to install/remove FC Network Blades. ■ Before installing ● Notes when installing and removing Each Network Blade can be installed/removed when the main power of the Chassis is turned on. •...
  • Page 47 PRIMERGY BX600 S3 Blade Server System Unit Hardware Guide ■ How to remove FC Network Blades Touch a metal part of the Chassis to discharge static electricity. Disconnect the Fibre Channel cable connected to the FC Network Blade. Lower the SFP module lever, unlock the lock and remove.
  • Page 48 Chapter 4 Installing Options ■ How to install a FC Network Blade Touch a metal part of the Chassis to discharge static electricity. Remove the Network Blade/ dummy Switch Blade. Remove any blade installed to the slot for installation. ■ "...
  • Page 49 PRIMERGY BX600 S3 Blade Server System Unit Hardware Guide Install a SFP module to a port to use. 1. Remove the cap from the port using FC Network Blade. 2. Check the SFP module direction and insert it into the port while keeping the lever raised, until you hear it click.

  • Page 50: Installing The Psu

    Chapter 4 Installing Options 4.4 Installing the PSU In this Chassis, two PSUs are installed by default and a maximum of four can be installed. Adding PSUs enables redundancy of the power supply. Install the PSUs in pairs and connect power cables to all the PSUs. This section explains points to note when expanding the PSUs, how to install/remove and replace the PSU.

  • Page 51: Installing/Removing The Psu

    PRIMERGY BX600 S3 Blade Server System Unit Hardware Guide Included PSU options Before installing a PSU, refer to the following to check the included options. • "6.1.3 PSU Specifications" ( p.67) ■ Place and order of installation Install PSUs in the order of the slot numbers.
  • Page 52 Chapter 4 Installing Options Remove the dummy PSU. Remove the dummy PSU using both hands. Be sure to keep the removed dummy PSU for later use. Install the PSU. Check that the handle of the PSU is lowered. If not, pull it down. 1.

  • Page 53: Replacing A Psu During Redundant Power Configuration

    PRIMERGY BX600 S3 Blade Server System Unit Hardware Guide 4.4.3 Replacing a PSU During Redundant Power Configuration • Do not operate when the PSU or dummy PSU has been removed. If one or two PSUs fail when the redundant power supply is configured, the PSU can be replaced without turning off the power of the device.

  • Page 54: Installing Advanced Kvm Module

    Chapter 4 Installing Options 4.5 Installing Advanced KVM Module One KVM module is installed to the Chassis by default, which enables to input/output using keyboard/display/mouse (KVM) of each Server Blade. When an optional advanced KVM module is installed, apart from normal KVM input/ output, it is possible to redirect each Server Blade console from remote terminals via LAN (graphic mode console redirection), and to emulate (virtualize) the floppy disk drive or CD/DVD drive connected to the remote terminals and the Server Blades can...
  • Page 55 PRIMERGY BX600 S3 Blade Server System Unit Hardware Guide ■ Advanced KVM module installation location Install the advanced KVM module in the KVM module slot on the rear of the Chassis. [Rear of the chassis] KVM module slot ■ Available advanced KVM module The following shows the type of advanced KVM module used for this Chassis.

  • Page 56: Installing/Removing Advanced Kvm Module

    Chapter 4 Installing Options 4.5.2 Installing/Removing Advanced KVM Module ■ How to install an advanced KVM module Turn off the Server Blade and the main power supply of the Chassis. "3.3 Turning Off the Server" (p.24) Touch the metal part of the Chassis to discharge static electricity. Remove the screws fixing the KVM module installed by default.
  • Page 57 PRIMERGY BX600 S3 Blade Server System Unit Hardware Guide Install an advanced KVM module. 1. Insert the KVM module while the handle is opened forward. 2. Set the handle inside. Handle Secure the module with screws. • For advanced KVM module...

  • Page 58: Replacing The Management Blade

    Chapter 4 Installing Options 4.6 Replacing the Management Blade In this Chassis two Management Blades are installed by default and the management/monitoring function is redundant. It is necessary to replace a broken Management Blade. Contact an office listed in the "Contact Information"...

  • Page 59: Replacing The System Fan Unit

    PRIMERGY BX600 S3 Blade Server System Unit Hardware Guide 4.7 Replacing the System Fan Unit This server supports the system fan redundancy function and "system down" can be prevented even if one of the fans fails. Also, replacement can take place while the main power is turned on (hot-swap/ hot- plug).
  • Page 60 Chapter 4 Installing Options...

  • Page 61: Chapter 5 Maintenance

    Chapter 5 Maintenance This chapter explains how to perform daily maintenance and the maintenance information. 5.1 Cleaning ........5.2 System Event Log .

  • Page 62: Cleaning

    Chapter 5 Maintenance 5.1 Cleaning To prevent trouble from occurring, clean the server regularly. This server should be cleaned as follows. • Before cleaning, turn off the Chassis and unplug the power cables from the outlets. Also power off peripherals and remove them from this product ( "3.3 Turning Off the Server" (p.24)). Failure to do so may cause electric shock.

  • Page 63: Cleaning The Floppy Disk Drive

    PRIMERGY BX600 S3 Blade Server System Unit Hardware Guide Be careful when removing components such as CPUs, memory modules, or hard disk units. Be sure to install parts and cables in the original position. Leaving dust on the server can cause failure. Be sure to remove any dust from the server.

  • Page 64: System Event Log

    Chapter 5 Maintenance System Event Log The Chassis management is performed on the Management Blade. For event logs relating to the Chassis, refer to the Management Blade event logs. For details, refer to "BX600 Management Blade Hardware Guide".
  • Page 65 Chapter 6 Technical Information This chapter explains the specifications and operational notes of the Chassis and optional devices. 6.1 Specifications ....... . . 6.2 Number of Server Blades that can be Installed .

  • Page 66: Chapter 6 Technical Information

    Chapter 6 Technical Information 6.1 Specifications This section describes the specifications of the Chassis and optional devices. 6.1.1 Server Specifications The specifications for the Chassis are shown in the table below. For details about blades and peripheral devices, refer to each device manual. Item Functions and Specifications Product ID...

  • Page 67: Fc Pass-Thru Blade Specifications

    PRIMERGY BX600 S3 Blade Server System Unit Hardware Guide 6.1.2 FC Pass-Thru Blade Specifications This section explains the specifications and items supplied with the FC Pass-Thru Blade. When you have bought a FC Pass-Thru Blade as a standard option, check that the following items are supplied with it before use.

  • Page 68: Specification Of Advanced Kvm Module

    Chapter 6 Technical Information 6.1.4 Specification of Advanced KVM Module This section explains the specifications and items supplied with the Advanced KVM Module. When you have bought an Advanced KVM Module as a standard option, check that the following items are supplied with it before use.

  • Page 69: Number Of Server Blades That Can Be Installed

    PRIMERGY BX600 S3 Blade Server System Unit Hardware Guide 6.2 Number of Server Blades that can be Installed A maximum of 10 Server Blades can be installed on this Chassis. The number of Server Blades that can be installed is limited by the Server Blade configuration, and the type and number of installed PSUs.

  • Page 70: Operating Advanced Kvm Module (Pg-Kvb102)

    Chapter 6 Technical Information 6.3 Operating Advanced KVM Module (PG-KVB102) When the optional advanced KVM module (PG-KVB102) is installed, the software (Global Viewer) which operates the screen display of the Server Blade can be used from the client computer. 6.3.1 Overview Global Viewer is software to redirect the window display of the Server Blade.

  • Page 71: Checking The Operating Environment

    PRIMERGY BX600 S3 Blade Server System Unit Hardware Guide 6.3.2 Checking the Operating Environment The required conditions for the client computer (remote terminal) to operate Global Viewer are as follows: • Windows is running • Internet Explorer is available Before starting Global Viewer, check the following settings as well.
  • Page 72 Chapter 6 Technical Information Click [Trusted sites] and click the [Sites...] button. The [Trusted sites] window appears. Enter each item in the [Trusted sites] window. 1. Uncheck "Require server verification (https:) for all sites in this zone" checkbox. 2. In "Add this Web site to the zone:", enter the IP address of the advanced KVM module in the "http://(IP address)"...
  • Page 73 PRIMERGY BX600 S3 Blade Server System Unit Hardware Guide ■ Setting Mouse Pointer (Server Blade) For the Server Blade to be redirected using the advanced KVM module, mouse pointer acceleration must be set to "disable" because the Server Blade and the mouse of the client computer are synchronized.
  • Page 74 Chapter 6 Technical Information • Windows Server 2003 screen Set the speed to 50%, and uncheck "Enhance pointer precision" if it is checked. Click [OK]. Select [Control] – [Mouse Sync] on Global Viewer menu. Login with an account that has administrative privileges (Administrator, etc.) and change status so the registry can be edited.
  • Page 75 PRIMERGY BX600 S3 Blade Server System Unit Hardware Guide ● Windows 2000 Server From the start menu, click [Setting] – [Control panel]. Double click [Mouse]. "Mouse Properties" window appears. Click [Motion] tab. "Motion" tab contents appear. Set the speed to 50%, and the acceleration to "None".

  • Page 76: Startup Procedure

    Chapter 6 Technical Information 6.3.3 Startup Procedure The following shows how to startup Global Viewer. For operations of Management Blade, refer to "BX600 Management Blade Hardware Guide". Start Web UI of Management Blade. From the setting item menu, select "KVM_Config" in Adv.KVM blade group. "KVM Configuration"...
  • Page 77 PRIMERGY BX600 S3 Blade Server System Unit Hardware Guide ■ Status bar The following shows each area displayed on the status bar. 1 Message area An area that displays various messages 2 Key code setting area This area is used to combine set keys with mouse click and key operations from the client computer.

  • Page 78: Global Viewer Setting Menu

    Chapter 6 Technical Information 6.3.5 Global Viewer Setting Menu This section explains the Global Viewer setting menu. Global Viewer settings can be performed from the drop-down menu at the top of the screen. Item Description File Clicking "Exit" exits Global Viewer and closes the session. Hotkey Key code setting for entry after emulating the redirected Server Blade.
  • Page 79 PRIMERGY BX600 S3 Blade Server System Unit Hardware Guide ■ Control menu Settings related to emulation and redirection. Item Setting value Description KVM Switch Blade 1 – Blade 10 Select a Server Blade to redirect. " " will be displayed at the selected blade number. A grayed out Server Blade indicates that no Server Blade is installed in the slot.
  • Page 80 Chapter 6 Technical Information • USB Floppy submenu Set the floppy disk drive of the client computer to be emulated. Item Setting value Description Floppy Emulation • No Emulation Select the floppy disk drive to be emulated. • Floppy (A:) The selected floppy disk and floppy disk image are copied to •...
  • Page 81 PRIMERGY BX600 S3 Blade Server System Unit Hardware Guide ■ Video menu Set the window display and save/read the setting values. Item Description Brightness Adjust brightness of the Global Viewer window by operating primitive signal, red, green, and blue scale bars separately.

  • Page 82: Operating Advanced Kvm Module (Pg-Kvb103)

    Chapter 6 Technical Information 6.4 Operating Advanced KVM Module (PG-KVB103) When the optional Advanced KVM module (PG-KVB103) is installed, the following operations are enabled. • Selecting and switching the Server Blade, and status display/setting of the Server Blade by using Menu window "6.4.1 OSCAR"...
  • Page 83 PRIMERGY BX600 S3 Blade Server System Unit Hardware Guide Resolution Horizontal Frequency (kHz) Refresh Rate (Hz) 64.0 1280×1024 80.0 91.1 75.0 87.0 1600×1200 93.8 106.3 ■ Basic operation The following indicates the common key operation of each menu. Item Description [F1] To open the Help window.
  • Page 84 Chapter 6 Technical Information ■ Booting (Main menu) Press the [Print Screen] key once or press the [Ctrl] key twice to display the following Main menu window. If a password has been assigned, enter the password and click [OK] to display the Main menu. Changing or deleting the Server Blade name can only be performed in the slot where the Server Blade is installed in.
  • Page 85 PRIMERGY BX600 S3 Blade Server System Unit Hardware Guide ■ Setup menu This menu appears when [Setup] is clicked in the Main menu. Click the button to display each submenu window. Item Description [Menu] To set about the display of the Main menu window.
  • Page 86 Chapter 6 Technical Information ● Menu submenu Sets the Main menu display. Item Description Display/Sort key To choose the name or slot number of the Server Blade by default for displaying the Main menu. Select [Name] to display and select Server Blades alphabetically by name. Select [Slot] to display and select Server Blades numerically by slot number.
  • Page 87 PRIMERGY BX600 S3 Blade Server System Unit Hardware Guide Item Description Display Mode To set the permeableness of status flag. • Opaque: Solid color • Transparent: See the desktop through the flag [Set Position] To set the position for displaying the status flag.
  • Page 88 Chapter 6 Technical Information ● Names submenu (Not supported) Sets the Server Blade name. The procedure for changing the Server Blade name is as follows. Select the Server Blade name to be changed in one of the following ways. • Double-click •...

  • Page 89: Video Viewer/Virtual Media

    PRIMERGY BX600 S3 Blade Server System Unit Hardware Guide 6.4.2 Video Viewer/Virtual Media Using Video Viewer and Virtual Media enables you to operate the Server Blade monitor, and connect floppy disks or CD/DVD drives from the client computer. ■ Checking and setting operating environment ●...
  • Page 90 Chapter 6 Technical Information ● Registering certificate The Management Blade and advanced KVM module certificates must be signed by a trusted certificate authority known in advance to the browser. Register the certificate according to the following procedure. Copy the following file in the PRIMERGY Startup Disc, and uncompress it. [CD/DVD drive]:\SSL certificate\RemoteView CA Cert.zip Double-click on the [RemoteView CA Cert.der] certificate file.
  • Page 91 PRIMERGY BX600 S3 Blade Server System Unit Hardware Guide Click [Next>]. The [Certificate Store] window appears. Be sure to select the [Automatically select the certificate store based on the type of certificate] radio button, and click [Next>]. The [Completing the Certificate Import Wizard] window appears.
  • Page 92 Chapter 6 Technical Information Click [Finish]. A warning similar to the following appears. Click [Yes] to complete the installation of the certificate. Click [OK]. ■ Booting Boot the Video Viewer and Virtual Media from the [DKVM Blade] group in the Management Blade. For the details about booting procedure, refer to the "BX600 Management Blade Hardware Guide".
  • Page 93 PRIMERGY BX600 S3 Blade Server System Unit Hardware Guide ● When Java version is other than 4.x, 5.x The Video Viewer and Virtual Media cannot be booted properly. Install the proper version of Java. When Java version is 6.x or later, the following window appears at the first booting. Click [Run] when in an environment where the Internet can be connected to in order to change the Java version.
  • Page 94 Chapter 6 Technical Information ● Keystroke Prefix Set a key or key combination that acts as a previous keystroke. Item Description <Ctrl> To select the [Ctrl] key that acts as a previous keystroke. <Alt> To select the [Alt] key that acts as a previous keystroke. <SysReq>...
  • Page 95 PRIMERGY BX600 S3 Blade Server System Unit Hardware Guide ● Calibrate When clicking the [Calibrate], the [Manual Video Adjust] window appears. Adjust the window display. Item Description To fine adjust the sampling by pixel (0 to 30). To adjust horizontal position of the image capture (0 to 400).
  • Page 96 Chapter 6 Technical Information ■ Virtual Media setting menu When booting the Virtual Media, the following window appears. Select the floppy disk drive or CD/DVD drive to be connected, and click [Connect Floppy] or [Connect CD/DVD] to connect the floppy disk drive or CD/DVD drive on the network.

  • Page 97: Non-Durable Components

    PRIMERGY BX600 S3 Blade Server System Unit Hardware Guide 6.5 Non-durable Components This Chassis monitors the status of power supply unit (PSU), sending notification when they need to be replaced. Management Blade performs monitoring and notifying. The following function is available.
  • Page 98 Chapter 6 Technical Information ■ Resetting lifetime When operating the system, if Management Blade information is lost, it is necessary to reset lifetime. Calculation is as follows: Enter the calculated value in Time Limited Count (lifetime) for the PSU and dummy PSU.

  • Page 99: Messages Displayed When A Non-Durable Components Life Has Been Reached

    PRIMERGY BX600 S3 Blade Server System Unit Hardware Guide 6.5.2 Messages Displayed When a Non-durable Components Life has been Reached ■ The flow of the replacement period notice 1 year of operation Component has exceeded time remaining the projected lifetime...
  • Page 100 Chapter 6 Technical Information ● Management after the notice Perform the following setup promptly, after a notification of end of life time. Contact an office listed in the "Contact Information" of "Start Guide". Check the "Contact Check Box" of corresponding PSU in the Web UI of the Management Blade.
  • Page 101 PRIMERGY BX600 S3 Blade Server System Unit Hardware Guide Index AC Power LED ..... . 14 KVM connector ..... . .12 Advanced KVM module .
  • Page 102 Security Hardware ......16 Software......17 Server Specifications .
  • Page 103 FUJITSU LIMITED • The contents may be revised without prior notice. • Fujitsu assumes no liability for damages to third party copyrights or other rights arising from the use of any information in this manual. • No part of this manual may be reproduced in any form without the prior written...
